Sauder 414764 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-22
Français p 23-25
Español p 26-28
Lot # 373380 05/26/15
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Dresser
414764
Don't et cauht with
your pants on the
round.

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
2-3
4-5
6-22
23-25
26-28
29-30
31
414764 www.sauder.com/servicesPae 2
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
Part Identification
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E BOTTOM (2)
F BACK (1)
G RIGHT FRONT LEG (1)
H LEFT FRONT LEG (1)
I REAR LEG (2)
M73 END MOLDING (2)
K2 SMALL RIGHT DRAWER FRONT (1)
L2 SMALL LEFT DRAWER FRONT (1)
Q2 RIGHT DRAWER FRONT (2)
R2 LEFT DRAWER FRONT (2)
M65 DRAWER BRACE (6)
SS BRACE (1)
D10 SMALL RIGHT DRAWER SIDE (2)
D11 SMALL LEFT DRAWER SIDE (2)
D132 RIGHT DRAWER SIDE (4)
D138 LEFT DRAWER SIDE (4)
D166 SMALL DRAWER BACK (2)
D167 DRAWER BACK (4)
D975 DRAWER BOTTOM (6)

Part Identification
414764www.sauder.com/services Pae 3
A
B
C
D
E
F
G
H
I
E
I
SS
D10
D11
D132
D138
D166
D167
D975
K2
L2
M65
R2
Q2
D975
D975
D975
D10
D11
D166
D167 D132
D138
M65
M65
M65
M73
M73

Hardware Identification
414764 www.sauder.com/servicesPae 4
AA2 HIDDEN CAM - 22
CC2 CAM DOWEL - 10
BB2 CAM SCREW -12
40CB CABINET LEFT - 6 40CA CABINET RIGHT - 6 40CC DRAWER RIGHT - 6
40CD DRAWER LEFT - 6
EE PULL - 8 KNOB - 4 FF
METAL PIN - 4
GG SLIDE CAM - 12 HH JJ WARNING LABEL - 1
(Refer to step 15 for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically desined to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
FOOT - 1
TT FOOT BASE - 1 UU WW SAFETY BRACKET - 1

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
414764www.sauder.com/services Pae 5
BLACK 1-1/8" MACHINE SCREW - 4
MM SILVER 3/4" MACHINE SCREW - 16 NN
BLACK 9/16" LARGE HEAD SCREW - 1
XX
BLACK 1-1/4" FLAT HEAD SCREW - 4
VV
BLACK 1-7/8" FLAT HEAD SCREW - 3
LL
GOLD 5/16" FLAT HEAD SCREW - 48
QQ NAIL - 47 RR
BLACK 9/16" FLAT HEAD SCREW - 4
OO
BLACK 2-1/4" FLAT HEAD SCREW - 6
KK
30S BLACK 1-9/16" FLAT HEAD SCREW - 30

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push twenty-two HIDDEN CAMS (AA2) into the
ENDS (A and B), UPRIGHT (C), BOTTOMS (E), and
DRAWER BRACES (M65). Then, insert ten CAM
DOWELS (CC2) into the HIDDEN CAMS.
414764 www.sauder.com/servicesPae 6
A
B
C
E
M65
E
Do not tihten the HIDDEN CAMS in this step.
(22 used)
(10 used)
Arrow
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not insert CAM
DOWELS into these edes.
Do not insert CAM
DOWELS into these parts.
AA2
CC2
M65
M65
M65
M65
M65
Arrow
AA2

Step 2
å Turn twelve CAM SCREWS (BB2) into the FRONT LEGS (G
and H) and DRAWER FRONTS (K2, L2, Q2, and R2).
414764www.sauder.com/services Pae 7
G
H
K2
L2
Q2
Q2
R2
R2
BB2
(12 used)

å Fasten the REAR LEGS (I) to the ENDS (A and B). Use six
BLACK 2-1/4" FLAT HEAD SCREWS (KK).
Step 3
414764 www.sauder.com/servicesPae 8
A
I
B
I
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS
Flat ede
BLACK 2-1/4" FLAT HEAD SCREW
(6 used in this step)
KK
Remember:
Rihty tihty.
Lefty loosey.

