Computer Desk
Model 411606
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-17
Français pg 18-20
Español pg 21-23
Lot # 529997 05/24/19
Purchased: __________________
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Share your journey!
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-523-3987.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sit and surf.

Table of Contents Assembly Tools Required
2-3
4
5-17
18-20
21-23
24-26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
411606 www.sauder.com/servicePage 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A3 RIGHT END (1)
B3 LEFT END (1)
C3 UPRIGHT (1)
D3 DESK TOP (1)
E2 TOP (1)
F3 BOTTOM (1)
G3 MODESTY PANEL (1)
H3 SMALL BACK (1)
I BACK (1)
J2 ADJUSTABLE SHELF (1)
K2 DRAWER FRONT (1)
D20 RIGHT DRAWER SIDE (1)
D21 LEFT DRAWER SIDE (1)
D148 DRAWER BACK (1)
D951 DRAWER BOTTOM (1)

Part Identification Now you know
our ABCs.
411606www.sauder.com/service Page 3
A3
B3
C3
D3
E2
F3
G3
H3
I
J2
K2
D20
D21
D951
D148

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
411606 www.sauder.com/servicePage 4
CORD CLIP - 1
4P
RUBBER SLEEVE - 4
2R
METAL PIN - 5
1R
PULL - 1
1K
SLIDE CAM - 2
10A TACK GLIDE - 6 12E
35DA CABINET RIGHT - 1 35DB CABINET LEFT - 1 35DC DRAWER RIGHT - 1 35DD DRAWER LEFT - 1
HIDDEN CAM - 6
1F CAM DOWEL - 6 2F
BROWN 1" FLAT HEAD SCREW - 2
12S
BLACK 9/16" LARGE HEAD SCREW - 6
1S GOLD 5/16" FLAT HEAD SCREW - 8 3S
NAIL - 10
1N
SCREW COVER - 6
20P
CAM COVER - 2
12P
BLACK 1-15/16" FLAT HEAD SCREW - 12
113S
30S BLACK 1-9/16" FLAT HEAD SCREW - 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/service/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push six HIDDEN CAMS (1F) into the ENDS (A3 and B3)
and UPRIGHT (C3). Then, insert the metal end of a CAM
DOWEL (2F) into each HIDDEN CAM.
411606www.sauder.com/service Page 5
C3
B3
A3
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
(6 used)

Step 2
å Fasten the CABINET RIGHT (35DA) and CABINET
LEFT (35DB) to the RIGHT END (A3) and UPRIGHT (C3).
Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through
holes #1 and #3.
411606 www.sauder.com/servicePage 6
A3
C3
1
2
3
1
2
3
3 5 D A
35DA
3 5 D B
35DB
Roller end
Roller end
Finished edge
Finished edge
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Remember:
Righty tighty.
Lefty loosey.

å Fasten the UPRIGHT (C3) to the DESK TOP (D3)
and BOTTOM (F3). Use four BLACK 1-15/16" FLAT
HEAD SCREW (113S).
Step 3
411606www.sauder.com/service Page 7
C3
F3
Surface without HIDDEN CAMS
Unfinished
surface
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S
D3
Curved edge
Unfinished edge
Surface with holes

Step 4
å Fasten the SMALL BACK (H3) to the DESK TOP (D3). Use
two BLACK 1-15/16" FLAT HEAD SCREW (113S).
å Fasten the LEFT END (B3) to the DESK TOP (D3). Tighten
two HIDDEN CAMS.
411606 www.sauder.com/servicePage 8
D3
H3
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Edge with
two holes
Finished edge
For support, place packing
foam and magazines here.
B3
BLACK 1-15/16" FLAT HEAD SCREW
(2 used in this step)
113S
Surface without HIDDEN CAMS
Unfinished edge

å NOTE: Start each SCREW a few turns before completely tighening
any of them.
å Fasten the MODESTY PANEL (G3) to the LEFT END (B3) and
UPRIGHT (C3). Use four BLACK 1-15/16" FLAT HEAD SCREW (113S).
Step 5
411606www.sauder.com/service Page 9
C3
B3
G3
Unfinished surface
The hole in the edge of
the MODESTY PANEL
is closer to this edge.
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S

Step 6
å Insert a METAL PIN (1R) into the edge of the SMALL BACK (H3).
å Fasten the TOP (E2) to the UPRIGHT (C3). Tighten two
HIDDEN CAMS.
å NOTE: Be sure the METAL PIN inserts into the hole in
the TOP (E2).
å Turn a CORD CLIP (4P) into the hole in the bottom
surface of the TOP (E2).
411606 www.sauder.com/servicePage 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
E2
C3
H3
1R
4P
Surface
with
holes
