Samsung DCS-816 Operating and maintenance instructions

B
DCS-816
DIGITAL COMMUNICATION SYSTEM
for Europe
GENERAL
DESCRIPTION

B
SAMSUNG ELECTRONICS CO. LTD.
Publication Information
Samsung Electronics reserves the right without prior notice to revise information in this publication for any
reason.
Samsung Electronics also reserves the right without prior notice to make changes in design or components
of equipment as engineering and manufacturing may warrant.
Copyright 1999
Samsung Electronics Co. Ltd
All rights reserved. No part of this manual may be reproduced in any form or by any means - graphic,
electronic or mechanical, including recording, taping, photocopying or information retrieval systems -
without express written permission of the publisher of this material.
March/99

SAMSUNG General Description
DCS-816 March 1999
i
Table of Contents
PART 1. SYSTEM OVERVIEW ......................................................................................1 - 1
1.1 Introduction ........................................................................................................................................ 1 - 1
1.2 Size and Configuration....................................................................................................................... 1 - 2
1.3 Technology ........................................................................................................................................ 1 - 4
1.4 Programming ..................................................................................................................................... 1 - 4
PART 2. HARDWARE DESCRIPTIONS ........................................................................2 - 1
2.1 Basic Key Service Unit....................................................................................................................... 2 - 1
2.2 Option Cards...................................................................................................................................... 2 - 2
2.3 Trunk Expansion Cards ..................................................................................................................... 2 - 2
2.4 Specifications..................................................................................................................................... 2 - 3
PART 3. STATION EQUIPMENT ...................................................................................3 - 1
3.1 LCD 24B Model Keyset (Figure 3-1).................................................................................................. 3 - 1
3.2 STD 24B Model Keyset (Figure 3-2).................................................................................................. 3 - 1
3.3 LCD 12B Model Keyset (Figure 3–3) ................................................................................................. 3 - 2
3.4 STD 12B Model Keyset (Figure 3-4)................................................................................................. 3 - 2
3.5 Enhanced 6B Model Keyset (Figure 3-5)........................................................................................... 3 - 3
3.6 DS-2100B Model Keyset (Figure 3-6)................................................................................................ 3 - 3
3.7 Door Phone Interface Module (DPIM) and Door Phone (Figure 3-7) ................................................ 3 - 4
3.8 CTI Interface Module (CTM-TAPI) (Figure 3-8)................................................................................. 3 - 4
PART 4. FEATURES......................................................................................................4 - 1
4.1 System Features................................................................................................................................ 4 - 1
4.2 System Feature Descriptions............................................................................................................. 4 - 2
4.3 Station Features………… ................................................................................................................ 4 - 17
4.4 Station Feature Descriptions ........................................................................................................... 4 - 17
4.5 Display Features .............................................................................................................................. 4 - 23
4.6 Display Feature Descriptions ........................................................................................................... 4 - 23
FIGURES
1-1 DCS-816 System Configuration Table
1-2 DCS-816 System Configuration
2-1 DCS-816 Key Service Unit
3-1 LCD 24B Model Keyset
3-2 STD 24B Model Keyset
3-3 LCD 12B Model Keyset
3-4 STD 12B Model Keyset
3-5 ENHANCED 6B Model Keyset
3-6 DS-2100B Model Keyset
3-7 Door Phone Interface Module (DPIM) and Door Phone
3-8 CTI Interface Module (CTM-TAPI)

SAMSUNG General Description
DCS-816 March 1999
1 - 1
PART 1. SYSTEM OVERVIEW
1.1 INTRODUCTION
DCS-816, Digital Communication System, is a digital telephone system designed for small to
medium-sized businesses. The system employs the very latest Digital Signal Processors (DSP)
technology.
DCS-816 is easy to install and maintain, convenient to use and provides a variety of features,
including advanced features such as ISDN and CTI.
DCS-816 provides some interface cards that allow connection to the public telephone network or
private networks. These are generally referred to as trunk cards. Besides the trunk cards, it
provides some option cards for serial interfaces and the Auto Attendant feature. Two types of
telephones can be connected to the system: proprietary digital phones called "keysets" connect to
digital line interface (DLI) ports; standard telephone sets, generally called "single line telephones,"
connect to single line interface (SLI) ports. In addition, DLI station ports are used to connect
peripheral devices such as door phone interface modules (DPIMs) and CTI interface modules.
Miscellaneous circuits are provided to allow such optional features as external paging, music on
hold, background music, general-purpose dry contact and emergency power failure transfer.
All DCS keysets utilise a single PCB with surface-mounted components assuring the highest
product quality and long life. Samsung's customary large, easy-to-read displays and LEDs in the
button (key) design make them much easier to use. In many instances, sophisticated features are
made simple through the use of friendly display prompts or push-on/push-off feature keys.
NOTE:
1. It is not possible to expand from DCS-816 to other DCS systems (e.g. DCS, DCS Compact).
2. DCS-816 cannot accommodate cards from other Samsung digital systems except for the DCS
Compact BRI card.

