Sauder Harbor View Library with Doors User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-22
Français p 23-25
Español p 26-28
Lot # 390995 05/05/16
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Library with Doors
Harbor View Collection | Model 401632
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Here's one for
the books.

Table of Contents Assembly Tools Required
2-3
4-5
6-22
23-25
26-28
29-30
31
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
401632 www.sauder.com/servicesPae 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C2 TOP (1)
D SHELF (1)
D83 RIGHT DRAWER SIDE (1)
D84 LEFT DRAWER SIDE (1)
D169 DRAWER BACK (1)
D977 DRAWER BOTTOM (1)
E BOTTOM (1)
F ADJUSTABLE SHELF (2)
G BACK (1)
H SMALL ADJUSTABLE SHELF (1)
I RIGHT DOOR (1)
J LEFT DOOR (1)
K2 DRAWER FRONT (1)
EE FOOT (2)
M12 TOP MOLDING (1)
M13 BOTTOM MOLDING (1)
M38 SHELF MOLDING (2)
M57 SKIRT (1)
M59 VALANCE (1)
M64 DRAWER BRACE (1)
M71 END MOLDING (2)

Part Identification Now you know
our ABCs.
401632www.sauder.com/services Pae 3
A
B
C2
D
E
F
G
H
M71
M12
M38
M59
M71 M38
F
K2
M64
D84
D169
D977
D83
I
J
EE
EE
M57
M13

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
35GA CABINET RIGHT - 1 35GB CABINET LEFT - 1 35GC DRAWER RIGHT - 1 35GD DRAWER LEFT - 1
7F TWIST-LOCK®
FASTENER - 12
ANGLE BRACKET - 10
5G
FOOT SCREW - 2
23F TIE PLATE - 6 3G
RUBBER SLEEVE - 12
2R
METAL PIN - 12
1R
10A SLIDE CAM - 2
LARGE RUBBER
SLEEVE - 2
58G
KNOB - 4
93K
HIDDEN CAM - 4
1F
CAM SCREW - 3
14F
401632 www.sauder.com/servicesPae 4
NAIL - 41
1N
CAM DOWEL - 1
2F
13H HINGE - 4 WASHER - 1 13M SAFETY STRAP - 1
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
60M
SAFETY DRYWALL
ANCHOR - 1
61M

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
401632www.sauder.com/services Pae 5
BLACK 1-7/8" FLAT HEAD SCREW - 2
2S
BLACK 1-1/8" PAN HEAD SCREW - 3
9S
BLACK 9/16" LARGE HEAD SCREW - 31
1S
BLACK 1/2" FLAT HEAD SCREW - 8
11S
3S GOLD 5/16" FLAT HEAD SCREW - 8
BLACK 1-7/8" PAN HEAD SCREW - 3
16S 30S BLACK 1-9/16" FLAT HEAD SCREW - 5
BLACK 1-1/4" FLAT HEAD SCREW - 4
7S

Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1668
to watch a video on how to assemble your unit.
Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the lare holes in the ENDS (A and B).
å Repeat this step for the SHELF (D) and BOTTOM (E).
401632 www.sauder.com/servicesPae 6
(12 used)
7F
Do not tihten the TWIST-LOCK® FASTENERS in this step.
A
B

å Slip the LARGE RUBBER SLEEVES (58G) over two TIE PLATES (3G). The
LARGE RUBBER SLEEVES will be a tiht fit.
å Fasten the TIE PLATES (3G) to one of the SHELF MOLDINGS (M38). Use two
BLACK 9/16" LARGE HEAD SCREWS (1S).
å Turn three CAM SCREWS (14F) into the other SHELF MOLDING (M38).
å Push four HIDDEN CAMS (1F) into the SHELF (D) and DRAWER BRACE (M64).
å Then, insert the metal end of a CAM DOWEL (2F) into the HIDDEN CAM in the
DRAWER BRACE (M64).
Step 2
401632www.sauder.com/services Pae 7
D
M38
M38
14F
Hole
Arrow
1F
58G
3G
This hole
is closer to
this ede.
This hole
is closer to
this ede.
Surface with
TWIST-LOCK®
FASTENERS
BLACK 9/16" LARGE HEAD SCREW
(2 used for the TIE PLATES)
1S
Arrow
The arrow in the HIDDEN
CAM must point toward the
hole in the ede of the board.
Hole
Arrow
2F
M64 1F
Do not tihten the
HIDDEN CAMS in
this step.

Step 3
å Fasten ten ANGLE BRACKETS (5G) to the ENDS (A and B).
Use ten BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: The ANGLE BRACKETS should be even with the edes
of the ENDS.
å Fasten a CABINET RIGHT (35GA) to the RIGHT END (A) and
a CABINET LEFT (35GB) to the LEFT END (B). Use four GOLD
5/16" FLAT HEAD SCREWS (3S) throuh holes #1 and #3.
401632 www.sauder.com/servicesPae 8
BLACK 9/16" LARGE HEAD SCREW
(10 used for the ANGLE BRACKETS)
1S
5G
A
B
5G
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
1
2
3
1
2
3
Roller end
Roller end
GOLD 5/16" FLAT HEAD SCREW
(4 used for the RAILS)
3S
Finished ede
Finished ede
(10 used)
Remember:
Rihty tihty.
Lefty loosey.

