RTA Products Techni Mobili RTA-7050 User manual

Thank you for purchasing our product.
MODEL RTA-7050
ASSEMBLY INSTRUCTIONS
REV.122020-0

• Please read carefully the assembly instructions
before the installation.
• Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.
P. 1
RTA-7050
P. 1

P. 2
RTA-7050
P. 2
1
x1
2
x1
3
x2
4
x1
Top panel for upper section
Middle panel for upper section
Short vertical
panel for upper
section
Long exterior
vertical panel for
upper section
MAIN PARTS LIST
5
x1
6
x1
7
x1
8
x1
Long interior
vertical panel for
upper section
Bottom panel for
upper section
Top panel for lower section
Bottom panel for lower section
9
x1
10
x1
Left panel for lower
section
Right panel for
lower section
11
x1
12
x1
Middle-left panel
for lower section
Middle-right
panel for lower
section
13
x1
14
x2
Back panel for
lower section
Drawer front
panel
15
x2
16
x2
Drawer left panel Drawer right
panel
17
x2
18
x2
Drawer back
panel
Drawer bottom
panel
19
x2
Sets
Sliders, SET of 4 pcs:
- 2 “flat” for inside the unit.
- 2 “L” shape for the drawers.

MAIN PARTS LAYOUT (FOR REFERENCE):
P. 3
RTA-7050
P. 3
LIST OF HARDWARE, SCREWS AND FITTINGS
PART
QTY ITEM
A26 M6x35
B34 ⌀8x30mm
(wooden dowels)
C16 ST7x58
D8ST3.5x40
PART
QTY ITEM
E16 ST3x14
F10 ⌀25 (felt)
G8⌀22 (laminate)
1
❶
❷
❸
❸
❹❺
❻
❼
❽
❾
⓬⓮
⓮

P. 4
RTA-7050
P. 4
☛
This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
assembly using this kind of hardware.
Cam Bolt Cam Lock
1. Screw the bolt into the
corresponding panel.
2. In the other panel, insert the cam
lock and align it so it can properly
receive the head of the bolt, then
join the panels. There might be a
very small gap between the panels
which is normal.
3. Turn the cam lock clockwise. This
will lock the parts together and will
close any gaps.
Alignment: Point towards
the panel with the bolt.

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do a quick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❸The replacement parts
service is limited to the
continental United States.If
you reside in Hawaii, Puerto
Rico, U.S. Dependencies or
other countries, please
contact the supplier from
where the unit was
purchased.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step. Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
P. 5
RTA-7050
P. 5

STEPS 1 THROUGH 11 IS FOR THE ASSEMBLY OF THE LOWER SECTION,
WHICH WILL ASSEMBLE UPSIDE-DOWN
P. 6
RTA-7050
P. 6
With the panels 9, 10, 11 and 12 oriented as shown, assemble the “Flat”
sliders 19 on the bottom of the panels using screws Eas shown. Please
note the correct holes to use on the sliders and make sure the wheels
face towards the front of the panels.
STEP 2
Hardware:
E
ST3x14
8
Pcs
Separate the sliders 19 according to their shape:
- The “L” sliders (for the drawers) will be used until step 10, please set
them aside.
- The "flat" sliders (for inside the unit) are the ones being used in the
next step.
STEP 1
(Top)
(Front) (Front)
(Top)
(Top)
(Top)
(Front) (Front)
Left sliders to panels 9 and 12: Right sliders to panels 10 and 11:
The groove on
panels 9 and 10
go at the back
of the panels.
Scan QR Code to
view this step

P. 7
RTA-7050
P. 7
On the top panel 7screw the bolts Ainto the outermost holes and insert
the wooden dowels Bin the innermost holes as shown.
STEP 3
Hardware:
A
M6x35
8
Pcs
B
Φ8x30
8
Pcs
With the panels 9, 10, 11 and 12 oriented upside-down, insert and
align the cam locks Ainto the panels, then slide down the panels over
the bolts and dowels of panel 7, and turn the cam locks to secure all
panels as shown and as explained in page 4.
STEP 4
Hardware:
A
Cam lock
8
Pcs
A
(Front)
B
Bolts: Outermost holes
Dowels: Innermost holes
Refer to page 4
(Front)
(Bottom)
STEP 5 Slide the back panel 13 through the groves of panels 7, 9and 10.
(Front)
The grooves on
panels 7, 9 and
10 go at the back
of the panels.

