Sauder Armoire Harbor View 401322 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-24
Français p 25-28
Español p 29-32
Lot # 388897 02/22/16
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Armoire
Harbor View Collection | Model 401322
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
You'll love what we
have in storage.

Table of Contents Assembly Tools Required
3
4-5
6-24
25-28
29-32
33-34
35
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Use of a TV that is too heavy or lare is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or
death. A TV that is too lare for the available space miht be accidentally pushed or bumped o the furniture, or subject to tip-over.
• Check the size and weiht of your TV. Compare it to the diaram below – before you begin assembly!
• This Sauder unit is desined for use with televisions weihin less than 50 pounds. Never use with a TV that weihs more.
• The size of the television, front-to-back and side-to-side, must fit within the space defined in the diaram.
• Never place the front ede of the TV past the front ede of the TV support shelf (or stop moldin – if equipped)
• Never allow the sides of the TV to extend past the side edes of the TV support surface.
• If the TV has a CRT picture tube, the picture tube cone may extend past the rear of the support shelf.
• Be sure to apply the warnin label as instructed in the last assembly step. The label provides important safety related information.
WARNING
!
50 lbs.
50 lbs.
39-1/2"
39-1/2"
35"
35"
Skip the power trip.
This time.
401322 www.sauder.com/servicesPae 2
Short Screwdriver
(provided)

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
401322www.sauder.com/services Pae 3
A2
B2
C2
D2
E
F
G2
HI2
J2
D194 D30
D31
D618
O
P
Q
R
S
T
U
V
W
CC
CC
X
D194 D30
D31
D618
M67
M67
CCC
A2 RIGHT END (1)
B2 LEFT END (1)
C2 TOP (1)
D2 SHELF (1)
D30 RIGHT DRAWER SIDE (2)
D31 LEFT DRAWER SIDE (2)
D194 DRAWER BACK (2)
D618 DRAWER BOTTOM (2)
E TV SHELF (1)
F BOTTOM (1)
G2 BACK (1)
H LOWER BACK (1)
I2 UPPER DRAWER FRONT (1)
J2 LOWER DRAWER FRONT (1)
M67 DRAWER BRACE (2)
O UPRIGHT (1)
P RIGHT DOOR (1)
Q LEFT DOOR (1)
R BOTTOM MOLDING (1)
S SKIRT (1)
T FRONT MOLDING (1)
U RIGHT MOLDING (1)
V LEFT MOLDING (1)
W ROD (1)
X LOUVER MOLDING (2)
CC FOOT (2)
CCC SHELF MOLDING (1)

Hardware Identification
401322 www.sauder.com/servicesPae 4
WARNING
Never use this furniture with a TV that is
too large or too heavy. Severe injury or
death can occur. The TV and furniture
will be unstable and may tip.
-The TV must less than 50 lbs.
-The base of the TV must be able to sit
completely on this shelf.
Refer to instruction book for complete
safety information.
Note: This is a permanent label. Do not
try to remove. Surface will be damaged.
08/05 2 6 9 2 2 0 269220
WARNING LABEL - 1
1L
(Refer to step 16 for proper
location and application)
5L WARNING LABEL - 1
(Refer to Step 17 for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically desined to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
ANGLE BRACKET - 3
5G
MAGNETIC CATCH - 1
1i
7A ROD HANGER - 2
7F TWIST-LOCK®
FASTENER - 17
FOOT SCREW - 2
23F
MOLDING
CONNECTOR - 2
16F 30H HINGE - 6
10A SLIDE CAM - 4
NAIL - 39
1N
HIDDEN CAM - 2
1F CAM DOWEL - 2 2F
35AA UNIVERSAL CABINET RAIL - 4 35AC DRAWER RIGHT - 2 35AD DRAWER LEFT - 2
WASHER - 1
13M SAFETY STRAP - 1
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
60M SAFETY DRYWALL
ANCHOR - 1
61M
93K KNOB - 6
STRIKE PLATE - 2
6I

