RSH-380 Laminator
OWNER'S MANUAL
Read all instructions carefully before use.
For any Customer Support needs please choose the
Customer Support tab on www.royalsovereign.com
Royal Sovereign International Inc.
13. WARRANTY
Royal Sovereign International warrants the equipment sold is free from defects in material
and workmanship for a period of One (1) year for Parts and Labor from the date of
installation, excluding lamination rollers which are warranted for Six (6) months. This
warranty is extended only to the original purchaser. This warranty is the only warranty
made by Royal Sovereign International and cannot be modified or amended. Royal
Sovereign’s sole and exclusive liability and the customer’s sole and exclusive remedy
under this warranty shall be, at Royal Sovereign’s option, to repair or replace any such
defective part or product. These remedies are only available if Royal Sovereign’s
examination of the product discloses to Royal Sovereign’s satisfaction that such defects
actually exist and were not caused by misuse, neglect, attempt to repair, unauthorized
alternation or modification, incorrect line voltage, fire, accident, flood or other hazard.
The warranty made herein is in lieu of all other warranties, expressed or implied, including
any warranty or merchantability or fitness for a particular purpose. Royal Sovereign will not
be liable for personal damage or personal injury (unless primarily caused by its
negligence), loss of profit, or other incidental or consequential damages arising out of the
use or inability to use this equipment.
This warranty specifically does not cover damage to laminating rollers caused by knives,
razor blades, or any sharp objects or abrasives, or failure caused by adhesives, or
damage caused by lifting, tilting and/or any attempt to position the machine other than
rolling on the installed castors or feet on even surfaces, or improper use of the machine.
Warranty repair or replacement by Royal Sovereign or its authorized Reseller(s) does not
extend the warranty beyond the initial one year period from the date of installation.
Unauthorized customer alterations will void this warranty.
LIMITED WARRANTY
www.royalsovereign.com
RS Holland B.V.
Columbusstraat 25 - 3165 AC Rotterdam,
The Netherlands
E-mail : [email protected]
[email protected]
RS International Australia PTY. LTD.
30 Prime Drive, Seven Hills, NSW 2147, Australia
TEL : [phone]
FAX : [phone]
E-mail : [email protected]
CORPORATE HEADQUARTERS
Royal Sovereign International Inc.
2 Volvo Drive, Rockleigh, NJ 07647 U.S.A.
TEL : [phone] FAX : [phone]
E-mail : [email protected]
Royal Sovereign Inc. <Oversea Sales Office>
1001, World Meridian II, 426-5, Gasan-dong,
Geumcheon-gu, Seoul, 153-759, KOREA
TEL : [phone] FAX : [phone]
E-mail : [email protected]
RS Canada Inc.
164 Oakdale Road, Toronto, Ontario M3N 2S5
CANADA
TEL : [phone] FAX : [phone]
E-mail : [email protected]

RSH-380
32
TABLE OF CONTENTS 1. INTRODUCTION
TOPIC PAGE
1. Introduction ......................................................................................................... 3
2. Package Contents .............................................................................................. 3
3. Safety Precautions............................................................................................... 4
4. Parts..................................................................................................................... 4
5. Control Pane ........................................................................................................ 5
6. Film Loading and Threading ............................................................................. 6.7
7. Before Laminatingl............................................................................................... 8
8. Operation Instructions .................................................................................... 9.10
9. Recommended Temperature and Speed Settings ........................................... 11
10. Maintenance..................................................................................................... 12
11. Trouble Shooting Guide................................................................................... 12
12. Specifications................................................................................................... 13
13. Warranty........................................................................................................... 14
2. PACKAGE CONTENTS
Thank you for purchasing a Royal Sovereign RSH-380 Table Top Laminator. It has been
designed and manufactured to provide years of continuous service. For complete
operating and maintenance information please read this instruction manual thoroughly.
Upon receipt of your laminator thoroughly inspect the box, machine and all other contents.
It is imperative that any shipping damage is reported and a claim is filed with the delivering
carrier immediately upon receipt.
Owner's Manual