P. 8
RTA-7050
P. 8
First insert the dowels Bin the innermost holes on panels 9, 10, 11 and
12, then with the help of another person place the bottom panel 8and
assemble it to the panels using screws Cas shown.
STEP 6
Hardware:
B
Φ8x30
8
Pcs
C
ST7x58
8
Pcs
Peel off and adhere the felt covers Fon panel 8 as shown. Then with the
help of another person turn the unit it upright.
STEP 7
Hardware:
F
Φ25 (Felt)
6
Pcs
C
B
STEP 8
Hardware:
D
ST3.5x40
4
Pcs
Assemble the drawer back panel 17 to the side panels 15 and 16 using
screws D, then slide in the drawer bottom panel 18 through all the
grooves as shown.
(Bottom)
(Front)
11
12
The groove on
panel 8 go at the
back of the panel.
The grooves go on the
bottom and facing
inwards in all the panels

P. 9
RTA-7050
P. 9
Insert and align the cam locks Ain the side panels 15 and 16. Then
screw the bolts Ainto panel 14, and assemble this panel to panels 15
and 16 as shown and as explained on page 4.
Put the drawer upside-down, and assemble the “L” shaped sliders 19
using screws Eas shown, making sure the wheel goes towards the back
and the sliders don’t protrude at the bottom. Please note that protruding
sliders rise the drawer 1” and won’t fit in the unit.
STEP 10
Hardware:
E
ST3x14
4
Pcs
(NOT INCLUDED)
STEP 9
Hardware:
A
M6x35
4
Sets
(Back)
(Top)
Refer to page 4
REPEAT STEPS 8 THROUGH 10
FOR THE SECOND DRAWER
VERY IMPORTANT!
INCORRECT
CORRECT
(Back)
(Top)
(Front)
STEP 11 Insert the drawers into the unit. If they don’t seem to fit, review steps 2
and 10 for the correct assembly of the sliders.
Scan QR Code to
view this step

P. 1 0
RTA-7050
P. 1 0
STEPS 12 THROUGH 17 ARE FOR THE ASSEMBLY OF THE UPPER SECTION,
WHICH WILL ALSO ASSEMBLE UPSIDE-DOWN
1st: Insert the dowels Bin the innermost holes on panel 1on the center
and right side.
2nd: Insert the bolts Ain the outermost holes on panel 1.
3rd: Insert and align the cam locks Ain the panels 3.
4th: Assemble the panels 3 to the panel 1 as shown and as explained on
page 4.
Following the same procedures as in step 12, and as explained in page
4, assemble panel 5to panel 2with bolts/cam locks Aand dowels Bas
shown.
(Left side)
(Right side)
Refer to page 4
STEP 12
Hardware:
A
M6x35
4
Sets
B
Φ8x30
4
Pcs
Refer to page 4
(All panels are shown upside-down)
(Bottom side)
(Right side)
STEP 13
Hardware:
A
M6x35
2
Sets
B
Φ8x30
2
Pcs
The cam locks
must go facing
towards the inside

P. 11
RTA-7050
P. 11
1st: Insert the dowels Bin the innermost holes on panels 1 and 3.
2nd: Insert the bolts A in the outermost holes on panel 1.
3rd: Insert and align the cam locks A in panel 5.
4th: Assemble the panel 2 to the panels 3, and the panel 5 to the panel
1 as shown and as explained in page 4.
1st: Secure the panel 2 to the panels 3 with screws C.
2nd: Insert the dowels B in the innermost holes on panel 1.
3rd: Assemble the panel 4to panel 1with bolts/cam locks Aas shown
and as explained in page 4.
Refer to page 4
Make sure to
assemble panel ❹
with the cam locks
facing inwards
STEP 14
Hardware:
A
M6x35
2
Sets
B
Φ8x30
6
Pcs
STEP 15
Hardware:
A
M6x35
2
Sets
B
Φ8x30
2
Pcs
CST7x58
4
Pcs
Refer to page 4

P. 1 2
RTA-7050
P. 1 2
Insert the dowels B in the innermost holes on panels 4 and 5, then
assemble panel 6 using screws C.
Place the following adhesive stickers:
Felt Fon panel 6.
Laminate G for the cam lock holes on panels 3, 4 and 5.
STEP 17
Hardware:
F
Φ25 (felt)
4
Pcs
G
Φ22
(laminate)
8
Pcs
STEP 16
Hardware:
B
Φ8x30
4
Pcs
CST7x58
4
Pcs
(Felt)
(Laminate)

