Sauder Manhattan Gate 429249 User manual

sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey!
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 565082 04/13/21
Purchased: __________________
Lateral File
Manhattan Gate Collection | Model 429249
Get all organized
and stu.

Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4
5
6-22
23-25
26-28
29-30
31
Page 2 www.sauder.com/service 429249

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B LEFT END (1)
C RIGHT END (1)
D BRACE (1)
E UPPER BACK (1)
F LOWER BACK (1)
G DRAWER FRONT (2)
H DRAWER BOTTOM (2)
J DRAWER BRACE (2)
K DRAWER BOX FRONT (2)
L DRAWER BACK (2)
M LEFT DRAWER SIDE (2)
N UPPER RIGHT DRAWER SIDE (1)
P DRAWER PULL (2)
Q LOWER RIGHT DRAWER SIDE (1)
Page 3www.sauder.com/service429249
A
B
C
D
E
F
G
H
J
K
L
M
N
P
G
H
J
K
L
M
Q
P

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
Page 4 www.sauder.com/service 429249
(EXTENSION SET SHOWN SEPARATED)
LARGE WOOD
DOWEL - 14
8
CAM SCREW - 24
6HIDDEN CAM - 24 7SMALL WOOD
DOWEL - 10
9
1" FLAT HEAD SCREW - 6
15
1-1/2" FLAT HEAD SCREW - 12
14
1EXTENSION
RAIL - 4 2EXTENSION SLIDE - 4 3LONG FILE GLIDE - 4
SHORT FILE
GLIDE - 4
4 5 FILE BAR - 4
LOCK SET - 1
13
APPLIQUE CARD - 1
12
INTERLOCK
MECHANISM - 1
10 DRAWER
ACTUATOR - 2
11
1/2" PAN HEAD SCREW - 9
16 1/2" FLAT HEAD SCREW - 8 17
3/8" PAN HEAD SCREW - 24
18

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Page 5www.sauder.com/service429249

Step 1 Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Turn four CAM SCREWS (6) into the exact holes shown in
the RIGHT END (C).
å Push two HIDDEN CAMS (7) into the RIGHT END (C).
å NOTE: Be sure the HIDDEN CAMS are inserted
completely into the holes.
Page 6 www.sauder.com/service 429249
Meet Part (C). This component has
been engineered to be lighter, stronger,
faster… well ok. Not technically faster.
But definitely makes for a sturdier
Lateral File that’s easier to assemble
and friendlier to the environment.
1
6
6
Arrow
7
C
Be sure the HIDDEN
CAMS are inserted
completely into the holes.
Remember:
Righty tighty.
Lefty loosey.

Step 2
Page 7www.sauder.com/service429249
7
å Separate the EXTENSION SLIDES (2) from the EXTENSION RAILS (1) as shown in the
upper diagram below. Be prepared, the parts are greasy.
å Fasten two EXTENSION RAILS (1) to the RIGHT END (C). Use six 3/8" PAN HEAD
SCREWS (18) through the exact holes shown.
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged
diagram. Then, slide the inner cartridge of the EXTENSION RAIL in to find the other
holes that line up with the holes in the END. Turn a SCREW into these holes.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
Push the lever and pull the SLIDE from the RAIL.
3/8" PAN HEAD SCREW
(6 used in this step)
18
2 1
C
Open end
1
1

å Fasten the INTERLOCK MECHANISM (10) to the
RIGHT END (C) exactly as shown. Use three 1/2"
PAN HEAD SCREWS (16).
Step 3
Page 8 www.sauder.com/service 429249
10
1/2" PAN HEAD SCREW
(3 used in this step)
16
C

å Push six HIDDEN CAMS (7) into the BACKS (E and F).
å Insert two LARGE WOOD DOWELS (8) into the edge of the
LOWER BACK (F).
å Push the UPPER BACK (E) onto the WOOD DOWELS in
the LOWER BACK (F).
Step 4
Page 9www.sauder.com/service429249
1
Arrow
7
7
Arrow
Arrow
7
F
E
8

å Insert two LARGE WOOD DOWELS (8) into the RIGHT END (C).
å Fasten the BACKS (E and F) to the RIGHT END (C). Tighten two HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the END insert into the BACKS.
å Remove the WASHER from the LOCK SET (13). Fasten the LOCK to the RIGHT
END (C). Use two 1/2" FLAT HEAD SCREWS (17). Place the WASHER over the end
of the LOCK, and press the prongs into the END.
Step 5
Page 10 www.sauder.com/service 429249
1
E
8
Surface with HIDDEN CAMS
F
Surface with HIDDEN CAMS
Edge with
HIDDEN CAMS
C
1/2" FLAT HEAD SCREW
(2 used in this step)
17
The prongs must press
into the RIGHT END. You
may need to gently tap
the prongs into the END.
WASHER 13
LOCK

å Push four HIDDEN CAMS (7) into the BRACE (D).
å Insert one LARGE WOOD DOWEL (8) into the RIGHT END (C).
å Fasten the BRACE (D) to the RIGHT END (C). Tighten two HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWEL in the END inserts into the BRACE.
Step 6
Page 11www.sauder.com/service429249
1
Arrow
7
7
Arrow
8
C
D
D
Surface without
HIDDEN CAMS

Step 7
Page 12 www.sauder.com/service 429249
Part (B). Another
sturdier, easier,
friendlier component!
å Turn four CAM SCREWS (6) into the exact holes shown in
the LEFT END (B).
å Push two HIDDEN CAMS (7) into the LEFT END (B).
å NOTE: Be sure the HIDDEN CAMS are inserted
completely into the holes.
1
6
6
Arrow
7
B
Be sure the HIDDEN
CAMS are inserted
completely into the holes.
Just think. The sooner
you do this, the sooner
you do something else.

