Sauder Manhattan Gate 429256 User manual

sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey!
English pg 1-30
Français pg 31-35
Español pg 36-40
Lot # 565102 04/29/21
Purchased: __________________
Credenza
Manhattan Gate Collection | Model 429256
Store behind
closed doors.

Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4
5
6-30
31-35
36-40
41-42
43
Page 2 www.sauder.com/service 429256

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B RIGHT END (1)
C LEFT END (1)
D SLIDING SHELF (1)
E FIXED SHELF (1)
F UPRIGHT (1)
G UPPER BACK (1)
H LOWER BACK (1)
J BOTTOM (1)
K SKIRT (2)
L SMALL SPACER (2)
M LARGE SPACER (2)
N FILE HANGER (1)
P LEFT DOOR (2)
Q RIGHT DOOR (2)
R PULL (4)
A
B
C
D
E
F
G
H
J
K
K
L
L
M
M
N
P
P
Q
Q
R
R
R
R
Page 3www.sauder.com/service429256

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
(EXTENSION SET SHOWN SEPARATED)
CAM SCREW - 30
3HIDDEN CAM - 30 4
1EXTENSION
RAIL - 4 2EXTENSION SLIDE - 4
SILVER 1/2" FLAT HEAD SCREW - 48
13 BLACK 1/2" FLAT HEAD SCREW - 8 14
3/8" PAN HEAD SCREW - 12
15 1/4" MACHINE SCREW - 6 16
9BUMPER CARD - 1 APPLIQUE CARD - 2
10
LONG WOOD
DOWEL - 44
5SHORT WOOD
DOWEL - 4
6HINGE - 4
7
HINGE -4
8
1-3/4" FLAT HEAD SCREW - 12
11 1" FLAT HEAD SCREW - 12 12
Page 4 www.sauder.com/service 429256

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Page 5www.sauder.com/service429256

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twelve HIDDEN CAMS (4) into the SKIRTS (K)
Sand BOTTOM (J).
å Turn eight CAM SCREWS (3) into the BOTTOM (J).
Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
K
K
J
1
Arrow
4
3
Page 6 www.sauder.com/service 429256
4
Arrow
Arrow
4

å Insert eight LONG WOOD DOWELS (5) into the BOTTOM (J).
å Fasten the SKIRTS (K) to the BOTTOM (J). Tighten eight
HIDDEN CAMS.
å NOTE: Be sure the LONG WOOD DOWELS in the
BOTTOM insert into the SKIRTS.
Step 2
J
K
K
1
5
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Page 7www.sauder.com/service429256
Remember:
Righty tighty.
Lefty loosey.

å Insert two SHORT WOOD DOWELS (6) into the UPRIGHT (F).
å Fasten a SMALL SPACER (L) to the UPRIGHT (F). Use
three 1" FLAT HEAD SCREWS (12).
å NOTE: Be sure the SHORT WOOD DOWELS in the
UPRIGHT insert into the SMALL SPACER.
Step 3
F
L6
1" FLAT HEAD SCREW
(3 used in this step)
12
Page 8 www.sauder.com/service 429256
These holes must be here.

Step 4
Page 9www.sauder.com/service429256
F
1
L
å Separate the EXTENSION SLIDES (2) from the EXTENSION RAILS (1) as shown in the upper diagram below. Be
prepared, the parts are greasy.
å Fasten an EXTENSION RAIL (1) to the SMALL SPACER (L). Use three 3/8" PAN HEAD SCREWS (15).
å NOTE: Turn a SCREW into the hole shown in the enlarged diagram. Then, slide the inner cartridge of the EXTENSION
RAIL in to find the other holes that lines up with the holes in the SMALL SPACER. Turn a SCREW into these holes.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
Open end
3/8" PAN HEAD SCREW
(3 used in this step)
15
1
2
Push the black lever and pull the SLIDE from the RAIL. Use these holes
Open end
7
These holes must be here.

å Flip the UPRIGHT (F) over.
å Push six HIDDEN CAMS (4) into the FIXED SHELF (E) and UPRIGHT (F).
å Turn two CAM SCREWS (3) into the UPRIGHT (F).
å Insert two LONG WOOD DOWELS (5) into the UPRIGHT (F).
å Fasten the FIXED SHELF (E) to the UPRIGHT (F). Tighten two HIDDEN CAMS.
å NOTE: Be sure the LONG WOOD DOWELS in the UPRIGHT insert into the FIXED SHELF.
Step 5
Page 10 www.sauder.com/service 429256
E
4
Arrow
1
E
F5
Surface with
HIDDEN CAMS
These edges must be even.
F
3
Arrow
4

Step 6
Page 11www.sauder.com/service429256
4
Arrow
G
H
å Insert eight LONG WOOD DOWELS (5) into the long edges of the
LOWER BACK (H).
å Push the UPPER BACK (G) onto the LONG WOOD DOWELS (5) in the
LOWER BACK (H).
å Push eight HIDDEN CAMS (4) into the BACKS (G and H).
5
Surface with HIDDEN CAMS
Notch
4
Arrow
Arrow
4

