Ruijie RG-S6910-3C Series Installation and operating manual

Ruijie RG-S6910-3C Series Switches
Hardware Installation and Reference Guide

Copyright Statement
RuijieNetworks©2021
RuijieNetworks reserves allcopyrights ofthis document.Any reproduction,excerption,backup,modification,
transmission,translationorcommercialuseofthis documentoranyportion of this document,inany form or by any
means,withoutthe priorwritten consentof Ruijie Networks is prohibited.
Exemption Statement
This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain
the latestinformationthroughtheRuijieNetworks website.RuijieNetworks endeavors toensurecontentaccuracyand
willnot shoulderanyresponsibilityfor losses and damages causedduetocontentomissions,inaccuraciesorerrors.

Preface
Thank you for usingourswitches.This guidewillhelpyouinstallanduse theswitches.
Scope
This manualdescribesthe functions andphysical features ofthe switches,and presentstheinstallationprocedure,
troubleshootingprocedure,technicalspecifications,andspecificationsandusages rulesofcables andconnectors.Itis
intendedfor the users thathave some experienceininstalling andmaintainingnetworkhardware andwanttolearnthe
above information.At the same time,itis assumed thatthe users ofthis switcharealreadyfamiliarwiththe relatedterms
and concepts of Ethernet.
Document Structure
Chapter1 "Product Overview" describes the maincharacteristics,technicalspecifications,andrelatedmodulesof
this product.
Chapter2 "Preparation before Installation" lists the safety, powersupply, andsite requirementsthatmustbe met
beforethe switchcan beinstalled.
Chapter3 "Product Installation" describes howtoinstalltheintegratedswitchandmodules,andconnectits power
cables andgroundinglines.
Chapter4 "System Debugging" describesthecommissioningafterthe switchis poweredon for the firsttime.
Chapter5 “Monitoring and Maintenance”
Chapter5 "Troubleshooting" describes possibleproblemsmetduringtheinstallationand useofthe switchand
solutions forsuchproblems.
AppendixA "Connectors and Connection Media"
AppendixB "Mini-GBIC, 10G, 40G and 100GModules"
AppendixC “Lightening Protection”
AppendixD “Cabling Recommendations in Installation”
AppendixE “Site Selection”
Obtaining Technical Assistance
RuijieNetworks Website:https://www.ruijienetworks.com/
TechnicalSupportWebsite:https://ruijienetworks.com/support
CasePortal:https://caseportal.ruijienetworks.com
Community:https://community.ruijienetworks.com
TechnicalSupportEmail:[e-mail]
Skype: [e-mail]
Related Documents
Documents
Description

ConfigurationGuide
Describes networkprotocolsandrelated mechanismsthatsupportedbythe
product, with configurationexamples.
CommandReference
Describes the relatedconfiguration commands,including commandmodes,
parameterdescriptions,usageguides,andrelatedexamples.
Symbol Conventions
Means readertake note. Notes containhelpful suggestionsorreferences.
Means reader be careful. In this situation,you mightdo somethingthatcouldresultin equipmentdamageorloss of
data.

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 3 -
1 Product Overview
RG-S6910-3C series switches are data center oriented high density 100G core switches, providing 100Gaccess, low
latency, and complete data center features. RG-S6910-3C series switches provide 96 100G ports and can be used with
other aggregationswitches tocompose ahigh-performanceandhigh-reliabilitydatacenter network.
Model
100G QSFP28
Ethernet Port
25G/10G SFP28
Ethernet Port
10GBase-
T
Expansion
Module Slot
Redundant
Fan
Redundant
PowerSupply
RG-
S6910-3C
-
-
-
3
5+1
2+2
M6900-
32CQ
32
-
-
-
-
-
A QSFP28 port supports 100G/40Gmode and4x25G/4x10G mode.
1.1 RG-S6910-3C
Specifications
Model
RG-S6910-3C
CPU
Quad-core eight-threadCPU processer,2.2 GHz, Intel Xeon D-1527
L2 Cache
16 MB
eMMC
64 GB
SDRAM
DDR416 GB
MAC Cache
16 GB
Expansion
Module Slot
3
Expansion
Module
M6900-32CQ
Fan Slot
6 (support5+1redundancy, configure at least5 fan modules in one switch)
Fan Module
M2EFAN I-F
PowerSupply
Slot
4 (support2+2redundancy)
PowerModule
RG-PA1200I-F
PowerSupply
Input
AC input
Ratedvoltage range: 100 VAC to 127VAC
Frequency: 50 Hz to 60 Hz
Ratedcurrent: 12 A
Ratedvoltage range: 200VAC to 240VAC
Frequency: 50 Hz to 60 Hz
Ratedcurrent: 9.6 A Max
Highvoltage direct current(HVDC) input:
Input voltage range:192 VDC to 288VDC
Input current range:6 A

