SaMASZ SAMBA 160 User manual

SaMASZ Sp. z o.o.
ul. Trawiasta 1
16-060 Zabłudów
Polska
tel. (+48) (85) 664 70 31
fax (+48) (85) 664 70 41
e-mail: [email protected]
www.samasz.pl
OPERATOR’S MANUAL
Serial no.
The original operator’s manual
ENGLISH
IN0670USA004
06.07.2020
EDITION NO. 4
LIGHTWEIGHT, REAR DISC MOWER
SAMBA 160
SAMBA 200
SAMBA 240
SAMBA 280
SAMBA 320

2
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
It is recommended to incline cutterbar up to angle of 3° in relation to
mowing direction. Operating in horizontal position is admissible.
DO NOT
TURN THE DRIVE ON IF THE MOWER
IS NOT IN WORKING POSITION.
DO NOT
LIFT THE MOWER BEFORE THE MOWING DISCS HAVE
COME TO COMPLETE STANDSTILL.
DO NOT
OPERATE WHEN ANY PERSON REMAINS IN THE
DANGER AREA OF 170'.
CAUTION:
Keep this manual for future reference.
Well-proven design with thousands of machines in regular use in many countries and quality
materials ensure high durability and reliability of SaMASZ mowers.
We congratulate you on the purchase of your new SaMASZ mower and wish you much
pleasure and the very best work results through the years to come.
GENERAL PRECAUTION:
When operating the mower warnings and safety rules marked
with this sign herein should be respected.

3
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
Table of contents page
1. IDENTIFYING THE MACHINE ...........................................................................................5
2. INTRODUCTION ............................................................................................................5
3. PROPER AND INTENDED USE ..........................................................................................5
3.1. Technical data ..................................................................................................................................7
3.2. Design and operating principle...........................................................................................................7
3.3. Standard equipment and spare parts..................................................................................................8
4. SAFETY PRECAUTIONS..................................................................................................9
4.1. Safety rules and regulations...............................................................................................................9
4.2. Qualifications of operator................................................................................................................11
4.3. Conditions of mounting mower on tractor.........................................................................................12
4.4. Transport........................................................................................................................................12
4.4.1. Loading the mower onto another vehicle for transport .................................................................12
4.5. Working parts..................................................................................................................................14
4.8. Residual risk ...................................................................................................................................15
4.9. Safety decals and their meaning ......................................................................................................17
5. OPERATION ...............................................................................................................20
5.1. Attaching the mower to the tractor...................................................................................................20
5.2. Connecting the articulated telescopic shaft (ATS) ............................................................................22
5.3. Preparing mower for transport .........................................................................................................23
5.4. Preparing mower for transport on public roads .................................................................................24
5.5. Moving the mower from transport to working position ......................................................................25
5.5.1. Operating positions of the mower...............................................................................................26
5.6. Preparing mower for operation.........................................................................................................26
5.7. Operation........................................................................................................................................27
5.7.1. Basic information on mowing......................................................................................................27
5.7.2. Essential information concerning mowing ...................................................................................27
5.7.3. Design and operation of safety breakaway device........................................................................28
5.7.4. Mower blocking and jams ...........................................................................................................28
5.7.5. Driving with mower over windrows when taking turns...................................................................29
5.8. Unhitching the mower from tractor...................................................................................................29
6. MOUNTING AND ADJUSTMENTS ...................................................................................30
6.1. Mounting and timing of the knives ...................................................................................................30
6.2. Controlling condition of knives and holder pins.................................................................................31
6.3. Replacing knives and holder pins .....................................................................................................31
6.4. Adjusting cutting height...................................................................................................................33
6.5. Adjusting pressure of the cutter bar using support springs................................................................33
6.6. Operating service ............................................................................................................................34
6.6.1. Checking the tension of V-belts on belt gear................................................................................34
6.6.2. Daily maintenance......................................................................................................................34
6.6.3. After-season maintenance and storing ........................................................................................35
7. LUBRICATING.............................................................................................................36
7.1. Risks present when lubricating.........................................................................................................36
7.2. Cutter bar........................................................................................................................................37
7.3. Intersecting axis gear ......................................................................................................................37
8. DEFECTS AND THEIR REPAIR........................................................................................38
9. DISASSEMBLY AND WITHDRAWAL FROM USE.................................................................40
9.1. Repair .............................................................................................................................................40
9.2. Scrapping .......................................................................................................................................40

