Record K 32 Z User manual

record K 32 Z / K 42 Z
User manual
Your global partner for entrance solutions www.record.group

Document identification
Article nr.: 121-006454230
Version: 2.5
Publication date: 05/07/2022
Translation of the original manual
Subject to technical modifications
Copyright © agtatec ag

Table of Contents
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 3 / 46
Table of Contents
List of changes ................................................................................................................................................. 5
1 Safety................................................................................................................................................................. 6
1.1 Presentation of warning signs............................................................................................................... 6
1.2 Intended purpose of use ....................................................................................................................... 6
1.3 General hazards ................................................................................................................................... 7
1.4 State of technology ............................................................................................................................... 9
1.5 Personal protective equipment ............................................................................................................. 9
1.6 Spare parts and liability ........................................................................................................................ 10
2 General information ......................................................................................................................................... 11
2.1 Purpose and use of the instructions ..................................................................................................... 11
2.2 Copyright .............................................................................................................................................. 11
2.3 Product identification ............................................................................................................................ 11
2.4 Manufacturer BLASI GmbH .................................................................................................................. 11
2.5 Target groups ....................................................................................................................................... 11
2.6 Definition of terms................................................................................................................................. 12
3 Description........................................................................................................................................................ 13
3.1 Graphical display .................................................................................................................................. 13
3.1.1 Main mechanical components ......................................................................................................... 13
3.2 Description of the door.......................................................................................................................... 14
3.3 Safety features and control elements K32 / K42 .................................................................................. 14
3.3.1 Legend for safety features and control elements............................................................................. 15
3.3.2 BDE-D-KTA control unit ................................................................................................................... 17
3.3.3 Emergency stop button ................................................................................................................... 17
3.3.4 Information on motion detectors ...................................................................................................... 18
3.3.5 Vertical safety sensors drum edge................................................................................................... 18
3.3.6 Information on safety strips.............................................................................................................. 18
4 Options .............................................................................................................................................................. 19
4.1 Electromagnetic turnstile lock ............................................................................................................... 19
4.2 Turnstile bar-bolt lock ........................................................................................................................... 19
4.3 Lock mechanism status indicator and door position indicator .............................................................. 19
4.4 BDE-V key switch ................................................................................................................................. 20
4.5 Key pivot contact (SSK)........................................................................................................................ 20
4.6 Disabled button..................................................................................................................................... 20
4.7 Start button ........................................................................................................................................... 21
4.8 Key emergency operation switch.......................................................................................................... 21
4.9 BDE-Lock key switch ............................................................................................................................ 22
4.10 Vertical sensors strips drum walking area ............................................................................................ 22
4.11 Air curtain control.................................................................................................................................. 22
4.12 Foldable turnstile wings and/or foldable drum walls ............................................................................. 22
4.13 Light switch ........................................................................................................................................... 23
4.14 Lighting control .................................................................................................................................... 23
4.15 Night shield ........................................................................................................................................... 24
4.15.1 Manual night shield .......................................................................................................................... 24
4.15.2 Night shield - deadman .................................................................................................................... 24
4.15.3 Fully automatic night shield.............................................................................................................. 24
5 Specifications ................................................................................................................................................... 26
5.1 Environmental conditions...................................................................................................................... 26
5.2 Electric specifications of the door ......................................................................................................... 26
5.3 Electrical specifications power supply .................................................................................................. 26

