Sauder Via 419612 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 376693 10/05/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
3-Drawer Pedestal
Via Collection | Model 419612
Get all organized
and stu.

Table of Contents Assembly Tools Required
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
2-3
4-5
6-22
23-25
26-28
29-30
31
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (1)
F DRAWER FRONT (1)
G BASE (1)
H SECURITY SHELF (1)
K SMALL DRAWER FRONT (2)
D78 DRAWER BACK (1)
D109 SMALL DRAWER BACK (2)
D494 RIGHT DRAWER SIDE (1)
D495 LEFT DRAWER SIDE (1)
D496 SMALL RIGHT DRAWER SIDE (2)
D497 SMALL LEFT DRAWER SIDE (2)
D707 SMALL DRAWER BOTTOM (2)
D708 DRAWER BOTTOM (1)
419612 www.sauder.com/servicesPage 2
Part Identification Now you know
our ABCs.
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.

Part Identification
419612www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
K
D78
D109
D494
D495
D496
D497
D707
D708

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
34G INTERLOCK MECHANISM - 1 DRAWER
ACTUATOR - 2
62G
(EXTENSION SET SHOWN SEPARATED)
EXTENSION RAIL - 2
LEXTENSION SLIDE - 2 M
35GA CABINET RIGHT - 2 35GB CABINET LEFT - 2 35GC DRAWER RIGHT - 2 35GD DRAWER LEFT - 2
FILE GLIDE - 2
6B
NON-SWIVEL CASTER - 2
8CN SWIVEL CASTER - 2 8CS
METAL BRACKET - 3
4G
TOUCH-UP PEN - 1
10M
10F TWIST-LOCK®
FASTENER - 12
10A SLIDE CAM - 6
LOCK
BRACKET - 1
5J
LOCK COVER - 1
10J LOCK - 1
16J PULL - 3
12K
419612 www.sauder.com/servicesPage 4
FILE ROD - 2
8B

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 9/16" PAN HEAD SCREW - 3
51S
BLACK 9/16" LARGE HEAD SCREW - 22
1S
SUPPORT PIN - 4
4R
BROWN 7/16" LARGE HEAD SCREW - 1
6S
BLACK 7/8" MACHINE SCREW - 6
37S
3S GOLD 5/16" FLAT HEAD SCREW - 24
METAL PIN - 4
1R
BLACK 1/2" FLAT HEAD SCREW - 8
11S 30S BLACK 1-9/16" FLAT HEAD SCREW - 12
419612www.sauder.com/services Page 5

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
419612 www.sauder.com/servicesPage 6
10F
Do not tighten the TWIST-LOCK®
FASTENERS in this step.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (10F) into the large holes in the ENDS (A
and B), BOTTOM (D), and BACK (E).
10F
10F
A
B
D
E

Step
419612www.sauder.com/services Page 7
Step 2
å Separate the EXTENSION SLIDES (M) from the EXTENSION RAILS (L) as shown in the enlarged diagram below. Be
prepared, the parts are greasy.
å Fasten two EXTENSION RAILS (L) to the ENDS (A and B). Use four GOLD 5/16” FLAT HEAD SCREWS (3S) through holes
#1 and #4.
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged diagram. Then, slide the inner cartridge
of the EXTENSION RAIL in to find the other hole that lines up with the hole in the END. Turn a SCREW into this hole.
å Using your hammer, gently tap four SUPPORT PINS (4R) into the holes in the ENDS (A and B).
å NOTE: Be sure to use the exact holes shown in the ENDS.
Open end
Push the black lever in and pull the SLIDE from the RAIL.
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
4R
A
B
LM
Open end
L
L
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
1
3
2
1
3
2
4
4
This hole
must be here.
This hole
must be here.

StepStep 3
419612 www.sauder.com/servicesPage 8
å Fasten the CABINET RIGHTS (35GA) to the RIGHT END (A)
and the CABINET LEFTS (35GB) to the LEFT END (B). Use
eight GOLD 5/16" FLAT HEAD SCREWS (3S) through holes
#1 and #3.
å Fasten the INTERLOCK MECHANISM (34G) to the RIGHT
END (A). Use three BLACK 9/16" PAN HEAD SCREWS (51S).
1
2
3
1
2
3
Roller end
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
Remember:
Righty tighty.
Lefty loosey.
34G
BLACK 9/16" PAN HEAD SCREW
(3 used in this step)
51S
1
2
3
Roller end
1
2
3
A
B
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
This hole
must be here.
This hole
must be here.