4
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
10. WARRANTY CARD .......................................................................................................41
11. WARRANTY TERMS .....................................................................................................41
11.1. Warranty claim procedures ..............................................................................................................41
11.2. Warranty repairs record ...................................................................................................................43

5
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
1. IDENTIFYING THE MACHINE
Data plate is permanently mounted to the mower's main frame in place shown below in Fig. 1.
Fig. 1. Data plate placement
Data plate includes:
❑name and adress of the manufacturer,
❑model year,
❑CE marking means, that the produce conforms
❑version number,
to 2006/42/EC Directive and harmonized standards,
❑machine weight,
❑machine symbol,
❑id number,
❑date of manufacture,
❑barcode.
NOTICE!
It is forbidden to transport the machine on public roads with damaged, illegible or
missing identification plate.
2. INTRODUCTION
❑This operator’s manual is essential for safe and proper use of this mower and should be read before
anyone operates this mower. It should be kept near the mower for future use. If the mower is used
by another operator, it should be in working condition and include this operator’s manual and all
other basic equipment.
❑Operator’s manual is attached to every machine in order that the operator can familiarize himself
with design, working principles, service and adjustment of the mower. The operator should be
familiar with common safety rules and procedures.
❑The mower is manufactured according to international safety rules.
❑Compliance with the safety precautions in this operator’s manual will help to enable safe operation.
❑Please contact your dealer if you have any queries relating to the operation and service of
the mower.
❑This operator’s manual is an indispensable part of any machine and is intended to familiarize future
user with principles of proper operation and use of the machine as well as the risks involvedd.
3. PROPER AND INTENDED USE
Light class rear disc mowers SAMBA are designed to operate on smaller farms, and are used for
mowing standing grass: common grass, medick, etc. on meadows and on stone free fields as well as
forming swath out of these. They do well in mountainous as well as swamp areas, where the machine's
and tractor's weight is of great importance. Application of innovative suspension assembly allows for
adjusting optimal pressure of cutter bar onto the ground.
Meadows or fields to be mowed should be even, previously prepared by rolling and other
processing.

6
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
WARNING!
Use of the mower for purposes other than mentioned herein is forbidden.
Different use than the above mentioned shall be considered as improper and
may lead to revoking of the warranty. The mower should be operated,
maintained and repaired only by personnel who are familiarized with its detailed
specifications and safety rules and procedures. Willful modifications to the
mower may lead to revoking the warranty.
Tab. 1. Mowing heights depending on cutter bar and its inclination angle
„Lite Cut” Cutter bar
No tilt
2° tilt
Standard mowing height
Cutting height setting increased for about 20 mm
Cutting height setting increased for about 25 mm
Cutting height setting increased for about 30 mm
NOTE: Grass, which has not grown much should be mowed with zero angle inclination.
NOTICE:
SAMBA mowers are not fully resistant to stones and therefore when operating on a stony field,
it is highly likely, that discs might be replaced frequently or in extreme case, cutter bar might be
seriously damaged, which is NOT COVERED by free warranty servicing

