Sauder 418073 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 369317 03/02/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
4-Drawer Chest
County Line Collection | 418073
You won't lose your
shirt with this one.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
(except where indicated)
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (1)
F FRONT LEG (2)
G BACK LEG (2)
H DRAWER FRONT (4)
I DRAWER BRACE (4)
D50 RIGHT DRAWER SIDE (4)
D51 LEFT DRAWER SIDE (4)
D175 DRAWER BACK (4)
D983 DRAWER BOTTOM (4)
2-3
4
5-18
19-21
22-24
25-26
27
418073 www.sauder.com/servicesPage 2
Now you know
our ABCs.
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.

Part Identification
418073www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
D50
D51
D175
D983
I
F
G

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
418073 www.sauder.com/servicesPage 4
DRAWER FRONT
BRACKET - 4
9G
5L WARNING LABEL - 1
(Refer to step 13 for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically designed to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or hang on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
40DA UNIVERSAL CABINET RAIL - 840DC DRAWER RIGHT - 440DD DRAWER LEFT - 4
SAFETY DRYWALL
ANCHOR - 1
61M
BLACK 9/16" LARGE HEAD SCREW - 17
1S
WASHER - 8
10I
BLACK 2-1/4" FLAT HEAD SCREW - 8
26S
7F TWIST-LOCK®
FASTENER - 8
SILVER 1/4" MACHINE SCREW - 8
61S
3S GOLD 5/16" FLAT HEAD SCREW - 32
CAM SCREW - 12
8F WOOD DOWEL - 2 15F
NAIL - 30
1N
30S BLACK 1-9/16" FLAT HEAD SCREW - 20
HIDDEN CAM - 12
1F
PULL - 4
98K SAFETY STRAP - 1
60M
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
WASHER - 1
13M

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the large holes in the ENDS (A and B)
and BOTTOM (D).
418073www.sauder.com/services Page 5
Do not tighten the TWIST-LOCK® FASTENERS in this step.
7F
A
B
D
7F
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1114
to watch a video on how to assemble your unit.

å Push twelve HIDDEN CAMS (1F) into the ENDS (A and B)
and DRAWER BRACES (I).
Step 2
418073 www.sauder.com/servicesPage 6
Arrow
1F
Arrow
The arrow in the HIDDEN CAM
must point toward the hole in
the edge of the board.
Hole
(12 used)
1F
Arrow
A
B
I
I
I
I

å Turn twelve CAM SCREWS (8F) into the exact holes shown
in the FRONT LEGS (F) and DRAWER FRONTS (H).
å NOTE: Position the LEGS exactly as shown. Be sure to use
the exact holes shown in the diagram.
Step 3
418073www.sauder.com/services Page 7
(12 used)
8F
H
F
F
H
H
H

Step 4
418073 www.sauder.com/servicesPage 8
å Insert two WOOD DOWELS (15F) into the ENDS (A and B).
å Fasten the FRONT LEGS (F) to the ENDS (A and B).
Tighten eight HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the ENDS insert
into the holes in the FRONT LEGS.
15F
15F
1
2
A
B
F
F
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
These surfaces must be even.
These surfaces must be even.

Step 5
418073www.sauder.com/services Page 9
Remember:
Righty tighty.
Lefty loosey.
å Fasten the BACK LEGS (G) to the ENDS (A and B). Use
eight BLACK 2-1/4" FLAT HEAD SCREWS (26S).
A
B
G
G
BLACK 2-1/4" FLAT HEAD SCREW
(8 used in this step)
26S
The LEG should
overhang this edge.
The LEG should
overhang this edge.
These surfaces must be even.

Step 6
418073 www.sauder.com/servicesPage 10
A
B
å Fasten the UNIVERSAL CABINET RAILS* (40DA) to the
ENDS (A and B). Use sixteen GOLD 5/16" FLAT HEAD
SCREWS (3S) through holes #1 and #4.
å *patent pending glide system
3
2
1
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
Glide end
F
3
2
1
4
3
2
1
4
3
2
1
4
F
Glide end
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
