Ruijie Reyee RG-EG Series User manual

Ruijie Reyee RG-EG Series Routers
ReyeeOS 1.216
Web-based Configuration Guide
Document Version: V1.0
Date: February 21, 2023
Copyright © 2023 Ruijie Networks

I
Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation, or commercial use of this document
or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks
is prohibited.
, and other Ruijie networks logos are trademarks of Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and terms. Some or all of
the products, services or features described in this document may not be within the scope of your purchase or
use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement
or guarantee for the content of this document.
Due to product version upgrades or other reasons, the content of this document will be updated from time to time.
Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder
any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Official website of Ruijie Reyee: https://www.ruijienetworks.com/products/reyee
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [email protected]
Conventions
1. GUI Symbols
Interface symbol
Description
Example
Boldface
1. Button names
2. Window names, tab name, field
name and menu items
3. Link
1. Click OK.
2. Select Config Wizard.
3. Click the Download File link.
>
Multi-level menus items
Select System >Time.
2. Signs
The signs used in this document are described as follows:
Warning
An alert that calls attention to important rules and information that if not understood or followed can result in data
loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in function failure
or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will not lead to
serious consequences.

II
Specification
An alert that contains a description of product or version support.
3. Note
This manual introduces the product model, port type and CLI for your reference. In case of any discrepancy or
inconsistency between the manual and the actual version, the actual version prevails.

Web-based Configuration Guide 1 Login
3
1 Login
1.1 Configuration Environment Requirements
1.1.1 PC
Browser: Google Chrome, Internet Explorer 9.0, 10.0, and 11.0, and some Chromium/Internet Explorer kernel-
based browsers (such as 360 Extreme Explorer) are supported. Exceptions such as garble or format error
may occur if an unsupported browser is used.
Resolution: 1024 x 768 or a higher resolution is recommended. If other resolutions are used, the page fonts
and formats may not be aligned, the GUI is less artistic, or other exceptions may occur.
1.2 Default Configuration
Table 1-1 Default Web Configuration
Item
Default
IP address
192.168.110.1
Username/Password
Username and password are not required at your first
login and you can configure the router directly.
1.3 Login to Eweb
1.3.1 Connecting to the Router
You can open the management page and complete Internet access configuration only after connecting a client to
the router in either of the following ways:
Wired Connection
Connect a local area network (LAN) port of the router to the network port of the PC, and set the IP address of the
PC. See Section 1.3.2 Configuring the IPAddress of the Management Client for details.
Wireless Connection
Connect the LAN port to the uplink port on theAP and power on the AP. On a mobile phone or laptop, search for
wireless network @Ruijie-mXXXX (XXXX is the last four digits of the MAC address of each device). In this mode,
you do not need to set the IP address of the management client, and you can skip the operation in Section 1.3.2
Configuring the IPAddress of the Management Client.
1.3.2 Configuring the IP Address of the Management Client
Configure an IP address for the management client in the same network segment as the default IP address of the
device (The default device IP address is 192.168.110.1, and the subnet mask is 255.255.255.0.) so that the

Web-based Configuration Guide 1 Login
4
management client can access the device. For example, set the IP address of the management client to
192.168.110.200.
1.3.3 Login
Enter the IP address (192.168.110.1 by default) of the router in the address bar of the browser to open the login
page.
Note
If the static IP address of the device is changed, or the device obtains a new dynamic IP address, the new IP
address can be used to access the web management system of the device as long as the management client
and the device are in the same network segment of a LAN.
(1) On the web page, enter the password and click Log In to enter the web management system.
Username and password are not required at your first login and you can configure the router directly.
For device security, you are advised to set the management password after your first login to the web
management system. After the password is set, you need to enter the password when you log in to the web
management system again.
If you forget the IP address or password, hold down the Reset button on the device panel for more than 5
seconds when the device is connected to the power supply to restore factory settings. After restoration, you
can use the default IP address and password to log in.
Caution
Restoring factory settings will delete the existing configuration and you are required to configure the device
again at your next login. Therefore, exercise caution when performing this operation.

