Ricoh M022 Installation instructions

RICOH Americas Corporation Content ID# RFG46217
Ver.1.1 Page 1 of 54 2/1/2011
Subject to change without notice
Product Support Guide
M022 / M024 / M026 / M028
Introduction
Model Type
Color MFP
Launch Date
12/01/2010
S/N Configuration
S72YMMXXXX
S73YMMXXXX
S74YMMXXXX
S75YMMXXXX
Product Code
M022
M024
M026
M028
Brand/Model Name
Product Code
Lanier
Ricoh
Savin
M022
LD130C
Aficio MP C300
C230
M024
LD130CSR
Aficio MP C300SR
C230SR
M026
LD140C
Aficio MP C400
C240
M028
LD140CSR
Aficio MP C400SR
C240SR
Product Concept
The MFP product lineup of Ricoh Group is being
focused in DLT MFPs at this moment, and Ricoh
Group has made a great success with this lineup,
as you know well. On the other hand, when seeing
the lineup from the viewpoint of LT MFP, we have
only one copier based BW MFP (D069) at this
moment and no color one. Regarding Printer-based
LT MFP, we have M018 series, but there is no
model in mid-high segment. From the viewpoint of
competition, we are facing the necessity of LT
MFPs which can compete in the market.

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 2 of 54 2/1/2011
Subject to change without notice
Order Number
Main Frame
Item
Model Name
EDP Code
Notes
Lanier
Ricoh
Savin
LD130C
Aficio MP C300
C230
415130
Standard Mainframe
Configuration
Printer Scanner
Lanier
Ricoh
Savin
LD130CSR
Aficio MP C300SR
C230SR
415179
Finisher Mainframe
Configuration
Printer Scanner
Lanier
Ricoh
Savin
LD140C
Aficio MP C400
C240
415132
Standard Mainframe
Configuration
Printer Scanner
Lanier
Ricoh
Savin
LD140CSR
Aficio MP C400SR
C240SR
415180
Finisher Mainframe
Configuration
Printer Scanner
Options
Item
Description
Product
Code
EDP Code
Common / Unique
Paper Feed Unit
PB1010
2 Tray Paper Bank
M368-17
415122
U
Paper Feed Unit
PB1000
1 Tray Paper Bank
M367-17
415123
U
1 Bin Tray
BN1000
Inner 1 Bin Tray
M370-17
415124
U
Side Tray Type
C400
Side Tray
M369-17
415125
U
Fax Option Type
C400
Fax Unit
D483-01
415126
U
Cabinet
TBA
TBA
TBA
Copy Data
Security Unit
Type F
Copy Data Security Unit
B829-07
413985
C
Optional Counter
Interface Unit
Type A
Key Counter I/F Unit 20 pin
B870-11
413012
C
IEEE802.11 a/g
Interface Unit
Type J
Wireless LAN Option
D377-01
414008
C
Memory Unit
Type B 32MB
Fax Memory Unit
n/a
n/a
C

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 3 of 54 2/1/2011
Subject to change without notice
Item
Description
Product
Code
EDP Code
Common / Unique
Gigabit Ethernet
Type B
Gigabit Ethernet
D377-21
414204
C
Bluetooth
Interface Unit
Type 3245
Bluetooth
B826-17
412866
C
File Format
Converter Type E
File Format Converter
D377-04
414007
C

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 4 of 54 2/1/2011
Subject to change without notice
Supplies/Yields
Item
Name
Order Code
Target Yield
Ricoh / Savin / Lanier
Toner Black
Print Cartridge Black Type MP
C400/C240/LD140C
841295
10,000prints/bottle
Toner Cyan
Print Cartridge Cyan Type MP
C400/C240/LD140C
841296
10,000prints/bottle
Toner Magenta
Print Cartridge Magenta Type
MP C400/C240/LD140C
841297
10,000prints/bottle
Toner Yellow
Print Cartridge Yellow Type
MP C400/C240/LD140C
841298
10,000prints/bottle
Staple Set
Cartridge for
Internal Finisher
SR1000
Staple Type T
415009
5,000shots/staple
Staple Refill
Cartridge for
Internal Finisher
SR1000
Refill Staple Type T
415010
5,000shots/staple
Supply Yield Condition:
1) ISO/IEC19752 is used to measure the above toner yield.
2) The condition is standard temperature and humidity.
3) This yield number may change depending on the circumstances and printing conditions.

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 5 of 54 2/1/2011
Subject to change without notice
Option Compatibility
Category
Product Name
You Must Install
You Cannot Install
Original
Feeding
Paper
Feeding
ARDF comes with standard
Paper Feed Unit PB1000
Paper Feed Unit PB1010
Finishing
1 Bin Tray BN 1000
This option cannot be
attached to M022 / M024
Finisher model and
M026 / M028 Finisher
model
Side Tray Type C400
Fax
Fax Option Type C400
Memory Unit TypeB 32MB
Printer
Option
IEEE802.11 a/g Interface Unit Type J
Gigabit Ethernet TypeB
Network
Option
Data Overwrite Security Unit Type H
Security
HDD Encryption Unit Type A
Copy Data Security Unit Type F
Others
Optional Counter I/F Type A