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
401322www.sauder.com/services Pae 5
BLACK 1-1/4" FLAT HEAD SCREW - 6
7S
BLACK 1-1/8" PAN HEAD SCREW - 4
9S
BLACK 9/16" PAN HEAD SCREW - 2
51S
SILVER 3/4" FLAT HEAD SCREW - 6
111S
BLACK 9/16" LARGE HEAD SCREW - 33
1S BLACK 1-7/8" FLAT HEAD SCREW - 8 2S
BLACK 2-1/4" FLAT HEAD SCREW - 4
26S
SILVER 2" FLAT HEAD SCREW - 7
57S
3S GOLD 5/16" FLAT HEAD SCREW - 16
BLACK 1/2" FLAT HEAD SCREW - 2
11S
30S BLACK 1-9/16" FLAT HEAD SCREW - 10

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the lare holes in the BOTTOM (F)
and TV SHELF (E).
å Repeat this step for the UPRIGHT (O) and SHELF (D2).
401322 www.sauder.com/servicesPae 6
F
E
7F
7F
(17 used)
Do not tihten the TWIST-LOCK® FASTENERS in this step.

å Fasten the UNIVERSAL CABINET RAILS* (35AA) to the
ENDS (A2 and B2). Use eiht GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #3.
å *patent pendin lide system
Step 2
401322www.sauder.com/services Pae 7
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
1
2
3
1
2
3
A2
B2
Glide end
1
2
3
1
2
3
Glide end
Finished ede
Finished ede
VIEW THE DRAWER GLIDE VIDEO

Step 3
å Tap two MOLDING CONNECTORS (16F) into the notches
in the MOLDINGS (T, U, and V).
401322 www.sauder.com/servicesPae 8
Flat end
Flat end
16F
16F
Use your hammer to tap the MOLDING CONNECTORS (16F) into the notches in the MOLDINGS.
T
U
VUnfinished surface
Unfinished surface

å Fasten the RIGHT END (A2) to the RIGHT MOLDING (U).
Use two BLACK 2-1/4" FLAT HEAD SCREWS (26S).
å Fasten the TV SHELF (E) to the RIGHT END (A2). Tihten
two TWIST-LOCK® FASTENERS.
å Fasten the UPRIGHT (O) to the TV SHELF (E). Tihten two
TWIST-LOCK® FASTENERS.
Step 4
401322www.sauder.com/services Pae 9
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the
hole of the adjoinin part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoinin
part while lockin the FASTENER.
2. Tihten the FASTENER with a Phillips
screwdriver as tiht as possible.
Dowel end
BLACK 2-1/4" FLAT HEAD SCREW
(2 used for the RIGHT MOLDING)
26S
A2
E
O
U
T
Surface with
TWIST-LOCK®
FASTENERS
Surface without
TWIST-LOCK®
FASTENERS
Finished surface
Finished ede

Step 5
å Fasten the SHELF (D2) to the RIGHT END (A2). Tihten two
TWIST-LOCK® FASTENERS.
å Fasten the SHELF (D2) to the UPRIGHT (O). Use two BLACK
1-7/8" FLAT HEAD SCREWS (2S).
å Fasten three ANGLE BRACKETS (5G) to the LOWER BACK (H).
Use three BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edes of the BRACKETS are even with the
ede of the LOWER BACK.
å Fasten the LOWER BACK (H) to the SHELF (D2). Use three
BLACK 9/16" LARGE HEAD SCREWS (1S) throuh the
BRACKETS and into the SHELF.
401322 www.sauder.com/servicesPae 10
A2
D2
H
5G
Surface with
TWIST-LOCK®
FASTENERS
Surface with holes
O
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
BLACK 9/16" LARGE HEAD SCREW
(6 used for the ANGLE BRACKETS)
1S
Ede with
TWIST-LOCK®
FASTENERS