Web-based Configuration Guide 1 Login
5
1.4 Work Mode
The device can work in router mode and AC mode. The system menu pages and configuration function scope
vary depending on the work mode. By default, the EG router works in router mode. To modify the work mode, see
Section 3.1 Switching the Work Mode.
1.4.1 Router Mode
The device supports routing functions such as route-based forwarding and network address translation (NAT),
VPN, and behavior management. It can allocate addresses to downlink devices, forward network data based on
routes, and perform NAT operations.
In the router mode, the device can access the network through Point-to-Point Protocol over Ethernet (PPPoE)
dialing, dynamic IP address, and static IP address. It can also directly connect to a fiber-to-the-home (FTTH)
network cable or an uplink device to provide network access and manage downlink devices.
1.4.2 AC Mode
The device supports Layer 2 forwarding only. The device does not provide the routing and Dynamic Host
Configuration Protocol (DHCP) server functions. By default, the WAN port obtains IP addresses through DHCP.
TheAC mode is applicable to the scenario where the network is working normally. In AC mode, the device serves
as the management controller to access the network in bypass mode and manage the AP.
1.5 Configuration Wizard (Router Mode)
1.5.1 Getting Started
(1) Power on the device. Connect the WAN port of the device to an uplink device using an Ethernet cable, or
connect the device to the optical modem directly.
(2) Configure the Internet connection type according to requirements of the local Internet Service Provider (ISP).
Otherwise, the Internet access may fail due to improper configuration. You are advised to contact your local
ISP to confirm the Internet connection type:
○Figure out whether the Internet connection type is PPPoE, DHCP mode, or static IP address mode.
○In the PPPoE mode, a username, a password, and possibly a service name are needed.
○In the static IP address mode, an IP address, a subnet mask, a gateway, and a DNS server need to be
configured.
1.5.2 Configuration Steps
1. Adding a Device to Network
You can manage and configure all devices in the network in batches by default. Please verify the device count
and network status before configuration.
Note
New devices will join in a network automatically after being powered on. You only need to verify the device
count.

Web-based Configuration Guide 1 Login
6
If a new device is detected not in the network, click Add to My Network and enter its management password to
add the device manually.
Note
If there is a firewall device in the network, the Firewall Port Config page appears. Select the corresponding
port for configuration.
2. Creating a Network Project
Click Start Setup to configure the Internet connection type and management password.
(1) Network Name: Identify the network where the device is located.
(2) Internet: Configure the Internet connection type according to the requirements of the local ISP.
○DHCP: The router detects whether it can obtain an IP address via DHCPby default. If the router connects
to the Internet successfully, you can click Next without entering an account.
○PPPoE: Click PPPoE, and enter the username, password, and service name. Click Next.
○Static IP: Enter the IP address, subnet mask, gateway, and DNS server, and click Next.
(3) Management Password: The password is used for logging in to the management page.
(4) Country/Region: You are advised to select the actual country or region.
(5) Time Zone: Set the system time. The network time server is enabled by default to provide the time service.
You are advised to select the actual time zone.

Web-based Configuration Guide 1 Login
7
Click Create Network & Connect. The device will deliver the initialization and check the network connectivity.
The device can access the Internet now. Bind the device with a Ruijie Cloud account for remote management.
Follow the instruction to log in to Ruijie Cloud for further configuration.
Note
If your device is not connected to the Internet, click Exit to exit the configuration wizard.
Please log in again with the new password if you change the management password.
1.5.3 Forgetting the PPPoE Account
(1) Consult your local ISP.
(2) If you replace the old router with a new one, click Obtain Account from Old Device. Connect the old and
new routers to a power supply and start them. Insert one end of an Ethernet cable into the WAN port of the
old router and connect the other end to a LAN port of the new router, and click Obtain. The new router
automatically fetches the PPPoE account of the old router. Click Save to make the configuration take effect.

Web-based Configuration Guide 1 Login
8
1.6 Configuration Wizard (AC Mode)
1.6.1 Getting Started
Power on the device and connect the device to an uplink device.
Make sure that the device can access the Internet.
1.6.2 Configuration Steps
(1) On the work mode setting page, change the work mode from router mode toAC mode. For details, see Section
3.1 Switching the Work Mode.