7
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
5
1
2
3
4
7
6
3.1. Technical data
Tab. 2. Technical data
Mower type:
SAMBA 160
SAMBA 200
SAMBA 240
SAMBA 280
SAMBA 320
Working width [ft.in.]
5' 3"
6' 7"
7' 10"
9' 2"
10' 6"
Number of knives [pcs]
8
10
12
14
16
Number of discs [pcs]
4
5
6
7
8
Tractor's PTO rears [rpm]
540
1000
Cooperating tractor power [HP]
from 20
from 30
from 45
from 60
from 75
Operating capacity [ac/h]
~ 3.7
~ 5.0
~ 6.2
~ 7.4
~ 8.6
Transport height [ft.in.]
7' 5"
5' 3"
9' 10"
11' 2"
12' 4"
Transport length [ft.in.]
5' 10"
Transport width [ft.in.]
5' 7"
Width after aggregation [ft.in.]
12' 1"
12' 12"
13' 11"
14' 9"
16' 4"
Weight [kg/lbs.]
410 / 903
445 / 981
490 / 1080
505 / 1113
560 / 1235
Cutting speed of knife [m/s]
83
Rotational speed of discs [rpm]
3115
3-point linkage category
I/II
II
Noise level LpA
77,0 ± 3,0 dB
LAmax
76,0 ± 3,0 dB
LCpeak
98,5 ± 3,0 dB
LpA –noise level related to 8 hour working time. Averaged in time acoustic pressure level corrected by
frequency characteristic A.
LAmax –maximum value corrected by frequency characteristic A of acoustic pressure level.
LCpeak –peak level of acoustic pressure corrected by frequency characteristic C.
3.2. Design and operating principle
Fig. 2. Overview of rear disc mower SAMBA
1 –Linkage
2 –Cylinder with support spring
3 –Belt gear
4 –Cutter bar
5 –Swath guide
6 –Safety guard
7 –3-point linkage frame

8
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
Linkage (1) allows mounting mower on tractor's 3-point linkage. Drive from tractor's PTO is
transmitted by belt gear (3) onto LiteCUT cutter bar (4). Hydraulic lifting cylinder (2) fed from the tractor
external hydraulics is used to adjust the mower to working position. 3-point linkage frame (7), onto
which spring suspended cutter bar is set. The frame has also swath guides (5), which are standard-
delivered, optional disc type guides (7) and protective guard (6).
3.3. Standard equipment and spare parts
Mowers are sold with the following standard equipment:
❑warranty card,
❑operator's manual with spare part list and declaration of conformity,
❑cutting knives: extra set,
❑knife mounting lever,
❑PTO shaft with overrunning clutch,
❑spray paint (150 ml).
Optional equipment (on extra charge):
❑warning triangle,
❑topping skids,
❑double rubber guide.
NOTICE:
Optional extra equipment should be ordered separately.
Tab. 3. Recommended PTO shaft
Mower
Power
Length
Momentum
Ref
Clutch
Manufacturer
HP
mm / ft. in.
Nm
SAMBA 160
SAMBA 200
SAMBA 240
SAMBA 280
SAMBA 320
35
660-900 /
2'2" - 2'11"
460
7G3N066CE007096MA
Right-hand
overrunning
BONDIOLI& PAVESI
NOTICE:
Lubricate the PTO shaft with high quality multi-purpose grease every 50 shaft operating
hours (Fig. 3). If access holes are accessible, lubricate fittings through access holes.

9
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
PTO shaft end without clutch –
To be mounted on the tractor side
.
PTO shaft end with right
overrunning clutch –To be
mounted from the mower side
Fig. 3. Shaft lubrication instructions. Shaft connection
PTO shafts of other brands with equivalent technical parameters may be used on the SaMASZ
permission.
4. SAFETY PRECAUTIONS
The following precautions are for your safety. They must be read carefully and
followed by every person who operates or maintains the machine. Failure to follow these safety
precautions could result in serious injury or death to the operator, maintenance person or bystanders
and property damage to the machine and surrounding property.
Safety Signal Words
This manual and the safety labels attached to this equipment utilize signal words that signify safety
hazards with different levels of severity. Below are the words used and the definitions for these
words:
❑DANGER indicates a hazardous situation which, if not avoided, will result in death or
serious injury
❑WARNING indicates a hazardous situation which, if not avoided, could result in death
or serious injury
❑CAUTION indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury
❑NOTICE is used to address practices not related to physical injury.
4.1. Safety rules and regulations
The following descriptions are for your safety: They must therefore be read
carefully and applied every time you use the machine.
❑The machine has been designed for use by one single operator.
❑When using, servicing, repairing, moving or storing the machine, the operator must wear safety
footwear, safety gloves plus ear protection and dusk mask if necessary.