å Fasten the SHELF MOLDING (CCC) to the SHELF (D2).
Tihten three TWIST-LOCK® FASTENERS.
å Fasten the BOTTOM (F) to the RIGHT END (A2). Tihten two
TWIST-LOCK® FASTENERS.
å Fasten the BOTTOM (F) to the LOWER BACK (H). Use three
BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å NOTE: You should start each SCREW a few turns before
completely tihtenin any of them.
å Fasten the LEFT END (B2) to the SHELF (D2), TV SHELF (E),
and BOTTOM (F). Tihten six TWIST-LOCK® FASTENERS.
å NOTE: Use the SHORT SCREWDRIVER to tihten the
TWIST-LOCK® FASTENERS in the TV SHELF (E).
å Fasten the LEFT END (B2) to the LEFT MOLDING (V). Use
two BLACK 2-1/4" FLAT HEAD SCREWS (26S).
Step 6
401322www.sauder.com/services Pae 11
A2
D2
B2
F
Surface with
TWIST-LOCK®
FASTENERS
E
V
BLACK 2-1/4" FLAT HEAD SCREW
(2 used for the LEFT MOLDING)
26S
BLACK 1-7/8" FLAT HEAD SCREW
(3 used for the LOWER BACK)
2S
26S
Finished ede
Lon ede with
more holes
H
CCC

Step 7
å Fasten the TOP (C2) to the MOLDINGS (T, U, and V). Use
seven SILVER 2" FLAT HEAD SCREWS (57S).
å NOTE: Do not overtihten the SCREWS into the TOP.
å Fasten two ROD HANGERS (7A) to the ENDS (A2 and B2).
Use two BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the ROD HANGERS are positioned
as shown.
Rounded ede
A2
B2
U
V
T
C2
7A
7A
BLACK 9/16" LARGE HEAD SCREW
(2 used for the ROD HANGERS)
1S
SILVER 2" FLAT HEAD SCREW
(7 used for the TOP)
57S
401322 www.sauder.com/servicesPae 12

å Fasten the SKIRT (S) to the BOTTOM MOLDING (R). Use
three BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 8
401322www.sauder.com/services Pae 13
S
R
BLACK 1-7/8" FLAT HEAD SCREW
(3 used in this step)
2S
Rounded ede
Unfinished surface
Flat surface

Step
å Fasten the BOTTOM MOLDING (R) to the BOTTOM (F).
Use four BLACK 1-1/8" PAN HEAD SCREWS (9S).
å NOTE: Do not overtihten the SCREWS.
å Fasten the MAGNETIC CATCH (1I) to the FRONT
MOLDING (T). Use two BLACK 9/16" PAN
HEAD SCREWS (51S).
Step 9
1I
T
F
R
Rounded ede
BLACK 9/16" PAN HEAD SCREW
(2 used in this step)
51S
401322 www.sauder.com/servicesPae 14
BLACK 1-1/8" PAN HEAD SCREW
(4 used in this step)
9S

å Carefully turn your unit over onto its front edes. Unfold the
BACK (G2) and lay it over your unit.
å Make equal marins alon all four edes of the BACK (G2).
Push on opposite corners of your unit if needed to make
it "square".
å Fasten the BACK (G2) to your unit usin the NAILS (1N).
å NOTE: Be sure to tap NAILS into the holes that line up over the
TV SHELF (E).
å NOTE: Perforated cut-out lines have been provided for access
throuh the BACK. Carefully cut out the holes needed.
å Carefully turn two FOOT SCREWS (23F) a few turns into the
two holes shown in the BOTTOM MOLDING (R).
å Next, turn a FOOT (CC) onto the other end of each FOOT
SCREW (23F). Turn the FEET clockwise until the FOOT
SCREWS are tiht in the BOTTOM MOLDING and each FOOT.
å NOTE: Do not overtihten the FOOT SCREWS.
Step 10
401322www.sauder.com/services Pae 15
G2
CC
CC
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
Unfinished
surface
These holes must line up
over the TV SHELF (E).
NAIL
(39 used in this step)
1N
R23F

