Hardware Installation and Reference Guide Product Overview
7
1 Product Overview
1.1 Introduction to RG-RSR30-XA Series
RG-RSR30-XA series multi-service routers are centralized devices with high-performance processing and high-
density access capabilities. It supports the Border Gateway Protocol (BGP), IP multicast protocols, and rich QoS
features, provides power modules in redundancy mode, and allows users to configure optional modules. They
can function as core routers on small- and medium-sized enterprise networks, or aggregation routers on large-
scale industry networks. The RG-RSR30-XA has one model: RG-RSR30-XA-24.
1.2 RG-RSR30-XA-24
Package Contents
Package Contents
No.
Item
Quantity
1
Chassis
1
2
Fixed bracket
2
3
Footbed
4
4
Fixed bracket installation
instruction
1
5
Warranty card and list of
hazardous substances
1
6
M4X8 Phillips countersunk screw
GB819-85
8
7
Yellow/Green ground cable
1
8
Console cable
1
9
Aggregation device management
software of Ruijie Networks
1
Note
The product management software is pre-installed in the device.

Hardware Installation and Reference Guide Product Overview
8
Product Appearance
1. Front Panel
Figure 1-1 Front Panel
Ports, LEDs, and Buttons on the Front Panel
No.
Item
Description
1 and 3
LED of the
10/100/1000Base-T
Ethernet port in auto-
negotiation mode
Solid yellow:A link is set up on the port at a rate of 10/100 Mbps.
Blinking yellow:A link is set up on the port at a rate of 10/100
Mbps and data is transmitted on the link.
Solid green: A link is set up on the port at a rate of 1000 Mbps.
Blinking green: A link is set up on the port at a rate of 1000 Mbps
and data is transmitted on the link.
Off: No link is set up on the port.
2 and 4
10/100/1000Base-T
Ethernet port in auto-
negotiation mode
The electrical port uses the RJ45 connector.
5
SFP+ optical port LED
Solid green: A link is set up on the port.
Blinking green: A link is set up on the port and data is transmitted
on the link.
Off: No link is set up on the port.
6
SFP+ optical port
For more information about applicable optical modules, see Pluggable
Modules.
7
USB 2.0 port
It supports the FAT32 file format and connects to a USB flash drive.
Non-USB 2.0 devices are not supported. This port allows you to read
the configuration from the storage device or save the configuration to
the storage device.
8
FUNC button
After the FUNC button is pressed, the system will reset and restart
according to the original software version.

Hardware Installation and Reference Guide Product Overview
9
No.
Item
Description
9
USB port LED
Solid green: The USB flash drive works properly.
Solid red: The USB flash drive encounters an exception.
Off: The USB flash drive is not installed.
10
Console port
It is connected to the console for onsite configuration.
11
Fan module LED
Fan module status:
Green: The fan module works properly.
Red: The fan module fails.
Off: Device hardware is abnormal or the device is not powered on.
11
Power LED
Power status:
Solid green: The power output is normal.
Solid red: The power output is abnormal.
Off: The system has no power supply.
11
System LED
System status:
Solid green: The system works properly.
Blinking green: The system is starting up.
Solid red:A fault occurs in the system.
Off: The system not powered on, or is powered on but does not
work properly.
The product nameplate is located on the bottom right corner of the device, as shown in Figure 1-2.

Hardware Installation and Reference Guide Product Overview
10
Figure 1-2 Location of the Nameplate
2. Rear Panel
Figure 1-3 Rear Panel

Hardware Installation and Reference Guide Product Overview
11
Description of the Rear Panel
No.
Module Slot and
Grounding Stud
Description
1
Slot 1
HSIC-E and HSIC service module slot 1
2
Slot 3
HSIC-E and HSIC service module slot 3
3
Slot 4
HSIC-E and HSIC service module slot 4
4
Grounding stud
Protection against lightning strikes and interference
5
PWR0
Power module slot 0: Install the power module first and then connect the AC
power cord.
Power modules can work in 1+1 redundancy mode.
6
PWR1
Power module slot 1: Install the power module first and then connect the AC
power cord.
Power modules can work in 1+1 redundancy mode.
7
Slot 2
Service module slot 2: It is reserved for another module but not the HSIC
service module.
Note
If you cannot determine the number of the slot where the module is located, run the show version slot
command in privileged EXEC mode of the device to view the slot number of the module (not the power module
and run the show env powers command to view the slot number of the power module.

