Ruijie Reyee RG-NBR-E Series User manual

Ruijie Reyee RG-NBR-E
Series Routers
Cookbook
Document Version: V1.0
Date: November 1, 2022
Copyright © 2022 Ruijie Networks

Copyright
Copyright © 2022 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translationor commercial use of this document
or any portion of this document, in any formor by any means, without the prior written consent ofRuijie Networks
is prohibited.
Trademarks including , , are owned
by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by theirrespective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and terms. Some or all of
the products, services or features described in this document may not be within the scope of your purchase or
use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement
or guarantee for the content of this document.
Due to product version upgrades or other reasons, the content of this document will be updated from time to
time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder
any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and service engineers
Network administrators
Technical Support
Official website of Ruijie Reyee: https://www.ruijienetworks.com/products/reyee
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [email protected]
Conventions
1. GUI Symbols
Interface
symbol
Description
Example
Boldface
1. Button names
2. Window names, tab name, field name and
menu items
3. Link
1. Click OK.
2. Select Config Wizard.
3. Click the Download File link.
>
Multi-level menus items
Select System >Time.
2. Signs
The signs used in this document are described as follows:
Warning
An alert that calls attention to important rules and information that if not understood or followed can result in
data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in function
failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will not lead to
serious consequences.

II
Specification
An alert that contains a description of product or version support.
3. Note
This manual is used to guide users to understand the product, install the product, andcomplete the configuration.
The example of the port type may be different from the actual situation. Proceed with the configuration
according to the port type supported by the product.
The example of display information may contain the content of other product series (such as model and
description). Refer to the actual display information.
The router and router product icons involved in this manual represent common routers and Layer 3 switches
running routing protocols.

i
Contents
Preface.................................................................................................................................................. I
1 Overview ........................................................................................................................................... 1
1.1 Introduction................................................................................................................................1
1.2 Specifications of Ruijie RG-NBR-E Series Routers ..................................................................1
1.2.1 Ruijie RG-NBR6120-E Router.......................................................................................1
1.2.2 Ruijie RG-NBR6205-E Router.......................................................................................4
1.2.3 Ruijie RG-NBR6210-E Router.......................................................................................7
1.2.4 Ruijie RG-NBR6215-E Router.....................................................................................10
1.3 Specifications of the Hard Disk Module...................................................................................14
2 Getting Started................................................................................................................................ 15
2.1 Preparing for Installation..........................................................................................................15
2.1.1 Safety Precautions.......................................................................................................15
2.1.2 Requirements on the Installation Environment............................................................15
2.1.3 Installation Tools...........................................................................................................18
2.2 Installing a Router....................................................................................................................18
2.2.1 Installation Procedure..................................................................................................18
2.2.2 (Optional) Installing the Hard Disk for the RG-NBR6200-E Series Routers ...............18
2.2.3 Installing the Device in a Specific Location.................................................................19
2.2.4 Performing EMC Grounding ........................................................................................20
2.2.5 Installing the Power Cord.............................................................................................20
2.2.6 Checking After the Installation.....................................................................................21
3 Configuration................................................................................................................................... 21
3.1 WAN Load Balance .................................................................................................................21

ii
3.2 DHCP Configuration ................................................................................................................25
3.2.1 Configuring DHCP Through the Web Page.................................................................25
3.2.2 Configuring DHCP in CLI Mode...................................................................................27
3.3 DNS Configuration...................................................................................................................28
3.3.1 Working Principle.........................................................................................................28
3.3.2 Effect............................................................................................................................28
3.3.3 Procedure.....................................................................................................................28
3.4 Behavior Policies .....................................................................................................................30
3.4.1 Basic Settings ..............................................................................................................30
3.4.2 Advanced Settings.......................................................................................................39
3.5 Rate Limit.................................................................................................................................52
3.6 Port Mapping............................................................................................................................54
3.7 DMZ Host Mapping..................................................................................................................57
3.8 IPsec VPN................................................................................................................................58
3.8.1A Branch RouterAccesses the HQ Router Using a Static IPAddress in Dialup Mode58
3.8.2 The Branch RouterAccesses the HQ Router Using a Dynamic IPAddress in Dialup
Mode...............................................................................................................................66
3.8.3 The Branch RouterAccesses the HQ Router on the LAN in Dialup Mode.................74
3.9 Integrating the NBR Device with Ruijie Cloud.........................................................................81
3.9.1 Synchronizing Voucher/Account Login to a Router.....................................................82
3.9.2 Synchronizing Voucher/Account Login to a Router.....................................................86
3.9.3 Synchronizing Voucher/Account Login to the NBR Device.........................................90
3.10 Local Web Authentication......................................................................................................91
3.11 AD Domain Integration ..........................................................................................................95

