INSTRUCTIONS FOR
MOBILE STAINLESS STEEL TOOL CABINET
10 DRAWER WITH BACKBOARD & 2 WALL CUPBOARDS
MODEL NO: AP5520SS
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
product.
9Locate in a suitable work area.
8DO NOT let children near the cabinet.
8DO NOT open more than one drawer at a time.
9 Fillfromthebottomdrawerup.Ifthetoolcabinetislledfromthetopdrawerdown,itwillbetopheavyandmayfallover.
8DO NOTattempttoliftbythesidehandles,usechains,ropesorotherliftingdevices.
8DO NOT step or climb on the product or on the drawers.
8DO NOT alter the product in any way, e.g. do not weld on external lock bars or attach electrical equipment. This may cause damage to
the product or cause personal injury.
9 Keeponalevelsurface.
9 WhenmovingthecabinetDO NOTpullit.Pushthecabinettopreventinjury.
9 Closeandlockthedrawersbeforemovingthecabinet.Ifthedrawerscameopentheycouldmakethecabinetunstable.
9Apply the brakes when in desired position.
8DO NOTmountonatruckbedoranyothermovingobject.
8 Beawareofsharpedgesweargloves.
2. INTRODUCTION
Anti-ngerprintstainlesssteelconstructionwitha38mmthickwoodenworktop.45kgcapacitydrawerswithaluminiumpullhandlesandnon-slip
liners.Fourlargecastorwheels,twoxedandtwoswivel(whichincludebrakes).Comeswithheavy-dutysidehandleforcomfortandcontrol
whenmanoeuvring.Suppliedwithlocksandkeys.
3. SPECIFICATION
Model no: ............................................................ AP5520SS
Overallsize(WxDxH):.....................1475x505x1860mm
Medium1/2drawer(x3): ...........................375x395x65mm
Large1/2drawer(x1):.............................375x395x140mm
X-large1/2drawer(x1): ..........................375x395x220mm
Mediumdrawer(x3): .................................855x395x65mm
Largedrawer(x1):...................................855x395x140mm
X-largedrawer(x1): ................................855x395x220mm
Wallcabinet(x2): ....................................645x300x410mm
AP5520SS|Issue1-10/05/16
Original Language Version
© Jack Sealey Limited
Refer to
Instruction
Manual
Wear
Protective
gloves

4. ASSEMBLY
4.1. Fit handle see Step 1
4.1.1. Attachhandlewith6mmx12mmhexbolts,springandatwashers.
4.2. Fit casters See Step 2
WARNING! Two or more people are required to lay down or stand up the cabinet. DO NOT stand in front or behind and lock drawers
 whilstturningover.
4.2.1. Carefully lay the cabinet upside down with a soft mat underneath for protection.
4.2.2. Fitthetwoswivel/brakedcastors,onthehandlesideusing10mmx25mmbolts,througheachcastorandintothebottomofthe 
cabinet. Tighten securely.
4.2.3. Repeat for the two rigid casters on the other side.
4.3. Drawers See Step 3
4.3.1. Newdrawersslidesmaybestiffanddifculttoopenatrst.Agentleoutwardpullshouldreleasethesafetycatchthatpreventsthe
 drawerfromopeningwhilstthecabinetisbeingmoved.
4.3.2. Removedrawersfromtheirslidesasbelow(pullleftslidetabdownandpullrightsideslidetabup).
4.4. Fit uprights See Step 4 & Step 5
4.4.1. Fitthetwouprightstothecabinetwithfour6mmx14mmhexbolts
to each.
4.4.2. Inserttheuppersectionoftheuprightsintothelowerone(Step5).
Step 3
Step 1 Step 2
AP5520SS|Issue1-10/05/16
Original Language Version
© Jack Sealey Limited
Step 4
Step 5

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP327AR
www.sealey.co.uk
[e-mail]
01284757500
01284703534
Web
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
AP5520SS|Issue1-10/05/16
Original Language Version
© Jack Sealey Limited
4.5. Fit backboard See Step 6
4.5.1. Fitthebackboardtotheuprightswithsix6mmx14mmbolts.
4.6. Fit wall cupboards see Step 7
WARNING! Two or more people will be required to hold the wall cupboard in position whilst it is being bolted to the uprights.
4.6.1. Fitwallcupboardtouprightswithsix6mmx14mmhexbolts.
5. MAINTENANCE
5.1. To clean use a soft cloth that will not scratch the surface.
5.2. DO NOTusesolventsofanykindtheymaydamagethesurface.
5.3.  Liquidspillsshouldberemovedimmediately,useasoftcleanclothtoblotthespillgently-avoidrubbing.
5.4. Grease the casters with good quality grease once a year.
5.5. Lubricate the drawer slides twice a year with light duty oil.
Step 6