SAMSUNG General Description
DCS-816 March 1999
1 - 2
1.2 SIZE AND CONFIGURATION
The DCS-816 system consists of the Basic Key Service Unit (KSU), option cards, trunk interface
cards, interface modules and digital keysets. The KSU is a single metal cabinet, and in its basic
form has 16 station ports: twelve (12) keyset ports and four (4) single line telephone (SLT) ports.
Additionally, the KSU contains one (1) trunk expansion slot, two (2) option connections and
miscellaneous circuits: one (1) external page Interface, one (1) general-purpose dry contact and
one (1) music interface selectable to internal built-in music (a melody chip) or external music.
Two types of telephones can be connected to the system: proprietary digital stations called
"keysets" that connect to digital line interface (DLI) ports and standard telephone sets, generally
called "single line telephones", that connect to single line interface (SLI) ports.
The Trunk Expansion slot provides an option to select an analogue trunk card or a BRI card.
The DCS-816 system also has some option cards to provide serial I/O ports or AA facilities.
The Basic KSU has two (2) analogue trunk ports and 16 stations, and the trunk expansion slot
provides a maximum capacity of 10 trunk ports and 16 stations.
The system maximum capacity is as follows:
Stations 16 (12 keysets, 4 SLTs)
ISDN channels 8 (4 BRI ports)
Analogue C.O. lines 10
Music channel 1 (Internal or External)
ExternalPage 1
General-purpose Dry Contact 1
Serial I/O ports 2 (DB9 connectors)
Auto Attendant channels 4
CONFIGURATION NOTES
1. No KDbs (keyset daughter-boards for additional DLI or SLI expansion) can be installed.
2. Only one (1) trunk expansion card can be installed.
3. Only one SIO option card and one AA option card can be installed.
4. The system cannot accommodate cards from other Samsung digital systems except for
the DCS Compact BRI card.
5. Every analogue trunk interface contains an interface for MPD or PRS which is optional.
The MPD or PRS hybrid chips of the DCS system can be used.
B
B
BThe DCS-816 system has only one expansion slot dedicated to a trunk expansion card.

SAMSUNG General Description
DCS-816 March 1999
1 - 3
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
DCS-816 System Configuration TableB
B
Trunk Expansion
Card Installed System Configuration
8TRK
616 System (Analogue Trunk)
4 Analogue C.O. Lines (Expansion Card)
2 Analogue C.O. Lines (Basic KSU)
12 Keysets (Basic KSU)
4 Single Line Telephones (Basic KSU)
2BRI
1016 System (Analogue Trunk)
8 Analogue C.O. Lines (Expansion Card)
2 Analogue C.O. Lines (Basic KSU)
12 Keysets (Basic KSU)
4 Single Line Telephones (Basic KSU)
1016 System (Analogue/Digital Trunk)
4 BRI ports (8 channels)
2 Analogue C.O. Lines (Basic KSU)
12 Keysets (Basic KSU)
4 Single Line Telephones (Basic KSU)
Figure 1-1
616 System (Analogue/Digital Trunk)
2 BRI ports (4 channels)
2 Analogue C.O. Lines (Basic KSU)
12 Keysets (Basic KSU)
4 Single Line Telephones (Basic KSU)
4TRK
4BRI