iii
3.12 Firewall.................................................................................................................................100
3.12.1 Attack Defense Configuration..................................................................................101
3.12.2 Security Zone Configuration....................................................................................108
3.12.3 Defense Zone Monitoring ........................................................................................121
3.12.4 IP Resource Configuration.......................................................................................123
3.12.5 Service Resource Configuration..............................................................................126
4 Upgrade and Maintenance............................................................................................................ 129
4.1 Logging In ..............................................................................................................................129
4.1.1 Logging In Through the Web Management System..................................................129
4.1.2 Logging In Through the Console Port........................................................................133
4.1.3 Logging In Through Telnet.........................................................................................136
4.2 Configuring a Password.........................................................................................................139
4.3 Upgrading ..............................................................................................................................141
4.3.1 Upgrading through Web Management System .........................................................141
4.4 Backing Up the Configuration and Resetting the NBR Device .............................................143
4.4.1 Exporting Configuration Files.....................................................................................143
4.4.2 Importing Configuration Files.....................................................................................144
4.5 Restoring Factory Settings....................................................................................................146
4.5.1 One-Click Reset Through Web..................................................................................146
4.5.2 One-Click Reset Through Reset Button....................................................................147

Cookbook Overview
1
1 Overview
1.1 Introduction
RG-NBR-E series enterprise-class routers are multi-service integrated routers tailored by Ruijie Reyee for
integrated scenarios such as office, hotel, restaurant, entertainment, and scenic spot. RG-NBR-E series
enterprise-class routers support many functions such as service acceleration channel, precise flow control,
network access behavior management, VPN total-division interconnection, and intelligent routing, and support
connection to Ruijie cloud platform (MACC free cloud platform) for remote cloud O&M and central management,
which can well meet the integrated network needs of scenarios such as office, hotel, restaurant, entertainment,
and scenic spot.
RG-NBR-E series enterprise-class routers support the web management GUI. The web management system
can be used to configure and manage the common functions of the devices.
1.2 Specifications of Ruijie RG-NBR-E Series Routers
1.2.1 Ruijie RG-NBR6120-E Router
1. Appearance of Ruijie RG-NBR6120-E Router
Figure 1-1 Front Panel of Ruijie RG-NBR6120-E Router
Table 1-1 Description of the Front Panel of Ruijie RG-NBR6210-E Router
No.
Indicator/Port
Description
1
SYS
System indicator:
If it blinks green, the system is being initialized.
If it is steady green, system initialization is completed.
2
Console
Console port. It connects to the console cable. After connecting to
the serial port of the management PC, the device can be managed
through the console port.
3
Reset
Restarts the device. Press and hold this button for more than 5s to
reset the device to factory defaults.
8
21 3
7
4 5
6

Cookbook Overview
2
No.
Indicator/Port
Description
4
LAN2
If it is steady orange, the port is connected at a rate of 1000
Mbit/s.
If it is off, the port is connected at a rate of 10 Mbit/s or 100
Mbit/s.
5
WAN2
If it is steady green, the port is connected.
If it blinks green, the port is receiving or transmitting traffic.
6
10/100/1000M self-
adaptive Ethernet ports
Five 10/100/1000M self-adaptive fast Ethernet ports: support
automatic recognition of network cables and cross-over cables.
LAN0 (GE 0/0) is a LAN port and WAN0 (GE 0/4) is a WAN
port, and they do not support the WAN/LAN switchover.
LAN3/WAN1 (GE 0/3) is a WAN port by default and supports
the WAN/LAN switchover.
LAN1/WAN3 (GE 0/1) and LAN2/WAN2 (GE 0/2) are LAN ports
by default and support the WAN/LAN switchover.
7
USB
USB2.0 port that connects to USB-compliant peripheral devices,
such as USB flash drives.
8
PWR
Power supply indicator:
If it is steady green, the device is receiving power properly.
If it is off, the power module is faulty or not powered on.
Figure 1-2 Back Panel of Ruijie RG-NBR6210-E Router
Table 1-2 Description of the Back Panel of Ruijie RG-NBR6210-E Router
No.
Button/Port
Description
1
Grounding screw
Connects to the grounding system of the installation site through the
grounding wire to provide grounding protection.
2
Power port
Connects to an AC power cord.
2
1

