Ruijie Reyee RG-EW Series User manual

Ruijie Reyee RG-EW Series Routers
Web-Based Configuration Guide

Copyright Statement
Ruijie Networks©2021
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification,
transmission, translation or commercial use of this document or any portion of this document, in any form or by any means,
without the prior written consent of Ruijie Networks is prohibited.
Exemption Statement
This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain
the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will
not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface
Thank you for using our products.
Audience
This manual is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Obtaining Technical
Assistance
Ruijie Networks Website: https://www.ruijienetworks.com/
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [e-mail]
Skype: [e-mail]
Related Documents
Documents
Description
Command Reference
Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Hardware Installation and Reference
Guide
Describes the functional and physical features and provides the device
installation steps, hardware troubleshooting, module technical specifications,
and specifications and usage guidelines for cables and connectors.
Conventions

This manual uses the following conventions:
Convention
Description
boldface font
Commands, command options, and keywords are in boldface.
italic font
Arguments for which you supply values are in italics.
[ ]
Elements in square brackets are optional.
{ x | y | z }
Alternative keywords are grouped in braces and separated by vertical bars.
[ x | y | z ]
Optional alternative keywords are grouped in brackets and separated by
vertical bars.

Configuration Guide Overview
1
1 Overview
eWeb is a Web-based network management system that manages or configures devices. You can access eWeb via
browsers such as Google Chrome.
Web-based management involves a Web server and a Web client. The Web server is integrated in a device, and is used to
receive and process requests from the client, and return processing results to the client. The Web client usually refers to a
browser, such as Google Chrome IE, or Firefox.
1.1 Conventions
In this document, texts in bold are names of buttons (for example, OK) or other graphical user interface (GUI) elements (for
example, ARP List).

Configuration Guide Configuration Guide
2
2 Configuration Guide
2.1 Preparation
Scenario
As shown in the figure below, an administrator can access the device from a browser and configure the device through the
eWeb management system.
Figure 2-1-1 Data Exchange Principle
Deliver or request
commands
through AJAX.
Administrator Return data
Web
service
Device
Remarks
The eWeb management system combines various device commands and then delivers them to the device
through AJAX requests. The device then returns data based on the commands. A Web service is available on the
device to process basic HTTP protocol requests.
Deployment
Configuration Environment Requirements
Client requirements:
An administrator can log into the eWeb management system from a Web browser to manage devices. The client refers
to a PC or some other mobile endpoints such as laptops or tablets.
Google Chrome, Firefox, IE10.0 and later versions, and some Chromium-based browsers (such as 360 Extreme
Explorer) are supported. Exceptions such as garble or format error may occur if an unsupported browser is used.
1024 x 768 or a higher resolution is recommended. If other resolutions are used, the page fonts and formats may not be
aligned and the GUI is less artistic, or other exceptions may occur.
The client IP address is set in the same LAN network as the device IP address, such as 192.168.110.X. The subnet
mask is 255.255.255.0. The default gateway is device management address 192.168.110.1. Alternatively, you can set
the IP assignment mode to Obtain an IP address automatically or enter ruiyi.cn into the address bar of the browser
to access eWeb.
Server requirements:
The device is enabled withWeb service (enabled by default).

Configuration Guide Configuration Guide
3
The device is configured with a management IP address (Default: 192.168.110.1).
To log into the eWeb management system, open the Google Chrome browser, and enter http://ruiyi.cn into the address bar,
and press Enter.
Figure 2-1-2 Login Page
Enter the password and click Login.
2.2 Wizard
You will enter the Wizard page without login at initial setup.
2.2.1 Welcome Page
The welcome page will appear when you configure the device for the first time.
Figure 2-2-1 Welcome Page

Configuration Guide Configuration Guide
4
2.2.2 Network Status
The page displays device count.
Figure 2-2-2 Network Status

Configuration Guide Configuration Guide
5
Network Status
If the device fails to access the network, click Start Setup, and you will go to the Internet page.
If the device has accessed the network, click Start Setup, and you will go to the WiFi Settings page.
2.2.3 Internet
If the device fails to access the Internet, the system will check IP assignment automatically. It is recommended to select
DHCP.
Figure 2-2-3 DHCP

Configuration Guide Configuration Guide
6
If you select PPPoE, please enter the PPPoE account provided by the ISP.
Figure 2-2-4 PPPoE

Configuration Guide Configuration Guide
7
2.2.4 WiFi Settings
Configure the SSID, WiFi password and management password and Click Deliver Setup.
Figure 2-2-5 WiFi Settings

Configuration Guide Configuration Guide
8
2.2.5 Finish
After the configuration is delivered, click Finish to enter the homepage.
2.3 GUI
2.3.1 Phone-Based GUI
The system switches between the phone-based GUI and PC-based GUI according to the screen width and browser type.
The phone-based GUI is more concise.
Figure 2-3-1 Phone-Based GUI

Configuration Guide Configuration Guide
9

Configuration Guide Configuration Guide
10

Configuration Guide Configuration Guide
11

Configuration Guide Configuration Guide
12
2.3.2 PC-Based GUI
Click Pro in the upper right corner of phone-based GUI to switch over to the PC-based GUI. The PC-based GUI provides
more configuration items. For details, see eWeb Configuration.
Figure 2-3-2 PC-Based GUI

Configuration Guide Configuration Guide
13

Configuration Guide eWeb Configuration
14
3 eWeb Configuration
This chapter introduces the features on the PC-based GUI.
3.1 Overview
The Overview page displays the device details, WiFi and interface details.
Figure 3-1 Overview
3.2 Clients
The Clients module allows you to view online clients and manage blocked time.
Figure 3-2-1 Online Clients

Configuration Guide eWeb Configuration
15
Figure 3-2-2 Blocked Time Management
Figure 3-2-3 Add Rule

Configuration Guide eWeb Configuration
16
You can convert a dynamic IP address to a static IP address by clicking Unbinded. In the displayed dialog box, configure
settings and click OK.
Figure 3-2-4 Convert Dynamic IP Address to Static IP Address
Figure 3-2-5 Confirm Conversion