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 4 -
Power
Consumption
Static power: 760 W, typical power: 1092 W, powerwith fullload: 2046 W
Optical Module
Refer toAppendix B
The supportedmodulesupdateatany time,contact RuijieNetworks fordetails.
SFP28 Port
Unsupported
QSFP28 Port
Supported.The numberofports depends ontheexpansionmodule.
10GBASE-T Port
Unsupported
Temperature
Warning
Supporttemperaturewarningandover-heating protection.
EMC Standards
GB9254-2008CLASS A
SafetyStandards
GB4943-2011
Working
Temperature
0 °C to 40 °C (32°F to 104 °F)
Storage
Temperature
-40 °C to 70 °C(-40 °F to 158 °F)
Working Humidity
10%to 90%RH (non-condensing)
Weight
Netweight:42kg (92.60 lbs,with 6fan modules ,4 powermodulesand3 M6900-32CQmodules)
Dimensions
(W x D x H)
442mmx 735mmx 173.6mm,4RU (17.40 in. x 28.93 in.x 6.83 in.)
RG-S6910-3C switchis a class A product. In a domesticenvironment,this product maycause radio interference in
whichcasethe usermaybe required to take adequate measures.
The 100G Ethernet port of the RG-S6910-3Cswitchsupports DAC. For a detailed modeland specification,refer to
AppendixB.
Product Appearance
The hardwareof the RG-S6910-3Cincludes thechassis,thepowersupplysystem and theheat dissipation system.
The power supply system: Provides four power supply slots, which support 2+2 power supply redundancy. It is
recommended users configurepowersupplyredundancy.
The heat dissipationsystem:Provides sixfan module slots,whichsupport5+1 fan redundancy. It is recommended
users configureall fans redundancy.
Figure1-1 Appearanceof the RG-S6910-3C

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 5 -
Front Panel
Figure1-2 Front Panel of the RG-S6910-3C
Notes:
1. EngineSlot
2. USB Port
3. MGMT Port
4. MGMT Indicator
5. ConsolePort
6. System Status Indicator
7. FIND Status Indicator
8. Expansion Module Slot
9. Mounting Bracket
Rear Panel
Figure1-3 RearPanel of the S6910-3C

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 6 -
Notes:
1. Fan Module Slot
2. Fan Indicator
3. PowerModule Slot
4. GroundingPoint
5. ESD WristStrap
6. AssetTag
Asset Tag
The assetmanagementlabelis in the lowerleft corner of the rear panel.The labelis movableandcan be removed from
the device. Users can mark the informationsuchas assetname,category, code and registrationdateon the labelwhich
helps toimprove assetmanagementaccuracyand efficiency.
Figure1-4 AssetTag of the RG-S6910-3C