SAMSUNG General Description
DCS-816 March 1999
1 - 4
DCS-816 System Configuration
CONFIGURATION NOTES
1. No KDbs (keyset daughterboards for additional DLI or SLI expansion) can be installed.
2. Only one (1) trunk expansion card can be installed.
3. Only one SIO option card and one AA option card can be installed.
4. The system cannot accommodate cards from other Samsung digital systems except for
the DCS Compact BRI card.
5. Every analogue trunk interface contains an interface for MPD or PRS, which is optional.
The MPD or PRS hybrid chips from the DCS system can be used.
B
Figure 1-2

SAMSUNG General Description
DCS-816 March 1999
1 - 5
1.3 TECHNOLOGY
SWITCHING
System switching is accomplished by means of a custom IC "engine" that provides 256 switchable
digital channels. The engine is controlled by its own 16-bit MotorolaMC 68000 microprocessor
and switching control program. Each of the 256 digital channels is automatically assigned to carry
voice or data as required by system operation in a PCM format.
In addition to the 256 channels mentioned above, the system also utilises Digital Signal
Processors (DSPs). Each DSP may be configured by the switching control program as a DTMF
sender, a DTMF receiver or as a C.O. tone detector on a per-call basis. DCS-816 is equipped with
one engine chip containing four (4) DSP channels.
The DSP channels are fully shared throughout the system as a common resource.
MEMORY
The systems operate using stored program control. This program is stored in EPROM chips. All
specific customer data is stored in random access memory (RAM) which is protected against the
loss of AC power to the system by an on-board battery backup system.
MICROPROCESSORS
DCS-816 uses distributed processing. The primary system processor is a 16-bit Motorola
MC68000 operating at a clock speed of 8 MHz. Secondary processing is done in some special
cards, such as BRI, and also in the keysets. The digital keyset uses a Hitachi H8 processor for
data communication within the DCS-816.
1.4 PROGRAMMING
DCS-816 is self-configuring. This means that when the power is switched on, the system reads the
types and locations of all installed cards and telephones and assigns default data to them. This
data provides for system operation within seconds after power is switched on. All trunks and
stations are assigned according to the default numbering plan. This numbering plan is flexible and
may be changed to suit customer requirements. The installing technician customises these
default data to meet the end user's requirements.
The systems can be programmed from any LCD display keyset without interrupting system
operation. There are three levels of programming: technician (or system), customer and station.
The technician (system) level has access to all programs and can allow the customer access to
system programs as needed. Technician and customer access is controlled by different security
passcodes and access procedures.
DCS-816 also allows the use of a proprietary computer program called PCMMC. This permits a
technician to program the system using a personal computer. PCMMC can be used on-site to
modify the customer database or to download (save) the entire customer database to a file. This
file can then be saved as a backup and be uploaded when required to restore the database.
Through the use of modems, PCMMC can access a DCS-816 system remotely (off-site) to make
database changes or perform uploads or downloads of the customer database as if the technician
were on-site.

SAMSUNG General Description
DCS-816 March 1999
2 - 1
PART 2. DCS-816 - HARDWARE DESCRIPTIONS
2.1 Basic Key Service Unit
The DCS-816 Key Service Unit
(KSU, Figure 2-1) is a single metal
cabinet containing the following:
• A power supply
• Processing, memory and switching:
CPU (68EC000), 2 Mbyte program memory,
256 Kbyte data memory with a backup super
capacitor, real-time clock
• Two (2) analogue C.O. line interfaces with
connections for PRS or MPD chips.
• Twelve (12) digital keyset interfaces
• Four (4) single line telephone interfaces
with loop-disconnect facilities
• One (1) Internal Music source or an External
Music interface for Music-on-Hold and Back-
ground Music
• One (1) External Page interface
• One (1) general-purpose dry contact
• Two (2) Power Failure Transfer relays. Two (2) pre-assigned analogue trunk lines will be
automatically transferred to station 15 and station 16 respectively in case of power failure.
Which analogue trunk lines are to be transferred must be decided by the installer
• A 1.5W sinusoidal ring generator for single line telephones
• One (1) trunk expansion slot, one (1) SIO option connection for SIO1 and one (1) AA option
connection
• One (1) champ connector and one (1) RJ-45 connector for external connections and other
connectors for the Power Supply Unit and the external backup battery.
Figure 2-1

