Ropox Vision Manual A User manual

User manual
Mountinginstruction
Keep always this folder with product!
PDF 6188 / 01.03.2018
Ropox Vision Electric

2
© ROPOX 2015
Warning:
KEEP TABLETOP IN BOX during assembly of leg
section,
otherwise tabletop will be damaged & right to complain
becomes void.

3
© ROPOX 2015
Contents:
1. TECHNICAL DATA .................................................................................................................................................... 4
2. INTRODUCTION ...................................................................................................................................................... 6
3. COMPLIANCE WITH EU-DIRECTIVES ........................................................................................................................ 6
4. APPLICATION .......................................................................................................................................................... 6
5. MODELS.................................................................................................................................................................. 7
6. COMPONENTS ........................................................................................................................................................ 9
7. MOUNTING INSTRUCTION .....................................................................................................................................12
8. HEIGHT ADJUSTMENT OF TABLE ............................................................................................................................17
9. OPERATION OF TILTING FACILITY ..........................................................................................................................17
10. MOVING THE TABLE.............................................................................................................................................18
11. MAGRULE (ACCESSORIES) ....................................................................................................................................18
12. MOUNTING OF ARMSUPPORT (ACCESSORIES).....................................................................................................19
13. PERFORMANCE TEST............................................................................................................................................20
14. SAFETY IN USE......................................................................................................................................................20
15. CLEANING/ MAINTENANCE..................................................................................................................................21
15.1 Cleaning of frame...................................................................................................................21
15.2 Cleaning of tabletop, laminate...............................................................................................21
15.3 Maintenance ..........................................................................................................................21
16. FAULT FINDING ....................................................................................................................................................22
16.1 The table seems loose or unstable ........................................................................................22
16.2 The height/tilting cannot be adjusted (adjustment is very difficult).....................................22
17. ACCESSORIES .......................................................................................................................................................23
18. CE-MARKING........................................................................................................................................................24
19. COMPLAINTS .......................................................................................................................................................25

4
© ROPOX 2015
1. Technical data
Product name: Ropox Vision Electric
Type A, B, C, D, E, F, G
Tabletop: 90x60 cm, 120x60 cm og 90x90 cm
Item numbers: 20-60XXX-21
Height range: 50–70 cm (electric) incl. tabletop
60–90 cm (electric) incl. tabletop
Frame material: Aluminium leg. 606045-T6
Stål St. 37
Various plastic components
Tabletop: Laminate
Power supply: 230VAC / 2,5A / 50Hz
Standby primary: 1W
Control voltage: 24VDC
Duty circle.: Max. 10 % conform to 1 min. active / 9 min. pause
Speed: Ca. 32 mm/sec
Lifting time: Ca. 10 sec.
Temperature: 5-45° C
Air humidity: 5-85 % (non-condensing)
Surface treatment: Anodiseret
Powder coating, various colours
Chromating
Max. Load on the table
(static): 100 kg evenly distributed over the entire tabletop
Max. Load during lifting
(dynamisk): 50 kg
Max. load on the tabletop
tilted (static): 30 kg
Max. load during tilting
the tabletop (dynamic): 4 kg

5
© ROPOX 2015
Complaints: See complaints, section 25
Manufacturer: Ropox A/S, DK-4700 Naestved, Tlf.: [phone]
E-mail: [email protected], www.ropox.com

6
© ROPOX 2015
2. Introduction
VISION is the new range of modern height-adjustable Ropox tables. In our opinion a product must
be functional and beautiful –no matter who is going to use it. That’s what we call VISION.
Vision is available in several sizes to suit individuals and carers needs. Sufficient legspace makes
the table ideal for wheelchair users and gives the therapist optimum working conditions in a
training situation. Due to the unique design with rounded corners there is no danger of hitting
sharp edges when moving round the table and two inconspicuous castors at the back, make it easy
to draw the table closer to the user. As an option extra arm supports may be clipped on and off as
required.
Vision meets all needs and ensures ergonomically correct working positions for people with or
without disability.
Correct use, operation and inspection are decisive factors for efficient and safe performance.
3. Compliance with EU-directives
This product has CE-marking according to the current Directives and thus complies with the basic
safety requirements. See separate CE-declaration.
4. Application
Vision is designed to obtain optimum working height for the user. It is an activity table not
intended for lifting people or objects.
Vision should be used indoor, at temperatures and humidity as described in section 1.
This document should always accompany the product and be read by and be available to
the user.
As this product is adjustable in height there is a risk of squeezing. The product must
therefore always be operated by or under the guidance of an experienced adult, who has
read and understood the importance of section ”Safety in use”.
It is very important that there are no obstacles between the tilted tabletop and the frame
to prevent any change of entrapment.
Maglist: Our maglists with magnets can affect pacemakers and implanted heart
defibrillators which can cause discomfort and sickness.
Persons that use such devices must therefore keep sufficient distance from magnets.