Step 4
414764www.sauder.com/services Pae 9
A
B
å Turn four BLACK 9/16" FLAT HEAD SCREWS (OO) into
the ENDS (A and B) until the shoulder of the SCREWS
rest on the surface of the ENDS.
å Slide the END MOLDINGS (M73) onto the ENDS (A and B).
Line up the roove in the MOLDINGS over the head of the
SCREWS in the ENDS.
These edes
should be even.
These edes
should be even.
Shoulder
Apply pressure with your hands
as you uide the MOLDINGS over
the SCREWS and onto the ENDS.
BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
OO
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS
M73
M73

Step 5
414764 www.sauder.com/servicesPae 10
A
G
B
H
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
å Fasten the FRONT LEGS (G and H) to the other surface of
the ENDS (A and B). Tihten six HIDDEN CAMS.
1
2
Anled ede

å Fasten the CABINET RIGHTS (40CA) and CABINET
LEFTS (40CB) to the ENDS (A and B) and UPRIGHT(C).
Use twenty-four GOLD 5/16" FLAT HEAD SCREWS (3S)
throuh holes #1 and #4.
Step 6
414764www.sauder.com/services Pae 11
C
A
G
B
H
GOLD 5/16" FLAT HEAD SCREW
(24 used in this step)
QQ
1
2
3
4
1
2
34
1
2
3
41
2
3
4
Roller end
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
1
2
4
1
2
4
Roller end
Finished ede
Surface with
HIDDEN CAMS
1
2
3
41
2
3
41
2
3
4
Roller end
1
2
3
4
3
4
3
4
3
3
3
3

å Fasten the LEFT END (B) and UPRIGHT (C) to the
TOP (D). Tihten four HIDDEN CAMS.
Step 7
414764 www.sauder.com/servicesPae 12
Start Tihten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
B
C
D
H
Unfinished surface
Finished ede
Lon finished ede
Surface
with
HIDDEN
CAMS
Surface
without
HIDDEN
CAMS
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

å Insert four METAL PINS (GG) into the BOTTOMS (E).
å Fasten the BOTTOMS (E) to the LEFT END (B). Tihten
two HIDDEN CAMS.
å NOTE: Be sure the METAL PINS in the BOTTOMS insert
into the holes in the LEFT END.
å Fasten the BOTTOMS (E) to the UPRIGHT (C). Use two
BLACK 1-7/8" FLAT HEAD SCREWS (LL).
Step 8
414764www.sauder.com/services Pae 13
B
C
E
E
GG
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Arrow
Minimum
190 derees
Maximum
210 derees
Finished ede
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
LL
Finished ede
(4 used)

å Fasten the RIGHT END (A) to the TOP (D) and
BOTTOMS (E). Tihten four HIDDEN CAMS.
å NOTE: Be sure the METAL PINS in the BOTTOMS insert
into the holes in the RIGHT END.
Step 9
414764 www.sauder.com/servicesPae 14
Arrow
Minimum
190 derees
Maximum
210 derees
E
E
D
A
G

å Fasten the BRACE (SS) and FOOT BASE (UU) to the
BOTTOM (E). Use four BLACK 1-1/4" FLAT HEAD
SCREWS (VV) throuh the BASE, throuh the BRACE,
and into the BOTTOM. Then, push the FOOT (TT) into
the FOOT BASE (UU).
å NOTE: Turn the screw end of the FOOT completely in.
Adjustments will be made to the FOOT after the unit is
standin upriht.
Step 10
414764www.sauder.com/services Pae 15
E
TT
UU
SS
BLACK 1-1/4" FLAT HEAD SCREW
(4 used in this step)
VV
Turn completely in.
Don't worry. It isn't
Rome. This can be built
in a day.

Step 11
414764 www.sauder.com/servicesPae 16
å Carefully turn your unit over onto its front edes. Unfold
the BACK (F) and lay it over your unit.
å Make equal marins alon all four edes of the BACK (F).
Push on opposite corners of your unit if needed to make
it “square”.
å Fasten the BACK (F) to your unit usin the NAILS (RR).
å NOTE: Be sure to tap NAILS into the holes that line up
over the UPRIGHT (C).
å NOTE: Perforations have been provided for access
throuh the BACK. Carefully cut out the holes needed.
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
NAIL
(47 used in this step)
RR
F
Printed information
must be facin up.
These holes must line up
over the UPRIGHT (C).
Cut-out