RSH-380
54
3. SAFETY PRECAUTIONS
4. PARTS
Failure to comply with any of the following safety procedures could result in
serious injury. Please read the instructions carefully and keep for future reference.
1. Only a licensed electrician should install wiring and outlet for the laminator.
2. Ensure the unit is plugged into a properly grounded outlet with the correct voltage.
3. Keep hands and clothing (i.e. Neckties) away from rollers.The rollers are pinch points
that can trap body parts or clothing and cause serious injury.
4. Keep flammable and wet objects away from the machine.
5. Place machine on a level surface.
6. Avoid excessive sunlight, humidity and extreme temperatures.
7. Ensure the unit is turned off, cooled, and unplugged from the outlet prior to moving
and/or repairing.
8. Keep out of reach of children.
9. Only Royal Sovereign authorized maintenance and service technicians should make
repairs.
10. Do not attempt to laminate items that exceed total recommended material thickness
for the unit
11. When cleaning the machine, don't use flammable sprays or materials.
12. Do not touch the rollers when they are hot or place foreign objects inside the
machine.
13. Do not cover the surface of the machine until the machine has completely cooled.
5. CONTROL PANEL
< TEMPERATURE >
This button is for changing the temperature of upper and
lower rollers,
Press the up button to increase temperature or the down
button to decrease temperature.
[range 20 oC(68 °F) through 150 oC(302 °F)]
< SPEED >
This button is used to change the speed of the rollers.
(Settings 1 - 9)
< T-CHECK >
To Check current upper and lower roller temperature.
Display automatically returns to previous settings after 5 blinks.
< REVERSE >
This button is used to reverse the rollers to undo jams and
correct misfed documents.
< RUN/STOP >
This button is used to Run and Stop the machine.
1.FILM-UPPER
2.FILM-LOWER
3.TENSION CONTROL KNOB
4.TOP HOT ROLLER
5.FRONT FEED TABLE
6.CONTROL PANEL
7.SAFETY SHIELD
8.PRESSURE LEVER

RSH-380
6
6. FILM LOADING & THREADING < Film Threading >
1. Turn the power switch on (“I” position). (The Power
switch is located on the rear the unit)
2. Complete the steps in the "Loading Film" section.
3. Set the desired temperature.
4. Remove the Front Feed Table.
5. Pull down the upper film over the Safety Shield to the
lower film; align and center the lower film to the
upper film and tighten the 2 lower bolt core
screws. (Figure 1)
6. Rewind the upper film until it aligns with the safety cover.
7. Thread the film over the Lower Idle Bar and underneath
the safety shield until the film rests on the upper
roller. Figure 2
8. Put the Front Feed Table back on and close the Safety
Shield. Figure 3
9. Press the Run button and thread the film using the
Laminating Threading Card. Figure 4
< Thermal Film Loading & Threading >
Loading Film
1. Remove the upper and lower film shafts from the
machine and load the films (do not tighten the
core screws at this time)
2. To load the top film, insert 1" core as shown on
Figure 1 (Note the direction of the film wound)
3. Insert the shaft as shown in Figure 2.
Figure 1
Figure 2
Figure 1
Figure 2
Figure 3
Figure 4
Figure 3
Figure 4
Figure 5
4. Insert the core plug on the left hand side. Figure 3
5. Align and center the film and tighten the two core
screws. Figure 4
6. Repeat steps 2 through 4 to load the lower film.
(Please note the direction of the
film wound for the bottom roll). Figure 5
7. Load the upper and lower film shafts on the machine.
7

98
7. BEFORE LAMINATING 8. OPERATING INSTRUCTIONS
1. Turn the laminator on, the power switch is located
on the rear of the machine.
2. Adjust the tension of the upper and lower films.
Clockwise to tighten and Counter
Clockwise to loosen.
3. Set the pressure lever to the "Laminating mode"
4. Choose appropriate laminating temperature by
pressing the "UP" or "DOWN" button.
5. When desired temperature is met an alarm will
sound and "READY" will appear on the
display.
6. Press the "RUN/STOP" button. (If rollers don't run
check that the safety shield is completely
closed).
7. Position the item to be laminated on the Front Feed Table.
8. Adjust the film tension or laminating speed if necessary.
9.Press the "RUN/STOP" button when your l amination is finished.
10.After finishing your work ,set the pressure lever to the "Hard Board/6mm"
11.Turn the Power switch off
NOTE:
* Stand by mode : If no activity is made within 30 minutes after each use the
machine will automatically switch to stand by mode.
* Auto power off mode : If the machine is in standby mode and no activity is
made for 90 minutes the machine will automatically power off.
1. For High Quality Lamination
- Refer to the "Recommended Temperature and Speed Settings" section before
laminating.
- The Upper and lower film tension must be same.
2. Changing Roll film.
- While laminating, if the roll film needs to be replaced, press the 'RUN/STOP'
button .
Once the rollers stop, cut the upper and lower film, remove and replace with new
rolls of film.
3. After lamination
- “Hot Spots” on the rollers may occur when the machine is idle. To help prevent
“Hot Spots”
you must run the sample paper between the front rollers and stop the machine
while the sample paper is in between the rollers. You must leave the sample
paper in this position until you laminate again.
- After laminating with Thinflex™,use “Cleaning Paper” to clean the rollers.
RSH-380