Table of Contents
4 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
5.4 Electrical specifications of the door control KST200............................................................................. 26
5.5 Electrical lighting specifications ............................................................................................................ 26
5.6 Sound pressure level ............................................................................................................................ 27
6 Operation........................................................................................................................................................... 28
6.1 Operating mode symbols...................................................................................................................... 28
6.2 Instructional symbols ............................................................................................................................ 28
6.3 Menu display......................................................................................................................................... 28
6.4 Status display ....................................................................................................................................... 29
6.5 Error display.......................................................................................................................................... 29
6.6 Operating modes selection ................................................................................................................... 29
6.7 Special function selection ..................................................................................................................... 30
6.8 Operating lock via the keyboard .......................................................................................................... 30
7 Servicing and maintenance ............................................................................................................................. 31
7.1 General remarks ................................................................................................................................... 31
7.2 Monthly inspection work performed by the operator............................................................................. 31
7.3 Cleaning and care................................................................................................................................. 33
8 Malfunctions ..................................................................................................................................................... 35
8.1 Conduct during malfunctions ................................................................................................................ 35
8.1.1 Troubleshooting options .................................................................................................................. 35
8.1.2 Tips for troubleshooting .................................................................................................................. 35
8.1.3 Status display and troubleshooting BDE-D-KTA.............................................................................. 36
8.1.4 Restarting the door control............................................................................................................... 43
8.2 Function during a power failure ............................................................................................................ 44
9 Taking out of service and disposal................................................................................................................. 45
9.1 Decommissioning ................................................................................................................................. 45
9.2 Dismantling and disposal...................................................................................................................... 45

List of changes
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 5 / 46
List of changes
Change Location
Complete revision of all Sections and content Entire document
New Section structure Entire document
Revision of all graphics Entire document

1Safety
6 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
1 Safety
1.1 Presentation of warning signs
Various symbols are used in this guide for easier understanding:
NOTICE
Useful advice and information to ensure correct and efficient workflow of the system.
IMPORTANT
Specific details which are essential for trouble-free operation of the system.
IMPORTANT
Important details which must be read for proper function of the system.
CAUTION
Against a potential hazardous situation that can lead to minor personal injury and property
damage.
WARNING
Against a latent hazardous situation that can lead to severe injuries or death and cause sub-
stantial property damage.
DANGER
Against an imminent hazardous situation that can lead to severe injury or death.
DANGER
Against an imminent or latent hazardous situation that could lead to electric shock and cause
serious injury or death.
1.2 Intended purpose of use
The system is designed exclusively for use as a pedestrian passage. The installation must only occur
in dry areas. If there are deviations then proper waterproofing and water drains will be required on-
site.
Any other application or use beyond this purpose is not considered to be an intended purpose. The
manufacturer bears no liability for any resulting damage; the operator alone shall bear the associated
risk.
The intended purpose also includes observation of the operating conditions specified by the manufac-
turer, in addition to regular care, maintenance and repair.
Interventions in or alterations to the installation performed by non-authorized maintenance technicians
exclude the manufacturer's liability for consequential damages.

Safety 1
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 7 / 46
1.3 General hazards
The following section lists hazards that can be caused by the system even when used as intended.
To reduce the risk of malfunction, damage to property or injury to persons and to avoid dangerous
situations, the safety instructions listed here must be observed.
The specific safety instructions in the other sections of this manual must also be observed.
IMPORTANT
The country-specific regulations must be observed and complied with!
IMPORTANT
To avoid malfunctions, moving objects such as flags or parts of plants must not be allowed to
enter the detection range of the sensors.
CAUTION
Risk of malfunctions, material damage or injury due to improper settings!
a) Improper settings can lead to malfunctions, material damage or personal injury.
ðDo not disconnect the system from the power supply overnight.
ðSettings should only be made by personnel qualified to do so.
ðDo not disassemble, put out of operation or manipulate safety devices.
ðHave faults rectified by specialist personnel or by personnel qualified to do so.
ðHave service and maintenance carried out according to locally applicable regulations or accord-
ing to a maintenance contract.
CAUTION
Risk of malfunctions, material damage or injuries due to insufficient or missing cleaning or
care!
a) Insufficient or inattentive cleaning or care of the system can lead to malfunctions, damage to
property or injury to persons.
ðCheck the sensors regularly for dirt and clean them if necessary.
ðRegularly remove dirt accumulations in the floor rail or under the floor mat.
ðKeep the system free from snow and ice.
ðDo not use aggressive or caustic cleaning agents.
ðUse road salt or loose chippings only conditionally.
ðLay the floor mat without folds and flush with the floor.
ðEquipment required for cleaning purposes such as ladders or similar must not be leaned on or at-
tached to the system.