10
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
❑During use, the machine may give rise to dust, especially if the soil is dry. You are advised to use a
tractor with a cab fitted with filters in the ventilation system. Failing this, wear a dust mask with
filter to protect your respiratory tract
❑Front axis of the tractor should be weighted to keep the balance. If need be, use front wheel weights.
❑In order to keep steering conditions, impact on front axis should be at least 20% of the complete
tractor.
❑Be extremely careful whenever using hydraulic lift lever or buttons. Any operation with hydraulic lift
lever should be done from operator’s seat; DO NOT move the lever from outside of a tractor.
❑In case of tractors equipped with EHR, operating with hydraulic lift is done by the buttons mounted
outside the tractor’s cabin. When operating be extremely careful.
❑When switching from mowing to transport position, remove the entire PTO shaft or at least one end
of the shaft from the tractor’s PTO so it cannot turn.
❑When attaching the mower to a tractor, the operator should wear protective gloves.
❑DO NOT operate the mower unless all safety guards are in place and operational. In addition, any
damaged protective aprons should be replaced with a new one
❑Start mowing only when the tractor's spline shaft reaches its nominal value of 540 rpm (for: SAMBA
160, 200, 240, 280) or 1000 rpm (for: SAMBA 320).
❑DO NOT exceed value of 600 rpm (for: SAMBA 160, 200, 240, 280) or 1050 rpm (for: SAMBA 320
for spline shaft.
❑No person (except operator) should stand within danger area which is a minimum of 170' from any
operating part, especially when operating near roads and in areas with stones and other debris. Be
certain that children and animals are at a safe distance away from the machine.
a) IMPORTANT: Maintenance and adjustment should ONLY be done after the following has
occurred:
❑tractor’s engine has been stopped and ignition key has been taken out,
❑all rotating parts have come to complete standstill (NOTE: cutting knives will rotate for
several minutes after engine is turned off),
❑the cutter bar is on the ground, and
❑Never tamper with or remove safety devices on the machine or make them inoperable.
1. Before starting work and periodically thereafter, replace any damaged, missing and/or worn knives
and knife holders.
2. When driving on public roads always comply with local traffic regulations, especially those
concerning warning lights.
3. When the mower is lifted for repair on 3-point linkage, it should be secured against falling by
mechanical support or by chain.
4. The bolts and other fasteners have to be periodically checked and, if necessary, tightened or
replaced. DO NOT work with damaged or worn fasteners.
5. Never lift the mower on tractor linkage when the drive is operating and the cutting discs are rotating.
6. When operating the mower, the tractor should always be equipped with operator protection that is
required by laws and regulations.
7. Never start the mower when the mower blades are off the ground.
8. Before you start the tractor make sure that all drives are turned off and the levers that turn the
hydraulics are in neutral position.