Cookbook Overview
3
2. Specifications of Ruijie RG-NBR6210-E Router
Table 1-3 Specifications of Ruijie RG-NBR6210-E Router
Item
Description
Model
RG-NBR6120-E
Storage
DDR3 SDRAM: 512 MB
eMMC: 4 GB
BOOTROM: 2 MB
I/O setup
Five 10/100/1000M self-adaptive fast Ethernet ports: support automatic recognition of
network cables and crossover cables.
WAN ports:
Two WAN ports by default. WAN0 (GE 0/4) port is a WAN port and does not support
the WAN/LAN switchover. LAN3/WAN1 (GE 0/3) port is a WAN port by default and
supports the WAN/LAN switchover.
LAN ports:
Three LAN ports by default. LAN0 (GE 0/0) port is a LAN port and does not support
the WAN/LAN switchover. LAN1/WAN3 (GE 0/1) and LAN2/WAN2 (GE 0/2) ports are
LAN ports by default and support the WAN/LAN switchover.
One console port
One USB port
Interface standard
Ethernet: 10Base-T/100Base-TX/1000Base-TX
Console port: RS-232
Dimension (W x H x
D)
440 mm x 43.6 mm x 200 mm (excluding the foot pad)
Voltage
100-240 V, 50/60 Hz
Power consumption
Less than 20 W
Working
environment
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Note
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.

Cookbook Overview
4
1.2.2 Ruijie RG-NBR6205-E Router
1. Appearance of Ruijie RG-NBR6205-E Router
Figure 1-3 Front Panel of Ruijie RG-NBR6205-E Router
Table 1-4 Description of the Front Panel of Ruijie RG-NBR6205-E Router
No.
Indicator/Port
Description
1
SATA
SATA hard disk indicator:
If it is steady green, the SATA hard disk is in place.
If it blinks green, the SATA hard disk is reading or writing data.
2
PWR
Power indicator:
If it is steady green, the router is receiving power properly.
If it is off, the power module is faulty or not powered on.
3
Console
Console port. It connects to the console cable. After connecting to the serial
port of the management PC, the device can be managed through the console
port.
4
USB
Two USB ports
They are USB2.0 ports that connect to USB-compliant peripheral devices,
such as USB flash drives.
5
LAN1
If it is steady orange, the port is connected at a rate of 1000 Mbit/s.
If it is off, the port is connected at are rate of 10 Mbit/s or 100 Mbit/s.
6
WAN6
If it is steady green, the port is connected at a rate of 10 Mbit/s, 100
Mbit/s or 1000 Mbit/s.
If it blinks green, the port is receiving or transmitting traffic.
7
8F
If it is steady green, the port is connected.
If it blinks green, the port is receiving or transmitting traffic.
8
GE fiber ports
Two SFP ports (8F, 9F):
WAN ports by default that support the WAN/LAN switchover.
Support 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-LX20/LH40-BIDI
SPF modules.
1 2
11 10
3 4 56 7
89

Cookbook Overview
5
No.
Indicator/Port
Description
9
GE copper ports
Eight 10/100/1000M self-adaptive fast Ethernet ports (copper ports 0-7) that
support automatic recognition of network cables and crossover cables:
LAN0 (GE 0/0) port is a LAN port and WAN0 (GE 0/7) port is a WAN
port, and they do not support the WAN/LAN switchover.
LAN6/WAN1 (GE 0/6) is WAN port by default and supports the
WAN/LAN switchover.
LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2), LAN3/WAN4 (GE 0/3),
LAN4/WAN3 (GE 0/4), LAN5/WAN2 (GE 0/5) are LAN ports by default
and support the WAN/LAN switchover.
In bridge mode, LAN0 (GE 0/0) port is also the MGMT port.
10
Reset
Restarts the router. Press and hold this button for more than 5 s to reset the
router to factory defaults.
11
SYS
System indicator:
If it blinks green, the system is being initialized.
If it is steady green, system initialization is completed.
If it is steady red, the system is in abnormal state.
Figure 1-4 Back Panel of Ruijie RG-NBR6205-E Router
Table 1-5 Description of the Back Panel of Ruijie RG-NBR6205-E Router
No.
Indicator/Port
Description
1
Retainer holder
Holds the power cord retainer to secure the power cord.
2
Power port
Connects to an AC power cord.
3
Power switch
Controls power supply.
4
Grounding screw
Connects to the grounding system of the installation site through the
grounding wire to provide grounding protection.
5
Hard disk expansion
card slot
Fits the hard disk module. The supported hard disk module model is
RG-NBR-HDD-1T.
2 3
5 4
1