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 7 -
External Ports
The RG-S6910-3Cprovides thefollowingports:
Universalserial bus (USB)port:This port canconnect withUSB memoryto save logs, switchversions,warnings
andother diagnosticmessages.Therefore,it is moreconvenientto upgradethe softwareversion ofthe switchon
lineandsave the loginformation.
To protect the data and avoid device damage,usequalifiedUSBflash disks of good brands.At the sametime,the
localUSB port is compatible withmostofthe USB controllers exceptsome USBflashdisks.
RG-S6910-3C series switches support debugging, configuration, maintenance, management and switch software
uploadingofConsoleports.
Consoleport:UseRS-232interfaceelectrical level andstandardRJ45connector.This interfaceis connected with
the serialportof terminalPC to perform system debugging,configuration,maintenance,management,and switch
software uploading.
MGMT port:This is an out-bandEthernet port, whichuses standardRJ45connector.This interfaceis connected
with Ethernetport of a PC to perform program downloading.
QSFP28 port: Thereare 96 100G QSFP28 ports whichsupportoptical modulesand DAC coppercables.These
ports can workin 100G/40G modeand 4x25G/4x10G mode.
Panel Indicators
Indicator
Panel
Identification
Status
Meaning
System Status
Indicator
SYS
Off
The system is notpowered on.
Solidred
System failure.
Blinkinggreen.
The system is beinginitialized.
Solidgreen
The system works properly.
Solidyellow
There is system alarm.
LocationIndicator
FIND
Solidgreen
The device is not being found.
Blinkingred
The device is to be found.
MGMT Port Indicator
Link/ACT
Off
The port is down.
Green
The port is connected at 1000Mbps.
Yellow
The port is connected at 100Mbps.
Blinking
The port is transmitting orreceiving data.
FAN Indicator
Fan Status Indicator
Status
Off
The fan modules are notpoweredon.
Solidgreen
The fan modules workproperly.
Solidred
The fan modules donotworkproperly.
Indicators on AC are Specified by Upstream Vendor
PowerIndicator
-
Off
The AC is not poweredon.
Solidgreen
The powermoduleworks properly.

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 8 -
Blinkinggreen
(1Hz)
The poweris PS off, 12VBS.
The power is in cold backup status and does not
output power.
Solidred
An error occurs, e.g., overcurrent, overvoltage or fan
fault.
The AC powerin redundancyis pluggedout.
Blinkingred(1Hz)
An alarm is generated but the power module keeps
working. The alarm may be caused by high power,
high current, high temperature, or low fan rotation
speed.
Port Indicator
QSFP28 Port Indicator
Link/Act
Off
The port is not connected.
Solidgreen
The port is connected at 100Gbps.
Blinkinggreen
The port is transmitting orreceiving data at 100Gbps.
When the deviceworks properly,its FINDindicatoris solidgreen.IftherearetoomanyRG-S6910-3Cseriesswitches
to locate a specific device, you can run the led-blink enable/disable command to configure the FIND indicator to
blinkat 1Hz in red, soas to locate the device.
Power Supply
The RG-S6910-3Cseries switchessupportRG-PA1200I-Fpowersupplymodule.Thesmartpowersupplymodule
supports powermanagement,andthe switch can readinput power,inputcurrent, and temperature in realtime.The
powersupplymodulesupports hotswapping.
The RG-S6910-3Cseries switches support2+2 powersupplyredundancy. To improvethe stabilityandreliabilityof
the entire system, it is recommended to configure 2+2 power supply redundancy. When the four power supply
modules worknormally,the switchis in the status ofcurrentsharing.
It requires at leasttwo powersupplymodules to work normally.Filler panels needto be installedinthe unoccupied
powersupplymoduleslots toensureventilationandheatdissipation andavoiddusts.
Heat Dissipation
The workingtemperature ofthe RG-S6910-3Cswitches is 0°Cto40°C (32°F to 104°F), and the heat dissipation design
needs toensurethestability,safety andmaintainabilityinsuch environment.TheRG-S6910-3Cseries switches adopt
fan ventilationand forcedconvection to ensurethe device can work normallyin specifiedenvironment.Dustthedevice
every three months toavoid blockingthe ventilationopenings.
The RG-S6910-3Cswitch supports M2EFAN I-F andprovides fan speedregulation,fanfailurewarning,andfan hot
swapping.
Figure1-5 Ventilation and Heat Dissipation ofthe RG-S6910-3C Switch