RSH-380
1110
9. RECOMMENDED TEMPERATURE AND SPEED SETTINGS
speed
4~5
3~4
2~4
4~5
2~3
2~4
2~3
Function
25~38mic
(1~1.5mil)
75mic(3mil)
100mic(4mil)
250mic(5mil)
Temperature
100~110 oC
(212~230 oF)
100~110 oC
(212~230 oF)
100~115 oC
(230~239 oF)
120~125 oC
(248~257 oF)
130~135 oC
(266~275 oF)
1) The cross cutter is located on the rear exit table
of the machine.
2) After lamination, move the cutter approximately
to the center of the application at the
desired point of detachment.
3) Grasp film with one hand, press the cutter
downward into he application and slide it
first to one end of the application, then to
the other end to complete the cut.
Paper
80 g/m2
Paper(both side can be used)
120g/m2
200g/m2
color paper
80g/m2
Paper(both side can be used)
120g/m2
200g/m2
color paper
80g/m2
Paper(both side can be used)
120g/m2
200g/m2
color paper
80g/m2
Paper(both side can be used)
120g/m2
200g/m2
color paper

1312
RSH-380
Rollers do not operate
after the RUN/STOP
button is pressed
Roller is not heating
Result of lamination is
waved.
Result of lamination is
not clear
Problem Possible Cause Possible Solution
1.Safety coveris opened.
2. Power cord is not
plugged in
Call your authorized
dealer
1. Film tension is
unbalanced.
2. lower idler bar is not
located in proper
position
1. Temperature is lower or
speed is higher than
recommended
1. Check to make sure the
safety shield is closed.
2. Check the power cord.
Call your authorized dealer
1. Adjust film tension by
rotating tension handle
2. Push idler bar up
1. Adjust speed and
temperature
10. MAINTENANCE 12. SPECIFICATIONS
11. TROUBLE SHOOTING GUIDE
1. Do not apply any cleaning fluids to the rollers, certain fluids may cause damage.
2. Do not clean rollers with sharp objects, use adhesive remover to clean resin off the
rollers.
3. Use a damp cloth with only water to clean the body of the machine.
4.Store machine in a dry clean area.
Description RSH-380
Power supply AC 100, 200, 220
W2@6K?e?W.?g
?W.M?I46K?O.Y?g
?.Y?e?I4@0Yh
240V 50/60Hz 120V 60Hz
Power consumption 1500W
Max laminating width 380mm / 15"
Film thickness 25~250 mic / 1~10mil
Max laminating speed 5m/min / 16.4ft/min
Ready time 8min
Heating method Hot roller
Driving motor DC geared
Max Temperature control 150 OC / 302 OF
Speed control 9 settings
Transport type 4 Roller
Film core size 1", 2.25", 3"
Cross cutter Yes
Hot lamination Yes
Mounting thickness 6mm / 0.24"
Reverse Yes
Unit dimensions (w
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
d
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
h) 550
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
690
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
605(mm) / 21.5"
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
27"
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
24"
Unit weight 45kg / 99 Ibs
Carton dimensions (w
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
d
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
h) 800
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
750
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
650(mm) / 31.5"
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
29.5"
?/X?gW.h
?V/Xf?W.Yh
V/X?eW.Y?h
?V/X?W.Yhe
V/T.Y?he
?S@Uhf
W.R/X?he
?W.Y?V/Xhe
W.Y?eV/X?h
?W.Yf?V/Xh
?.Y?gV/h
25,5"
Carton weight 57kg / 126 Ibs
