INSTRUCTIONS FOR:
HEAVY-DUTY WORKSTATION WITH 5 DRAWERS
MODEL:AP2050
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
2. CONTENTS
1.1 GENERAL SAFETY
pWARNING! Ensure Health & Safety, local authority, and general workshop practice
regulations are adhered to when using this bench.
3Locate bench in a suitable working area.
3Keep the work area clean, uncluttered and ensure there is adequate lighting.
pWARNING! Use bench on level and solid ground, preferably concrete. Avoid tarmacadam
since the bench may sink into the surface.
3Keep the bench clean and tidy in accordance with good workshop practice.
3Keep children and unauthorised persons away from the working area.
7DO NOT use the bench for any purpose other than that for which it is designed.
7DO NOT undertake work on the bench without the workpiece being adequately secured. Use
clamps or a vice (not included) to secure the workpiece. Available from your Sealey dealer.
7DO NOT use the bench out of doors.
7DO NOT get the bench wet or use in damp or wet locations or areas where there is
condensation.
7DO NOT clean the bench with any solvents which may damage the paint surface or the
protective coating on the wooden top.
7DO NOT pull out all drawers at the same time.
pMaximum weight for each drawer is 25 kg, full load for Workbench is 180 kg.
AP2050 - 1 - 101005
2.1 Carefully unpack the product and check the contents against the diagram below. Should any items be missing or damaged make
immediate contact with your Sealey dealer.
01284 757500
01284 703534 sales@sealey.co.uk
Sole UK Distributor
Sealey Group,
Bury St. Edmunds, Suffolk.
www.sealey.co.uk
Web
email
3. ASSEMBLY
STEP 1. Take two crossrails (B) and bolt them
to the cabinet sides (A) using 8 bolts (O), 8 lock
washers (P), and 8 nuts (Q). Ensure that the
pairs of holes that accept the corner braces are
facing downwards. (Refer to STEP 5.)
STEP 2. Bolt 1 left & 1 right slide panels (D) &
(E) into position, only bolt at front of Work
Bench using 4 bolts (O), 4 lock washers (P),
and 4 nuts (Q). Fix 5 left hand female slide (L),
onto each slide panel (D) and 5 right hand
female slide (L), onto each slide panel (E)
Refer to Diagram 9 on how to fit slides.
STEP 4. Take two crossrails (B) and bolt them
to the cabinet sides (A) using 8 bolts (O), 8 lock
washers (P), and 8 nuts (Q).
STEP 3. Take two draw stops (G) and back
panel (F) and bolt them to the back of the
cabinet with the draw stops between the panel
and the cabinet. Use 4 bolts (O), 4 lock
washers (P), and 4 nuts (Q).
STEP 5. Screw in the four adjustable leg
levellers (R). Bolt the four corner braces (I) into
position using 16 bolts (O), 16 lock washers
(P), and 16 nuts (Q)
STEP 6. Place the wooden top (N) face down
on a flat, clean, smooth surface. Position the
cabinet upside down on the wooden top and
mark the hole locations on the top. Move the
cabinet to one side and drill 5/32 diameter x
1/2 deep holes in the top. DO NOT DRILL
DEEPER THAN 1/2. Attach frame to top with
the 4 hex head screws (S).
AP2050 - 1 - 101005
3
12
64 5
STEP 8. Attach a left hand female slide (K) to left
hand side of each draw and a right hand female
slide (K) to the right hand side of each draw (see
diagram 9). Engage each draw onto the protruding
male slides and push fully home, then open the
draw to check that it is retained.
Diagram 9. Orientate each slide as shown in the diagram above with the rear hook pointing
towards the rear of the draw or the rear of the cabinet. Put the rear hook on each slide into the
square hole nearest the back of the draw or the back of the cabinet and push the slide backwards
to engage the hook. Swivel the front of the slide up or down slightly until the other two hooks
appear in the other two holes. Keep the rear face of the slide up against the draw or slide panel.
On the draws pull the slide sharply upwards to engage it. On the cabinet push the slides down to
engage.
STEP 7. Take the 10 male slide components (M) and
slide 5 onto the female slides on the left of the draw
compartment and 5 onto the female slides on the
right hand side of the draw compartment. Push them
fully in to engage them, then pull them out to the stop
point.
AP2050 - 1 - 101005
8
7
9