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 9 -
Maintain a minimum clearanceof20cm aroundthe switchfor ventilation.
It requires atleastfive fan modules toworknormally.Fillerpanels needtobe installedin theunoccupiedfanmodule
slots toensure ventilation and heat dissipationand avoid dusts.
The powermoduleandfanmodulewithdifferent ventilation directioncannotbeusedtogether.
1.2 Modules
The RG-S6910-3Cseriesswitchesadoptthemodule-baseddesign.Compliantwith industrystandards,thedesigndivides
modulesandintegratesmoduleinterfacestoensuretheswitchsystem'sfunctioningandindependenceofvarious function
modules.
The RG-S6910-3C series switches support the following modules: M6900-32CQ (expansion module), RG-PA1200I-F
(powermodule),andM2EFAN I-F (fan module).
1.2.1 M6900-32CQ
Module Appearance
Figure1-6 M6900-32CQ

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 10 -
Notes:
1. Status Indicator
2. 1F-32F Port Status Indicator
3. 100G/40G QSFP28 Port
External Ports
The M6900-32CQprovides 32 QSFP28ports andsupportshotswappingofQSFP+modules.BothfibermodulesandDAC
can beused.
Indicator
Indicator
Panel
Identification
Status
Meaning
Status Indicator
Status
Off
The system is notpowered on.
Solidred
The modulefails orresets.
Blinkinggreen
The system is beinginitialized..
Solidgreen
The system works properly.
Solidyellow
The temperatureexceeds thethreshold.
QSFP28 Port
Indicator
1F-32F
Off
The port is down.
Solidgreen
The port is connected at 100G/40G.
Blinkinggreen
Theport is receiving ortransmittingdataat100G/40G.
Specifications
Module
M6900-32CQ
Device
RG-S6910-3C
Port Type
32 100GQSFP28 ports
Transmission
Medium
See AppendixB
The supportedmodulemaychange.PleasecontactRuijieNetworks fordetails.
Hot Swapping
Supported
Power
Consumption
<329W
EMC
GB9254-2008ClassA
Safetyspecification
GB4943-2011
Operating
Temperature
0°C to 40°C (32°F to 104°F)
Storage
Temperature
-40°Cto 70°C(-40°Fto 158°F)
Operating Humidity
10%to 90%RH (non-condensing)
Weight
2.1 kg (4.63 lbs)
Dimensions
(W x D x H)
420mmx 203.5mmx 42 mm(16.5 in. x 8.01 in. x 1.65 in.)
QDFP28 ports of M6900-32CQsupport100G/40Gmode and4x25G/4x10G mode.Please configurethe portto work
in the correspondingmodebased on RG-S6910-3CSeriesSwitchRGOS Configuration Guide.

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 11 -
When the QSFP28 ports of M6900-32CQis divided into 4x25G mode or 4x10G mode, the port configuration takes
effect based on the port group insteadof an individual port, and four consecutive100G ports form a port group. For
example, if the port hun 1/1 is divided, ports hun 1/1-4 are divided at the same time. In addition, four consecutive
100Gports can bedivided into 8x25G or 8x10G. The dividedports are distributedonodd-numbered QSFP28ports,
and even-numberedQSFP28ports are not available.
Dueto MAC chip limitation,ports 1/1-1/4canonly workin the sameratemodeatthesame time,and ports 3/21-3/24
can onlywork inthe sameratemodeatthe sametime.
The100GEthernetports ofM6900-32CQsupportDAC.QSFP28ports support3mcables.SeeAppendixBfordetails.
1.2.2 M2EFAN I-F
M2EFAN I-F is the fan module which provides a ventilation system for the switch to ensure stabilityand supports speed
adjustment,faultalarm and hot swapping.
Module Appearance
Figure1-7 M2EFAN I-F

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 12 -
Notes:
1. Handle
2. Status Indicator
3. Screw
Indicator
Indicator
Panel
Identification
Status
Meaning
Status Indicator
Status
Off
The fan is not poweredon.
Blinkinggreen
The fan is beinginitialized.
Solidgreen
The fan works properly.
Solidred
The fan fails or stops.
Specifications
Model
M2EFAN I-F
VentilationRate
109.43CFM