11
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
9. Never leave tractor’s engine running without supervision. Before you leave the tractor, turn off the
engine and remove the key from tractor’s ignition.
10. DO NOT operate the mower when driving the tractor backwards.
❑Permissible inclination of the mower on a slope when working and during transport is 8°. Exceeding
this incline can result in mower tipover.
❑Never stand between tractor and mower unless tractor and mower are secured against moving by
the tractor’s brake.
❑If any maintenance must be done under an elevated mower, it must be blocked or otherwise secured
against falling.
❑When the parts of the mower need replacement, use only original spare parts as described in the
spare parts list. Pay particular attention to PTO shaft’s guards and mower’s and tractor’s spline
shaft guards.
❑Hydraulic hoses are potentially very dangerous. Do the following to minimize any hazards:
1. Hydraulic hoses should be periodically checked and if any damage to the hoses
have occurred or if they have been used more than 5 years, replace with new ones.
2. Never use scotch tape to repair hydraulic hoses.
3. When connecting hydraulic hoses to tractor’s hydraulic connectors, make sure that
the tractor’s or mower’s hydraulic system is not under pressure.
❑The mower should be stored under roof and in manner that effectively prevents animals and persons
from being injured.
❑Operating without safety guards is not permitted. Neither operation with damaged or raised guard
is permitted (danger of stones, etc. being thrown out). Damaged protective apron should be
replaced with a new one.
❑When operating the mower, control damages to structures, protective aprons, chains, rubber
elements and if need be, replace these with new ones, even not completely worn out elements.
❑Before carrying out any maintenance works, assembly, disassembly or parking, place the machine
on firm ground and secure it against unintentional movement.
❑During repair and maintenance work it is mandatory to use personal protective equipment (PPE) in
the form of protective clothing, protective gloves, safety shoes and safety glasses.
❑In case of a fatal failure, stop the machine's drive, turn the tractor's engine off and take out the
ignition key. Then call for technical service, and if an accident (in this case: road accident) occurs,
respect first aid rules and contact responsible authorities.
❑Mower should be kept clean, so as to avoid danger of fire.
❑Do not leave agricultural machinery on slopes or other descents without providing protection
against its free runaway.
❑It is forbidden to ride on the mower or to transport any kind of thing on it.
❑The operator is not allowed to leave the tractor while driving.
❑When used in storm, the machine is exposed to lightning.
4.2. Qualifications of operator
To provide safe machine operation each person being the machine operator must meet the
following requirements:
❑Operator should hold driving license, have ability to drive vehicles safely and know road traffic
rules.

12
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
❑Operator must be in proper physical condition to be able to operate the machine.
❑Operator must not be under the influence of alcohol, drugs and medicines, which all have
influence on vehicle driving and machine operation.
❑Operator should be familiarized with this manual and follow its provisions.
❑Operator should be familiar with working principles of both the tractor and the machine, and be
able to recognize and avoid hazards resulting from operation of the aggregate.
4.3. Conditions of mounting mower on tractor
❑Prior to the mounting operation, check whether the tractor's and the mower's hitch categories are
compatible and make sure that tractor's hitch load is adequate for the machine aggregated.
❑When mounting the machine, examine technical condition of the mower's hitch assembly
and tractor's 3-point linkage.
❑Use only genuine pins and cotters to mount the mower on a tractor.
❑Once the machine is mounted on tractor check stability and manoeuvrability of the latter. Load on
the front axle should be approx. 20% of the weight of tractor. Otherwise, ballast front of the tractor.
4.4. Transport
The lifting, handling and transporting operations can be very dangerous unless they are carried out with
the utmost caution. Have all persons not involved in the actual work move away from the area and limit
the zone where the operations are to be carried out. Also make sure that the area in which the
operations take place is clear and that there is a sufficient escape route, i.e. a free, safe zone to which
the operators can quickly move if the load should fall.
The safety hooks and ropes used to lift the machine must be of an adequate carrying capacity.
To minimize the risk of serious injury or death, do the following:
❑When the machine is converted from the transport position to the work position and vice versa, you
could be pinched or crushed by some of its parts. Take extra care when carrying out these
maneuvers and have all persons keep well clear of the danger zone.
❑Do not change position of the mower until there are no people or animals around (pay particular
attention to children).
❑While transporting the mower, put a warning plate with warning triangle on the mower.
❑During transport, always put the mower in its proper and safe transport position. See section 5.2.
❑Before putting the mower in transport position, make sure that the tractor’s PTO is turned off and
all rotating parts have come to a complete stop.
❑Do not drive over 25 km/h (15 mph). Drive slower if road conditions are poor, especially on irregular
surfaces or steep slopes.
❑The behavior of the tractor on the road, such as its turning and braking capacities, are affected by
the implements mounted.
❑When driving on the road after work, check to make sure that the tires and soil working tools are
clean to prevent the road surface from becoming dirty.
❑Make sure that the machine is not damaged during transport.
4.4.1. Loading the mower onto another vehicle for transport
The driver and the carrier are responsible for the mower’s transport safety. Equipment and parts must
be secured during transport. To put the mower onto another vehicle in a safe way, please obey the
following rules:

13
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
❑Transport should be done by qualified and specifically trained personnel,
❑Grab the mower by any lifting devices only in places indicated by hook sign (Fig. 4),
❑For mower lifting, use only lifting devices with hoisting capacity larger than mower’s weight shown
in data plate. This also applies to ropes and chains used for lifting,
❑Do not lift if transport belts, belt suspensions, ropes are damaged. Whenever damage to these
parts occurs, replace with new ones,
❑When mounting slings, chains, handles etc., always set the machine's center of gravity properly,
❑To safely support the machine, use ropes of adequate length so that the angle between them is no
greater than 120°, and the angle between the strand and the vertical is no greater than 60°,
❑Lift the machine with the utmost caution and move it slowly,
❑No one should be within the range of action of the lifting equipment when any transporting
operations are being carried out,
❑Collapsible parts should be blocked in transport position,
❑When the mower is on the vehicle’s trailer, the machine should be secured against moving.
Fig. 4. Transport holders
NOTICE:
Securing both the danger area and activity performed shall lie under the responsibility
of the person in charge of the mower transporting.

14
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
Fig. 5. Location of center of gravity for SAMBA mowers
Tab. 4. Location of center of gravity
Dimension
[ft. in]
Mower type
SAMBA 160
SAMBA 200
SAMBA 240
SAMBA 280
SAMBA 320
A
1' 8"
1' 8"
1' 8"
1' 8"
1' 8"
B
2 ½"
3"
8"
1' 2"
1' 2.4"
C
2' 2"
2' 4"
2' 4"
2' 6"
2' 3.6"
4.5. Working parts
❑Before operating the mower, check knife’s and knife holder’s condition.
❑Worn or damaged knives or knife holders should be immediately replaced with new ones.
❑During replacement of working parts, it should be used personal protective gloves.
4.6. PTO shaft
❑Before operating learn provisions found in bar manufacturer's manual placed on the bar.
❑Use only the mower's manufacturer recommended PTO shafts featuring guards in good technical
condition.
❑In order to operate safely use only fully technically fit, undamaged PTO shafts. Damaged PTO shaft
shall be repaired or replaced with new one.
❑Pay particular attention to PTO shaft’s guards and rake’s and tractor’s spline shaft guards. Never
work with damaged guards.
❑Before operation, check all guards (in tractor, machine and the shaft), if they are in place and are
functional. Any worn or damaged guard must be replaced. Damaged or missing guard of drive shaft
may cause serious accident and even death.
❑Possible inclination of the shaft depends on shape and size of the guard. Before operation check if
guards in any position are not damaged or locked.