Web-based Configuration Guide 1 Login
9
(2) After mode switching, the device will restart. After restart, the WAN port on the device obtains an IP address
through DHCP and accesses the network by using a dynamic IP address. The default Internet connection type
is DHCP mode. You can use the default value or manually configure a static IP address for the WAN port. For
details, see Section 1.5.2 Configuration Steps.

Web-based Configuration Guide 1 Login
10
1.7 Switching Between Management Pages
After you disable self-organizing network discovery, the web page is in the Local Device mode. (Self-organizing
network discovery is enabled upon delivery. For details, see Section 3.1 Switching the Work Mode)
After you enable self-organizing network discovery, you can switch between the Network and Local Device web
pages. Click the current management mode in the navigation bar and select the desired mode from the drop-
down list box.
Network mode: View the management information of all devices in the network and configure all devices in the
current network from the network-wide perspective.
Local Device mode: Configure the device that you log in to.
Network page:
Local Device page:

Web-based Configuration Guide 1 Login
11

Web-based Configuration Guide 1 Network-Wide Monitoring
12
2 Network-Wide Monitoring
Choose Network > Overview.
The Overview page displays the current network topology, uplink and downlink real-time traffic, network
connection status, and number of users and provides short-cut entries for configuring the network and devices.
On the current page, you can monitor, configure, and manage the network status of the entire network.
2.1 Viewing Networking Information
The networking topology contains information about online devices, connected port numbers, device SNs, and
uplink and downlink real-time traffic.

Web-based Configuration Guide 1 Network-Wide Monitoring
13
Click a traffic data item to view the real-time total traffic information.
Click a device in the topology to view the running status and configuration of the device and configure device
functions. By default, the product model is used as the device name. Click to modify the device name
so that the description can distinguish devices from one another.

Web-based Configuration Guide 1 Network-Wide Monitoring
14
Click List in the upper-left corner of the topology to switch to the device list view. Then, you can view device
information in the current networking. Click an item in the list to configure and manage the device separately.
The update time is displayedin the lower-left corner of the topology view. Click Refresh to update the topology
to the latest state. It takes some time to update the topology data. Please wait patiently.

Web-based Configuration Guide 1 Network-Wide Monitoring
15
2.2 Adding Networking Devices
2.2.1 Wired Connection
(1) When a newdevice connects to an existing device on the network, the system displays the message Adevices
not in SON is discovered. and the number of such devices in orange under Devices. You can click Manage
to add this device to the current network.

Web-based Configuration Guide 1 Network-Wide Monitoring
16
(2) After the system switches to the Network List page, click Other Network. In the Other Network section,
select the device to be added to the network and click Add to My Network.

Web-based Configuration Guide 1 Network-Wide Monitoring
17
(3) You do not need to enter the password if the device is newly delivered from factory. If the device has a
password, enter the management password of the device. Device addition fails if the password is incorrect.
2.2.2 AP Mesh
If the AP supports theAP Mesh (Reyee Mesh) function, you do not need to connect cables after powering on the
AP. The AP can be added to the current network in Reyee Mesh mode, establish a mesh networking with other
wireless devices, and automatically synchronize Wi-Fi configuration.
Caution
To scan the AP, the Reyee Mesh function must be enabled on the current network. (For details, see Section 4.11
Enabling Reyee Mesh.) The AP should be powered on nearby. It may fail to be scanned in case of long distance
or obstacle blocking.

Web-based Configuration Guide 1 Network-Wide Monitoring
18
(1) Place the powered new AP near an existing AP, where the new AP can receive Wi-Fi signals from the existing
AP. Log in to a device in the network. On the Overview page, click +AP in the upper-right corner of the topology
to scan nearby APs that do not belong to the current network and are not connected to a network cable.
(2) Select the target AP to add it to the current network. You do not need to enter the password if the device to
add is new. If the device has a password, enter the management password of the device.
2.3 Configuring the Service Network
The wireless and wired network configurations of the current network are displayed in the lower-left of the
Overview page. Click Setup to switch to the service network configuration page (Network > Network Planning).