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 13 -
Max Rotation
Speed
11000RPM
Consumption
44.4 W
Weight
0.25 kg (0.55lbs)
Dimension(W x
D x H)
166mmx 83 mmx 83 mm(6.54in. x 3.27 in. x 3.27in.)
1.2.3 RG-PA1200I-F
RG-PA1200I-F is a smart power supply for RG-S6910-3C, obtaining power status, output power, current and working
temperatureinrealtime.RG-PA1200I-F supports bothAC and HVDC input.
Module Appearance
Figure1-8 RG-PA1200I-F
Notes:
1. Handle
2. Connector(10A PowerCord)
3. PowerStatus Indicator
External Ports
The front panel of the power supplymodule provides a three-pin connector, which can be connected to standard 10 A
powercord.

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Product Overview
- 14 -
Indicator
Indicator
Panel
Identification
Status
Meaning
Status Indicator
N/A
Off
Thereis no powerinputorthepowersupplyfails.
Solidgreen
The powerinputis normal.
Blinkinggreen at 1 Hz
The poweris PS off, 12VBS.
The poweris in coldbackupstatus anddoes not
output power.
Solidred
An erroroccurs,e.g., overcurrent, overvoltage or
fan fault.
The AC powerin redundancyis pluggedout.
Blinkingred at 1 Hz
An alarm is generated but the power module
keeps working. The alarm may be caused by
high power, high current, high temperature, or
lowfan rotation speed.
Specifications
Model
RG-PA1200I-F(AC)
RG-PA1200I-F(HVDC)
Rated Voltage
100VAC to 240VAC
50/60Hz
240VDC
Max Voltage
90 VAC to 264VAC
47 Hz to 63 Hz
180VDC to 310 VDC
Max PowerOutput
1200W
1200W
Input Leakage
Current
≤1.75 mA
Weight
0.9 kg (1.98 lbs)
Dimension (W x D x
H)
224.94mm x 73.5mm x 40 mm (8.86in. x 2.89 in. x 1.57 in.)
PowerCord
10 A powercord
Pleasemakesurethatthe powercord has beenremovedbeforeplugginginorpluggingoutthe powermodule.

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Preparation before Installation
15
2 Preparation before Installation
2.1 SafetyPrecautions
To avoid body injury and device damage,please carefullyread the safety precautions before you install the RG-
S6910-3C.
The following safetyprecautions donot cover all possibledangers.
2.1.1 Installation Safety
Keepthe chassis cleananddust-free.
Do notplacethe device inwalking areas.
Do not wearloose clothes,ornaments oranyotherthings that maybe hookedbythe chassis during theinstallation
andmaintenance.
Turn off allpowersuppliesandunplugall powercords andcables before theinstallationorthedismantling.
Avoid transferringtheequipmentwithoutpackingmaterials.
If stackingis requiredduringtransportation,the numberofstackedlayers shouldnotexceed the numbermarked on
the packagingbox. Do not placethe box upsidedown oronthe side.
After takingout switches forinstallation,switches cannotbestackeddirectly. Each switchshould be separated by
packingpads andplaced rightside up.The numberof stackinglayers shouldnotexceed3 (the stackingheight
cannotexceed 1M). The packing pads needtobe placedin a stablealignment.
2.1.2 Removal Safety
Avoid frequent removals afterthe device is installed.
Turn off allpowersuppliesandunplugall powercords andcables before theinstallationorthedismantling.
When removingthedevice, pay attentionto the balanceandavoid hurtinglegs and feet or strainingtheback.
When the device is being removed, do not hold the power supplyhandle or the fan handle for these parts are not
designed for bearing the entire weight of the device. It will cause damageto the device or to your body if you hold
theseparts when removingthe device.
To reducethe weightofthe chassis duringtheremoval,dismantletheexpansionmodule,fanmoduleandthepower
supplymodulefirst.
Installandoperatethe device in places whereremovingis restricted.
2.1.3 Electric Safety
Observe localregulations andspecifications whenelectricoperations are performed.Relevantoperators mustbe
qualified.
Carefullycheckany potential dangerinthe workingarea, suchas ungroundedpowersupply,unreliable grounding
of the powersupply, and damp/wetground.