Step 4
401632www.sauder.com/services Pae 9
å Fasten the TOP (C2), SHELF (D), and BOTTOM (E) to the
RIGHT END (A). Tihten six TWIST-LOCK® FASTENERS.
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin
the FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
Dowel end
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
A
E
D
C2
Surface with
TWIST-LOCK®
FASTENERS
Lon finished ede
Finished ede
Surface
with holes
Ede with HIDDEN CAMS
These holes should be here.
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step 5
å Fasten the LEFT END (B) to the TOP (C2), SHELF (D), and
BOTTOM (E). Tihten six TWIST-LOCK® FASTENERS.
401632 www.sauder.com/servicesPae 10
B
E
D
C2
Surface without TWIST-LOCK® FASTENERS
Finished ede

å Fasten the TOP MOLDING (M12) to the TOP (C2). Use three
BLACK 1-7/8" PAN HEAD SCREWS (16S).
å NOTE: Do not overtihten the SCREWS into the TOP.
å Fasten the SHELF MOLDING (M38) (with the CAM SCREWS)
to the SHELF (D). Tihten three HIDDEN CAMS.
Step 6
401632www.sauder.com/services Pae 11
C2
M38
M12
D
1
2
BLACK 1-7/8" PAN HEAD SCREW
(3 used for the TOP MOLDING)
16S
Curved ede
These surfaces should be even.

Step 7
å Fasten four TIE PLATES (3G) to the VALANCE (M59). Use four
BLACK 9/16" LARGE HEAD SCREWS (1S).
å Fasten the VALANCE (M59) to the TOP MOLDING (M12). Use two
BLACK 9/16" LARGE HEAD SCREWS (1S) throuh the TIE PLATES
and into the TOP MOLDING.
å Fasten the END MOLDINGS (M71) to the ENDS (A and B) and
VALANCE (M59). Use ten BLACK 9/16" LARGE HEAD SCREWS (1S)
throuh the TIE PLATES and ANGLE BRACKETS and into the
END MOLDINGS.
å NOTE: There are no pre-drilled holes in the END MOLDINGS. The
SCREWS will tihten into the rooves.
å Fasten the SHELF MOLDING (M38) (with the LARGE RUBBER
SLEEVES) to the ENDS (A and B). Use two BLACK 9/16" LARGE
HEAD SCREWS (1S) throuh the ANGLE BRACKETS and into the
SHELF MOLDING.
401632 www.sauder.com/servicesPae 12
B
M59
M12
M71
M71
A
3G
M59
3G
The LARGE RUBBER
SLEEVES should be here.
BLACK 9/16" LARGE HEAD SCREW
(18 used in this step
1S
D
M38

å Fasten the SKIRT (M57) to the BOTTOM MOLDING (M13). Use
two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å Fasten the BOTTOM MOLDING (M13) to the BOTTOM (E). Use
three BLACK 1-1/8" PAN HEAD SCREWS (9S).
å Carefully turn two FOOT SCREWS (23F) a few turns into the
BOTTOM MOLDING (M13).
å Next, turn a FOOT (EE) onto the other end of each FOOT
SCREW (23F). Turn the FEET clockwise until the FOOT SCREWS
are tiht in the BOTTOM MOLDING and each FOOT.
å NOTE: Do not overtihten the FOOT SCREWS.
Step 8
401632www.sauder.com/services Pae 13
M57
EE
M13
M13
E
EE
23F
BLACK 1-1/8" PAN HEAD SCREW
(3 used for the BOTTOM MOLDING)
9S
BLACK 1-7/8" FLAT HEAD SCREW
(2 used for the SKIRT)
2S
Rounded ede
Rounded ede
Unfinished surface
Flat surface

Step 9
å Carefully turn your unit over onto its front edes. Unfold
the BACK (G) and lay it over your unit.
å Make equal marins alon all four edes of the BACK (G).
Push on opposite corners of your unit if needed to make
it "square".
å Fasten the BACK (G) to your unit usin the NAILS (1N).
å NOTE: Be sure to tap NAILS into the holes that line up
over the SHELF (D).
å NOTE: Perforations have been provided for access
throuh the BACK. Carefully cut out the holes needed.
401632 www.sauder.com/servicesPae 14
Unfinished
surface
These holes must line
up over the SHELF (D).
NAIL
(41 used in this step)
1N
Cut-outs (used for liftin)
G
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

å Fasten the HINGES (13H) to the DOORS (I and J). Use
eiht BLACK 1/2" FLAT HEAD SCREWS (11S).
Step 10
401632www.sauder.com/services Pae 15
J
I
BLACK 1/2" FLAT HEAD SCREW
(8 used in this step)
11S
Now miht be a
ood time to refresh
your drink.
13H
13H

