Sauder 413854 User manual

PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
Made in the USA
Archbold, OH
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English.................... Page 1-13
Français...............Pages 14-15
Espanol.............Páginas 16-17
Lot #: 359842 02 / 24 / 14
Date Purchased: ____________________
413854
Table with Benches

ASSEMBLY TOOLS REQUIRED
No. 2 Phillips Screwdriver
Tip Shown Actual Size
TABLE OF CONTENTS
Part Identification.......................3
Hardware Identification .............4
Assembly Steps....................5-13
Français..............................14-15
Espanol...............................16-17
Safety .......................................18
Warranty...................................19
Page 2 www.sauder.com/services 413854

PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
A LARGE END 2
B2 SMALL END 4
C LARGE TOP 1
D LEAF 2
E UPPER SUPPORT 1
F LOWER SUPPORT 1
G SMALL TOP 2
H2 SKIRT 4
I END MOLDING 4
Page 3
www.sauder.com/services413854
A
B2
C
D
E
F
H2
I
A
B2
G
H2
I
I
I
D
B2
H2 B2
G
H2

HARDWARE IDENTIFICATION
Page 4 www.sauder.com/services 413854
Screws are shown actual size. You may receive extra hardware with your unit.
BLACK 9/16" LARGE HEAD SCREW - 40
S
CAM DOWEL - 12
K
HIDDEN CAM - 12
JWOOD DOWEL - 18 LGLUE - 1 M
SCREW COVER - 24
Q
LEAF SUPPORT - 4
O
HINGE - 6
NCAM COVER - 12 P
SILVER 2" FLAT HEAD SCREW - 24
57S

Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
1
1
S
t
e
p
Arrow
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Push twelve HIDDEN CAMS (J) into the ENDS (A and B2). Then, insert the metal end of a CAM DOWEL (K) into each
HIDDEN CAM.
Page 5
www.sauder.com/services413854
Do not tighten the HIDDEN
CAMS in this step.
(12 used)
A
B2
A
B2
B2
B2
J
K
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow

2
2
S
t
e
p
Page 6 www.sauder.com/services 413854
C
E
L
M
First, fill the holes in the UPPER SUPPORT (E) 1/4 to 1/2 full with GLUE (M). Then, insert two WOOD DOWELS (L) into these
holes. Wipe away the excess GLUE.
Now, fill the center holes in the LARGE TOP (C) 1/4 to 1/2 full with GLUE. Then, insert the WOOD DOWELS in the UPPER
SUPPORT into these holes as shown. Wipe away the excess GLUE.
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely difficult.
Caution
Surface with holes

Fasten the LARGE ENDS (A) to the LARGE TOP (C). Tighten four HIDDEN CAMS.
Now, fasten the LARGE ENDS (A) to the UPPER SUPPORT (E). Use four SILVER 2" FLAT HEAD SCREWS (57S).
3
3
S
t
e
p
Page 7
www.sauder.com/services413854
E
A
A
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Caution
Risk of damage or
injury. Hidden Cams
must be completely
tightened. Hidden
Cams that are not
completely tightened
may loosen, and parts
may separate.
To completely tighten:
Start Tighten
Arrow
Arrow
Maximum
210 degrees
Minimum
190 degrees
C
SILVER 2" FLAT HEAD SCREW
(4 used in this step)
57S

4
4
S
t
e
p
Page 8 www.sauder.com/services 413854
A
A
You will need someone's help in this step.
Fasten the LOWER SUPPORT (F) to the LARGE ENDS (A). Use four SILVER 2" FLAT HEAD SCREWS (57S).
Slide four END MOLDINGS (I) onto the notched edges of the LARGE ENDS (A).
*U.S. Patent No. 5,499,886
F
I
I
I
I
Unfinished edge
Notched edge
Notched edge
Notched edge
Unfinished
surface facing out.
U
n
f
i
n
i
s
h
e
d
Unfinished
surface facing out.
Notched edge
SILVER 2" FLAT HEAD SCREW
(4 used in this step)
57S

Fasten six HINGES (N) to the LARGE TOP (C). Use twelve BLACK 9/16" LARGE HEAD SCREWS (S).
Now, fasten both LEAVES (D) to the HINGES on the LARGE TOP (C). Use twelve BLACK 9/16" LARGE HEAD SCREWS (S).
5
5
S
t
e
p
Page 9
www.sauder.com/services413854
C
D
N
BLACK 9/16" LARGE HEAD SCREW
(24 used in this step)
S
N
Turn a SCREW thru
these oval holes and into
the LARGE TOP (C).
Surface with holes
Surface with holes
Turn a SCREW thru
these oval holes and into
the LARGE TOP (C).
There should be a slight
gap between the LARGE
TOP (C) and LEAVES (D).
D

Fasten four LEAF SUPPORTS (O) to the LARGE TOP (C). Use sixteen BLACK 9/16" LARGE HEAD SCREWS (S).
6
6
S
t
e
p
Page 10 www.sauder.com/services 413854
BLACK 9/16" LARGE HEAD SCREW
(16 used in this step)
S
Curved end
Curved end
O
O
C
