Sauder Palladia Collection 412902 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-40
Français pg 41-46
Español pg 47-52
Lot # 398172 11/23/16
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Executive Desk
Palladia Collection | Model 412902
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Get executive
with this decision.

Table of Contents Assembly Tools Required
2-4
5-7
8-40
41-46
47-52
53-54
55
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
412902 www.sauder.com/servicesPage 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A OUTER END (2)
B3 RIGHT END (1)
C3 LEFT END (1)
D2 RIGHT UPRIGHT (1)
D32 LARGE LEFT DRAWER SIDE (2)
D33 LARGE RIGHT DRAWER SIDE (2)
D34 SMALL RIGHT DRAWER SIDE (2)
D35 SMALL LEFT DRAWER SIDE (2)
D36 RIGHT DRAWER SIDE (2)
D37 LEFT DRAWER SIDE (2)
D74 SMALL DRAWER BACK (2)
D77 DRAWER BACK (2)
D78 LARGE DRAWER BACK (2)
D708 LARGE DRAWER BOTTOM (2)
D716 DRAWER BOTTOM (4)
E2 LEFT UPRIGHT (1)
F2 TOP (1)
G2 BOTTOM (2)
H2 MODESTY PANEL (1)
I BACK (1)
J PEDESTAL BACK (1)
K BRACE (4)
L DOOR (1)
M ADJUSTABLE SHELF (1)
M26 MOLDING (4)
N SKIRT (4)
O KEYBOARD FRONT (1)
P KEYBOARD BACK (1)
Q KEYBOARD SIDE (2)
R KEYBOARD SHELF (1)
S LARGE DRAWER BOX FRONT (2)
T LARGE RIGHT DRAWER FRONT (1)
U LARGE LEFT DRAWER FRONT (1)
Z DRAWER BOX FRONT (2)
AA RIGHT DRAWER FRONT (1)
BB LEFT DRAWER FRONT (1)
DD PLINTH (8)
FF SMALL RIGHT DRAWER FRONT (1)
GG SMALL LEFT DRAWER FRONT (1)
LL TOP REAR MOLDING (1)
MM UPPER BACK MOLDING (1)
NN SIDE MOLDING (2)
OO LOWER MOLDING (1)
PP UPPER MOLDING (1)
RR LEFT BOTTOM MOLDING (2)
TT RIGHT BOTTOM MOLDING (2)
UU TOP FRONT MOLDING (1)
VV HALF DISK (8)

Part Identification Now you know
our ABCs.
412902www.sauder.com/services Page 3
A
B3
C3
D2
E2
F2
G2
H2
I
J
K
L
M
N
DD
LL
MM
NN
OO
RR
UU
A
G2
K
K
K
N
N
N
DD
DD
DD
DD
DD
PP
NN
DD
TT
RR
VV
VV
DD
TT
VV
VV
M26
M26
M26
M26

Part Identification Now you know
our ABCs.
412902 www.sauder.com/servicesPage 4
O
PQ
R
Q
ST
US
Z
AA
BB
Z
FF
GG
D716
D716
D716
D716
D708
D708
D78 D33
D32
D37
D36
D77
D35
D34
D74
D32
D78 D33
D37
D77 D36
D34
D35
D74

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
412902www.sauder.com/services Page 5
(EXTENSION SET SHOWN SEPARATED)
(EXTENSION SET SHOWN SEPARATED)
NARROW
EXTENSION RAIL - 8
AAA NARROW
EXTENSION SLIDE - 8
BBB
WIDE
EXTENSION SLIDE - 4
DDD FILE ROD - 4
WIDE
EXTENSION RAIL - 4
CCC
ZZ LEFT DRAWER SLIDE - 1
RIGHT CABINET RAIL - 1
WW LEFT CABINET RAIL - 1 XX RIGHT DRAWER SLIDE - 1 YY
8B
FILE GLIDE - 4
6B
7F TWIST-LOCK®FASTENER - 25
HIDDEN CAM - 8
1F CAM DOWEL - 8 2F

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
412902 www.sauder.com/servicesPage 6
FELT DISC CARD - 1
1M
ANGLE BRACKET - 40
27G
GROMMET CAP - 2
1P
MOLDING
CONNECTOR - 4
17F
METAL PIN - 12
1R
19G METAL BRACKET - 2
KEYBOARD
HINGE - 2
12H
CORD CLIP - 1
9P
GROMMET - 3
10P
KNOB - 8
33K
RUBBER SLEEVE - 4
2R
14H HINGE - 2
SMALL DRAWER
FRONT BRACKET - 2
6G
LARGE DRAWER
FRONT BRACKET - 4
10G
DRAWER FRONT
BRACKET - 2
9G

