Sauder Whitaker Point 429366 User manual

sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey!
Enlish p 1-41
Français p 42-46
Español p 47-52
Lot # 573750 11/07/21
Purchased: __________________
Computer Desk
Whitaker Point Collection | Model 429366
For all your
newfanled gadgetry.

Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4-5
6
7-41
42-46
47-52
53-54
55
Pae 2 www.sauder.com/service 429366

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A LEFT END (1)
B RIGHT END (1)
C LEFT UPRIGHT (1)
D RIGHT UPRIGHT (1)
E TOP (1)
F BOTTOM (2)
G MODESTY PANEL (1)
H BACK (2)
J SMALL DRAWER FRONT (1)
K SMALL LEFT DRAWER SIDE (1)
L SMALL RIGHT DRAWER SIDE (1)
M SMALL DRAWER BACK (1)
N SMALL DRAWER BOTTOM (2)
O DRAWER FRONT (1)
P LEFT DRAWER SIDE (1)
Q RIGHT DRAWER SIDE (1)
R DRAWER BACK (1)
S LARGE DRAWER FRONT (1)
T LARGE LEFT DRAWER SIDE (1)
U LARGE RIGHT DRAWER SIDE (1)
V LARGE DRAWER BACK (1)
W LARGE DRAWER BOTTOM (1)
X ADJUSTABLE SHELF (1)
Y DOOR (1)
Z TOP MOLDING (1)
A
ZB
C
D
E
F
F
G
H
H
JK
L
M
N
NO
P
Q
R
S
T
U
V
W
X
Y
Pae 3www.sauder.com/service429366

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
(EXTENSION SET SHOWN SEPARATED)
1SHORT EXTENSION
RAIL - 4 2SHORT EXTENSION SLIDE - 4
(EXTENSION SET SHOWN SEPARATED)
3LONG EXTENSION
RAIL - 2 4LONG EXTENSION SLIDE - 2
5FILE GLIDE - 2 6FILE
HANGER  2
LARGE WOOD
DOWEL - 41
7SMALL WOOD
DOWEL - 20
8
LARGE HIDDEN
CAM - 34
9SMALL HIDDEN
CAM - 10
10 11 CAM SCREW - 44 DOOR STOP- 1
12
13 HINGE - 2 GROMMET
WITH CAP- 2
14 15 GROMMET - 4 METAL PIN - 4
16
PULL - 3
17 KNOB - 1 18 APPLIQUE CARD - 1 2019 METAL
BRACKET - 2
Pae 4 www.sauder.com/service 429366

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
2" FLAT HEAD SCREW - 4
22 1-1/2" FLAT HEAD SCREW - 10 23
24 78" MACHINE SCREW  1 1/2" PAN HEAD SCREW - 6
25
26 12" MACHINE SCREW  6 1/2" FLAT HEAD SCREW - 4
27
3/8" FLAT HEAD SCREW - 38
28
Pae 5www.sauder.com/service429366

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Pae 6 www.sauder.com/service 429366

Step 1 Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push six LARGE HIDDEN CAMS (9) into the LEFT
END (A) and LEFT UPRIGHT (C).
å Turn ten CAM SCREWS (11) into the exact holes shown in
the LEFT END (A) and LEFT UPRIGHT (C).
A
C
11
11
(10 used)
9
Arrow
9
Arrow
Pae 7www.sauder.com/service429366
1

Step 2
Push the black lever and pull the SLIDE from the RAIL.
Use these holes.
1
2
å Separate the SHORT EXTENSION SLIDES (2) from the SHORT EXTENSION RAILS (1) as shown in the upper diaram
below. Be prepared, the parts are reasy.
å Fasten four SHORT EXTENSION RAILS (1) to the LEFT END (A) and LEFT UPRIGHT (C). Use twelve 3/8" FLAT
HEAD SCREWS (28).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner
cartride of the EXTENSION RAIL in to find the other holes that lines up with the holes in the END and UPRIGHT. Turn
a SCREW into these holes.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
1
1
1
1
C
A
3/8" FLAT HEAD SCREW
(12 used in this step)
28
Pae 8 www.sauder.com/service 429366
7

Step 3
Push the black lever and pull the SLIDE from the RAIL.
Use these holes.
3
å Separate the LONG EXTENSION SLIDES (4) from the LONG EXTENSION RAILS (3) as shown in the upper diaram
below. Be prepared, the parts are reasy.
å Fasten two LONG EXTENSION RAILS (3) to the LEFT END (A) and LEFT UPRIGHT (C). Use eiht 3/8" FLAT
HEAD SCREWS (28).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner
cartride of the EXTENSION RAIL in to find the other holes that lines up with the holes in the END and UPRIGHT. Turn
a SCREW into these holes.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
A
C
3/8" FLAT HEAD SCREW
(8 used in this step)
28
3
3
4
Pae 9www.sauder.com/service429366
7