1Safety
8 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
CAUTION
Risk of material damage or injury due to unforeseen opening, closing or turning of the door!
a) The door can open, close or turn unexpectedly. This may result in damage to property or injury
to persons.
ðNo persons may be present in the opening area of the system.
ðEnsure that moving objects such as flags or parts of plants do not enter the detection range of
the sensors.
ðDo not make any settings on the control unit when the system is in use.
ðHave faults rectified immediately by specialist or personnel qualified to do so.
ðRemove objects from the opening area.
ðDo not disassemble, put out of operation or manipulate safety devices.
ðDo not rush through a closing system.
CAUTION
Risk of bruising and severing of limbs!
a) If the system moves, careless behaviour can lead to serious injuries to limbs or severance of
limbs.
ðDo not reach in when parts of the system are moving.
ðKeep a distance when parts of the system move.
ðDo not bump into or touch the system when it is moving.
ðDo not open or remove protective covers during operation.
ðDo not permanently remove covers from the system.
ðOnly carry out inspection, service, maintenance and cleaning when the system is stationary and
switched off.
CAUTION
Danger of material damage or injury due to non-functioning safety devices!
a) If safety devices are not functioning, manipulated or put out of operation, there is a risk of dam-
age to property or injuries that can lead to death.
ðNever disable or manipulate safety devices.
ðHave inspection, service and maintenance of the safety devices carried out according to local
regulations or according to a maintenance contract.
CAUTION
Danger of malfunctions, damage to property or risk of injury if used by unauthorised persons!
a) If unauthorised persons use the system, there is a risk of malfunction, damage to property or in-
jury to persons.
ðChildren under 8 years of age may only use the system under supervision.
ðChildren must not play, clean or maintain the system.
ðPersons with limited physical, sensory or mental abilities as well as persons with insufficient
knowledge or experience may only use the system under supervision or must have received and
understood instructions to do so.

Safety 1
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 9 / 46
DANGER
Danger to life due to electric current!
a) In case of contact with live parts, there is an immediate danger to life due to electric shock.
Damage to or removal of the insulation or individual components can be life-threatening.
ðBefore starting work on active parts of electrical systems and equipment, ensure that all poles are
voltage free and that this is maintained for the duration of the work.
ðKeep moisture away from live parts. This can lead to a short circuit.
ðNever bridge fuses or put them out of operation.
ðDo not connect the power supply until all work has been completed.
ðHave work on the electrical system performed by qualified personnel only.
DANGER
Danger to life due to non-functioning safety devices of the fire protection system!
a) If safety devices of the fire protection system do not function properly, there is a risk of serious
or fatal injuries.
ðNever disconnect the fire protection system from the power supply overnight.
ðDo not disassemble, put out of operation or manipulate safety devices.
ðDo not remove safety instructions on the system.
ðNever block, hold open or otherwise prevent fire doors from closing.
ðHave inspection, service and maintenance of the fire protection system carried out in accordance
with locally applicable regulations or according to a maintenance contract.
ðHave the fire protection system checked and maintained according to the state of the art.
1.4 State of technology
This system was developed using state of the art technology and officially recognized technical safety
regulations. The system, depending on its options and diameter, comply with the requirements of the
Machine Guidelines 2006/42/EG as well as EN 16005 and DIN 18650 (D).
Nevertheless, danger may arise if not used as intended.
IMPORTANT
Installation, commissioning, inspection, maintenance and repair work may only be conducted
by qualified, trained and authorized technicians.
After commissioning or repair work, fill in the check list and give it to the customer for safe
keeping.
We recommend obtaining a service agreement.
1.5 Personal protective equipment
Personal protective equipment is used to protect persons from adverse effects on health. Personnel
must wear personal protective equipment during the various work activities on and with the system.
Personal protective equipment is explained below:
Hearing protection is used to protect the hearing from noise. As a rule of
thumb, hearing protection is compulsory from when normal conversa-
tion with other people is no longer possible.

