RTA Products Techni Mobili RTA-S18 User manual

Thank you for purchasing our product.
MODEL RTA-S18
ASSEMBLY INSTRUCTIONS
REV.LS-6541-0422-1

•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.
P. 1 RTA-S18 P. 1

P. 2 RTA-S18 P. 2
1
x1 2
x1 3
x1 4
x1
Left panel Right panel Back panel Top panel
MAIN PARTS LIST
5
x1 6L
x2 7
x1 8
x1
Bottom panel Locking casters Middle front panel Small drawer front
panel
9
x1 10
x1
Small drawer left
panel
Small drawer right
panel
11
x1 12
x1
Small drawer
bottom panel
Small drawer back
panel
13
x1
set
Small drawer metal sliders,
SET of 4 pcs
14
x6
15
x1
Drawer connector
File drawer front
panel
16
x1
17
x1
File drawer left
panel
File drawer right
panel
18
x1 20
x1
File drawer back
panel
File drawer wheel
6N
x1 Non-Locking
casters
“Flat”: 2 pcs, go
inside the cabinet
“L shaped”: 2 pcs,
go on the drawers
21
x1 L bracket and nut
19
x2 File drawer hanger
15.75"x13"

MAIN PARTS LAYOUT (FOR
REFERENCE):
P. 3 RTA-S18 P. 3
22
x2 File drawer metal
slider
MAIN PARTS LIST (cont.)
23
X1
Set
File drawer tube,
SET of 2 pcs
24A
X1
Set
Metal fitting A,
SET of 2 pcs
24B
X1
Set
Metal fitting B,
SET of 2 pcs
24C
X1
Set
Metal fitting C,
SET of 2 pcs
24D
X1
Set
Lock and keys,
SET
24E
X1 Metal locking bar
24F
X1
Set
Tiny screws, for
24C, SET of 2 pcs
25
x1 File drawer bottom
panel
15
6L
1
20
8
6N
9
10
15
16
17
12
87
4
18
LIST OF HARDWARE, SCREWS AND FITTINGS
PART
QTY ITEM
A28 M3x12
B24 M3x15
C7M6x12
D18 M4x14
E8M4x35
F8M6x40 Bolt
G6M6x25 Bolt
1Screwdriver
1Hex wrench
(spanner)
24G
X1 Ring for the lock
15.75"x13"

P. 4 RTA-S18 P. 4
☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
assembly using this kind of hardware.
Cam Bolt
Cam Lock
1. Screw the bolt into the corresponding hole
on panel “A”.
3. Insert the cam lock on panel “B” making
sure it goes aligned to receive the bolt’s head.
4. Turn the cam lock clockwise. This will lock the
parts together and will close any gaps.
Alignment: The cross points
towards the panel “A” with the bolt.
2. Join panel “B” to panel “A”. If panel “B” comes
with the cam lock pre-installed, make sure it is
aligned to receive the bolt’s head (refer to point
3). There might be a very small gap between the
panels which is normal.
Panel “B”
Panel “B”
Panel “B”
Panel “B”

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do aquick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step.Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
P. 5 RTA-S18 P. 5
❸The replacement parts
service is limited to the
48 contiguous United States.
If you reside in Alaska,
Hawaii, Puerto Rico,
U.S. territories or other
countries, please contact the
supplier from where the unit
was purchased.

ASSEMBLY STEPS
P. 6 RTA-S18 P. 6
(Top)
•Slide the metal fittings through the metal bar 24E in the following
exact order:
-One of 24A
-Both 24C
-The second 24A.
•Align the pieces 24C in between the marks on the bar 24E, and insert
the tiny screws 24F into 23C and tighten to leave 23C stationary
within those marks.
STEP 1
Hardware:
FIRST:
THEN:
(Bottom)
24A
24C
24E
Assemble the locking system 24 to the right panel 2 by attaching the
fittings 24A with screws B as shown.
STEP 2
Hardware:
BM3x15
8
Pcs
(Top)
(Bottom)
(Front)
(Back) 2
24A24C
24A 24A
24F24F
24E
(Top)
(Bottom)
24A
B

P. 7 RTA-S18 P. 7
Grab all the sets of drawer sliders 13 (total 4pcs) and separate them into
2 groups according to their shape:
-The “Flat” ones will be used on the next step.
-The “L Shaped” will be used until step 19, set them aside.
STEP 3
(“Flat” Right)
(Front)
(Front)
(Front)
(Front)
The “Flat” ones will
be used on step 5.
The “L-Shaped” will
be used on step 19,
set them aside.
13
13
13
13
(“Flat” Left)
(“L” Right)
(“L” Left)
Assemble the “Flat” sliders 13 to the top set of holes on the side panels
1 and 2 with screws B. Please note:
•The wheel is at the front, and faces down with 2 holes above it.
•The sliders attach at the front on the 2nd hole.
•The grooves on the panels are located at the back.
STEP 4
Hardware:
BM3x15
4
Pcs
1
13
2
(Top)
2nd hole from front
(Front)
Wheel at front
below 2 holes
2nd hole from front
Wheel at front
below 2 holes
"Flat"
left
"Flat"
right
13
(Front)
(Top)