Hardware Installation and Reference Guide Product Overview
12
Technical Specifications
Technical Specifications of the RG-RSR30-XA-24
Model
RG-RSR30-XA-24
Service Module Slots
Four slots, and HSIC and HSIC-E service modules supported
Number of Power Slots
2
Hot Swapping
Supported (the power module and HSIC-2E1/CE1 service module support hot
swapping)
Power Redundancy
Supported
Storage Media
DDR4: 8 GB
Flash/eMMC: 16 GB
10/100/1000Base-T
Ethernet Port in Auto-
Negotiation Mode
16 (0/0–0/3, 0/12–0/23)
SFP+ Optical Port
8 (4F–11F)
Console Port
1
Port LED
24
System LED
4 (SYS, PWR0, PWR1, and FAN)
Voltage
100 V AC to 240 V AC, 50 Hz to 60 Hz
Power Module
Input voltage: 100 V AC to 240 VAC, 50 Hz to 60 Hz
Maximum power: 150 W
Power Consumption
< 150 W
Temperature
Operating temperature: 0ºC to 50ºC (32ºF to 122ºF)
Storage temperature: –40ºC to +70ºC (–40ºF to +158ºF)
Humidity
Operating humidity: 10% to 90% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
Dimensions
(W x D x H)
440 mm x 44 mm x 420 mm (17.21 in. x 1.47 in. x 16.17 in.)
Weight
< 7.8 kg (17.19 lbs, full configuration without packaging materials)
Warning
In a domestic environment, this product may cause radio interference in which case the user may be required
to take adequate measures.

Hardware Installation and Reference Guide Product Overview
13
1.3 RG-PA150IB-F Power Module
Module Appearance
Figure 1-4 Appearance of the RG-PA150IB-F Power Module
RG-PA150IB-F LED
LED
Description
Power module status
LED
Green: The power output is normal.
Red: The power output is abnormal.
Off: The power cord is not inserted, the power module is not installed properly, or
the power module has no output.

Hardware Installation and Reference Guide Product Overview
14
Technical Specifications
Technical Specifications of the RG-PA150IB-F Power Module
Model
RG-PA150IB-F
Rated AC Input Voltage
Range
100 V AC to 240 V AC, 50 Hz to 60 Hz
Maximum AC Input Voltage
Range
90 V AC to 264 V AC, 50 Hz to 60 Hz
Maximum Output Power
150 W
Hot Swapping of the Power
Module
Supported
Power Module Redundancy
1+1 redundancy
Overvoltage Protection
Supported
Overcurrent Protection
Supported
Power Cord
10 A power cord
Dimensions (W x D x H)
51 mm x 40 mm x 196 mm (2.01 in. x 1.57 in. x 7.72 in.)
Temperature
Operating temperature: 0ºC to 50ºC (32ºF to 122ºF)
Storage temperature: –40ºC to +70ºC (–40ºF to +158ºF)
Humidity
Operating humidity: 10% to 90% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
Note
Power modules in 1+1 redundancy mode use the active/standby mode. That is, only one power module
works at one time, and the other power supply is in standby mode. The power module that works or is in
standby mode is random.
The power module in standby mode is not working, so it discharges slowly. If you turn off the power
module in standby mode, the power status LED turns off after a period of time. In specific environments,
the interval for the power status LED to turn off varies depending on the power charge.

Hardware Installation and Reference Guide Product Overview
15
1.4 Service Modules
HSIC-2E1/CE1 Service Module
1. Module Appearance
Figure 1-5 Appearance of the HSIC-2E1/CE1 Service Module
Description of LEDs and Button of the HSIC-2E1/CE1 Service Module
No.
Description
RDY
Function module status LED:
Blinking green: The module is being initialized.
Solid green: Initialization is complete, and the module works properly.
Off: The module is not powered on, is not installed properly, or is removed.
Link/ACT
E1/CE1 port 0-1 working status LED:
Blinking green: The port is connected normally, and is receiving or sending
data.
Solid green: The port is connected normally.
Off: The port is not connected.
OFL
Hot swapping button: When you press and hold the button for more than 3
seconds, the RDY LED stats blinking. After the button is released, the module
completes uninstallation. When the RDY LED is off, the module can be hot-
swapped.
Warning
The HSIC-2E1/CE1 service module can be only installed in slot 2, slot 4, or slot 5.