15
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
❑Always pay attention to the recommended overlap of the PTO shafts in working and transport
positions.
❑Before you start work, you must make sure that the PTO shaft is spinning in the right direction and
that the tractor PTO RPM matches the permissible RPM levels of the machine.
❑When using the power PTO shaft there must be nobody in the danger zone of the rotating telescopic
joint shaft or PTO shaft!
❑The PTO shaft should always be switched off if the tractor/machine aggregate is making too sharp
of a turn or when it is not in use!
4.7. Hydraulic assembly
❑Hydraulic assembly is under high pressure. Hydraulic oil under pressure may penetrate skin and
cause serious injury or death. Skin and eyes should be protected when working around this
assembly.
❑In case of injury caused by a liquid under pressure, call a doctor immediately.
❑Hydraulic hoses can be connected to the tractor's hydraulics provided that both the tractor’s and
the mower's hydraulic assemblies are not under pressure. To remove the pressure from the
hoses, start the tractor's hydraulic valves several times with the tractor off.
❑When looking for oil leaks, do so safely. Use a cardboard card. Do not touch any potential leaks
until the entire hydraulic assembly has been relieved of pressure.
❑It is recommended that the using hydraulic oil should not exceed 10 oil purity class in accordance
with NAS 1638.
When using hydraulic hoses:
❑Avoid stretching the hoses when operating.
❑Do not allow hydraulic hoses to get deflected.
❑Do not expose hydraulic hoses to contact with any sharp edges.
❑If damaged or worn, replace the hoses with new ones.
❑Useful life for hydraulic hoses is 5 years from their production date.
4.8. Residual risk
Despite the fact that SaMASZ, the manufacturer of the mower, has taken great care in the design and
manufacturing of the mower, certain risks during mower operation and maintenance are unavoidable.
A major source of risk that could result in serious injury or death can occur during the performance of
these operations.
Major source of risk follows performance of these operations:
❑operation of mower by minors,
❑operation by individuals who have not read the operator's manual and safety labels,
❑operation of mower by persons under influence of alcohol or other substances,
❑not being cautious during transportation and moving mower during operation,
❑transport of persons who are on the machine,
❑presence of persons and animals within the mower operation range,
❑performing servicing and machine adjustments with the engine on.

16
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
1. Danger of machine entanglement
This risk occurs when (1) changing position of a mower, (2) operating near rotating parts, and (3)
working without safety guards. During operation, maintenance and adjustment, always wear protective
gloves, shoes and clothes without loose parts, belts and so on. Always comply with safety labels placed
on the mower.
2. Danger of injury, abrasion and damage of skin
This risk occurs during replacement of working parts with sharp edges, cleaning the machine and
removal of any clogging and jams. For any repair and maintenance works always wear safety gloves.
3. Danger of injury from liquid ejection out of hydraulic system
During connection of hydraulic hoses to hydraulic connectors, be sure that tractor’s or mower’s
hydraulic system is not under pressure. Regularly check hydraulic hoses for leaks.
4. Forbidden actions
During mower’s operation, do not do the following:
❑never unblock the mower, make any regulations or repairs of the mower while it is in motion,
❑never change order of operation and maintenance activities described in operator’s manual,
❑never operate the mower when it is not in working order or has damaged safety guards,
❑never get your hands and legs close to rotating parts of the mower,
❑during repair and maintenance of the mower, always comply with descriptions included in operator’s
manual. Always do these activities when the tractor’s drive is off,
❑never operate the mower under influence of alcohol, drugs, or strong medicine that impair your
attention,
❑do not wear jewelry or clothes that are too loose or too tight. Too loose clothing or jewelry may be
pulled in by the rotating parts of the mower,
❑the mower should not be operated by children or by handicapped people,
When describing residual risk, the mower complies with the state of the art in technology on the date it
was manufactured.
WARNING!
Despite following the specified instructions and prohibitions, residual risk is still
present.
5. Residual risk assessment
Residual risk occurs from not complying with the instructions and safety precautions. Such risk can
be minimized by doing the following:
❑thorough familiarizing yourself with operator’s manual,
❑allow no persons on the machine when operating,
❑allow no persons within the mower operation range,
❑adjust, maintain and lubricate the machine with the engine off,
❑only skilled persons should perform repairs of the machine,
❑children and strangers must keep away when the machine is operating.