SAMSUNG General Description
DCS-816 March 1999
2 - 2
2.2 OPTION CARDS
B
SIO Option Card
Two dedicated connectors in the Basic KSU are for the SIO option card. The SIO1 option card
contains two (2) RS232C serial interfaces with DB9 connectors for connection to a personal
computer, a printer or a modem. They are for SMDR or PCMMC. One per system.
AA Option Card
The AA option card is equipped with 4-channel built-in AA. There are two dedicated connectors in
the Basic KSU for the option card. The card has its own processor, 68EC000, 64 Kbyte program
memory, 512 Kbyte pre-recorded message memory, 1 Mbyte data and customer message
memory and a DSP chip for AA processing. One card per system.
2.3 TRUNK EXPANSION CARDS
Only one slot is available for trunk expansion.
4TRK Card
The 4TRK card provides four (4) analogue C.O. interfaces. Each interface contains an interface
for MPD or PRS, which is optional. The MPD or PRS hybrid chips from the DCS system can be
used.
8TRK Card
The 8TRK card provides eight (8) analogue C.O. interfaces. Each interface contains an interface
for MPD or PRS, which is optional. The MPD or PRS hybrid chips from the DCS system can be
used.
2BRI Card
The DCS-816 system accommodates the 2BRI card from the DCS Compact system, which
contains two (2) basic rate access ports, i.e. four (4) ISDN channels. Protocol is compatible with
Euro-ISDN BRI.
4BRI Card
The DCS-816 system accommodates the 4BRI card from the DCS Compact system, which
contains four (4) basic rate access ports, i.e. eight (8) ISDN channels. Protocol is compatible with
Euro-ISDN BRI.
B
NOTE: DCS-816 cannot accommodate interface cards from other DCS systems (i.e. DCS, DCS
Compact I, or DCS Compact II) except for the DCS Compact BRI cards.

SAMSUNG General Description
DCS-816 March 1999
2 - 3
2.4 SPECIFICATIONS
The following tables provide technical data for the DCS-816 hybrid/key telephone system.
ELECTRICAL SPECIFICATIONS
AC INPUT 220 VAC ±20%, 48-63 Hz
POWER CONSUMPTION (MAX) 60 WATTS MAX
DC OUTPUT FUSE RATING 2.0 AMP
+5 VOLTS 1.5 AMPS MAX
-5 VOLTS 0.5 AMPS MAX (on the base board)
-55 VOLTS 0.7 AMPS MAX
-54 VOLTS 0.4 AMPS MAX
DIMENSIONS AND WEIGHTS
HEIGHT WIDTH DEPTH WEIGHT
(mm) (mm) (mm) (kg)
BASIC KSU 465 315 120
DIGITAL KEYSET (12/24B MODELS) 108 216 229 1.2
DIGITAL KEYSET (DS-2100B) 88 155 215 0.6
DOOR PHONE [phone]
DOOR PHONE INTERFACE MODULE (DPIM) 29 90 120 0.2
CTI INTERFACE MODULE 29 90 120 0.2
ENVIRONMENTAL LIMITS
OPERATING TEMPERATURE 0 - 40 °C
STORAGE TEMPERATURE -10.5 - 70 °C
CABLE REQUIREMENTS
EQUIPMENT CABLE AWG MAX FEET MAX METRES
DIGITAL KEYSETS 1 PR. TWISTED 24 1300 400
SINGLE-LINE STATION 1 PR. TWISTED 24 3000 1 KM
DOOR PHONE 2 PR. TWISTED 24 330* 100
CTI INTERFACE MODULE 1 PR. TWISTED 24 1300 400
*This is the maximum length of the cable between the door phone and the DPIM. The DPIM can
be installed up to 250 cable metres from the KSU.
Details of system tones may differ as specified by local regulations
SYSTEM TONES
TONE FREQUENCIES CADENCE
DIAL TONE 350 + 440 Hz CONTINUOUS
RING BACK TONE 440 + 480 Hz 1 sec on + 3 sec off
BUSY TONE 480 + 620 Hz 0.5 sec on + 0.5 sec off
DND/NO MORE CALLS 480 + 620 Hz 0.25 sec on + 0.25 sec off
ERROR TONE 480 + 620 Hz 0.25 sec of each tone
CONFIRMATION TONE 350 + 440 Hz Three bursts of tone: 0.1 sec on + 0.1 sec off
TRANSFER/CONF 350 + 440 Hz 0.1 sec on + 0.1 sec off

