ASSEMBLY INSTRUCTIONS
ITEM #: 06-116 White
RiverRidge®Bayfield Linen Tower with Open Shelves
ADULT ASSEMBLY REQUIRED
WARNING
SEE FULL WARNING ON PAGE 2
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
Young children can be seriously injured or killed if furniture tips over.
Don’t use this item for a TV stand or place heavy objects on top of item.
Always use angle-braces or anchors to secure furniture to the wall.

THIS SHELF UNIT WILL HOLD UP TO 20 POUNDS PER SHELF OR A TOTAL OF
100 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 20 POUNDS OR
100 POUNDS TOTAL WEIGHT. IF OVERLOADED WITH MORE THAN 20 POUNDS
PER SHELF OR 100 POUNDS TOTAL WEIGHT, SHELF MAY TIP FROM THE WALL
AND CAUSE SERIOUS INJURY OR DEATH.

1
2
3
4
4
5
6
7
10
11
9
8
Top Board
DESCRIPTION
Left Side Panel
Right Side Panel
Front Cross Bar
Adjustable Shelf
Upper Shelf
Rear Cross Bar
Bottom Shelf
Back Board
Door
Middle Shelf
1PC
QTY
1PC
1PC
2PCS
1PC
1PC
1PC
1PC
1PC
1PC
1PC
NO
1
2
3
4
5
6
7
8
9
10
11
PARTS LIST

TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED
PARTS LIST
NO QTYPARTS DESCRIPTION
A16PCS Cam Bolt
B16PCS Cam Lock
C26PCS Wood Dowel
D
2PCS
E
F
Screw (2.5x10mm)
G8PCS
H
10PCS
J
4PCS
2PCS Hinge
Shelf Holder
Screw (4x30mm)
4PCS
Screw (4x12mm)
Screw (4x35mm)
Screw (4x12mm)2PCS
K
Adjustable Anchor Bracket2PCS
L
Plastic Anchor2PCS
I
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.

STEP 1
1. Insert 6 cam bolts (A) into cam bolt holes on left side panel (2).
2. Insert 6 cam bolts (A) into cam bolt holes on right side panel (3).
1. Insert 4 cam bolts (A) into cam bolt holes on top board (1).
2. Attach 2 brackets (L) to top board (1) by inserting 2 screws (K) through holes on brackets (L),
then tighten to top board (1).
1. Attach rear cross bar (7) to upper shelf (6) by inserting 2 screws (F) through holes on rear cross
bar (7), then tighten to upper shelf (6).
2. Insert 2 wood dowels (C) into wood dowel holes on front cross bar (4). Attach front cross bar (4)
to middle shelf (11) by inserting wood dowels into wood dowel holes on middle shelf (11). Insert
1 screw (F) through hole on front cross bar (4), then tighten screw (F).
STEP 2
STEP 3
A
A
A
A
A
AA
AA
A
A
A
F
F
F
C
C
6
7
23
11
4
A
K
KL
L
A
A
A
1

1. Attach 2 hinges (E) to door (10) by inserting 4 screws (G) through holes on hinges (E), then
tighten to door (10).
1. Insert 9 wood dowels (C) into wood dowel holes on left side panel (2).
2. Attach front cross bars (4), upper shelf (6), rear cross bar (7), bottom shelf (8) and middle
shelf (11) to left side panel (2) by inserting wood dowels (C) into wood dowel holes and inserting
cam bolts (A) into cam lock holes on front cross bars (4), upper shelf (6), rear cross bar (7),
bottom shelf (8) and middle shelf (11).
3. Insert 6 cam locks (B) into cam lock holes on upper shelf (6), bottom shelf (8) and middle
shelf (11), then rotate clockwise to secure cam bolts (A) in place.
STEP 4
STEP 5
GG
E
10
GG
GG
E
E
CC
C
B
B
B
B
B
B
CC
C
CC
C
2
4
4
6
7
11
8

1. Insert 9 wood dowels (C) into wood dowel holes on right side panel (3).
2. Attach right side panel (3) to front cross bars (4), upper shelf (6), rear cross bar (7), bottom
shelf (8) and middle shelf (11) by inserting wood dowels (C) into wood dowel holes and inserting
cam bolts (A) into cam lock holes on front cross bars (4), upper shelf (6), rear cross bar (7),
bottom shelf (8) and middle shelf (11).
3. Insert 6 cam locks (B) into cam lock holes on upper shelf (6), bottom shelf (8) and middle
shelf (11), then rotate clockwise to secure cam bolts (A) in place.
1. Insert 6 wood dowels (C) into wood dowel holes on top board (1).
2. Attach top board (1) to left side panel (2), right side panel (3) and front cross bar (4) by
inserting wood dowels (C) into wood dowel holes and inserting cam bolts (A) into cam lock
holes on left side panel (2), right side panel (3) and front cross bar (4).
3. Insert 4 cam locks (B) into cam lock holes on left side panel (2) and right side panel (3), then
rotate clockwise to secure cam bolts (A) in place.
4. Insert 2 screws (F) through holes on front cross bar (4), then tighten screw (F).
STEP 6
STEP 7
3
28
11
6
4
4
7
C
C
C
C
C
C
C
C
CB
B
B
B
B
B
C
C
C
C
C
C
F
F
BB
BB
1
2
3
4

1. Attach back board (9) to back of cabinet by inserting 10 screws (J) through holes on back
board (9) then tighten to cabinet.
1. Insert 4 shelf holders (D) into desired position.
2. Place adjustable shelf (5) onto 4 shelf holders (D), making sure all 4 shelf holders are at
same height.
STEP 8
STEP 9
D
D
D
D
D
5
J
J
J
JJ
JJ
J
JJ
9

1. Attach door (10) to cabinet by inserting 4 screws (G) through holes on hinges (E) then tighten to
right side panel (3).
2. Note: Tightening screw in position “a” will adjust door up or down; tightening screw in position
“b” will adjust door to or from cabinet and tightening screw in position “c” will adjust door side
to side.
G
G
G×2
G×2
b
a
a
bc
c
STEP 10
E
10

STEP 11
Option #1: Securing to Drywall
1. Position cabinet against wall in desired location. Using a pencil, make 2 small marks on wall through holes
on brackets (L). Move cabinet away from wall and screw 2 plastic anchors (I) into wall on pencil marks.
2. Place cabinet against wall, insert 2 screws (H) through holes on metal brackets (L), then tighten to plastic
anchors (I).
Option #2: Securing to Drywall and Wood Stud
1. Position cabinet against wall in desired location. Insert 2 screws (H) through holes on metal brackets (L),
then tighten through drywall and into wood stud.
*Tip: Anchor brackets (L) can be adjusted to correct distance from wall to cabinet as needed. Once adjusted,
be sure to re-tighten brackets inside cabinet for stability.
I
H
H
DRYWALL
WALL ANCHOR
WITH SCREW
SCREW
ONLY
DRYWALL
OPTION #2OPTION #1
WOOD
STUD
H
H
I
I
H
I
ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure youritem is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.
IMPORTANT:
Keep assembly instructions for future reference.

Enjoy your new RiverRidge®Cabinet!
To order replacement parts at no cost to you,email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
