Sauder 420456 User manual

sauder.com
Dresser
Model 420456
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 531427 07/18/19
Purchased: __________________
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Share your journey!
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-523-3987.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
Table of Contents Assembly Tools Required
3
4
5-18
19-21
22-24
25-26
27
420456 www.sauder.com/servicePage 2

åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Part Identification Now you know
our ABCs.
A2 RIGHT END (1)
B2 LEFT END (1)
C2 UPRIGHT (1)
D TOP (1)
D36 RIGHT DRAWER SIDE (4)
D37 LEFT DRAWER SIDE (4)
D42 SMALL RIGHT DRAWER SIDE (2)
D43 SMALL LEFT DRAWER SIDE (2)
- 1 with label
D165 SMALL DRAWER BACK (2)
D167 DRAWER BACK (4)
D974 DRAWER BOTTOM (6)
E BACK (1)
F BRACE (4)
G2 BASE (1)
H LARGE DRAWER FRONT (4)
I SMALL DRAWER FRONT (2)
J TOP MOLDING (1)
M67
DRAWER BRACE (6)
(Hidden part using recycled
material. Color may vary.)
420456www.sauder.com/service Page 3
A2
B2
C2
D
E
FG2
H
I
J
F
F
FD974
D974
D42
D43
D165
D36
D37
D167
M67
M67

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
420456 www.sauder.com/servicePage 4
SMALL DRAWER
FRONT BRACKET - 2
7G
DRAWER FRONT
BRACKET - 4
9G
35AA UNIVERSAL CABINET RAIL - 12 35AC DRAWER RIGHT - 6 35AD DRAWER LEFT - 6
BLACK 1-1/8" PAN HEAD SCREW - 6
9S
METAL
BRACKET - 7
4G
BLACK 9/16" LARGE HEAD SCREW - 34
1S
SILVER 1-1/8" FLAT HEAD SCREW - 4
10S
3S GOLD 5/16" FLAT HEAD SCREW - 48
TACK GLIDE - 6
13E
NAIL - 45
1N
HIDDEN CAM - 20
1F CAM DOWEL - 20 2F
KNOB - 6
91K
30S BLACK 1-9/16" FLAT HEAD SCREW - 30
FURNITURE TIPPING
RESTRAINT KIT - 1
97

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/service/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twenty HIDDEN CAMS (1F) into the ENDS (A2 and B2),
UPRIGHT (C2), BRACES (F), and DRAWER BRACES (M67).
Then, insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM.
420456www.sauder.com/service Page 5
(20 used)
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
A2
B2
C2
F
F
F
F
M67
M67
M67
M67
M67
M67
Some assembly
(and snacks) required.

Step 2
420456 www.sauder.com/servicePage 6
å Fasten six UNIVERSAL CABINET RAILS* (35AA) to the
ENDS (A2 and B2). Use twelve GOLD 5/16" FLAT HEAD
SCREWS (3S) through holes #1 and #3.
å *patent pending glide system
GOLD 5/16" FLAT HEAD SCREW
(12 used for the RAILS)
3S
3
2
1
1
2
3
VIEW THE DRAWER GLIDE VIDEO
1
2
31
2
3
3
2
13
2
1
A2
B2
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Finished edge
Finished edge
Glide end
Glide end

Step 3
420456www.sauder.com/service Page 7
å Fasten six UNIVERSAL CABINET RAILS* (35AA) to both
surfaces of the UPRIGHT (C2). Use twelve GOLD 5/16"
FLAT HEAD SCREWS (3S) through holes #1 and #3.
å *patent pending glide system
GOLD 5/16" FLAT HEAD SCREW
(12 used for the RAILS)
3S
1
2
3
VIEW THE DRAWER GLIDE VIDEO
Finished edge
Surface with
HIDDEN CAMS
C2
1
2
3
1
2
3
1
2
31
2
1
2
Glide end

å Fasten the TOP MOLDING (J) to the TOP (D). Use four
SILVER 1-1/8" FLAT HEAD SCREWS (10S).
å NOTE: Do not overtighten the SCREWS into the TOP.
å Open the FURNITURE TIPPING RESTRAINT KIT (97)
and fasten the SAFETY STRAP to the TOP (D). Use the
provided BLACK 9/16" LARGE HEAD SCREW.
å NOTE: Position the SAFETY STRAP exactly as shown.
Step 4
420456 www.sauder.com/servicePage 8
DJ
Rounded edge
SILVER 1-1/8" FLAT HEAD SCREW
(4 used for the TOP MOLDING)
10S
Surface with holes
BLACK 9/16" LARGE HEAD SCREW
(1 used for the SAFETY STRAP)
Safety strap
97

å Fasten the UPRIGHT (C2) to the TOP (D). Tighten two
HIDDEN CAMS.
å NOTE: Be sure to move the SAFETY STRAP on the TOP
o to one side.
Step 5
420456www.sauder.com/service Page 9
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
D
Surface with holes
C2
Finished edge
Rounded edge
Surface
with
HIDDEN
CAMS

å Fasten the BRACES (F) to the UPRIGHT (C2). Tighten four
HIDDEN CAMS.
Step 6
420456 www.sauder.com/servicePage 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
C2
F
Surface with HIDDEN CAMS
These holes
must be here.
Don't worry. It isn't
Rome. This can be built
in a day.
F
Surface with HIDDEN CAMS
F
Surface with HIDDEN CAMS
F
Surface with HIDDEN CAMS
These holes
must be here.