Cookbook Overview
6
2. Specifications of Ruijie RG-NBR6205-E Router
Table 1-6 Specifications of Ruijie RG-NBR6205-E Router
Item
Description
Model
RG-NBR6205-E
Storage
DDR4 SDRAM: 2 GB
BOOTROM: 8 MB
eMMC: 8 GB
SATA: 1 TB (optional)
I/O setup
Eight 10/100/1000M self-adaptive fast Ethernet ports: support automatic
recognition of network cables and cross-over cables.
○By default, LAN0 (GE 0/0), LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2),
LAN3/WAN4 (GE 0/3), LAN4/WAN3 (GE 0/4) and LAN5/WAN2 (GE 0/5)
are LAN ports, while WAN0 and LAN6/WAN1 (GE 0/6) are WAN ports.
○LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2), LAN3/WAN4 (GE 0/3),
LAN4/WAN3 (GE 0/4), LAN5/WAN2 (GE 0/5) and LAN6/WAN1 (GE 0/6)
support the WAN/LAN switchover.
Two SFP ports:
○Support 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-LX20/LH40-BIDI
SPF modules.
○By default, the SFP ports are WAN ports, and support the WAN/LAN
switchover.
One management port (in bridge mode)
One console port
Two USB ports
Hardware disk module
One hardware disk module (optional)
Hot swapping
Not supported
Interface standard
Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX,
10GBASE-SR/LR/ZR
Console port: RS-232
Dimension (W x H x D)
440 mm x 43.6 mm x 200 mm (excluding the foot pad)
Voltage
100-240 V; 50/60 Hz
Power
Less than 25 W
Working environment
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Note
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.

Cookbook Overview
7
Caution
Avoid vibration and collision during device moving and usage.
To power off the device with the hard disk module installed, turn off the power button. Do not remove the
power cord until the PWR LED turns off; otherwise, the hardware disk will be damaged.
1.2.3 Ruijie RG-NBR6210-E Router
1. Appearance of Ruijie RG-NBR6210-E Router
Figure 1-5 Front Panel of Ruijie RG-NBR6210-E Router
Table 1-7 Description of the Front Panel of Ruijie RG-NBR6210-E Router
No.
Indicator/Port
Description
1
SATA
SATA hard disk indicator:
If it is steady green, the SATA hard disk is in place.
If it blinks green, the SATA hard disk is reading or writing data.
2
PWR
Power indicator:
If it is steady green, the device is receiving power properly.
If it is off, the power module is faulty or not powered on.
3
Console
Console port. It connects to the console cable. After connecting to
the serial port of the management PC, the device can be managed
through the console port.
4
USB
2 USB ports
They are USB2.0 ports that connect to USB-compliant peripheral
devices, such as USB flash drives.
5
LAN1
If it is steady orange, the port is connected at a rate of 1000
Mbit/s.
If it is off, the port is connected at a rate of 10 Mbit/s or 100
Mbit/s.
6
WAN6
If it is steady green, the port is connected at a rate of 10 Mbit/s,
100 Mbit/s, or 1000 Mbit/s.
If it blinks green, the port is receiving or transmitting traffic.
7
8F
If it is steady green, the port is connected.
If it blinks green, the port is receiving or transmitting traffic.
1 2
11 10
3 4 567
89

Cookbook Overview
8
No.
Indicator/Port
Description
8
GE fiber ports
Two SFP ports (8F, 9F):
WAN ports by default and support WAN/LAN switchover.
Support 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-
LX20/LH40-BIDI SPF modules.
9
GE copper ports
Eight 10/100/1000M self-adaptive fast Ethernet ports (0~7 copper
ports):
10/100/1000M self-adaptive and support automatic recognition
of network cables and cross-over cables.
LAN0 (GE 0/0) is a LAN port and WAN0 (GE 0/7) is a WAN
port. Both do not support WAN/LAN switchover.
By default, LAN6/WAN1 (GE 0/6) is a WAN port and supports
WAN/LAN switchover.
By default, LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2),
LAN3/WAN4 (GE 0/3), LAN4/WAN3 (GE 0/4) and LAN5/WAN2
(GE 0/5) are LAN ports and support WAN/LAN switchover.
In bridge mode, LAN0 (GE 0/0) is also the MGMT port.
10
Reset
Restarts the router. Press and hold this button for more than 5 s to
reset the router to factory defaults.
11
SYS
System indicator:
If it blinks green, the system is being initialized.
If it is steady green, system initialization is completed.
If it is steady red, the system is in abnormal state.
Figure 1-6 Back Panel of Ruijie RG-NBR6210-E Router
Table 1-8 Description of the Back Panel of Ruijie RG-NBR6210-E Router
No.
Indicator/Port
Description
1
Retainer holder
Holds the power cord retainer to secure the power cord.
2
Power port
Connects to an AC power cord.
3
Power switch
Controls power supply.
4
Grounding screw
Connects to the grounding system of the installation site through the
grounding wire to provide grounding protection.
2 3
5 4
1