17
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
When the risk of exposure to noise cannot be avoided or eliminated by any
protective means or organization of work, the employer (farmer) must:
1) provide the operator with individual means of noise protection if the noise level
in work place exceeds 80 dB.
2) provide the operator with individual means of noise protection and supervise
the correctness of its usage, if the noise level in work place reaches or exceeds
85 dB.
4.9. Safety decals and their meaning
Safety labels are critical to safe use of this mower. They must be read, understood and followed.
Also, be sure that:
❑All warning decals are clean and legible,
❑All lost or damaged decals are replaced by ordering new decals from your dealer or supplier,
❑All persons using this mower have read the section of this manual explaining the meanings of these
labels,
❑All spare part used for repair of the mower should have all safety labels provided by the
manufacturer.
N-01
Be extremely careful when
PTO shaft is rotating
N-02
Remark: cutting knives!
Do not get near to the
operating mower
N-03
Prior to operation
commencement read the
operator's manual
carefully
N-04
Prior to approaching any
maintenance or repair works,
turn the machine off
N-05
Remark: belt gear, keep
particular attention
N-06
Remark: pulling-in parts
N-07
Operating the mower is
forbidden with presence of
any unauthorized personnel
within the danger area
of 50 m / 170 ft
N-11
Lubrication points

18
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
N-28
(For: SAMBA 320)
N-14
N-15
N-29
(For: SAMBA 160, 200, 240, 280)
N-23
Watch out!
Power lines
N-40
Catching point when
relocating mower
N-32
(For: SAMBA 240, SAMBA 280,SAMBA 320)
N-48
Nie dotykać elementów
maszyny przed
zatrzymaniem się jej
wszystkich zespołów
N-49
Nie zajmować miejsca
wpobliżu cięgien
podnośnika podczas
sterowania podnośnikiem
N-50
Nie przebywać w polu
wychylenia kosiarki
N-55

19
OPERATOR’S MANUAL
REAR DISC MOWERS
SAMBA
N-65 (For: SAMBA 160, SAMBA 200)
N-63
N-162
N-109
N-117
Avoid contact with liquid
coming out under pressure
N-155
N-167
Do not get onto guardrails
or protective guards
N-168
Do not touch machine parts
until all of its assemblies are
stopped
N-224
Do not open and remove
safety guards with motor
operating
N-52
Hand protection
must be worn
N-100
Eye protection
must be worn
N-101
Protective clothing
protection
must be worn
N-102
Head protection
must be worn
N-103
Hearing protection
must be worn
N-104
Foot protection
must be worn

20
SAMBA
REAR DISC MOWER
OPERATOR’S MANUAL
Fig. 6. Location of warning decals on mower
NOTICE:
Any spare part used for repair of the mower should have all warning decals provided
by the manufacturer.
5. OPERATION
WARNING!
Before beginning to use this machine, do the following:
❑Read manual, especially safety precautions in section 4.
❑Make sure you are familiar with all controls and functions.
❑Make sure all safety devices are in place and working. Fix or replace if not
working or damaged.
❑Replace protective cover if damaged.
5.1. Attaching the mower to the tractor
WARNING!
❑Only hitch and unhitch machine on a flat surface with compact dirt.
❑Keep everyone away from area between mower and tractor.
❑Be careful near link road zone of tractor's rear power lift. Contains sharp parts.
❑Any accidental maneuvering with the set may cause to crushing of
unauthorized personnel.
The mower is connected to the tractor’s 3-point-linkage Fig. 8.
In order to mount the mower to the tractor:
❑Carefully drive the tractor up to the mower rods,
❑Place the mower pins (A) in the tractor lower rods hooks (W),
❑Adjust spacing of the mower pins to the width of the tractor lower links,
❑Secure the adjustable pin with the bolt (R), next counter-screw the mounting with a nut (Fig. 7).
N-01; N-02; N-03; N-04; N-05; N-06 N-07;
N-23; N-48; N-49; N-50; N-117 N-167;
N-168; N-224
N-14; N-15; N-63; N-162
N-155
N-49
N-32/ N-65
N-28/ N-29
N-40
N-40
N-109
N-52; N-100
N-101; N-102
N-103; N-104