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Preparation before Installation
16
Find out the locationof the emergencypowersupplyswitchinthe room beforeinstallation.Firstcut off the power
supplyin the caseofanaccident.
Be sure to makea carefulcheck beforeyou shutdownthe powersupply.
Do notplacethe device ina damplocation.Donot let anyliquidenterthe chassis.
Any nonstandard and inaccurate electrical operation can cause accidents such as fires or electrical attacks, thus
causingsevere,oreven fatal damages tohumanbodies and thedevices.
Direct or indirecttouchthrougha wet objecton high-voltageandmains supplycanbringa fatal danger.
2.1.4 Electrostatic DischargeDamage Precautions
The RG-S6910-3Cdesigning gives agreatconsideration to prevent electrostaticdischarge damageand adopts multiple
measures.Butif the electrostaticexceeds certainlimit,it can stillcausegreatdamagestothe circuitryand the device. In
networks connectedbythe RG-S6910-3C,the majorsources ofelectrostaticinductionareoutdoorhighvoltage
transmission cables,lightening,indoorfloormaterials andthemachinestructure.
Pay attentionto the followingtips:
The device and the floor are wellgrounded.
Take dustpreventionmeasures intheroom.
Maintain anappropriatehumidity.
When the pluggablemodulesoftheswitchare beinginstalled,wearantistaticwriststrap andmakesurethe
antistaticwriststrap is wellgrounded.
Do notusebarehand to directly touchthe components andtheprinted-circuitboard(PCB)whenthe boards are
used.
Use ananti-staticshieldingbagtoproperlystore the board.
Do not let anyclothes toucha circuitboard. An antistaticwriststrap can onlyprevent human staticelectricityfrom
damaging thecircuitboard,but cannot prevent any staticelectricityon clothes.
2.1.5 Laser Safety
Amongthe modules supported bythe RG-S6910-3C,there are a great numberofoptical modules thatareClass I laser
product.
Precautions:
When a fibertransceiverworks,ensure thatthe port has beenconnectedwitha fiber or has been covered by a dust
cap so as to keep out dustand prevent it from burning your eyes.
Do not stare atany fiberport.
Do not stare atany fiberport under anycircumstances,as this maycausepermanentdamagetoyour eyes.
2.2 InstallationSite Requirements
Installthe RG-S6910-3Cindoor.To ensurenormaloperationanda prolongedservicelifeof the device, the installation
sitemustmeetthefollowingrequirements.