SAMSUNG General Description
DCS-816 March 1999
2 - 4
KEYSET LED INDICATIONS
CONDITION LED COLOUR LED ON LED OFF
LINE IDLE OFF - OFF
LINE IN USE RED/GREEN STEADY -
RECALL AMBER 500 ms 500 ms
CALL ON HOLD RED/GREEN 500 ms 500 ms
RINGING C.O. CALL RED/GREEN 100 ms 100 ms
RINGING INTERNAL CALL GREEN 100 ms 100 ms
DND INDICATION RED 100 ms ON/100 ms
OFF for 500 ms
500 ms
RESERVE POWER DURATION ESTIMATES (minutes)*
UPS CAPACITY IN VOLT AMPS (VA)
NO. OF STATIONS 250 400 450 600 900 1250 2000
*These are approximate values based on an idle system. The greater the C.O. line activity on the
system, the lower these readings will become. In addition, specific UPS devices, due to their
internal construction, can have greater or lesser values.

SAMSUNG General Description
DCS-816 March 1999
3 - 1
PART 3. STATION EQUIPMENT
3.1 LCD 24B Model Keyset (Figure 3-1)
• Built-in speakerphone
• 24 programmable soft keys (16 with tri-coloured LEDs)
• Eight fixed-function keys
• 32-character display (2 x 16) with three associated soft keys and a scroll key
• UP/DOWN keys for digital control of speaker, handset and ringer volumes
• Eight selectable ring tones per keyset
• Desk-mounted or wall-mounted
• Available in dark grey
3.2 STD 24B Model Keyset (Figure 3-2)
• Built-in speakerphone
• 24 programmable soft keys (16 with tri-coloured LEDs)
• Eight fixed-function keys
• UP/DOWN keys for digital control of speaker, handset and ringer volumes
• Eight selectable ring tones per keyset
• Desk-mounted or wall-mounted
• Available in dark grey
Figure 3-1 Figure 3-2

SAMSUNG General Description
DCS-816 March 1999
3 - 2
3.3 LCD 12B Model Keyset (Figure 3-3)
• Built-in speakerphone
• 12 programmable soft keys (6 with tri-coloured LEDs)
• Eight fixed-function keys
• 32-character display (2 x 16) with three associated soft keys and a scroll key
• UP/DOWN keys for digital control of speaker, handset and ringer volumes
• Eight selectable ring tones per keyset
• Desk-mounted or wall-mounted
• Available in dark grey
3.4 STD 12B Model Keyset (Figure 3-4)
• Built-in speakerphone
• 12 programmable soft keys (6 with tri-coloured LEDs)
• Eight fixed-function keys
• UP/DOWN keys for digital control of speaker, handset and ringer volumes
• Eight selectable ring tones per keyset
• Desk-mounted or wall-mounted
• Available in dark grey
Figure 3-3 Figure 3-4

SAMSUNG General Description
DCS-816 March 1999
3 - 3
3.5 Enhanced 6B Model Keyset (Figure 3-5)
• Built-in speakerphone
• 6 programmable keys
• Four fixed-function keys
• UP/DOWN keys for digital control of speaker, handset and ringer volumes
• Eight selectable ring tones per keyset
• Desk-mounted or wall-mounted
• Available in dark grey
3.6 Standard Model Keyset (DS-2100B) (Figure 3-6)
• Built-in speakerphone
• Four fixed-function keys
• UP/DOWN keys for digital control of speaker, handset and ringer volumes
• Eight selectable ring tones per keyset
• Desk-mounted or wall-mounted
• Available in dark grey
Figure 3-5 Figure 3-6

SAMSUNG General Description
DCS-816 March 1999
3 - 4
3.7 Door Phone Interface Module (DPIM) and Door Phone (Figure 3-7)
• The DPIM adapts any DLI circuit for use with the door phone unit
• Commonly used to request entry through locked doors (interior or exterior) or as a room
monitoring box
• Door phone is wall-mounted
• Door phone is weather-proof
3.8 CTI Interface Module (CTM-TAPI) (Figure 3-8)
• Provides RS232 connection via DB9 for CTI
• Connects to any DLI circuit
Figure 3-7 Figure 3-8