Step 8
Page 13www.sauder.com/service429249
å Fasten two EXTENSION RAILS (1) to the LEFT END (B). Use six 3/8" PAN HEAD
SCREWS (18) through the exact holes shown.
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the
enlarged diagram. Then, slide the inner cartridge of the EXTENSION RAIL in to find
the other holes that line up with the holes in the END. Turn a SCREW into these holes.
1
B
Open end
1
1
3/8" PAN HEAD SCREW
(6 used in this step)
18
Open end

å Insert three LARGE WOOD DOWELS (8) into the
LEFT END (B).
å Fasten the LEFT END (B) to the BRACE (D) and
BACKS (E and F). Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the END
insert into the BRACE and BACKS.
Step 9
Page 14 www.sauder.com/service 429249
1
8
B
E
F
D

å Turn six CAM SCREWS (6) into the exact holes shown in
the TOP (A).
å Insert six LARGE WOOD DOWELS (8) into the TOP (A).
å Fasten the TOP (A) to the ENDS (B and C) and UPPER
BACK (E). Tighten six HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the TOP insert
into the ENDS and BACK.
Step 10
Page 15www.sauder.com/service429249
Part (A). Another
sturdier, easier,
friendlier component!
1
8
B
E
A
C
A
6
8

å Fasten the EXTENSION SLIDES (2) to the DRAWER SIDES (M, N,
and Q). Use twelve 3/8" PAN HEAD SCREWS (18).
å Fasten the DRAWER ACTUATORS (11) to the RIGHT DRAWER
SIDES (N and Q). Use six 1/2" PAN HEAD SCREWS (16).
Step 11
Page 16 www.sauder.com/service 429249
3/8" PAN HEAD SCREW
(12 used for the SLIDES)
18
2
1/2" PAN HEAD SCREW
(6 used for the ACTUATORS)
16
11
Open end
M
N
Q
Open end
Edge with more holes
M
2
2
2
2

å Turn five CAM SCREWS (6) into the exact holes shown in
the DRAWER FRONT (G).
å Fasten one DRAWER BOX FRONT (K) to the DRAWER
FRONT (G). Use three 1" FLAT HEAD SCREWS (15).
å Repeat this step for the other drawer.
Step 12
Page 17www.sauder.com/service429249
1
6
1" FLAT HEAD SCREW
(6 used in this step)
15
Groove
Notch
K
G
(10 used)

å Push five HIDDEN CAMS (7) into the DRAWER BRACE (J) and
DRAWER SIDES (M and N).
å Insert five SMALL WOOD DOWELS (9) into the DRAWER FRONT (G).
å Fasten the DRAWER BRACE (J) and DRAWER SIDES (M and N) to the
DRAWER FRONT (G). Tighten five HIDDEN CAMS.
å Slide one DRAWER BOTTOM (H) into the grooves in the DRAWER
FRONT (G) and DRAWER SIDES (M and N).
å Repeat this step for the other drawer.
Step 13
Page 18 www.sauder.com/service 429249
(10 used)
1
M
N
G
J
M
N
G
H
9
(10 used)
Groove
7
Arrow
If you're doing this to
help a friend, don't
leave without a bite.

å Fasten one DRAWER BACK (L) to the DRAWER BRACE (J) and DRAWER
SIDES (M and N). Use six 1-1/2" FLAT HEAD SCREWS (14).
å NOTE: You should start each SCREW a few turns before completely
tightening any of them.
å Fasten one DRAWER PULL (P) to the DRAWER FRONT (G). Use three 1/2"
FLAT HEAD SCREWS (17).
å Repeat this step for the other drawer.
Step 14
Page 19www.sauder.com/service429249
M
N
L
J
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK groove.
1-1/2" FLAT HEAD SCREW
(12 used for the BACKS)
14
G
1/2" FLAT HEAD SCREW
(6 used for the PULLS)
17
P

å Push two LONG FILE GLIDES (3) onto the DRAWER BOX FRONT (K)
and DRAWER BACK (L).
å Push two SHORT FILE GLIDES (4) onto the DRAWER SIDES (M and N).
å Push two FILE BARS (5) onto the LONG FILE GLIDES (3).
å Repeat this step for the other drawer.
Step 15
Page 20 www.sauder.com/service 429249
M
NL
K
4
3
4
3
3
3
5