ALL DONE!
Give yourself a nice pat on the back. You did a
great job!
P. 1 3
RTA-7050
P. 1 3
You can place the upper section over the lower section according to your
preference. The below illustrations show some suggestions.
WARNING:
For safety, when setting the unit in expanded option, do not place the upper
section too close to the edge on the lower section.
CLOSED:
EXPANDED:

AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING
CARE AND MAINTENANCE WARNINGS:
•Do not exceed the indicated weight limits.
•When setting the unit in expanded option, do not place the upper section too close to the
edge on the lower section.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the top panel.
•Do not seat on the unit or stand on it to use it as a ladder.
•Do not allow small children to play over the unit or under the upper section (expanded
option), or reach inside the drawers or compartments without your supervision.
•Do not pull, push or drag the unit to move it for more than 1 feet. The unit must be lifted by
at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit or re-positioning the top section, remove your TV and make sure to
secure or remove any object that is heavy or might fall off.
•When lifting the unit, use both hands and bend your knees, not your backs.
•
When transporting the unit to places far away, protect and secure the unit to avoid damage
in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts
might be available to you at no charge. Please refer to the last pages on this manual.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes
liability for damages or consequences due to accidents, incorrect assembly, negligence,
improper use, modifications, or not heeding the above warnings.
WEIGHT LIMITS:
= 55 Lbs. (25 Kg) expanded
88 Lbs. (40 Kg) closed
= 44 Lbs. (20 Kg)
A
A
B
B= 88 Lbs. (40 Kg)
CC
C
D
C
CD
D= 11 Lbs. (5 Kg)
MAXIMUM RECOMMENDED
EXPANDED LENGTH:
82.5” (210 cm)
P. 1 4
RTA-7050
P. 1 4

TECHNI MOBILI WARRANTY
DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY
TV Stand/Entertainment Center: 2 YEAR WARRANTY
RTA Products, LLC warrants to the Original Purchaser who acquired a new product from
RTA Products or its authorized resellers that this product will be free from defects in its
workmanship and materials, under normal use and service conditions, as described
herein. "Defects" as used in this warranty, is defined as any imperfections that impair the
use of the furniture or product. RTA Products LLC will replace any defective part, at its
discretion, and without charge to the original purchaser other than the freight from the end
consumer to RTA Products.
Replacement parts can only be supplied if parts are available. Items out of production
may be unavailable. This warranty will be effective for the applicable time period
beginning the date of purchase on your original sales receipt. RTA product’s obligation
under this warranty is limited to repairing or replacing products or parts as provided
herein.This product has been designed for and is intended for office and home-office use
only.This warranty is Original Purchaser’s sole remedy for product defects, and this
warranty does not extend to any product, or damage to any product, caused by or
attributed to abuse or misuse, products used for commercial or rental purposes, use
modifications of, or attachments to the product, and products or parts not used,
maintained, or extended hereunder is in lieu of any and all other warranties, express or
implied, including without limitations any implied warranty or merchantability or of fitness
for a particular purpose. Please note, all desks made with PVC Laminate surface should
not be exposed to direct sunlight, as it may damage the material.Damage of this nature
is not covered under this warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential
damages.This warranty is limited to merchandise purchased in the Continental United
States.Some States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty
gives you specific legal rights.You may also have other rights that may vary from state to
state.
RTA Products will advise you of the procedure to follow in making warranty claims. The
following are the procedures for warranty claims:
a. Call us Monday – Friday, from 9am-5pm (Eastern Time) at [phone] to explain
the defect and give your name, address and phone number. Please have ready the
model number of our product, date and place of purchase. You can also write to us by
e-mail to [email protected] and include the same information.
b. If we determine that replacement will remedy the situation, and in order to determine
the extent or the cause of the defect, purchaser will need to send the part in question
at purchaser’s expense. Once we receive the part, we will examine it and determine
whether the claim is valid (or not), and then proceed to send the replacement. We will
ship the replacement at our expense.
P. 1 5
RTA-7050
P. 1 5

FOR SEVERAL HELP OPTIONS
INCLUDING REPLACEMENT PARTS ORDERS
_________________________________________________________________
VISIT: WWW.TECHNIMOBILI.COM
CLICK ON SUPPORT TAB
Scan QR Code to order replacement parts
OR EMAIL US: [e-mail]
P. 1 6
RTA-7050
P. 1 6