SAMSUNG General Description
DCS-816 March 1999
4 - 1
PART 4. FEATURES
4.1 SYSTEM FEATURES
Account Code Entry
Forced
Voluntary
All Call Voice Page
Attention Tone
Authorisation Codes
Forced
Voluntary
Auto Attendant
Automatic Hold
Background Music
Branch Groups
Call Forwarding
All Calls
Busy
No Answer
Busy/No Answer
Follow Me
External
To Voice Mail
Call Hold (Exclusive)
Call Hold (System)
Call Park and Page
Call Pickup
Directed
Groups
Call Waiting/Camp On
Chain Dialling
Class of Service
CLIP
(
Calling Line Identification Presentation
)
Name/Number Display
Next Call
Save CLIP Number
Store CLIP Number
Inquire Park/Hold
CLIP Review List
Investigate
Abandon Call List
CLIP On SMDR
Number To Name Translation
Common Bell Control
Computer Telephony Integration (CTI)
TAPI
Conference
Add On (5 parties)
Unsupervised
Data Security
Direct Dialling Inward (DDI)
Direct In Lines
Direct Inward System Access (DISA)
Direct Trunk Selection
Directory Names
DISA Security
Distinctive Ringing
Door Lock Release (Programmable)
Door Phones
Door Phone Night Ring
Executive Barge–In (Override)
With Warning Tone
Without Warning Tone
Executive/Secretary Pooling
External Music Interfaces
External Page Interfaces
Flash Key Operation
Flexible Numbering
Flexible Ringing
Hot Line
In Group/Out of Group
Incoming Call Distribution
Incoming/Outgoing Service
Individual Line Control
ISDN service
2BRI
4BRI
Least Cost Routing
Live System Programming
Long Line Extensions
Meet Me Page and Answer
Memory Protection
Message Waiting Indications
Microphone On/Off Per Station
Music On Hold–Flexible
Night Service
Automatic
Manual
Night Group
Holiday
Operator Group
Orbit Parking
Overflow
Operator
Station Group
Paging
Power Failure Transfer
Prime Line Selection
Private Lines
Programmable Line Privacy
Programmable Timers
Recalls
Remote Programming–PC
Ring Over Page
Single Line Connections
Speed Dial Numbers
Speed Dial By Directory
Station Hunt Groups
System Alarms
System Directory
Station Message Detail Recording (SMDR) (Call Logging)
Toll Restriction (Call Barring)
Toll Restriction (Call Barring) Override
Tone or Pulse Dialling
Transfer
Trunk Groups
Uniform Call Distribution (UCD/ACD)
Maximum of three Groups
Call Statistics
Agent Statistics
Generic UCD/ACD Statistics
Group Supervisors
Universal Answer
Voice Mail Integration
VPN
Walking Class of Service (WCOS)

SAMSUNG General Description
DCS-816 March 1999
4 - 2
4.2 SYSTEM FEATURE DESCRIPTIONS
Account Code Entry
Station users may enter an account code (maximum 12 digits) before hanging
up from a call. This account code will appear in the last column of the SMDR
printout for that call record. Keyset users may enter this code using an account
(ACCT) key without interrupting a conversation. Single line telephone users
must temporarily interrupt the call by hook–flashing and dialling the feature
access code. Account codes can be up to 12 digits long.
 Forced
When forced, account codes are always verified from a system list of 200
entries. Account codes are always printed on the SMDR report. They can
contain digits 0–9.
 Voluntary
Users may select to enter an account code for any call. Digits can include
0–9, star (*) and #.
All Call Voice Page
Users can page all the internal and all the external paging at the same time by
dialling the All Page code. Keysets may be restricted from making or receiving
pages in system programming.
Attention Tone
To get your attention, a brief tone precedes all page announcements or intercom
voice calls. There are separate programmable duration timers for page and
voice announce tones.
Authorisation Codes
Authorisation codes are used to give permission to make a call. These four digit
authorisation codes can be either forced or voluntary. When used, authorisation
codes will automatically change the dialling station's class of service to the level
assigned to the authorisation code. Authorisation codes may or may not be
programmed to print on SMDR.
 Forced
When a station is programmed for forced authorisation the user must
always enter this code before dialling is allowed. The dialled authorisation
code is verified from a system list of 30 entries.
 Voluntary
Any station user can always enter an authorisation code before they begin
dialling. The dialled authorisation code is verified from a system list of 30
entries.
Auto Attendant
The integrated digital automated attendant option provides four ports per AA
option card. One AA option card per system. Sixteen professionally recorded
prompts inform callers of the progress of their calls. Some examples are: "I am