Step 11
401632 www.sauder.com/servicesPae 16
å Carefully stand your unit upriht.
å Before fastenin the DOOR to your unit, be sure the
mountin screw is aainst the stops as shown in the
diaram. If it isn't, loosen the mountin screw to slide it
aainst the stops. Then tihten the mountin screw.
å Fasten the RIGHT DOOR (I) to the RIGHT END (A) as
shown in the lower diaram. Use the screws in the
HINGES. You should start each SCREW a few turns before
completely tihtenin any of them.
å Fasten a KNOB (93K) to the RIGHT DOOR (I). Use one
BLACK 1-1/4" FLAT HEAD SCREW (7S).
å Repeat this step for the LEFT DOOR (J).
å See the next step for DOOR adjustments.
AI93K
Pro Tip: Lift with your
les. And, you know,
your arms.
Mountin
screw
Stop
Hine
BLACK 1-1/4" FLAT HEAD SCREW
(2 used for the KNOBS)
7S

Step 12
401632www.sauder.com/services Pae 17
å Refer to the enlared diaram to identify the parts on the HINGES.
å The DOORS may need some adjustments. Follow the text below to make
needed adjustments.
å DOOR ADJUSTMENTS:
To adjust the DOORS from side to side (horizontal), turn the adjustin screw
in or out.
å To adjust the DOORS up and down (vertical), loosen both vertical
adjustment screws. Move the DOORS up or down to the desired location.
Tihten the screws after makin adjustments.
å To adjust the DOORS in or out (depth), loosen the mountin screw one turn
and move the DOORS in or out, as needed. Tihten the mountin screw
after makin adjustments.
Adjustin screw (horizontal)
Mountin screw (depth)
(vertical adjustment)

Step 13
401632 www.sauder.com/servicesPae 18
å Insert the DRAWER SIDES (D83 and D84) at
an angle into the slot at each end of the
DRAWER FRONT (K).
å Slide the DRAWER BOTTOM (D977) into the
grooves in the DRAWER SIDES (D83 and D84) and
DRAWER FRONT (K).
å Fasten the DRAWER BRACE (M64) to the
DRAWER FRONT (K). Tighten one HIDDEN CAM. å Fasten the DRAWER BACK (D169) to the DRAWER
SIDES (D83 and D84) and DRAWER BRACE (M64). Use
five BLACK 1-9/16" FLAT HEAD SCREWS (30S).
The tabs should insert freely into the
slots. Gently tilt the DRAWER SIDES side
to side until the tabs slip into the slots.
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of your hand, tap the
DRAWER BOTTOM down into the roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
KK
M64
K
M64
VIEW THE T-LOCK BOX VIDEO
D84
D83
D84
D977
D83
D83
D84
D169
Unfinished
surface
30S
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(5 used in this step)
Be sure the
DRAWER
BOTTOM inserts
into the DRAWER
BACK roove.
Surface with
HIDDEN CAM

Step 14
401632www.sauder.com/services Pae 19
å Insert the SLIDE CAMS (10A) into the lare holes in the
DRAWER SIDES (D83 and D84).
å Fasten a DRAWER RIGHT (35GC) to the DRAWER RIGHT
SIDE (D83) and a DRAWER LEFT (35GD) to the DRAWER
LEFT SIDE (D84). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #3.
å NOTE: The screw head in the CAM must be visible
throuh the slotted hole in the SLIDE.
å Fasten two KNOBS (93K) to the DRAWER FRONT (K).
Use two BLACK 1-1/4" FLAT HEAD SCREWS (7S).
1
2
3
1
2
3
GOLD 5/16" FLAT HEAD SCREW
(4 used for the SLIDES)
3S
Roller end
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
10A
Roller end
D84
D83
93K
BLACK 1-1/4" FLAT HEAD SCREW
(2 used for the KNOBS)
7S
K

Step 15
401632 www.sauder.com/servicesPae 20
60M
61M
BLACK 9/16" LARGE HEAD SCREW
(1 used in this step)
1S
13M
å Position your unit in its final location. We recommend usin the SAFETY STRAP (60M) for added stability.
å NOTE: Do not turn the SAFETY DRYWALL ANCHOR (61M) into a wall stud. If you prefer to fasten the SAFETY
STRAP (60M) to a wall stud, o to your local hardware store for proper hardware.
å INSTALLATION INSTRUCTIONS: (Also available at www.yl-anchors.com)
1. Insert the SAFETY DRYWALL ANCHOR (61M) throuh the WASHER (13M) and one end of the SAFETY STRAP (60M).
2. Usin a Phillips screwdriver or a hand drill, press the screw slihtly onto the drywall.
3. Apply pressure; turn the screw until a pilot hole is made and the nylon sheath slips throuh.
4. Turn the screw until it is flush aainst the wall and you feel a firm resistance.
5. Continue to turn until the screw starts spinnin freely.
å Fasten the SAFETY STRAP (60M) to the TOP (C2). Use a BLACK 9/16" LARGE HEAD SCREW (1S).
å NOTE: Before movin your unit to a dierent location, unscrew the SAFETY DRYWALL ANCHOR (61M) from your wall.
The nylon sheath will remain behind your wall.
C2