Step 4
F
H
9
Arrow
Arrow
9
å Push ten LARGE HIDDEN CAMS (9) into one each of the
BOTTOMS (F) and BACKS (H).
1
Some assembly
(and snacks) required.
Pae 10 www.sauder.com/service 429366

Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
Step 5
F
H
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
7
This HIDDEN CAM should
be closer to this ede.
å Insert two LARGE WOOD DOWELS (7) into the BACK (H).
å Push the BOTTOM (F) onto the LARGE WOOD
DOWELS (7) in the BACK (H).
Pae 11www.sauder.com/service429366

Step 6
å Insert four LARGE WOOD DOWELS (7) into the
LEFT END (A).
å Fasten the BOTTOM (F) and BACK (H) to the LEFT
END (A). Tihten five LARGE HIDDEN CAMS.
å NOTE: Be sure the LARGE WOOD DOWELS in the LEFT
END insert into the BOTTOM and BACK.
F
A
H
7
7
1
Pae 12 www.sauder.com/service 429366

Step 7
7
7
å Insert four LARGE WOOD DOWELS (7) into the
BOTTOM (F) and BACK (H).
å Fasten the LEFT UPRIGHT (C) to the BOTTOM (F) and
BACK (H). Tihten five LARGE HIDDEN CAMS.
å NOTE: Be sure the LARGE WOOD DOWELS in the
BOTTOM and BACK insert into the LEFT UPRIGHT.
F
H
C
1
Pae 13www.sauder.com/service429366

Step 8
F
H
9
Arrow
Arrow
9
å Push ten LARGE HIDDEN CAMS (9) into the remainin
BOTTOM (F) and BACK (H).
1
Pae 14 www.sauder.com/service 429366

Step 9
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
F
H
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
7
This HIDDEN CAM should
be closer to this ede.
å Insert two LARGE WOOD DOWELS (7) into the BACK (H).
å Push the BOTTOM (F) onto the LARGE WOOD
DOWELS (7) in the BACK (H).
Pae 15www.sauder.com/service429366

Step 10
å Push six LARGE HIDDEN CAMS (9) into the RIGHT
END (B) and RIGHT UPRIGHT (D).
å Turn ten CAM SCREWS (11) into the exact holes shown in
the RIGHT END (B) and RIGHT UPRIGHT (D).
B
D
11
9
Arrow
9
Arrow
1
Pae 16 www.sauder.com/service 429366
(10 used)

Step 11
F
H
D
å Insert four LARGE WOOD DOWELS (7) into the
RIGHT UPRIGHT (D).
å Fasten the BOTTOM (F) and BACK (H) to the RIGHT
UPRIGHT (D). Tihten five LARGE HIDDEN CAMS.
å NOTE: Be sure the LARGE WOOD DOWELS in the RIGHT
UPRIGHT insert into the BOTTOM and BACK.
7
7
1
Pae 17www.sauder.com/service429366

Step 12
7
7
å Insert four LARGE WOOD DOWELS (7) into the
BOTTOM (F) and BACK (H).
å Fasten the RIGHT END (B) to the BOTTOM (F) and BACK (H).
Tihten five LARGE HIDDEN CAMS.
å NOTE: Be sure the LARGE WOOD DOWELS in the
BOTTOM and BACK insert into the RIGHT END.
F
H
B
1
Pae 18 www.sauder.com/service 429366

Step 13
å Insert four LARGE WOOD DOWELS (7) into the
MODESTY PANEL (G).
å Fasten the MODESTY PANEL (G) to the RIGHT
UPRIGHT (D). Use two 2" FLAT HEAD SCREWS (22).
å NOTE: Be sure the LARGE WOOD DOWELS in the
MODESTY PANEL insert into the RIGHT UPRIGHT.
å Fasten the LEFT UPRIGHT (C) to the MODESTY
PANEL (G). Use two 2" FLAT HEAD SCREWS (22).
å NOTE: Be sure the LARGE WOOD DOWELS in the
MODESTY PANEL insert into the LEFT UPRIGHT.
å Push two LARGE HIDDEN CAMS (9) into the
MODESTY PANEL (G).
1
Arrow
9
G
C
D
7
7
(4 used)
22
2" FLAT HEAD SCREW
(4 used in this step)
22
Curved ede
Surface with holes
Pae 19www.sauder.com/service429366

å Turn fourteen CAM SCREWS (11) into the TOP (E).
å Insert three LARGE WOOD DOWELS (7) into the TOP (E).
å Push the TOP MOLDING (Z) onto the WOOD DOWELS (7)
in the TOP (E).
Step 14
Surface
with HOLES
Z
7
11
(14 used)
E