1Safety
10 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
The head protection serves to protect against falling and flying parts
and materials. It also protects the head from bumping into hard objects.
Protective goggles protect the eyes from flying parts, dust, splinters or
splashes.
Protective gloves are designed to protect hands from friction, abrasions,
punctures or serious injury and from burning caused by contacting hot
surfaces.
Safety shoes protect the feet from crushing, falling parts and slipping on
surfaces. The puncture resistance of the shoes ensures, that pointy ob-
jects do not penetrate the foot.
The high-visibility vest is used to make the personnel stand out and
therefore to be seen. With improved visibility and attention, the high-vis-
ibility vest protects personnel in busy work areas from collisions with
vehicles.
Depending on the place of work and the working environment, the protective equipment varies and
must be adapted accordingly. In addition to protective equipment for specific work, the work site may
require other protective equipment ( for example a harness).
In hygiene-protected areas, special or additional requirements of personal protective equipment may
be required. These requirements must be considered when choosing personal protective equipment.
If there is any uncertainty regarding the choice of personal protective equipment, the safety officer
must be consulted at the place of work.
1.6 Spare parts and liability
Reliable and trouble free operation of the door is only guaranteed when using parts that were recom-
mended by the manufacturer. The manufacturer declines any liability for damages resulting from un-
authorized modifications to the door or the use of parts that are not permitted.

General information 2
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 11 / 46
2 General information
2.1 Purpose and use of the instructions
These instructions are an integral part of the system and enable efficient and safe handling of the sys-
tem. In order to ensure proper functioning, the instructions must be accessible at all times and kept in
the immediate area of the system.
Although only the male form has been chosen for reasons of better legibility, the information refers to
members of both sexes.
The operator must have read and understood the manual before starting any work. The basic require-
ment for safe working is to follow the safety instructions and the handling instructions. In addition, the
local regulations and safety rules apply.
The manual can be handed over in extracts to instructed personnel who are familiar with the opera-
tion of the system.
The illustrations are for basic understanding and may differ from the actual presentation. Specific rep-
resentations are contained in the drawings.
2.2 Copyright
The copyright of the instructions remain at:
BLASI GmbH
Carl-Benz-Str. 5-15
D – 77972 Mahlberg
It is prohibited to reproduce, distribute or use the manuals for purpose of competition without the writ-
ten authorization of BLASI GmbH.
Violation of the here stated copyrights will be prosecuted and fined with compensation of damage.
Subject can change without prior notice.
Differences between product and manual are thereby possible.
2.3 Product identification
The nameplate located on the door provides accurate identification of the product.
2.4 Manufacturer BLASI GmbH
BLASI GmbH Automatic Door Systems
Carl-Benz-Str. 5-15
D-77972 Mahlberg
Germany
Telephone: [phone]
Fax: [phone]
2.5 Target groups
CAUTION
Risk of injury if personnel are insufficiently qualified!
If unqualified personnel work on the system or are in the danger zone of the system, dangers may
arise which can cause serious injuries and considerable damage to property.
a) All work must be carried out by qualified personnel only.
b) Keep unqualified personnel away from danger areas.
This operating manual is intended for the target groups listed below:
– Operating entity of the system:
the person who is responsible for the technical maintenance of this system
– Operator of the system:
the person who operates the system every day and has been suitably instructed