P. 8 RTA-S18 P. 8
•Grab the sliders 22 and extend them completely towards your RIGHT.
•In between the smaller piece and the middle piece there is a black
plastic lever sticking out, with the tip of your thumb press the lever and
at the same time pull out the smaller piece away from the rest.
•The slider will now be split into piece 22A (big) and 22B (small).
•The big slider 22A will be used on the next step, while the small slider
22B will be used until step 28, so set it aside.
(Front)
STEP 5
22
22
22A 22B
The “Big” pieces 22A will
be used on next step.
The “Small” pieces 22B will be
used on step 28, set them aside.
•
•
Attach the big sliders 22A to the back hole on panels 1 and 2 with
screws B.
Open the sliders slowly until you see the middle hole on the panels
through the opening and secure the slider with screws B.
Open the slider completely and also slide the piece with the bearings
towards the front, and secure the slider to the panels’ front hole with
screws B.
(Front)
(Front)
STEP 6
Hardware:
BM3x15
6
Pcs
2
1
22A
The back and middle holes:
1. Extend 2. Push and pull out
(Front)
(Front)
(Front)
The front hole:
1
2
(Front)
The middle hole will
be seen though the
openings
The front hole will
be seen though the
openings
•
3. Separate

P. 9 RTA-S18 P. 9
(Front)
(Back)
STEP 8
Hardware:
GM6x25
Bolt
1
Pc
5
3
Cam lock
alignment
on 3
Attach the casters 6 to the bottom surface of panel 5 with screws D as
indicated:
•The locking casters 6L go at the FRONT of the panel.
•The non-locking casters 6N go at the BACK.
(Front)
(Back)
STEP 7
Hardware:
DM4x14
16
Pcs
5
5
5
TOP surface:
BOTTOM surface:
LOCKING
go at the front
NON-LOCKING
go at the back
6N
6L
•Attach a bolt Gto the top surface of panel 5.
•Align the cam lock on panel 3to make sure it is able to receive the
bolt’s head.
•Join panel 3to panel 5and turn the cam lock to lock the pieces as
explained in page 5.
5
3
5
THEN THEN

P. 1 0 RTA-S18 P. 1 0
•Attach bolts Fto the bottom holes of panels 1and 2.
•Attach bolts Gto the back holes of panels 1and 2.
(Top)
(Front)
(Front)
STEP 9
Hardware:
FM6x40
4
Pcs
GM6x25
4
Pcs
STEP 10
2
1
3
2
Cam locks
alignment
on 3 and 5
•With the help of another person, assemble panel 2to panels 3and 5
as explained in page 5.
•Attach panel 7to panel 2.
G
F
7
5
MAKE SURE TO USE THE CORRECT SIZES ON THE CORRECT HOLES
For the back holes
For the bottom holes
(Front)
(Top)
(Front)

P. 11 RTA-S18 P. 11
•Attach bolts Fto the left and right holes of panel 4.
•Attach one bolt Gto the back hole of panel 4.
•Assemble panel 4to panels 1, 2and 3as explained in page 5.
(Top)
(Front)
(Front)
(Back)
STEP 11
Hardware:
3
1
3
4
Cam locks
alignment
on 1, 2, 3
With the help of another person, assemble panel 1to panels 3, 5and 7
as shown and as explained in page 5.
Cam locks
alignment
on 3 and 5
7
5
STEP 12
Hardware:
FM6x40
4
Pcs
GM6x25
1
Pcs
THEN
2
1
G
F
4
Only for the back hole

P. 1 2 RTA-S18 P. 1 2
Attach the drawer connectors 14 to the small drawer side panels 9and
10 with screws A.
Assemble the small drawer back panel 12 to the side panels 9and 10
with screws E.
(Bottom)
(Front)
(Back)
STEP 13
Hardware:
AM3x12
4
Pcs
STEP 14
Hardware:
EM4x35
4
Pcs
9
10
12
11
14
(Top)
(Bottom)
9
10 12
STEP 15 Slide in the small drawer bottom panel 11 through the grooves of panels
9and 10, and into the groove of back panel 12.
9
10

P. 1 3 RTA-S18 P. 1 3
Assemble the small drawer front panel 8to the drawer connectors 14
with screws C.
Attach the metal fitting 24B to the drawer right panel 10 with screws A.
NOTE: The “U” on the fitting must face DOWN.
(Top)
(Bottom)
Rod faces down and rotates counter-clockwise
STEP 16
Hardware:
CM6x12
2
Pcs
STEP 17
Hardware:
AM3x12
2
Pcs
14
8
Fitting must face down
10
24B
•Assemble the lock 24D to the interior face of the front panel 8with
screws B, making sure the keys will make the rod rotate from the
bottom to the top in a counter-clock motion.
•Attach the ring 24G to the lock at the front.
NOTE: If the lock is installed turning the wrong way, the rod might
get stuck with the drawer locked, unable to open it.
STEP 18
Hardware:
BM3x15
2
Pcs
24G
8
24D