Step
419612www.sauder.com/services Page 9
Step 4
å Fasten the BACK (E) to the LEFT END (B). Tighten
two TWIST-LOCK® FASTENERS. How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Dowel end
B
Roller end
Surface with
TWIST-LOCK®
FASTENERS
E
Surface with
TWIST-LOCK®
FASTENERS
Edge with
TWIST-LOCK®
FASTENERS

Step 5
419612 www.sauder.com/servicesPage 10
B
å Insert four METAL PINS (1R) into the SECURITY SHELF (H).
å Insert the METAL PINS (1R) in one end of the SECURITY
SHELF (H) into the holes in the LEFT END (B).
å Fasten the BOTTOM (D) to the LEFT END (B). Tighten two
TWIST-LOCK® FASTENERS.
1R
H
D
Surface with
TWIST-LOCK®
FASTENERS
This hole must be here.
Surface with hole
Curved edge
(4 used)

å Fasten the RIGHT END (A) to the BOTTOM (D) and
BACK (E). Tighten four TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the SECURITY
SHELF (H) insert into the holes in the RIGHT END.
Step 6
419612www.sauder.com/services Page 11
A
Surface without
TWIST-LOCK®
FASTENERS
Roller end
H
D
Edge with
TWIST-LOCK®
FASTENERS
E

å Fasten the TOP (C) to the ENDS (A and B). Tighten four
TWIST-LOCK® FASTENERS.
Step 7
419612 www.sauder.com/servicesPage 12
B
C
These edges should be even.
A
Surface with holes
This hole must be here.

Step 8
419612www.sauder.com/services Page 13
å Fasten the METAL BRACKETS (4G) to the ENDS (A and B)
and BOTTOM (D). Use three BLACK 9/16" LARGE
HEAD SCREWS (1S).
å NOTE: Be sure the edges of the METAL BRACKETS are
even with the edges of the ENDS and BOTTOM.
å Fasten the BASE (G) to the ENDS (A and B) and BOTTOM (D).
Use three BLACK 9/16" LARGE HEAD SCREWS (1S) through
the METAL BRACKETS and into the BASE.
å Fasten the LOCK BRACKET (5J) to the SECURITY SHELF (H).
Use a BROWN 7/16" LARGE HEAD SCREW (6S).
å NOTE:
Be sure to use the correct screw in the LOCK BRACKET.
B
A
H
D
G
5J
BROWN 7/16" LARGE HEAD SCREW
(1 used for the LOCK BRACKET)
6S
4G
4G
4G BLACK 9/16" LARGE HEAD SCREW
(6 used for the METAL BRACKETS)
1S
Unfinished edge

Step 9
419612 www.sauder.com/servicesPage 14
å Fasten the NON-SWIVEL CASTERS (8CN) to the
BOTTOM (D) exactly as shown. Use eight BLACK 9/16"
LARGE HEAD SCREWS (1S).
å NOTE: The NON-SWIVEL CASTERS will be located closer
to the BASE (G).
å Fasten the SWIVEL CASTERS (8CS) to the BOTTOM (D).
Use eight BLACK 9/16" LARGE HEAD SCREWS (1S).
BLACK 9/16" LARGE HEAD SCREW
(16 used in this step)
1S
8CS
8CN
D
Notch
G
Now might be a
good time to refresh
your drink.