2General information
12 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
2.6 Definition of terms
Term: Explanation:
System The term is also used in these instructions as a synonym for the
product. Door operators, revolving doors, sliding doors, etc. are re-
ferred to as a system.
If information in these instructions refers to a specific type, this is
shown accordingly in the text.
User Users are all persons who use the system.
System operator The respective owner is referred to as the system operator, regardless
of whether they operate the system as the owner or pass it on to third
parties.
Authorized representative The authorized representative takes over certain parts of the manufac-
turer's obligations with regard to fulfilling the requirements of the Ma-
chinery Directive. In particular, the authorized representative may also
place the system on the market and/or sign EC declarations of incor-
poration.
Qualified personnel Qualified personnel are authorized and appropriately trained to perform
the following work:
– Disassembly, Assembly, Commissioning, Operation, Audit, Main-
tenance, Troubleshooting, Decommissioning
The qualified personnel have several years of professional experience
in the technical field, e.g. as mechanics or machine fitters.
The qualified personnel are aware of the residual risks arising from the
installation site and, due to their professional training, knowledge and
experience, are able to carry out the work assigned to them and to in-
dependently identify and avoid possible danger points.
Manufacturer The manufacturer is whoever designs and/or builds machinery or in-
complete machinery under the scope of the Machinery Directive.
Life phases All phases of the system's condition and use are referred to as life
phases. This applies from the time the system leaves the factory until it
is disposed of.
Personnel All persons who carry out activities on and with the system are referred
to as personnel. Personnel can be, for example, the operator, the
cleaning staff, or the security staff. The personnel meet the personnel
qualifications required by the manufacturer.
Service technician Experts and specialists or representative authorized by the manufac-
turer to perform commissioning, maintenance and servicing.

Description 3
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 13 / 46
3 Description
3.1 Graphical display
K3x K4x
Abbreviation Description Abbreviation Description
A Passage width B Floor ring height
G Passage height I Cladding height
J Total height Q Total diameter
T Exterior diameter U Interior diameter
3.1.1 Main mechanical components
Abbreviation Description
aDrum wall
Curved, fixed aluminum frame for supporting curved glass or panelling.
bDrum wall edge
Fixed structure made of vertical frame profiling for accommodating control units.
cRotation unit turnstile
Rotating inner part of the door.

3Description
14 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
3.2 Description of the door
The door consists of two or three turnstile wings
It has a microprocessor-controlled drive system, which can be used in several operating modes.
The different operating modes can be selected with the corresponding BDE-D-KTA control unit.
A built in error analyzer detects operating errors.
Safety sensors prevent hazardous rotational movement which slows down or stops the turnstile at the
right time. The operating state or system error is displayed on the BDE-D-KTA control unit.
3.3 Safety features and control elements K32 / K42
Interior View in the closed position
Operating element variations available
Interior column Exterior column Wall installation

Description 3
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 15 / 46
Triple winged Four winged
EXTERIOR
INTERIOR
EXTERIOR
INTERIOR
Position of the turnstile wings in the locked position:
Turnstile wing K32 K42
DKF1 = Turnstile wing 1 0° 0°
DKF2 = Turnstile wing 2 120° 90°
DKF3 = Turnstile wing 3 240° 180°
DKF4 = Turnstile wing 4 — 270°
3.3.1 Legend for safety features and control elements
Pos. No. Components
1Motion detector canopy or floor installation (AKI / AKA)
2Vertical forward sensor radial protective sliding wing (OP-VLS)
3, 3A, 3B Vertical sensors drum edges (OP-VSS)
4Horizontal heel protection light barrier SLOW (OP-HSR)
5Horizontal heel protection light barrier STOP (OP-HSR)
6Vertical safety strips drum edges (SL-TRK)
7Vertical safety strip radial protective sliding wing (SL-RSF)
8Vertical safety strip radial fixed wing (SL-VSR)
9Vertical safety strips turnstile wings (SL-VSR)
10 Radial protective sliding wing (RSF)
11 Power storage (rubber rope)
12 Surveillance contact radial protective sliding wing (UW-RSF)
13 Rotor lock
14 Radial protective sliding wing lock