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 6 of 54 2/1/2011
Subject to change without notice
Branding Information
Branding is required as the machines are shipped as a generic version.
Ricoh version machines: You must attach the model label (provided) to the front cover.
Savin/Lanier: You must attach the model label (provided) to the front cover and set the Plug and Play name with
SP 5-907.
MFP Options
MFP Option Board Slot / SD Card Assignments

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 7 of 54 2/1/2011
Subject to change without notice
Installation
Installation Requirements
Temperature Range:
10 C to 32 C (50 F to 89.6 F)
Humidity Range:
15% to 80% RH
Ambient Illumination:
Less than 1,500 lux (do not expose to direct sunlight)
Ventilation:
3 times/hr/person
Ambient Dust:
Less than 0.075 mg/m3 (2.0 x 10-6oz/yd3)
Avoid areas exposed to sudden temperature changes:
Areas directly exposed to cool air from an air conditioner.
Areas directly exposed to heat from a heater.
Do not place machine where it will be exposed to corrosive gas or vapor.
Do not install the machine at any location over 2,500m(8,200 ft.) above sea level.
Place the machine on a strong and level base. Inclination on any side should be no more than 5mm (0.2”)
Do not place the machine where it may be subject to strong vibrations.
Machine level
Front to back: within 5mm (0.2”) of level
Right to left: within 5mm (0.2”) of level
Power Requirements
Input voltage level: 110 - 120 V, 60Hz:12A
Do not place anything on power cord.
The required wall outlet is a NEMA 5-15R (receptacle)
Space
Foot Print
A (Left)
Over 100 mm (3.9")
B (Rear)
Over 100 mm (3.9")
C (Right)
Over 315 mm (12.4")
D (Front)
Over 400 mm (15.7")
Dimensions (W x D x H): 21.7 x 22.4 x 28.0 (including ARDF and operation panel)
21.7 x 21.5 x 23.6 (mainframe only, height up to contact glass)
The recommended 750 mm (30”) front space is sufficient to
allow the paper tray to be pulled out. Additional the front
space is required to allow operators to stand at the front of
the machine.

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 8 of 54 2/1/2011
Subject to change without notice
Power Consumption / Noise Emission
Power Consumption
Max Power
－
Full Option Max Power
NA：1600
Operating Power
M022 / M024: 950
M026 / M028: 1100
Ready Mode
260
Panel Off
Power
260
Recovery
3
Panel Off Level2
Power
230
Shift time
1
Recovery
10
Low Power
Power
217
Shift time (Default)
M022 / M024: 5
M026 / M028: 5
Recovery
M022 / M024: 22
M026 / M028: 26
Sleep Mode
Power
2.5
Shift time (Default)
M022 / M024: 11
M026 / M028: 11
Recovery
M022 / M024:45
M026 / M028:NA:50
TEC (Typical Electricity
Consumption)
M022 / M024(Std)
3218(NA
Noise Emission
Sound Power Level
Stand-by
M022 / M024
Less than 40
(Mainframe Only)
M026 / M028
Less than 45
Copying
M022 / M024
Less than 66.5(B&W)
Less than 67.0(FC)
M026 / M028
Less than 70(B&W)
Less than 70(FC)
Sound Power Level
Stand-by
M022 / M024
Less than 44
(Full System)
M026 / M028
Less than 49
Copying
M022 / M024
Less than 70.5(B&W)
Less than 71(FC)
M026 / M028
Less than 74(B&W)
Less than 74(FC)
Sound Pressure Level
Stand-by
M022 / M024
Less than 34
(Mainframe Only)
M026 / M028
Less than 39
Copying
M022 / M024
Less than 60.5(B&W)
Less than 61(FC)
M026 / M028
Less than 64(B&W)
Less than 64(FC)
Sound Pressure Level
Stand-by
M022 / M024
Less than 38

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 9 of 54 2/1/2011
Subject to change without notice
(Full System)
M026 / M028
Less than 43
Copying
M022 / M024
Less than 64.5(B&W)
Less than 65(FC)
M026 / M028
Less than 68(B&W)
Less than 68(FC)

Product Support Guide
M022 / M024 / M026 / M028
Ver.1.1 Page 10 of 54 2/1/2011
Subject to change without notice
Installation Times
Mainframe: 30 min
Unit
Installation Time
(Minutes)
Paper Feed Unit PB1000
3.0
Paper Feed Unit PB1100
3.0
1 Bin Tray PM1000
9.5
Side Tray Type C400
1.0
FAX unit
12.5
Fax SAF Memory
0.5
Media Link Board
1.0
Gigabit Ethernet
8.0
Browser card
1.0
IEEE802.11a/g
2.0
Copy data security unit
9.0
Key Counter Interface unit
8.0
Storage/Transportation
Storage
Transportation
Mainframe
Temperature
-30 ~ 40C
Humidity
Less than
80% RH
Storage Period
Max: 12
months
Temperature
-30 ~ 50C
Humidity
15% ~ 95%
RH
Conditions for Toner
Usage and Storage
Temperature
Humidity
Storage Period
Usage
15~ 32℃
15~ 80%RH
Storage
-30~ 40℃*
15~ 80%RH
2 yrs after production
(Unopened)
Remarks:
* Do not store more than 12 hours under the temperature between 41 and 50 ℃.
* Do not store more than a month under the temperature between 35 and 40 ℃.