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
412902www.sauder.com/services Page 7
BLACK 1-1/8" PAN HEAD SCREW - 16
9S
GOLD 1" MACHINE SCREW - 4
50S
BLACK 9/16" LARGE HEAD SCREW - 106
1S
BLACK 1-1/4" FLAT HEAD SCREW - 46
7S
SILVER 1-1/4" MACHINE SCREW - 4
35S
18S BROWN 1" FLAT HEAD SCREW - 12
3S GOLD 5/16" FLAT HEAD SCREW - 48
SILVER 5/8" FLAT HEAD SCREW - 4
23S
SILVER 9/16" LARGE HEAD SCREW - 2
54S 100S BLACK 2-3/4" FLAT HEAD SCREW - 3
BLACK 1/2" FLAT HEAD SCREW - 4
11S
30S BLACK 1-9/16" FLAT HEAD SCREW - 24
BLACK 1-15/16" FLAT HEAD SCREW - 8
113S

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the large holes in the OUTER ENDS (A).
å Repeat this step for the ENDS (B3 and C3), UPRIGHTS (D2
and E2), BOTTOMS (G2), MODESTY PANEL (H2), and UPPER
BACK MOLDING (MM).
412902 www.sauder.com/servicesPage 8
A
A
(25 used)
Do not tighten the TWIST-LOCK® FASTENERS in this step.
7F
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1658
to watch a video on how to assemble your unit.

å Push eight HIDDEN CAMS (1F) into the BOTTOMS (G2).
Then, insert the metal end of a CAM DOWEL (2F) into
each HIDDEN CAM.
Step 2
412902www.sauder.com/services Page 9
G2
G2
(8 used)
Arrow
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
1F
2F

Step 3
å NOTE: Before beginning this step, separate the NARROW EXTENSION
SETS (AAA and BBB) from the WIDE EXTENSION SETS (CCC and DDD).
Do not confuse these SETS once they are separated.
å Separate the NARROW EXTENSION SLIDES (BBB) from the NARROW EXTENSION
RAILS (AAA) as shown in the upper diagram below. Be prepared, the parts are greasy.
å Fasten the NARROW EXTENSION RAILS (AAA) to the ENDS (B3 and C3) and
UPRIGHTS (D2 and E2). Use sixteen GOLD 5/16" FLAT HEAD SCREWS (3S).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged
diagram. Then, slide the inner cartridge of the EXTENSION RAIL in to find the other
hole that lines up with the hole in the END and UPRIGHT. Turn a SCREW into this hole.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
412902 www.sauder.com/servicesPage 10
C3
B3
D2
E2
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
Push the release lever in and pull the SLIDE from the RAIL.
AAABBB
Narrow
Extension
Rails
Open end
Open end
Open end
Open end
Narrow
Extension
Rails
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S

å Separate the WIDE EXTENSION SLIDES (DDD) from the WIDE EXTENSION RAILS (CCC) as shown in the upper diagram
below. Be prepared, the parts are greasy.
å Fasten the WIDE EXTENSION RAILS (CCC) to the ENDS (B3 and C3) and UPRIGHTS (D2 and E2). Use twelve GOLD
5/16” FLAT HEAD SCREWS (3S).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged diagram. Then, slide the inner
cartridge of the EXTENSION RAIL in to find the other holes that line up with the holes in the ENDS and UPRIGHTS. Turn a
SCREW into this hole.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
å Fasten four ANGLE BRACKETS (27G) to the RIGHT END (B3) and RIGHT UPRIGHT (D2). Use four BLACK 9/16" LARGE
HEAD SCREWS (1S).
å NOTE: Be sure the edges
of the ANGLE BRACKETS
are even with the edges of
the END and UPRIGHT.
Step 4
412902www.sauder.com/services Page 11
C3
B3
D2
E2
CCC
CCC
CCC
CCC
BLACK 9/16" LARGE HEAD SCREW
(4 used for the ANGLE BRACKETS)
Push the black lever in and pull the SLIDE from the RAIL.
CCCDDD
Wide
Extension
Rails
Wide
Extension
Rails
GOLD 5/16" FLAT HEAD SCREW
(12 used in this step)
Open end
Open end
Open end
Open end
(4 used)
3S
27G
27G
1S

Step 5
å Fasten the CABINET RAILS (WW and XX) to the other
surfaces of the UPRIGHTS (D2 and E2). Use four GOLD
5/16" FLAT HEAD SCREWS (3S).
å NOTE: The CABINET RAILS are marked "CABINET
RIGHT" and "CABINET LEFT" for easy identification.
412902 www.sauder.com/servicesPage 12
D2
E2
WW
XX
Surface without
TWIST-LOCK
®
FASTENERS
Surface without
TWIST-LOCK
®
FASTENERS
Roller end
These holes must be here.
Roller end
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S

