REPAIR SHEET
BRAND
RYOBI
DESCRIPTION
18 Volt Handheld Electrostatic Sprayer
MODEL NO.
PSP02
ONE WORLD TECHNOLOGIES, INC.
P.O. Box 1288, Anderson, SC 29622 1-800-525-2579 www.ryobitools.com 9-30-20 (Rev:01)
The model number and manufacturing location will be found on a label attached to the product. Always mention this information in all communications regarding this product and when ordering parts.

2
PSP02
1
1
2
3
8
9
10 11
12
13
14
15 16 17 18
18
19
20
21
23
22
25
25
24
4
7
6
5

3
PSP02
KEY NO. PART NO. DESCRIPTION QTY.
1 204186002 Housing Assembly (Inc. Key Nos. 4-6) 1
2 281223001 Electrode and Battery Contact Assembly 1
3 204186003 Tank Assembly (Inc. Key No. 7) 1
4 941114323 Logo Label 1
5 941123174 Data Label 1
6 941120670 Icon Warning Label (ENG/FR) 1
7 941120671 Warning Label (SP) 1
8 565816001 Connecting Device Gasket 1
9 542056001 Tank Connecting Device 1
10 698924001 Trigger Spring 1
11 542166001 Trigger 1
12 565818001 Inlet Tube 1
13 565873001 Motor Rear Rubber 1
14 565872001 Motor Front Rubber 1
PARTS LIST
KEY NO. PART NO. DESCRIPTION QTY.
15 634401001 Spring Plate 1
16 370058002 Electrostatic Discharge Button 1
17 316868001 Motor and Pump Assembly 1
18 643220002 Hose Clamp 2
19 565819001 Outlet Tube 1
20 206186002 Turret Assembly 1
21 316869001 Nozzle (50 Micron) 1
22 316971001 Nozzle (75 Micron) 1
23 316972001 Nozzle (100 Micron) 1
24 660570005 Screw (M3 x 14 mm) 19
25 635294005 Hose Clamp 2
Not Shown:
998000301 Operator’s Manual (961153426)

4
PSP02
WIRING DIAGRAM
CIRCUIT
BOARD
BATTERY
CONTACT
PLATE
HOLDER
MICRO
SWITCH
ESD
ASSEMBLY
LED
GROUND
RING
ESD
SWITCH
CONNECT
ADAPTOR WITH
CHARGING RING
MOTOR AND
PUMP ASSEMBLY
BLUE
RED
BLACK
BLACK
GREEN
GREEN
RED
BLACK
RED
BLACK
BLUE
BLUE
RED
BLUE