Hardware Installation and Reference Guide Product Overview
16
2. Technical Specifications
Technical Specifications of the HSIC-2E1/CE1 Service Module
Number of Ports
2
Connector Type
DB9 female connector
Cable
Balanced or unbalanced cable
Standards
Compliance
ITU-T G.703
Temperature
Operating temperature: 0ºC to 50ºC (32ºF to 122ºF)
Storage temperature: –40ºC to +70ºC (–40ºF to +158ºF)
Humidity
Operating humidity: 10% to 90% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
EMC Standards
EMI: GB/T9254.1-2021 ClassA
EMS: GB/T 17618-1998
3. Cables
You can choose to configure crystal head balanced cables, crystal hole interface balanced cables, and
unbalanced cables. For more information about cable types, see E1 Cables.
HSIC-4G-LTE Service Module
1. Module Appearance
Figure 1-6 Appearance of the HSIC-4G-LTE Service Module
Description of LEDs of the HSIC-4G-LTE Service Module
LED
Description
RDY
Function module status LED:
Solid green: The module is powered on and completes initialization.
Off: The module fails to be powered on and initialized.

Hardware Installation and Reference Guide Product Overview
17
LED
Description
WWAN
Network status LED:
Solid green: The dial-up is successful.
Blinking green: The port is receiving or sending data.
Off: The dial-up fails.
4G
4G service LED:
Solid green: 4G services are available.
Off: 4G services are unavailable.
3G
3G service LED:
Solid green: 3G services are available.
Off: 3G services are unavailable.
RSSI
RSSI LED:
Solid green: high signal strength
Blinking green: low to medium signal strength
Off: low signal strength or no signal
Warning
The HSIC-4G-LTE service module does not support hot swapping, and there is no OFL button on the
panel. To install and remove this service module, first power off the device. Otherwise, the operation may
damage the service module or device.
The HSIC-4G-LTE service module can be only installed in slot 2, slot 4, or slot 5.
2. Technical Specifications
Technical Specifications of the HSIC-4G-LTE Service Module
Number of
Ports
One 4G port
Connector
Type
Two SMA-J connectors for connecting dual antennas
Cable
4G antenna
Supported
Rate
All bands
Temperature
Operating temperature: 0ºC to 50ºC (32ºF to 122ºF)
Storage temperature: –40ºC to +70ºC (–40ºF to +158ºF)
Humidity
Operating humidity: 10% to 90% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
EMC
Standards
EMI: GB/T9254.1-2021 ClassA
EMS: GB/T 17618-1998

Hardware Installation and Reference Guide Product Overview
18
3. Cables
One HSIC-4G-LTE service module needs to be used with two antennas.
You only need to connect the external antenna to the external antenna interface ANT 0 or ANT 1 correctly,
and rotate and fasten them.
Warning
The external antenna must be installed or removed only when the device is powered off. The external antenna
does not support hot swapping. Otherwise, it may be damaged.
1.5 Pluggable Modules
The SFP+ optical port supports SFP and SFP+ modules, which can be selected as needed. The following types
of pluggable optical port modules are supported.
GE Optical Modules
List of GE SFP Modules
SFP
Wavelength
(nm)
Fiber
Type
DDM
Supported
(Yes/No)
Transmit
Power
(dBm)
Receive
Power (dBm)
Mi
n.
Ma
x.
Min.
Ma
x.
Mini-GBIC-SX
850
Multim
ode
No
–
9.5
–3
–17
0
Mini-GBIC-LX
1310
Single-
mode
No
–
9.5
–3
–20
–3
GE-eSFP-SX-MM850
850
Multim
ode
Yes
–
9.5
–3
–17
0
GE-eSFP-LX-
SM1310
1310
Single-
mode
Yes
–
9.5
–3
–20
–3
Mini-GBIC-LH40
1310
Single-
mode
Yes
–3
–2
–22
–3
GE-SFP-LX20-
SM1310-BIDI
1310TX/155
0RX
Single-
mode
Yes
–9
–3
–20
–3
GE-SFP-LX20-
SM1550-BIDI
1550TX/131
0RX
Single-
mode
Yes
–9
–3
–20
–3
GE-SFP-LH40-
SM1310-BIDI
1310TX/155
0RX
Single-
mode
Yes
–5
0
–24
–1
