Sauder Shoal Creek Night Stand 410412 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-18
Español pg 19-21
Lot # 359206 01/20/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Night Stand
Shoal Creek Collection | 410412
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
2-3
4
5-15
16-18
19-21
22
23
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
410412 www.sauder.com/servicesPage 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (1)
F RIGHT FRONT LEG (1)
G LEFT FRONT LEG (1)
H REAR LEG (2)
I DRAWER FRONT (1)
N END MOLDING (2)
O BOTTOM MOLDING (1)
D16 DRAWER RIGHT SIDE (1)
D17 DRAWER LEFT SIDE (1)
D109 DRAWER BACK (1)
D706 DRAWER BOTTOM (1)

Part Identification
410412www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
I
N
O
H
N
D16
D17
D706
D109

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
410412 www.sauder.com/servicesPage 4
35GA CABINET RIGHT - 1 35GB CABINET LEFT - 1 35GC DRAWER RIGHT - 1
35GD DRAWER LEFT - 1 HIDDEN CAM - 12
T2
GOLD 5/16" FLAT HEAD SCREW - 8
CC
CAM SCREW - 4
V2
CAM DOWEL - 8
U2
SLIDE CAM - 2
Y
BLACK 9/16" FLAT HEAD SCREW - 4
BB
KNOB - 1
W
BLACK 1-1/8" MACHINE SCREW - 1
AA
BLACK 2-1/4" FLAT HEAD SCREW - 4
Z
NAIL - 16
DD BLACK 1-9/16" FLAT HEAD SCREW - 4 30S

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twelve HIDDEN CAMS (T2) into the ENDS (A and B)
and BOTTOM (D). Then, insert eight CAM DOWELS (U2)
into the HIDDEN CAMS.
410412www.sauder.com/services Page 5
Hole
A
B
D
T2
Do not tighten the HIDDEN CAMS in this step.
Arrow
Arrow
(12 used)
(8 used)
Arrow
T2
U2
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not insert
CAM DOWELS
into these edges.

Step 2
å Fasten the CABINET RIGHT (35GA) and CABINET LEFT (35GB)
to the ENDS (A and B). Use four GOLD 5/16" FLAT HEAD
SCREWS (CC) through holes #1 and #3.
å Fasten the REAR LEGS (H) to the ENDS (A and B). Use four
BLACK 2-1/4" FLAT HEAD SCREWS (Z).
410412 www.sauder.com/servicesPage 6 410412 www.sauder.com/servicesPage 6
A
B
H
H
1
2
3
3
2
1
Edge with HIDDEN CAMS
Angled edge
Roller end
Edge with HIDDEN CAMS
Roller end
Surface with
HIDDEN CAMS Surface with
HIDDEN CAMS
BLACK 2-1/4" FLAT HEAD SCREW
(4 used for the LEGS)
Z
GOLD 5/16" FLAT HEAD SCREW
(4 used for the RAILS)
CC

å Fasten the LEFT END (B) to the TOP (C). Tighten two
HIDDEN CAMS.
Step 3
410412www.sauder.com/services Page 7 410412www.sauder.com/services Page 7
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Unfinished surface
B
C
Surface with
HIDDEN CAMS
Long finished edge
Roller end

Step 4
å Fasten the BOTTOM (D) to the LEFT END (B). Tighten two HIDDEN CAMS.
å Slide the BOTTOM MOLDING (O) onto the notched edge of the BOTTOM (D).
å Fasten the RIGHT END (A) to the TOP (C) and BOTTOM (D). Tighten four
HIDDEN CAMS.
å * U.S. Patent No. 5,499,886
410412 www.sauder.com/servicesPage 8
Unfinished
surface
BDO
A
C
D
Roller end
Notched edge
Arrow
Minimum
190 degrees
Maximum
210 degrees

å Turn four BLACK 9/16" FLAT HEAD SCREWS (BB) into the ENDS (A and B)
until the shoulder of the SCREWS rest on the surface of the ENDS.
å NOTE: Do not overtighten the SCREWS.
å Slide the END MOLDINGS (N) onto the ENDS (A and B). Line up the groove
in the MOLDINGS over the head of the SCREWS in the ENDS.
å NOTE: If the MOLDINGS come up o of the SCREWS, remove them and
slide them on again.
Step 5
410412www.sauder.com/services Page 9
Apply pressure with your hands as you
guide the MOLDINGS onto the ENDS.
A
B
N
N
Shoulder BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
BB

Step 6
å Turn four CAM SCREWS (V2) into the LEGS (F and G).
å Fasten the LEGS (F and G) to the ENDS (A and B). Tighten
four HIDDEN CAMS.
410412 www.sauder.com/servicesPage 10
V2
A
BF
G
F
G
Angled edge
(4 used)
1
2
