Resolution RE159 User manual

360 Degree PIR Motion Sensor
360 PIR Motion Sensor alarms when motion is sensed.
It is a commercial battery-powered ceiling mount sensor
with a 360 degree detection range.
Features
• 360° detection range with 62 distinct detection zones
• Range up to 40 feet in diameter
• Selectable pulse count 2 or 4
• Designed for commercial application
• 5 year warranty
Enroll by placing the panel into wireless enrollment mode
and tripping the sensor’s enrollment sequence. Interlogix® ,
DSC®, Qolsys® and Cryptix™ variants can be enrolled by
pulling the battery tab or by tampering the unit. Honeywell
® and 2GIG™ variants can be enrolled by tripping the unit
three times (tamper or motion) or by holding the tamper
down and powering the unit up by pulling the battery
tab. Honeywell and 2GIG sensors must be enrolled as a
“Loop1” sensor. Alternatively, all variants of the motion
sensor can be enrolled by entering its serial number into the
panel.
Install by screwing two #8 screws into the ceiling, leaving 1/4
inch of thread exposed. Next, slide the back plate over the
screws and rotate the back plate. Screw the third #8 screw
through the wall tamper into the ceiling, ensuring that the
wall tamper screw is attached to something solid. Tighten all
screws until snug. Then, insert the square nut into the square
slit of the cover and start threading the #4 screw into the
side of the cover. Close the cover and conduct a walk test.
After walk testing, take the unit out of walk test mode and
close the cover again. Finally, nish threading the #4 screw
until it is snug.
Use your panel’s installation guide to verify proper system setup.
I
N
S
T
A
L
L
G
U
I
D
E
I
Mounting Tips
• Avoid direct sunlight
• Avoid facing directly to AC or heating vents
• Avoid vapor or high humidity
• Avoid curtains, screens, etc. from blocking detection
• Do not install outdoors

Sensor functions
Alarm LED can be switched either “ON” or “OFF”.
Pulse Count can be switched to either “2” or “4” mode
depending on the environmental conditions of the
installation.
Walk Test Switch LED lights up when the unit has
detected motion. An alarm signal is outputted
whenever detection occurs.
Normal Operation (Battery Saving Mode)
LED lights up when the unit has detected if “LED ON”
is selected. Once alarm is outputted, it does not output
alarm again for 2 minutes. It goes back after 2 minutes
and outputs alarm again when receiving detection
signal.
Detection Range
Pulse Count
• Select “2” for normal applications.
• Select “4” for use in areas where there may be
movement by small animals or other objects,
such as fax machines or curtains.

Troubleshooting
Problem Probable Cause Remedy
Alarm is not activated
although someone is
walking in detection
area
Detection area is improper,
battery is dead, Walk Test
switch is OFF and 2 minute
delay is active
Conduct a walk test, change
the battery
Alarm is activated with
nobody in the area
Moving object within
detection area, temperature
of object within area is
changing rapidly
Remove the object from
the detection area, remove
the heat sources from the
detection area or relocate the
detector
LED does not light up
at the time of the walk
test
Walk test switch is OFF,
battery is dead
Turn the walk test switch ON,
change the battery
LED does not light up
in normal operation
LED switch is OFF, battery
is dead
Turn LED switch ON, change
battery
Pro Tips
Save battery life by taking unit out of walk test mode after
completing walk test. There is no 2 minute delay when
in walk test mode. Leaving in walk test mode will
severely decrease battery unit life.
Light changes will cause the sensor to trip. Ensure that the
detector is not placed near windows.
Sudden temperature changes will cause the sensor to trip.
Ensure the motion detector is not placed near heating
and cooling vents.
High humidity environments can cause condensation of
the detection lens. Ensure the motion detector is not
installed in these kinds of environments.
Protective lm should be removed from the lens after
installation.
Sensor Specications: The table below displays the
functional frequencies of each compatible sensor.
Part Number Frequency Compatible
RE159 319.5 Interlogix/Qolsys
RE259 345 Honeywell
RE259T 345 2GIG
RE359 433 DSC
RE659 433 Cryptix