Cookbook Overview
9
No.
Indicator/Port
Description
5
Hard disk expansion
card slot
Fits the hard disk module. The supported hard disk module model is
RG-NBR-HDD-1T.
2. Specifications of Ruijie RG-NBR6210-E Router
Table 1-9 Specifications of Ruijie RG-NBR6210-E Router
Item
Description
Model
RG-NBR6210-E
Storage
DDR4 SDRAM: 2 GB
BOOTROM: 8 MB
eMMC: 8 GB
SATA: 1 TB (optional)
I/O setup
Eight 10/100/1000M self-adaptive fast Ethernet ports: support automatic
recognition of network cables and cross-over cables.
○By default, LAN0 (GE 0/0), LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2),
LAN3/WAN4 (GE 0/3), LAN4/WAN3 (GE 0/4) and LAN5/WAN2 (GE 0/5)
are LAN ports, while WAN0 and LAN6/WAN1 (GE 0/6) are WAN ports.
○LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2), LAN3/WAN4 (GE 0/3),
LAN4/WAN3 (GE 0/4), LAN5/WAN2 (GE 0/5) and LAN6/WAN1 (GE 0/6)
support the WAN/LAN switchover.
Two SFP ports:
○Support 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-LX20/LH40-BIDI
SPF modules.
○By default, these two SFP ports are WAN ports, and support the WAN/LAN
switchover.
One management port (in bridge mode)
One console port
Two USB ports
Hardware disk module
One hardware disk module (optional)
Hot swapping
Not supported
Interface standard
Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX,
10GBASE-SR/LR/ZR
Console port: RS-232
Dimension (W x H x D)
440 mm x 43.6 mm x 200 mm (excluding the foot pad)
Voltage
100-240 V; 50/60 Hz
Power
Less than 25 W

Cookbook Overview
10
Item
Description
Working environment
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Note
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.
Caution
Avoid vibration and collision during device moving and usage when the device has the hard disk module
installed.
To power off the device equipped with the hard disk module, turn off the power button. Do not remove the
power cord until the PWR LED turns off; otherwise, the hardware disk will be damaged.
1.2.4 Ruijie RG-NBR6215-E Router
1. Appearance of Ruijie RG-NBR6215-E Router
Figure 1-7 Front Panel of Ruijie RG-NBR6215-E Router
Table 1-10 Description of the Front Panel of Ruijie RG-NBR6215-E Router
No.
Indicator/Port
Description
1
SATA
SATA hard disk indicator:
If it is steady green, the SATA hard disk is in place.
If it blinks green, the SATA hard disk is reading or writing data.
2
PWR
Power indicator:
If it is steady green, the device is receiving power properly.
If it is off, the power module is faulty or not powered on.
3
Console
Console port. It connects to the console cable. After connecting to the serial
port of the management PC, the device can be managed through the
console port.
1 2
12 11
3456 7
910 8