P. 1 4 RTA-S18 P. 1 4
•Assemble the L bracket 21 to the bottom holes of panel 15 with
screws C and D.
•Assemble the wheel 20 to the bracket 21 with the nut 21.
(Top)
(Bottom)
(Bottom)
STEP 21
Hardware:
CM6x12
1
Pc
DM4x14
2
Pcs D
C
Flip the drawer upside-down and assemble the “L” sliders 13 with screws
B, making sure the wheel goes towards the back, and that they don’t
protrude, otherwise, the drawer raises 1” and won’t fit in the cabinet.
STEP 19
Hardware:
BM3x15
4
Pcs When finished, the sliders
should look like this from the
back of the drawer:
The assembly below is
incorrect, it raises 1” and the
drawer won’t fit:
(Top)
(Bottom)
(Back)
Attach the file hanger 19 to the top holes of panels 15 and 18 with
screws A.
STEP 20
Hardware:
AM3x12
6
Pcs
15
15
21 20
13 "L"
left
13 "L"
Right
15
19
18
19
(Top)
(Bottom)
THEN 21
(Top)

P. 1 5 RTA-S18 P. 1 5
Attach the drawer connectors 14 to the file drawer side panels 16 and 17
with screws A.
Assemble the file drawer back panel 18 to the side panels 16 and 17
with screws E.
(Front)
(Back)
STEP 22
Hardware:
AM3x12
8
Pcs
STEP 23
Hardware:
EM4x35
4
Pcs
16
14
17
(Front)
(Back)
16
18
17
14
15
Slide the bottom panel 25 through the grooves of panels 16 and 17 and
into the groove of panel 18.
STEP 24
STEP 25
Hardware:
CM6x12
4
Pcs
16
18
17
25
Assemble the file drawer front panel 15 to the drawer connectors 14 with
screws C.

P. 1 6 RTA-S18 P. 1 6
Attach the metal fitting 24B to the drawer right panel 17 with screws A.
NOTE: The “U” on the fitting must face DOWN.
Insert the file tubes 23 through the holes on the back panel 18 and
screw them into the front panel 9, but DO NOT OVERTIGHTEN to avoid
accidental damage humps or perforation. Please note that such kind of
damage is not covered by the product’s warranty.
(Front) (Back)
STEP 26
Hardware:
AM3x12
2
Pcs
STEP 27
17
24B
17
DO NOT OVERTIGHTEN
to avoid accidental humps
or perforation.
Assemble the small sliders 22B to the file drawer side panels 16 and 17
with screws A.
STEP 28
Hardware:
AM3x12
6
Pcs
18
15
23
22B
22B
Fitting must face down
16
(Front)
(Back)

P. 1 7 RTA-S18 P. 1 7
•Pull out the bottom sliders 22A and slide the piece with the bearings
all the way towards the front.
•With the help of another person, install the bottom file drawer into the
cabinet by engaging the drawer sliders 22B through the black plastic
guide and the bearings of 22A, and pushing slowly into the cabinet.
•Insert the top drawer into the cabinet at an angle with its front facing
down, making sure the wheels from the drawer slide in the middle of
the sliders inside the cabinet. If the top drawer does not enter, review
the assembly done in steps 4and 19.
•Test the lock on the top drawer: make sure the rod on the lock is
facing DOWN and the bottom drawer is completely closed; the key
must turn COUNTER-CLOCKWISE. If the key turns clockwise, or the
drawers don’t lock, review the assembly done in steps 1, 2, 17, 18
and 26 .
The piece with bearings must be slid
towards the front
(Front)
STEP 29
The slider 22B must go
through the plastic guide and
engage into the bearings.
Push in
slowly
The drawer slider
must slide in the
middle, not on top The rod must face
DOWN and the
key must turn
COUNTER-
CLOCKWISE.
22A
22B
22A
(Front)

ALL DONE!
Give yourself a nice pat on the back. You did a
great job!
P. 1 8 RTA-S18 P. 1 8

WEIGHT LIMITS
P. 1 9 RTA-S18 P. 1 9
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as the
back panel of the drawers.
•Do not sit on the unit or lean against it.
•Do not allow small children to climb over the unit.
•Do not allow small children to reach inside the drawers without your supervision.
•Before moving the unit, make sure the front casters are unlocked.
•Make sure to secure or remove any object that might fall off the top while the unit is in
movement.
•When transporting the unit to places far away, protect and secure the unit to avoid damage
in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts
might be available to you at no charge. Please refer to the last pages on this manual.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes
liability for damages or consequences due to accidents, incorrect assembly, negligence,
improper use, modifications, or not heeding the above warnings.
CARE, MAINTENANCE AND SAFETY WARNINGS:
15 Lbs.
(6.8 Kg)
15 Lbs.
(6.8 Kg)
35 Lbs.
(16 Kg)