SAMSUNG General Description
DCS-816 March 1999
4 - 3
sorry. There is no answer", "That station is busy" and "Invalid number. Please try
again". Two minutes of battery–backed random access memory (RAM) provide
up to 48 customer recordings for announcements or greetings. Twelve individual
greeting boxes, each with its own dialling options, allow you to build call routing
branches as needed. Callers are routed through the branches by dialling
extension numbers or single digits.
NOTE
Requires optional hardware and/or software. Ask your dealer for details.
Automatic Hold
While a keyset user is engaged in an outside (C.O.) call, pressing another trunk
key, route key or CALL key automatically places the call on hold when this
feature is enabled. Pressing TRSF, CONFERENCE, PAGE or a DSS key always
automatically places a C.O. call on hold. Intercom calls can be automatically
held only by pressing TRSF or CONFERENCE. Each keyset user can enable or
disable Automatic Hold.
Background Music
Keyset users may choose to hear music through their keyset speakers. Each
user may adjust this level by the use of a volume control program at the selected
keyset.
Branch Groups
Each station can assign its branch group. There are 8 branch groups in DCS-
816. When incoming or intercom call is ringing on station, any other stations that
included the same branch group can answer by lifting the handset or pressing
the speaker or ANS/RLS key.
Call Forwarding
This feature allows the user to redirect (forward) incoming calls. The calls can be
redirected to the attendant, a hunt group, voice mail, external number or another
station user. If the destination station is in Do Not Disturb (DND) mode, the
calling party will receive DND/NO MORE tone. Calls cannot be forwarded to a
door phone.
 All Calls
This type of forwarding is not affected by the condition of the station. All
calls are immediately redirected to the designated destination. If desired,
the destination station may redirect the call back to the forwarded station
by using the transfer feature. The forwarded station user can continue to
originate calls as usual. If no key is programmed as Forward All, the TRSF
key lights steady when a forwarded all condition is set.
 Busy
This feature forwards all calls only when the station set is busy. The station
user can originate calls as usual.
 No Answer
This feature forwards calls that are not answered within a preprogrammed
time. The user can originate calls as usual and receive calls if present. The

SAMSUNG General Description
DCS-816 March 1999
4 - 4
timer is programmable on a per–station basis to allow for differences in
individual work habits.
 Busy/No Answer
This feature allows the station user to use both types of forwarding
simultaneously, provided the destinations have already been entered in the
usual manner.
 Follow Me
This feature allows the station user to forward all calls from another station
to the user's station or change the forward destination to the user's current
location.
 External
This feature forwards C.O. calls to an external number via a central office
trunk if allowed by class of service. These C.O. calls forward only after the
programmable external call forward delay timer expires.
 To Voice Mail
Each station may be programmed to allow or deny the ability to forward
intercom calls to voice mail.
Call Hold (Exclusive)
Outside calls can be placed on exclusive hold at any keyset by pressing the
HOLD key twice during a call. Calls placed on exclusive hold can only be
retrieved at the keyset that placed the call on hold. Intercom calls are always
placed on exclusive hold.
Call Hold (System)
Outside calls can be placed on system hold at any station. Users may dial the
access code or press the HOLD key. Calls on system hold may be retrieved at
any station.
Call Park and Page
Each C.O. line has its own park zone. This simple method eliminates confusion
and ensures that a park zone is always available. Pressing the PAGE key parks
the call automatically. There are no extra keys to press and there is no lost time
looking for a free zone.
Call Pickup
 Directed
With directed call pickup, users can answer calls ringing at any station by
dialling a code plus that station's extension number/incoming trunk number
or by pressing the feature key and then dialling the extension
number/incoming trunk number. You can pick up not only incoming and
intercom call, but also hold recalling call if allowed.
 Groups (8)
In addition, calls can be picked up from a station group in a similar
manner. The group pickup feature allows users to answer any call ringing
within any pickup group. There are 8 pickup groups available. A station
cannot be in more than one pickup group. To use this feature, station