Cookbook Overview
11
No.
Indicator/Port
Description
4
USB
Two USB ports
They are USB2.0 ports that connect to USB-compliant peripheral devices,
such as USB flash drives.
5
LAN1
If it is steady orange, the port is connected at a rate of 1000 Mbit/s.
If it is off, the port is connected at a rate of 10 Mbit/s or 100 Mbit/s.
6
WAN6
If it is steady green, the port is connected at a rate of 10 Mbit/s, 100
Mbit/s, or 1000 Mbit/s.
If it blinks green, the port is receiving or transmitting traffic.
7
8F
If it is steady green, the port is connected.
If it blinks green, the port is receiving or transmitting traffic.
8
SFP
One SFP port (9F):
A WAN port by default and supports the WAN/LAN switchover.
Supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-LX20/LH40-
BIDI SPF modules.
9
SFP/SFP+
One SFP+/SFP port (8F):
An SFP+ port by default and supports XG-SFP-SR-MM850, XG-SFP-
LR-SM1310 and XG-SFP-ER-SM1550 modules and BIDI modules.
Can be configured as an SFP port and supports 1000BASE-SX/LX/ZX
mini GBIC and GE-SFP-LX20/LH40-BIDI SPF modules.
A LAN port by default and supports the WAN/LAN switchover.
10
GE copper ports
Eight 10/100/1000M self-adaptive fast Ethernet ports (copper ports 0-7 )
that support automatic recognition of network cables and cross-over cables:
LAN0 (GE 0/0) is a LAN port and WAN0 (GE 0/7) is a WAN port, and
they do not support the WAN/LAN switchover.
By default, LAN6/WAN1 (GE 0/6) is a WAN port and supports the
WAN/LAN switchover.
By default, LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2), LAN3/WAN4
(GE 0/3), LAN4/WAN3 (GE 0/4) and LAN5/WAN2 (GE 0/5) are LAN
ports and support the WAN/LAN switchover.
In bridge mode, LAN0 (GE 0/0) port is also the MGMT port.
11
Reset
Restarts the router. Press and hold this button for more than 5 s to reset the
router to factory defaults.
12
SYS
System indicator:
If it blinks green, the system is being initialized.
If it is steady green, system initialization is completed.
If it is steady red, the system is in abnormal state.

Cookbook Overview
12
Figure 1-8 Back Panel of Ruijie RG-NBR6215-E Router
Table 1-11 Description of the Back Panel of Ruijie RG-NBR6215-E Router
No.
Indicator/Port
Description
1
Retainer holder
Holds the power cord retainer to secure the power cord.
2
Power port
Connects to an AC power cord.
3
Power switch
Controls power supply.
4
Grounding screw
Connects to the grounding system of the installation site through the
grounding wire to provide grounding protection.
5
Hard Disk expansion
card slot
Fits the hard disk module. The supported hard disk module model is
RG-NBR-HDD-1T.
2. Specifications of Ruijie RG-NBR6215-E Router
Table 1-12 Specifications of Ruijie RG-NBR6215-E Router
Item
Description
Model
RG-NBR6215-E
Storage
DDR4 SDRAM: 2 GB
BOOTROM: 8 MB
eMMC: 8 GB
SATA: 1 TB (OPTIONAL)
2 3
5 4
1

Cookbook Overview
13
Item
Description
I/O setup
Eight 10/100/1000M self-adaptive fast Ethernet ports that support automatic
recognition of network cables and cross-over cables:
○By default, LAN0 (GE 0/0), LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2),
LAN3/WAN4 (GE 0/3), LAN4/WAN3 (GE 0/4) and LAN5/WAN2 (GE 0/5)
are LAN ports, while WAN0 and LAN6/WAN1 (GE 0/6) are WAN ports.
○LAN1/WAN6 (GE 0/1), LAN2/WAN5 (GE 0/2), LAN3/WAN4 (GE 0/3),
LAN4/WAN3 (GE 0/4), LAN5/WAN2 (GE 0/5) and LAN6/WAN1 (GE 0/6)
support the WAN/LAN switchover.
One SFP+/SFP port:
○An SFP+ port by default and supports XG-SFP-SR-MM850, XG-SFP-LR-
SM1310 and XG-SFP-ER-SM1550 modules and BIDI modules.
○Can be configured as an SFP port and supports 1000BASE-SX/LX/ZX mini
GBIC and GE-SFP-LX20/LH40-BIDI SPF modules.
○A LAN port by default and supports the WAN/LAN switchover.
One SFP port:
○Supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-LX20/LH40-BIDI
SPF modules.
○A WAN port by default and supports the WAN/LAN switchover.
One management port (in bridge mode)
One console port
Two USB ports
Hardware disk module
One hardware disk module (optional)
Hot swapping
Not supported
Interface standard
Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX,
10GBASE-SR/LR/ZR
Console port: RS-232
Dimension (W x H x D)
440 mm x 43.6 mm x 200 mm(excluding the foot pad)
Voltage
100-240 V; 50/60 Hz
Power
Less than 25 W
Working environment
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Note
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.
Caution
Avoid vibration and collision during device moving and usage when the device has the hard disk module
installed.
