Resolution CryptiX RE610P Series User manual

Ceiling
Floor
RE610P Series CryptiX™PIR Motion Sensor
CryptiX PIR Motion Sensor alarms when motion is sensed
or when the external contact is opened. It is battery
powered and requires no installation tools. A Pyroex™
sensor with HighBar™signal processing allows for industry-
leading pet immunity and catch performance.
Features
• Industry-leading pet immunity and catch performance
• Supports both motion zone and an external contact zone
• Mountable on walls or in corners
• 5 year warranty
Enroll by placing the panel into wireless enrollment mode
and then sending an enrollment signal from the motion
sensor. Alternatively, the motion sensor can be enrolled by
scanning its bar code using the HeliLink app or by entering
its 8-character serial number on the interactive service
provider’s web portal.
Options for sending an Enrollment Signal
• Remove the battery tab, OR
• Remove the cover to trip tamper
Install using the included 3M VHB®tape to adhere the motion
sensor on a wall or in a corner. The tape should be applied
to the back when wall mounting or to the back bevels when
corner mounting. Alternatively, screw mounting can be
done by punching out the screw mounting holes.
Installation Tips
• Mount 7.5 to 9.5 feet from the oor for an
optimal balance between catch performance
and pet immunity.
• Remove the cover and circuit board before
trying to punch out the screw mounting holes.
• Ensure the bug foam stays intact and snug
around the IR sensing element when re-
installing the circuit board.
External Contact (not evaluated by ETL)
• Use a normally-closed contact because the
motion sensor will transmit an alarm when it
sees the external contact open.
• Do not use end-of-line resistors.
CE installations must use a cover-securing screw.
Mounting Screw Holes
Cover-Securing Screw Hole
Use the Helix installation guide to verify proper system setup.
I
N
S
T
A
L
L
G
U
I
D
E
I

Pro Tips
Walk test mode is entered by pressing the motion
sensor’s tamper button. The walk test lasts three
minutes.
Walk Test Operation
• The walk test LED turns on when motion
is sensed.
• The motion sensor performs a
re-calibration after each activation. The
re-calibration takes about 30 seconds.
The sensor will NOT sense motion
during the re-calibration.
• Wireless transmissions are sent for each
detection, so walk test mode can also
be used to test the panel.
3M VHB Tape works great if the surface is properly
prepared and rm pressure is applied for over 10
seconds.
Surface Preparation
• Clean the surface
• Ensure the mounting surface
temperature is above 50 °F
Motion lockout is active for three minutes after a motion event is detected. During the
motion lockout period, motion events will be ignored.
Motion sensitivity can be adjusted by the sensitivity jumper on the circuit board.
• Jumper Installed (lower sensitivity): Detects person in 3 to 5 steps.
Increases pet immunity. Usually for security applications.
• Jumper NOT Installed (higher sensitivity): Detects person in 2 to 4 steps.
Usually for occupancy applications.
Pet immunity is optimized when the motion sensor is mounted at 7.5 to 9.5 feet high
and aimed away from house features that could allow pets to be high in the detection
eld (e.g. stairs, counter tops, tall furniture).
Motion catch performance is best when the motion sensor is positioned so a person
would typically walk across the front of the motion sensor instead of directly toward
the motion sensor.
Motion Detection Tips
• Provide a clear line-of-sight to the monitored area and remember that glass
blocks infrared energy (PIR = Passive InfraRed).
• Aim away from windows and sunlight.
• Aim away from air conditioners, heaters or heating/cooling vents.
Walk Test LED
Cover Tamper Switch
Battery
Bug Foam IR Sensing Element
Sensitivity
Low - Jumper ON
High - Jumper OFF
External Contact
7.5ft
0
0 10ft 20ft 30ft 40ft
3.2ft

Side eld of view for a mounting height of 7.5 feet
0
10ft
20ft
30ft
40ft
Top eld of view
010ft 10ft20ft 20ft30ft 30ft
7.5ft
3.2ft
010ft 20ft 30ft 40ft
3.2ft
9.5ft
6.4ft
010ft 20ft 30ft 40ft
Side eld of view for a mounting height of 9.5 feet
Accessories
Gimbal mount (RE019 and RE019-10) allows the motion sensor direction to be adjusted
after mounting on a wall.
Horizontal beam lens (RE020) has less look-down which results in increased pet
immunity.
Specications

47-0005-08 • RevB • 2016-09-21
Tech Support Line [phone]
www.ResolutionProducts.com
WARRANTY
Resolution Products, Inc. will replace products that are defective in
their rst ve (5) years.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 8310A-RE310P
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the Resolution
Products, Inc. could void the user’s authority to operate this
equipment.
FCC ID: U5X-RE310P
CE DECLARATION OF CONFORMITY
Hereby, Resolution Products, Inc. declares that this RE610P-CE is
in compliance with the essential requirements and other relevant
provisions of directive 1999/5/EC.
(This declaration can be translated to other languages via a myriad
of translation tools found on the Internet.)
Specications
Physical
Housing Dimensions
Weight with Battery
Mounting Fastener
3.50 x 2.40 x 1.70 inches (8.9 x 6.1 x 4.3 cm)
3.2 ounces (91 grams)
3M VHB (Very High Bond) Tape or Screws (both provided)
Environmental
Operating Temperature
Maximum Humidity
32 to 120 °F (0 to 49 °C)
85% non-condensing relative humidity
Sensor Specications
Frequency
Pet Immunity
Replacement Battery
Nominal Battery Life
Battery Voltage
Current Draw
Optimal Mounting Height
Transmitted Indications
433.92 MHz
Two 60-pound dogs or one 85-pound dog
One Panasonic CR132A
6 to 8 years
3.0 VDC (Nominal), 2.2 VDC (Low)
30 mA (Maximum), 20 uA (Quiescent)
7.5 to 9.5 feet (2.3 to 3.0 m)
Cover Tamper, Low Battery, Supervision
Certication
RE610P
RE610P-CE
UL639, ULC-S309-03, ETL, FCC, IC
EN 50131-2-2, EN 60950-1, EN 300 220, EN 301 489,
CE Security Grade 1, CE Environmental Class 2, RCM
Specications subject to change without notice