7
© ROPOX 2015
5. Models
Model name
Description
Size
Height 50-70cm
Height 60-90cm
Vision Electric B
Tilt-function of
entire tabletop
90x60cm
20-60011-21
20-60021-21
Vision Electric B
Tilt-function of
entire tabletop
120x60cm
20-60211-21
20-60221-21
Model name
Description
Size
Height 50-70cm
Height 60-90cm
Vision Electric A
Without tilting
of tabletop
90x60cm
20-60010-21
20-60020-21
Vision Electric A
Without tilting
of tabletop
120x60cm
20-60210-21
20-60220-21
Model name
Description
Size
Height 50-
70cm
Height 60-
90cm
Vision Electric C
Devided
tabletop, right
side tilt section
90x60cm
Fixed plate: 30cm
Adjustable plate: 60cm
20-60012-21
20-60022-21
Vision Electric C
Devided
tabletop, right
side tilt section
120x60cm
Fixed plate: 30cm
Adjustable plate: 60cm
20-60212-21
20-60222-21
Model name
Description
Size
Height 50-
70cm
Height 60-
90cm
Vision Electric D
Devided
tabletop, left
side tilt section
90x60cm
Fixed plate: 30cm
Adjustable plate: 60cm
20-60013-21
20-60023-21
Vision Electric D
Devided
tabletop, left
side tilt section
120x60cm
Fixed plate: 30cm
Adjustable plate: 90cm
20-60213-21
20-60223-21
Model name
Description
Size
Height 50-
70cm
Height 60-
90cm
Vision Electric E
Devided
tabletop, middle
tilt section
90x60cm
Fixed plate: 20cm
Adjustable plate: 50cm
Fixed plate: 20cm
20-60014-21
20-60024-21
Vision Electric E
Devided
tabletop, middle
tilt section
120x60cm
Fixed plate: 30cm
Adjustable plate: 60cm
Fixed plate: 30cm
20-60214-21
20-60224-21

8
© ROPOX 2015
Model name
Description
Size
Height 50-
70cm
Height 60-
90cm
Vision Electric F
Devided
tabletop, right
side tilt section
120x60cm
Fixed plate: 60cm
Adjustable plate: 60cm
20-60215-21
20-20225-21
Model name
Description
Size
Height 50-
70cm
Height 60-
90cm
Vision Electric G
Devided
tabletop, left
side tilt section
120x60cm
Fixed plate: 60cm
Adjustable plate: 60cm
20-60216-21
20-60226-21
Model name
Description
Size
Height 50-70cm
Height 60-90cm
Vision Electric A
Without tilting of
tabletop
90x90cm
20-60310-21
20-60320-21

9
© ROPOX 2015
6. Components
Leg section 1 pc.
Contains:
Beam:
90x60cm: 20-60320-397, 1 pc.
90x90cm: 20-60320-397, 1 pc.
120x60cm: 20-60320-409, 1 pc.
Leg height 50-70cm:
20-60320-069, 2 pcs.
Leg height 60-90cm:
20-60320-065, 2 pcs.
Screws M6x16, 95010618, 4 pcs.
Screws M8x30, 95010830, 4 pcs.
Motor box:
90x60cm: 97701-787, 1 pc.
90x90cm: 97701-787, 1 pc.
120x60cm: 97701-792, 1 pc.
Flexible spindle/axle 90x60cm:
B+E: 20-60320-413, 2 pcs.
C+D: 20-60320-413, 1 pc.
Flexible spindle/axle 120x60cm:
B: 20-60320-423, 2 pcs.
C+D: 20-60320-423 + 20-60320-424, 1 + 1
E: 20-60320-424, 2 pcs.
F+G: 20-60320-424, 1 pc.
Centre axle:
F+G: 20-60320-292, 1 pc.
Motor:
A: 96000553, 2 pcs.
B-G: 96000553, 3 pcs.
Motorcable:
A: 96000573, 2 pcs.
B-G: 96000573, 3 pcs.
Control unit:
A: 20-60320-576, 1 pc.
B-G: 20-60320-578, 1 pc.
Power cable 30-30002, 1 pc.
Split print:
B-G: 98002081, 1 pc.