Step 12
414764www.sauder.com/services Pae 17
å Insert the DRAWER SIDES (D132 and D138) at
an angle into the slot at each end of the RIGHT
DRAWER FRONT (Q2).
å Slide the DRAWER BOTTOM (D975) into the grooves in
the DRAWER SIDES (D132 and D138) and RIGHT DRAWER
FRONT (Q2).
å Fasten the DRAWER BRACE (M65) to the
DRAWER FRONT (Q2). Tighten one HIDDEN CAM.
å Fasten the DRAWER BACK (D167) to the DRAWER SIDES (D132
and D138) and DRAWER BRACE (M65). Use five BLACK 1-9/16" FLAT
HEAD SCREWS. (30S). Repeat this step for the other DRAWERS using the
DRAWER FRONTS (Q2 and R2). Use the SMALL DRAWER
FRONTS (K2 and L2), SMALL DRAWER SIDES (D10 and D11), and SMALL
DRAWER BACKS (D166) for the small drawers.
The tabs should insert freely into the
slots. Gently tilt the DRAWER SIDES side
to side until the tabs slip into the slots.
UNFINISHED
Surface with
HIDDEN CAM
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of your hand, tap the
DRAWER BOTTOM down into the roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(30 used in this step)
30S
Q2
Q2
VIEW THE T-LOCK BOX VIDEO
D138
D975
D132
D132
D138
D167
Q2 D138
D132
M65
M65

Step 13
414764 www.sauder.com/servicesPae 18
å Insert a SLIDE CAM (HH) into the DRAWER SIDES (D132
and D138).
å Fasten the DRAWER RIGHT (40CC) and DRAWER
LEFT (40CD) to the DRAWER SIDES (D132 and D138).
Use four GOLD 5/16" FLAT HEAD SCREWS (3S) throuh
holes #1 and #4.
å NOTE: The screw head in the CAM must be visible
throuh the slotted hole in the SLIDE.
å Repeat this step for the other drawers.
1
2
3
4
Roller end
Roller end
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
HH
HH
GOLD 5/16" FLAT HEAD SCREW
(24 used in this step)
3S
1
2
3
4D138
D132

å Fasten the KNOBS (FF) to the SMALL RIGHT DRAWER
FRONT (K2). Use two BLACK 1-1/8" MACHINE
SCREWS (MM). Repeat this step for the other
small drawer.
å Fasten the PULLS (EE) to the RIGHT DRAWER
FRONT (Q2). Use four SILVER 3/4" MACHINE
SCREWS (NN). Repeat this step for the other drawers.
Step 14
414764www.sauder.com/services Pae 19
EE
FF
Q2
K2
SILVER 3/4" MACHINE SCREW
(16 used for the PULLS)
NN
BLACK 1-1/8" MACHINE SCREW
(4 used for the KNOBS)
MM

å Carefully stand your unit upriht.
å Position your unit in its final location.
å Turn the ADJUSTABLE FOOT (TT) downward until it touches the floor.
å IMPORTANT: The ADJUSTABLE FOOT should not extend beyond the
bottom edes of the LEGS (G, H, and I).
å To insert the drawers into your unit, tip the front of the drawer down
and drop the rollers on the drawer behind the rollers on the unit. Lift
the front of the drawer up and slide it into the unit.
å Apply the WARNING LABEL (JJ) to the upper DRAWER
BOTTOM (D975). You should be able to read the label when the
drawer is open. When the drawer is closed, it will hide the label.
Peel o the backin and apply the label as shown in the diaram.
å NOTE: This is a permanent label intended to last for the life of the
product. Once applied, do not try to remove it.
Step 15
414764 www.sauder.com/servicesPae 20
Q2
Q2
R2
K2
L2
R2
JJ
Serious or fatal crushin injuries can
occur from furniture tip-over. To help
prevent tip-over:
-Place heaviest items in the lowest drawers.
-Unless specifically desined to accommodate,
do not set TVs or other heavy objects on top of
this product.
-Never allow children to climb or han on
drawers, doors, or shelves.
-Never open more than one drawer at a time.
-If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
WARNING
D975
G
I
H
Turn the ADJUSTABLE FOOT
downward until it touches the floor.
TT
Floor
Pro Tip: Lift with your
les. And, you know,
your arms.