3Description
16 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
15, 15A Sensors turnstile wings (OP-VSR)
16 Horizontal heel protection safety strips (SL-FES)
17 Foot protection sensor radial protective sliding wing
18 Vertical light barriers drum edges
19 Monitoring contact night shield (UW-NAS)
20 Main power switch (UW-HAS)
21 Control unit BDE-D-KTA
22 Key-operated switch BDE-V
23 Key-operated emergency switch
24 Emergency stop switch
25 Disabled person button
26 Start button
27 Key pivot contact
28 Contact mat blocked segment
29 Key-operated switch
30 Sliding door drive STA 20
31 Sliding door control unit BDE-D-STA
32 Traffic light red / green (alternatively in the standing column)
33 Turn key switch night shield
34 Light barriers pivot wing joints
35 Emergency open button
36 Contact mat exit direction
37 Contact mat entrance direction
38 On-site code card reader (1x interior and 1x exterior)
39 Horizontal sensor strip (opening and closing side)
40 Lock mechanism status indicator VRM rotor
41 Door position indicator TPA rotor
42 Lock mechanism status indicator VRM radial protective sliding wing
43 Door position indicator TPA radial protective sliding wing
44 Drive gear box (subfloor)
45 Safety sensors (shearing edge / crushing edge)
46 Electromagnetic lock with bolt contact
47 Turnstile lock
48 “Open position” night shield wing
49 FPC service outlet

Description 3
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 17 / 46
50 Lighting
51 Combination sensors
60 Plastic manufacturer's logo
61 System nameplate
62 Sticker STOP
63 Sticker Baby carriage / Wheel chair / Mother + Child / Dog
64 Sticker Mother + Child/ Dog
65 Sticker START
66 Sticker Maximum weight
67 Sticker “Opening service trap”
70 Glass label (example)
Labelling the glass surface reduces the danger of collision. Transparent wings or wing surfaces
must be must be clearly visible, for example, by permanent labelling, appropriate markings or use of
coloured materials.
Stickers, sandblasting, dyeing or etching can be used for labelling. Quantity and design are determ-
ined separately.
71 Brush seals
The door wing frames of the rotation unit are sealed all around with interchangeable brush strips to
prevent drafts.
72 Canopy
Encircling canopy panels made of bent aluminum sheets. The entire drive system and controls are
located behind the canopy panels. The ceiling panels are part of the turnstile unit and are lined with
concentric cut aluminum panels, which can be removed for inspection.
73 External control box
74 Deadman button
3.3.2 BDE-D-KTA control unit
The electronic BDE-D-KTA control unit is a convenient input and output terminal for operat-
ing the door. Clearly arranged buttons enable easy operation of the door modes and naviga-
tion of the drive-specific menu structure. The LCD display with backlight supports users with
logical symbols and text messages and provides information on the state of the door.
3.3.3 Emergency stop button
When the emergency stop button is pushed the rotating turnstile is stopped immediately, the
turnstile is released and can be rotated manually.
After resetting the emergency stop button, the preset operating mode will continue.
NOTICE
The turnstile cannot be turned manually on a subfloor door with a geared motor!

3Description
18 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
3.3.4 Information on motion detectors
NOTICE
Moving objects, i.e. loose poster or plants that move in the detection area can trigger an unin-
tentional startup.
Motion detectors are installed on each access side of the door (see “Safety and operating compon-
ents legend”).
These motion detectors detect moving persons. If for example, the detection field of a motion detector
is entered in the AUTOMATIC operating mode, the turnstile will start to rotate from the start position.
If the detection field is entered in the CONTINUOUS operating mode, (slow speed) the turnstile will
accelerate from slow speed to walking speed.
3.3.5 Vertical safety sensors drum edge
The danger zones between the rotating turnstile wings and the fixed drum wall edges, on the access
sides of the door are secured with vertical safety sensors that radiate to the ground.
These safety sensors are only enabled when the rotating turnstile wing approaches the drum wall
edge within approx. 40 degrees (danger zone). When a safety sensor is activated inside the danger
zone, the turnstile will either stop immediately or switch to slow speed, depending on how the para-
meters have been set on the door control. As long as a safety sensor is activated, the stop setting will
be held. The slow speed setting remains active until the turnstile reaches the end position. Then the
turnstile will accelerate again and resume until another safety sensor is activated. When the safety
sensors are no longer activated, the turnstile will accelerate back to the pre-adjusted speed.
3.3.6 Information on safety strips
CAUTION
Risk of destruction Safety edge
a) Personal injury and damage to property due to malfunctions on the safety edge
ðDo not use pointed or sharp-edged objects when working on the safety edge.
ðDo not use aggressive cleaning agents such as mineral oils or petrol when working on the safety
edge.
NOTICE
On the drum wall edges of the system and on the lower and outer turnstile profiles of the turn-
stile wings, vertical and horizontal safety bars made of soft rubber are mounted in the direc-
tion of rotation. When a safety bar is actuated, the turnstile stops turning immediately.
When the safety bar is no longer actuated, the turnstile resumes turning.

