Sauder 423033 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 512095 12/12/17
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
5-Shelf Bookcase
Model 423033
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Great for all those
books you’ll never read.

Table of Contents Assembly Tools Required
2-3
4
5-18
19-21
22-24
25-26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
423033 www.sauder.com/servicesPage 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A2 RIGHT END (1)
B2 LEFT END (1)
C LOWER RIGHT END (1)
D LOWER LEFT END (1)
E2 TOP (1)
F BOTTOM (1)
G2 SHELF (1)
H2 LARGE BACK (1)
I BACK (1)
J ADJUSTABLE SHELF (3)
K END MOLDING (2)
M25 TOP MOLDING (1)
M48 BASE (1)
N SHELF MOLDING (3)
O SKIRT (1)
P LOWER END MOLDING (2)
Skip the power trip.
This time.
Tape Measure

Part Identification Now you know
our ABCs.
423033www.sauder.com/services Page 3
A2
B2
C
D
E2
F
G2
H2
I
J
K
N
O
P
N
N
K
P
J
J
M48
M25

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
423033 www.sauder.com/servicesPage 4
HIDDEN CAM - 12
1F CAM DOWEL - 12 2F
CAM COVER - 8
19P HOLE PLUG - 3 80P METAL PIN - 12 1R
BLACK 1-1/8" PAN HEAD SCREW - 3
9S
BLACK 9/16" LARGE HEAD SCREW - 17
1S
NAIL - 55
1N
ANGLE BRACKET - 8
44G
SAFETY STRAP - 1
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
60M SAFETY DRYWALL
ANCHOR - 1
61M
WASHER - 1
13M
BLACK 1-15/16" FLAT HEAD SCREW - 4
113S

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the
empty carton to avoid scratching your unit or the floor.
å Push twelve HIDDEN CAMS (1F) into the ENDS (A2
and B2), LOWER ENDS (C and D), and BOTTOM (F).
Then, insert the metal end of a CAM DOWELS (2F)
into the HIDDEN CAMS.
423033www.sauder.com/services Page 5
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
A2
B2
C
D
F
Arrow
1F
2F
(12 used)
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=2072
to watch a video on how to assemble your unit.

Step 2
å Fasten the SAFETY STRAP (60M) to the TOP (E2). Use a
BLACK 9/16" LARGE HEAD SCREW (1S).
å NOTE: Position the SAFETY STRAP (60M) exactly as shown.
423033 www.sauder.com/servicesPage 6
E2
60M
BLACK 9/16" LARGE HEAD SCREW
(1 used in this step)
1S
Surface with holes
Long finished edge
Remember:
Righty tighty.
Lefty loosey.

Step 3
423033www.sauder.com/services Page 7
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
A2
B2
E2
Notched edge
Notched edge
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface with holes
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
å Fasten the TOP (E2) to the ENDS (A2 and B2). Tighten
four HIDDEN CAMS.
Long finished edge

Step 4
å Fasten the TOP MOLDING (M25) to the TOP (E2). Use three BLACK 1-1/8" PAN
HEAD SCREWS (9S).
å NOTE: Do not overtighten the SCREWS into the TOP.
å Insert three HOLE PLUGS (80P) into the holes in the TOP MOLDING (M25).
å Slide the END MOLDINGS* (K) onto the notched edges of
the ENDS (A2 and B2).
å * U.S. Patent No. 5,499,886
423033 www.sauder.com/servicesPage 8
Notched edge
Notched edge
A2
B2
K
K
Slide the END MOLDINGS (K)
onto the notched edges.
The large groove is
closer to this edge.
The large groove is
closer to this edge.
Curved edge
E2
80P BLACK 1-1/8" PAN HEAD SCREW
(3 used in this step)
9S
M25

å Fasten the SHELF (G2) to the ENDS (A2 and B2). Use four
BLACK 1-15/16" FLAT HEAD SCREWS (113S).
Step 5
423033www.sauder.com/services Page 9
A2
B2
G2
Long finished edge
Surface with holes
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S
Don't worry. It isn't
Rome. This can be built
in a day.

Step 6
å Fasten the LOWER LEFT END (D) to the SHELF (G2).
Tighten two HIDDEN CAMS.
å Fasten the BOTTOM (F) to the LOWER LEFT END (D).
Tighten two HIDDEN CAMS.
423033 www.sauder.com/servicesPage 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
Notched edge
Surface with
HIDDEN CAMS
G2
F
Surface with
HIDDEN CAMS
These holes
must be here.
D
