Resolution RE218 User manual

RE218 Honeywell®Compatible Trident™Environmental Sensor
Trident is an integrated environmental sensor. It detects water
and reports extreme temperature conditions.
Features
• Titanium probes for unmatched corrosion immunity
• IP67 rated waterproof enclosure
• GORE® vent equalizes enclosure pressure
• 5 year warranty
Enroll by placing the panel into wireless enrollment mode and
removing the battery tabs or tampering the sensor.
Loop Conguration
• Loop 1 = Heat
• Loop 2 = Flood
• Loop 3 = Freeze
• Loop 4 = Tamper
Install by placing the sensor in the location requiring water or air
temperature detection. If desired, the wall clip can be used to
secure the Trident sensor.
Optional Wall Clip Securing
• Remove the Trident body from wall clip.
• Secure wall clip to a surface with a #6 mounting
screw.
• Example securing locations: wall, baseboard or
Optional Wall Clip Securing
• Remove the Trident body from wall clip.
• Secure wall clip to a wall with a #6 screw.
• Example securing locations are a wall, baseboard
or cupboard.
Detects water pooled under the sensor and reports extreme air
temperature conditions.
Temperature Trip Points
• Heat larms when over 100.4° F (38° C)
• Heat restores when under 96.8° F (36° C)
• Freeze alarms when under 44.6° F (7° C)
• Freeze restores when over 48.2° F (9° C)
To replace the battery, insert a at blade screwdriver into the
front slot and twist. To reinstall the cover, align the rear latches
and roll the cover forward until it snaps into place.
I
N
S
T
A
L
L
G
U
I
D
E
I
Mounting Screw Hole
Front slot
Wall Clip
Verify proper enrollment and operation using your control panel’s installation manual.

47-0028-02 • RevA • 2016-11-10
Tech Support Line [phone]
www.ResolutionProducts.com
Specications
Specications subject to change without notice.
WARRANTY
Resolution Products, Inc. will replace products that are defective in
their rst ve (5) years.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 8310A-RE218
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the Resolution
Products, Inc. could void the user’s authority to operate this
equipment.
FCC ID: U5X-RE218
TRADEMARKS
“Honeywell” is a trademark owned by Honeywell International, Inc.
Resolution Products, Inc. products will function with Honeywell
systems. However, no Resolution product is produced by,
endorsed by, or is ofcially associated with Honeywell.
Resolution recommends verifying proper enrollment and operation,
per control panel installation instructions, at installation.
Physical
Housing Dimensions
Weight with Battery
Mounting Fastener
2.43 x 2.48 x 1.17 inches (6.2 x 6.3 x 3 cm)
1.34 ounces (38 grams)
#6 screw (not provided)
Environmental
Operating Temperature
Maximum Humidity
Water Resistance
32 to 120 °F (0 to 49 °C)
85% non-condensing relative humidity
IP67 rated (Waterproof for over 30 minutes at 1 meter depth)
Sensor Specications
Frequency
Replacement Battery
Nominal Battery Life
Battery Voltage
Current Draw
Transmitted Indications
345 MHz
Two Panasonic CR2032
10 years
3.0 VDC (Nominal) 2.3 VDC (Low)
20 mA (Maximum) 0.5 uA (Quiescent)
Cover Tamper, Wall Tamper, Low Battery, Supervision
Certication
RE218 FCC, IC