Options 4
BAL_K32_K42_Z_EN_2V5_BLA_121-006454230 19 / 46
4 Options
4.1 Electromagnetic turnstile lock
The door is equipped with a turnstile lock. In the LOCKED operating mode, the turnstile will lock auto-
matically in the home position and will unlock when a different operating mode is selected.
During a power failure, the current LOCKED or UNLOCKED state is maintained. If the turnstile is
locked during a power failure, it can be manually unlocked by pulling the release knob (Bowden
cable).
Observe the following instructional steps:
Unlock the turnstile
Pull the knob
Turn the knob to the right until it stops and then re-
lease it.
Lock turnstile
Turn the knob to the left.
Let the knob go and it should retract.
Rotate the turnstile manually to the home position from
the outside of the door until you hear the locking pin en-
gage. Ensure that the turnstile can no longer be rotated
manually.
4.2 Turnstile bar-bolt lock
The turnstile can be locked with a bar-bolt lock, integrated in the door frame profile. By rotating the
profile cylinder together with the ceiling construction, and/or additionally with a fitted socket integrated
in the floor.
4.3 Lock mechanism status indicator and door position indicator
Signal contacts (potential-free NO contacts maximum contact load 24 volt AC/DC/0.3 amps) for indic-
ating the locked state of the turnstile and / or night shield. The position of the night shield wing can
also be indicated.
In some countries (VdS) tested signal contacts (potential-free NO contacts, tested according to VdS
class C, maximum contact load 24 volt AC/DC/0.3 amps) are required according to the German Prop-
erty Insurers Association. These are then suitable for use in certified alarm systems.

4Options
20 / 46 BAL_K32_K42_Z_EN_2V5_BLA_121-006454230
4.4 BDE-V key switch
The turnstile can be locked or unlocked with the BDE-V key switch (see Safety and operating
components legend).
Only a specific group of people are entitled to lock or unlock and consequently operate the
door.
CAUTION
Danger of people being trapped inside the turnstile.
a) Bruises and contusions through from the turnstile wing.
ðVisual inspection, check whether people are trapped inside.
Switch Operating mode Display symbol Function
Locked
– The operating mode LOCKED is selected by
turning the key switch to the right until it stops.
Varies, accord-
ing to the preset
mode
Varies, according to
the preset mode
– The LOCKED operating mode will switch back to
the mode preset on the control unit by turning the
key switch to the left until it stops.
4.5 Key pivot contact (SSK)
When the key pivot contact is activated (see “Safety and operating components legend”), the
turnstile starts and rotates a minimum of 360° in all operating modes except for MANUAL
mode.
In the MANUAL mode or when the emergency stop switch is activated, the turnstile can only
be rotated manually, with the exception of subfloor system with a geared drive.
In the LOCKED mode the turnstile will automatically lock again (if an electric lock is avail-
able).
Or – on-site code card reader (CKL)
4.6 Disabled button
If the disabled button is pressed in the AUTOMATIC or ONEWAY operating mode, the turn-
stile will start and rotate 360° plus an additional segment, at slow speed.
The motion detectors (if available) will be disabled during this time.
In the operating mode CONTINOUS the turnstile rotates a slow speed. If a disabled button is
pressed, the slow speed will be maintained.