Step 11
å Fasten six HINGES (30H) to the DOORS (P and Q). Use
twelve BLACK 9/16" LARGE HEAD SCREWS (1S).
å Fasten two STRIKE PLATES (6I) to the DOORS (P
and Q). Use two BLACK 1/2" FLAT HEAD SCREWS (11S).
30H
30H
BLACK 9/16" LARGE HEAD SCREW
(12 used for the HINGES)
1S
BLACK 1/2" FLAT HEAD SCREW
(2 used for the STRIKE PLATES)
11S
Q
P
401322 www.sauder.com/servicesPae 16
6I
Indented holes

å Carefully stand your unit upriht.
å Fasten the LEFT DOOR (Q) to the LEFT END (B2). Use six BLACK
9/16" LARGE HEAD SCREWS (1S).
å NOTE: To make adjustments to the DOORS, loosen the SCREWS in
the HINGES, make needed adjustments, and tihten the SCREWS.
å Fasten a KNOB (93K) to the LEFT DOOR (Q). Use a BLACK 1-1/4"
FLAT HEAD SCREW (7S).
å Fasten a LOUVER MOLDING (X) to the LEFT DOOR (Q). Use three
SILVER 3/4" FLAT HEAD SCREWS (111S).
å NOTE: Be sure the indicated hole in the LOUVER MOLDING is
positioned toward the top of the DOOR.
å Repeat this step for the RIGHT DOOR (P).
Step 12
401322www.sauder.com/services Pae 17
BLACK 9/16" LARGE HEAD SCREW
(12 used for the HINGES)
1S
BLACK 1-1/4" FLAT HEAD SCREW
(2 used for the KNOBS)
7S
Q
B2
X
93K
SILVER 3/4" FLAT HEAD SCREW
(6 used for the LOUVER MOLDINGS)
111S
This hole in the LOUVER MOLDING (X) must
be postioned toward the top of each DOOR.
Want options? Customize
your item with add-on
hardware kits available
on sauder.com.

Step 13
401322 www.sauder.com/servicesPae 18
Arrow
1F
2F
å Push two HIDDEN CAMS (1F) into the DRAWER BRACES (M67).
Then, insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM.
Do not tihten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
M67
M67

Step 14
401322www.sauder.com/services Pae 19
å Insert the DRAWER SIDES (D30 and D31) at an
angle into the slot at each end of the UPPER
DRAWER FRONT (I2).
å Slide the DRAWER BOTTOM (D618) into the grooves in
the DRAWER SIDES (D30 and D31) and UPPER
DRAWER FRONT (I2).
å Fasten the DRAWER BRACE (M67) to the UPPER
DRAWER FRONT (I2). Tighten one HIDDEN CAM.
å Fasten the DRAWER BACK (D194) to the DRAWER
SIDES (D30 and D31) and DRAWER BRACE (M67).
Use five BLACK 1-9/16" FLAT HEAD SCREWS (30S).
Repeat this step for the other DRAWER using the LOWER
DRAWER FRONT (J2).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Surface with
HIDDEN CAM
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
I2
VIEW THE T-LOCK BOX VIDEO
D31
D618
D30
D194
Unfinished surface
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK roove.
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(10 used in this step)
30S
I2 D31
D30
M67
I2
M67
D31
D30
With the palm of your hand,
tap the DRAWER BOTTOM
down into the roove.

Step 15
å Insert SLIDE CAMS (10A) into the lare holes in the DRAWER SIDES (D30 and D31).
å Fasten a DRAWER RIGHT (35AC) and DRAWER LEFT (35AD) to the DRAWER SIDES (D30
and D31). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) throuh holes #1 and #2.
å NOTE: The screw head in the CAM must be visible throuh the slotted hole in the SLIDE.
å NOTE: The lides are not intended to rotate.
å Fasten two KNOBS (93K) to the UPPER DRAWER FRONT (I2). Use two BLACK 1-1/4" FLAT
HEAD SCREWS (7S).
å Repeat this step for the other drawer.
401322 www.sauder.com/servicesPae 20
VIEW THE DRAWER GLIDE VIDEO
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
BLACK 1-1/4" FLAT HEAD SCREW
(4 used for the KNOBS)
7S
93K
D31
D30
I2
1
2
1
2
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
Glide end
Glide end
10A