Step 10
419612www.sauder.com/services Page 15
VIEW THE T-LOCK BOX VIDEO
å Fasten the DRAWER BACK (D78) to the DRAWER SIDES (D494 and D495). Use four BLACK 1-9/16" FLAT HEAD
SCREWS (30S).
å NOTE: Be sure the DRAWER BOTTOM (D708) inserts into the groove of the DRAWER BACK (D78).
å Repeat this step for the small drawers using the SMALL DRAWER FRONTS (K), SMALL DRAWER BACKS (D109), SMALL
DRAWER SIDES (D496 and D497), and SMALL DRAWER BOTTOMS (D707).
12
3
å Insert the DRAWER SIDES (D494 and D495) at an angle
into the slot at each end of the DRAWER FRONT (F).
å Slide the DRAWER BOTTOM (D708) into the grooves in the
DRAWER SIDES (D494 and D495) and DRAWER FRONT (F).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Groove
30S
Start each screw a few turns before
completely tightening any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(12 used in this step)
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT groove.
D494
D495
D708
D78
F
Unfinished
surface
With the palm of your
hand, tap the DRAWER
BOTTOM down into
the groove.
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK groove.
D494
D495
F
D708
D494
D495

Step 11
419612 www.sauder.com/servicesPage 16
å Insert a SLIDE CAM (10A) into the DRAWER SIDES (D494
and D495).
å Fasten the EXTENSION SLIDES (M) to the DRAWER
SIDES (D494 and D495). Use four GOLD 5/16" FLAT
HEAD SCREWS (3S) through holes #1 and #4.
å NOTE: Use the exact holes shown in the DRAWER SIDES.
å NOTE: The screw head in the CAM must be visible through
the slotted hole in the SLIDE.
Open end
Open end
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
1
2
3
4
M
M
10A
10A
1
2
3
4
D494
D495

Step 12
419612www.sauder.com/services Page 17
å Insert a SLIDE CAM (10A) into the SMALL DRAWER
SIDES (D496 and D497).
å Fasten a DRAWER RIGHT (35GC) to the SMALL RIGHT
DRAWER SIDE (D496) and a DRAWER LEFT (35GD) to
the SMALL LEFT DRAWER SIDE (D497). Use four GOLD
5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3.
å NOTE: Use the exact holes shown in the SMALL DRAWER SIDES.
å NOTE: The screw head in the CAM must be visible
through the slotted hole in the SLIDE.
å Repeat this step for the other small drawer.
1
2
3
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
(4 screws per drawer)
Roller end
1
2
3
Roller end
D496
D497
10A
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A

Step 13
419612 www.sauder.com/servicesPage 18
å Fasten the PULLS (12K) to the DRAWER FRONTS (F and K). Use
four BLACK 7/8" MACHINE SCREWS (37S).
å Repeat this step for the other small drawer.
å Fasten the DRAWER ACTUATORS (62G) to the RIGHT DRAWER
SIDES (D494 and D496). Use six BLACK 1/2" FLAT HEAD
SCREWS (11S).
å NOTE: Be sure to use the upper set of holes in the RIGHT
DRAWER SIDE (D494) as shown in the diagram.
D494
D496
12K
12K
K
F
62G
BLACK 7/8" MACHINE SCREW
(6 used for the PULLS)
37S
BLACK 1/2" FLAT HEAD SCREW
(6 used for the ACTUATORS)
11S

Step 14
419612www.sauder.com/services Page 19
å Fasten a LOCK (16J) to the DRAWER FRONT (F). Use two BLACK 1/2"
FLAT HEAD SCREWS (11S).
å NOTE: Be sure the metal bar on the LOCK is facing the direction shown.
å Push a LOCK COVER (10J) over the key extension on the LOCK.
F
16J
10J
Metal bar
Key extension
BLACK 1/2" FLAT HEAD SCREW
(2 used in this step)
11S
Be sure the METAL
BAR bends away from
the KEY EXTENSION.

Step 15
419612 www.sauder.com/servicesPage 20
å Push a FILE GLIDE (6B) onto the RIGHT DRAWER SIDE (D494).
å Slide the FILE RODS (8B) into the FILE GLIDE (6B) on the
RIGHT DRAWER SIDE (D494).
å Slide another FILE GLIDE (6B) onto the other end of the FILE
RODS (8B), then press this FILE GLIDE over the LEFT DRAWER
SIDE (D495).
Insert the FILE RODS into
the holes in the FILE GLIDES
depending on your file sizes.
D494
D495
6B
8B
6B
8B