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Preparation before Installation
17
2.2.1 Rack Mounting Requirements
Make surethecabinetcomplies withthefollowing conditionsifthe RG-S6910-3Cis installed inthe cabinet:
Installthe switchinan opencabinetas muchas possible.Ifyou installtheswitchinsidea closed cabinet,besure
thatthe cabinethas a goodventilation andheat dissipation system.
Be sure that the cabinetis firm enough to bear the weightof the RG-S6910-3Candits installationaccessories.
Be sure that the dimensionsofthe cabinetis appropriateforinstallationof theRG-S6910-3Cthat can reserve a
certainspace for the front, back, left and rightpanels forheat dissipation.
The cabinetshouldbeproperlygrounded.
2.2.2 Ventilation Requirements
Maintain a minimum clearanceof20cm aroundthe switchfor ventilation. After various cables areconnected,bundlethe
cables orplace them in the cablemanagementbrackettoavoid blockingairinlets. Dustthe device every three months to
avoid blockingtheventilation openings.
2.2.3 Temperature and Humidity Requirements
To ensurethenormaloperationanda prolonged servicelifeof the RG-S6910-3C,maintain an appropriatetemperature
andhumidityin the equipmentroom.Theequipmentroom withtoo highor too low temperatureand humidityfor a long
period of timemaydamage theequipment.
In an environmentwithhighrelative humidity, the insulatingmaterial mayhave badinsulationoreven leak
electricity. And sometimes thematerialsmaysufferfrom mechanicalperformancechange andmetallicparts may
get rusted.
On the other hand,in an environmentwithlowrelative humidity, the insulatingstrip maydry andshrink,and static
electricitymayoccur easilyandendangerthe circuiton the device.
In an environmentwithhightemperature,the equipmentis subjectedtoeven greater harm,as its performancemay
degradesignificantlyandits service life maybeshortenedathightemperaturefor long that expedites the aging
process.
Temperatureand humidityrequirements ofthe RG-S6910-3C:
Model
Working Temperature
Working Humidity
RG-S6910-3C
0ºC to 40ºC / 32ºF to 104ºF
10%to 90%(non-condensing)
The ambienttemperatureandhumidityare measuredatthe pointthat is 1.5 m above the floorand 0.4 m before the
device whenthere is noprotective platein front or at the backof the device rack.
2.2.4 Cleanness Requirements
Dustposes thetopthreatto the runningof the device. The indoordustfallingon the device maybe adheredbythe static
electricity, causing poorcontactof the metallicjoint.Such electrostaticadherencemayoccurmoreeasilywhen the
relative humidityis low, not onlyaffecting the servicelife of the device, but alsocausing communicationfaults.The
followingtableshows the requirementsforthe dustcontentand granularityin the equipmentroom.
Substance
Concentration Limit (particles/m3)
Dustparticles (diameter≥0.5μm)
≤3.5×106
Dustparticles (diameter≥5μm)
≤3×104

RG-SS6910-3C Series Switch Hardware Installation and Reference Guide Preparation before Installation
18
Apart from dust, the salt,acidand sulfideinthe airin the equipmentroom mustalsomeetstrictrequirements;as such
poisonoussubstancesmayacceleratethe corrosionofthe metalandthe agingof someparts.The equipmentroom
shouldbeprotectedfrom the intrusionofharmful gases (forexample,SO2, H2S, NO2and Cl2), whoserequirements are
listedin the followingtable.
Gas
Average (mg/m3)
Maximum (mg/m3)
SO2
0.3
1.0
H2S
0.1
0.5
NO2
0.5
1.0
Cl2
0.1
0.3
The Average refers to the average limitof harmful gas in one week. The Maximum value is the upper limit of the
harmful gas inone week,and maximum valuecan lastfor upto 30minutes everyday.
2.2.5 System Grounding Requirements
A good groundingsystem is thebasis forthestableandreliable operationofthe RG-S6910-3C.It is the key to prevent
lightning stroke andresistinterference.Please carefullycheckthe groundingconditionson the installation site according
to the groundingrequirements,and perform grounding properlyas needed.
Safety Grounding
The device usingAC or HVDC power supplymustbegrounded byusing theyellow/greensafetygroundingcable.
Otherwise,when grounding faulthappens in thehighvoltage circuitinside thedevice, electricshockmayoccur.
The buildinginstallation shallprovideameans for connectionto protective earth, and the device is to be connected
to that means.
Lightning Grounding
The lightningprotectionsystem ofthe facility is anindependentsystem thatconsists ofthelightningrod, down lead
conductorandthe connector to the groundingsystem,whichusuallysharesthepowerreferenceground and
yellow/greensafetycable ground.The lightningdischarge ground is forthe facilityonly, not for the device.
For lightningprotection,refer to Appendix C.
EMC Grounding
The groundrequiredforEMC design includes shielding ground,filterground,noiseandinterferencesuppression,and
level reference.All the above constitutethe comprehensivegroundingrequirements.The groundingresistance shouldbe
less than 1Ω. Thereis one groundingconnectoratthe left bottom of the chassisofRG-S6910-3Cseriesswitches.The
groundingconnectoris pastedwithconspicuouswarning labels.
Figure2-1 EMC grounding