å Tap four MOLDING CONNECTORS (17F) into the notches in
the TOP MOLDINGS (LL and UU) and SIDE MOLDINGS (NN).
Step 6
412902www.sauder.com/services Page 13
LL
NN
UU
NN
Flat end Flat end
Use your hammer to tap the MOLDING CONNECTORS (17F) into the notches in the MOLDINGS.
17F
17F

Step 7
å Fasten the TOP MOLDINGS (LL and UU) and SIDE
MOLDINGS (NN) to the TOP (F2). Use sixteen BLACK
1-1/4" FLAT HEAD SCREWS (7S).
å NOTE: Do not overtighten the SCREWS into the TOP.
412902 www.sauder.com/servicesPage 14
LL
NN
UU
NN
F2
Surface with holes
The large holes must be here.
The TOP REAR
MOLDING (LL)
has more holes.
BLACK 1-1/4" FLAT HEAD SCREW
(16 used in this step)
7S

å Fasten the METAL BRACKETS (19G) to the UPPER
BACK MOLDING (MM). Use two BLACK 9/16" LARGE
HEAD SCREWS (1S).
å Fasten the UPPER BACK MOLDING (MM) to the TOP
REAR MOLDING (LL) on the TOP (F2). Tighten three
TWIST-LOCK® FASTENERS.
Step 8
412902www.sauder.com/services Page 15
LL
F2
MM
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Edge and surface with
TWIST-LOCK® FASTENERS
MM
Dowel end
BLACK 9/16" LARGE HEAD SCREW
(2 used in this step)
19G
19G
1S

Step 9
å Fasten the HALF DISKS (VV) to the PLINTHS (DD). Use
eight BROWN 1" FLAT HEAD SCREWS (18S).
å Fasten twenty ANGLE BRACKETS (27G) to the
OUTER ENDS (A). Use twenty BLACK 9/16" LARGE
HEAD SCREWS (1S).
å NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the OUTER ENDS.
412902 www.sauder.com/servicesPage 16
DD
VV
A
A
DD
VV
DD
VV
DD
VV
DD
VV
DD
VV
DD
VV
DD
VV
The larger hole
should be facing up.
Surface with
TWIST-LOCK
®
FASTENERS
Surface with
TWIST-LOCK
®
FASTENERS
(20 used)
BROWN 1" FLAT HEAD SCREW
(8 used in this step)
27G
27G
18S
BLACK 9/16" LARGE HEAD SCREW
(20 used for the ANGLE BRACKETS)
1S

å Fasten the OUTER ENDS (A) to the SIDE
MOLDINGS (NN) on the TOP (F2). Tighten four
TWIST-LOCK® FASTENERS.
Step 10
412902www.sauder.com/services Page 17
A
A
NN
F2
NN
Surface with
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS

Step 11
å Fasten the PLINTHS (DD) and MOLDINGS (M26) to
the OUTER ENDS (A). Use twenty BLACK 9/16" LARGE
HEAD SCREWS (1S).
412902 www.sauder.com/servicesPage 18
A
A
DD
DD
DD
DD
VV
VV
VV
VV
The MOLDING (M26) should be
centered over the HALF DISK (VV).
These holes
must be here.
These holes
must be here.
M26
M26
M26
M26
BLACK 9/16" LARGE HEAD SCREW
(20 used for the ANGLE BRACKETS)
1S
Use outer holes.
Use outer holes.
Use outer holes.
Use outer holes.

å Insert four METAL PINS (1R) into the ENDS (B3 and C3).
å Fasten the ENDS (B3 and C3) to the TOP (F2). Tighten
four TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the ENDS insert into
the holes in the TOP.
Step 12
412902www.sauder.com/services Page 19
F2
C3
B3
Surface with
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS
Open end
Open end
(4 used)
1R

Step 13
å Fasten the BOTTOMS (G2) to the OUTER ENDS (A). Tighten
four TWIST-LOCK® FASTENERS.
å Fasten the BOTTOMS (G2) to the ENDS (B3 and C3). Use
four BLACK 1-15/16" FLAT HEAD SCREWS (113S).
å Insert four METAL PINS (1R) into the PEDESTAL BACK (J).
å Insert the METAL PINS (1R) in one end of the PEDESTAL
BACK (J) into the holes in the LEFT END (C3).
412902 www.sauder.com/servicesPage 20
Surface with
TWIST-LOCK
®
FASTENERS
Surface with
TWIST-LOCK
®
FASTENERS
A
A
JC3
G2
G2
B3
113S
The large holes must be here.
Unfinished
surface
(4 used)
1R
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S