å Carefully place the UPRIGHT (F) and FIXED SHELF (E) onto
the BACKS (G and H) as shown.
å Insert two LONG WOOD DOWELS (5) into the UPRIGHT (F).
å Fasten the BOTTOM (J) to the UPRIGHT (F) and LOWER
BACK (H). Tighten six 1-3/4" FLAT HEAD SCREWS (11).
å NOTE: Be sure the LONG WOOD DOWELS in the LOWER
BACK and UPRIGHT insert into the BOTTOM.
å NOTE: You should start each SCREW a few turns before
completely tightening any of them.
Step 7
J
H
G
E
F
5
Surface without HIDDEN CAMS
Surface with
HIDDEN CAMS
Surface without HIDDEN CAMS
1-3/4" FLAT HEAD SCREW
(6 used in this step)
11
Page 12 www.sauder.com/service 429256

Step 8
B
C
å Push four HIDDEN CAMS (4) into the ENDS (B and C)..
å Turn ten CAM SCREWS (3) into the ENDS (B and C).
3
3
1
4
Arrow
Meet Parts (B and C). These components
have been engineered to be lighter,
stronger, faster… well ok. Not technically
faster. But definitely makes for a sturdier
Credenza that’s easier to assemble and
friendlier to the environment.
Page 13www.sauder.com/service429256

Step 9
5
B
J
H
G
E
å Insert six LONG WOOD DOWELS (5) into the RIGHT END (B).
å Fasten the RIGHT END (B) to the FIXED SHELF (E), BACKS (G and H), and
BOTTOM (J). Tighten six HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the RIGHT END insert into the
FIXED SHELF, BACKS, and BOTTOM.
Page 14 www.sauder.com/service 429256
1

å Insert two LONG WOOD DOWELS (5) into the LEFT END (C).
å Fasten a LARGE SPACER (M) to the LEFT END (C). Use
three 1-3/4" FLAT HEAD SCREWS (11).
å NOTE: Be sure the LONG WOOD DOWELS in the LEFT
END insert into the LARGE SPACER.
å NOTE: You should start each SCREW a few turns before
completely tightening any of them.
Step 10
C
M
5
1-3/4" FLAT HEAD SCREW
(3 used in this step)
11
Page 15www.sauder.com/service429256

Step 11
M
1
C
å Fasten an EXTENSION RAIL (1) to the LARGE SPACER (M). Use
three 3/8" PAN HEAD SCREWS (15).
å NOTE: Turn a SCREW into the hole shown in the enlarged
diagram. Then, slide the inner cartridge of the EXTENSION
RAIL in to find the other holes that lines up with the holes in the
LARGE SPACER. Turn a SCREW into these holes.
Page 16 www.sauder.com/service 429256
Use these holes
Open end
Open end
3/8" PAN HEAD SCREW
(3 used in this step)
15

Step 12
C
5
å Insert four LONG WOOD DOWELS (5) into the LEFT END (C).
å Fasten the LEFT END (C) to the BACKS (G and H) and BOTTOM (J).
Tighten four HIDDEN CAMS.
å NOTE: Be sure the LONG WOOD DOWELS in the LEFT END insert
into the BACKS and BOTTOM.
J
G
H
Surface without holes
Page 17www.sauder.com/service429256
1

å Turn ten CAM SCREWS (3) into the TOP (A).
Step 13
A
3
Part (A). Another
sturdier, easier,
friendlier component!
Page 18 www.sauder.com/service 429256
Now might be a
good time to refresh
your drink.
1

Step 14
A
å Insert ten LONG WOOD DOWELS (5) into the TOP (A).
å Fasten the TOP (A) to the ENDS (B and C), UPRIGHT (F), and UPPER
BACK (G). Tighten ten HIDDEN CAMS.
å NOTE: Be sure the LONG WOOD DOWELS in the TOP insert into the
ENDS, UPRIGHT, and UPPER BACK.
5
B
C
F
G
Page 19www.sauder.com/service429256
1

Step 15
This view is shown for
clarity of the above view.
å Insert two SHORT WOOD DOWELS (6) into the UPRIGHT (F).
å Fasten the remaining SMALL SPACER (L) to the UPRIGHT (F). Use three 1" FLAT HEAD SCREWS (12).
å NOTE: Be sure the SHORT WOOD DOWELS in the UPRIGHT insert into the SMALL SPACER.
å Insert two LONG WOOD DOWELS (5) into the RIGHT END (B).
å Fasten the remaining LARGE SPACER (M) to the RIGHT END (B). Use three 1-3/4" FLAT HEAD SCREWS (11).
å NOTE: Be sure the LONG WOOD DOWELS in the RIGHT END insert into the LARGE SPACER.
å NOTE: You should start each SCREW a few turns before completely tightening any of them.
6
1" FLAT HEAD SCREW
(3 used in this step)
12
5
1-3/4" FLAT HEAD SCREW
(3 used in this step)
11
B
F
M
L
Page 20 www.sauder.com/service 429256
See below for detail