10
© ROPOX 2015
Communication cable:
B-G: 98002107, 1 pc.
Klemliste:
C+D+F+G: 30-69056, 1 pc.
E: 30-69056, 2 pcs.
Adapter cable:
C-G: 96000598, 1 pc.
Adapter plug:
C+D+F+G: 98002091, 1 pc.
E: 98002091, 2 pcs.
Split cable:
E: 96000657, 1 pc.
Feet mounted with plugs and adjusting screws
90x60cm: 20-60320-045 2 pcs.
90x90cm: 20-60320-066 2 pcs.
120x60cm: 20-60320-045 2 pcs.
Tabletop 1 pc.
Contains:
Tabletop:
A 90x60cm: 64109060
B 90x60cm: 64109061
C + D 90x60cm: 64109062
E 90x60cm: 64109064
A 120x60cm: 64112060
B 120x60cm: 64112061
C + D 120x60cm: 64112062
E 120x60cm: 64112064
F + G 120x60cm: 64112065
A 90x90cm: 64109090
Support arms 90x60/120x60 cm:
Right: 20-60320-168 1 pc.
Left: 20-60320-165 1 pc.
Support arms 90x90cm:
20-60320-187 2 pcs.
Front profile:
90x60cm: 20-60320-077 1 pc.
90x90cm: 20-60320-077 2 pcs.
120x60cm: 20-60320-108 1 pc.

11
© ROPOX 2015
Tabletop bracket (not for table B ):
90x60cm: 97702-034 1 pc.
120x60cm: 97702-034 1-2 pcs.
Hinges for tabletops (not for table A ):
20-60320-140 2 pcs.
Tilting 90x60cm:
B: 20-60320-026, 2 pcs.
C+D+E: 20-60320-026, 1 pc.
Skråtstilling 120x60cm:
B-G: 20-60320-026, 2 pcs.
Gearbox for tilting 90x60cm:
B: 96000656, 2 pcs.
C+D+E: 96000656, 1 pc.
Gearbox for tilting 120x60cm:
B-G: 96000656, 2 pcs.
Handcontrol:
A: 93000039 1 pc.
B-G: 93000039 2 pcs.
Allen key 4mm 95001019: 1 pc.
Allen key 6 mm 95000006: 1 pc.

12
© ROPOX 2015
7. Mounting instruction
1. Mounting of legsection
4x M6x16

13
© ROPOX 2015
2. Mounting of tilting fitting of tabletop (not table A)
1
2
M5x16

14
© ROPOX 2015
3. Mounting of feet
4x M8x16

15
© ROPOX 2015
Mounting of control panel for
height adjustment and tilting.

16
© ROPOX 2015
Connecting of safety strip (for C + D + E
+ F + G models)
Remove yellow resistor
Connect the safety strip
(the picture show Vision type E
with 2 safety strips)

17
© ROPOX 2015
8. Height adjustment of table
9. Operation of tilting facility

18
© ROPOX 2015
10. Moving the table
By lifting the table slightly in the front, it can easily be pushed around.
11. Magrule (accessories)

19
© ROPOX 2015
12. Mounting of armsupport (accessories)

20
© ROPOX 2015
13. Performance test
After installation and prior to use, all functions of the table must be tested. Subsequently this
test must be carried out by competent personnel at least once a year:
1. Check that the mounting instructions have been observed.
2. Check that all bolts have been tightened.
3. Make sure that there is no load on the table.
4. Make sure that there are no objects or the like preventing the table from moving unhindered
within the range of height adjustment.
5. Push the ”DOWN” button and move the table to the bottom position. Check that the movement is
even and smooth.
6. Now move the table to the top position. Check that the movement is even and smooth.
If tilt fitting is mounted:
7. Make sure to execute a complete inclination of tabletop. Check that the movement is even and
smooth.
When the above mentioned items have been checked, the table is ready for use. See “Safety in
use” section 14.
14. Safety in use
Vision must only be used by persons, who have read and understood these instructions.
Vision is an activity table and must not be used as a lifting table or person lifter.
Always use the table in a manner excluding the risk of damage to persons or property. The person
operating the table is responsible for avoiding damage or injury.
Make sure that there is free space above and below the table to allow height adjustment.
Do not operate the table in case of defects or damage.
Do not overload the table and ensure that the load distribution is correct.
During inspections, service or repairs any load must be removed from the table.
Modifications, which may influence the performance or design of the table, are not allowed.
Assembly, service and repairs must be carried out by competent personnel.
If the table has not been assembled according to these mounting instructions, the guarantee may
become void.
Only use Ropox original spare parts for replacement. If other spare parts are used, the guarantee
may become void.
