Sealey APMS01 User manual

MODULAR FLOOR CABINET/ DRAWER
775/1550MM HEAVY DUTY
MODEL NO’S: APMS01, APMS02, APMS03, APMS04
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
I
MPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using these
cabinets.
9Locate the cabinets in a suitable work area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use the cabinets on level and solid ground, preferably concrete.
9Keep the cabinets clean and tidy in accordance with good workshop practice.
9Keep children and unauthorised persons away from the work area.
8DO NOT use these cabinets for any purpose other than that for which they are designed.
8DO NOT use the cabinets outdoors.
8DO NOT place the cabinets in a damp or wet location or an area where there is condensation.
8DO NOT clean the cabinets with any solvents which may damage the surfaces or the protective coating.
2. INTRODUCTION
Heavy-duty high end Modular Garage Storage System with an appearance to enhance any garage/workshop. Built to withstand the rigours of
any garage environment. Versatile and durable steel construction that will last for years. Easily adjusts to specic needs; purchase a simple base
cabinet or create a full garage storage system.
3. SPECIFICATION
Refer to
instruction
manual
Wear
protective
gloves
Model no APMS01 APMS02 APMS03 APMS04
Overall size (W x D x H) 775 x 610 x 955mm 1550 x 610 x 955mm 775 x 610 x 955mm 1550 x 640 x 955mm
Small drawer (W x D x H) (3) 670 x 535 x 55mm (6) 670 x 535 x 55mm
Large drawer (W x D x H) (2) 670 x 535 x 130mm (2) 670 x 535 x 130mm
Xlarge drawer (W x D x H) (2) 670 x 535 x 205mm (2) 670 x 535 205mm
Full width drawer (W x D x H) (1) 445 x 535 x 125mm
Nett weight 42kg 75kg 88kg 159kg
Pictured with top tted, supplied
separately
Original Language Version
© Jack Sealey Limited APMS01, APMS02, APMS03, APMS04 | Issue:3 (H,F) 15/01/19

4. ASSEMBLY
4.1. FIT WORKTOP
4.1.1. The only assembly required is to t the worktop supplied separately and the door handles (if applicable).
4.1.2. Fit worktop by screwing from underneath using 4 x hex ange bolts (see g.1) or 6 x hex ange bolts for 60” wide models (see g.2).
4.2. FIT HANDLES
4.2.1. Handles screw on from the rear, using cross head screws (see g.2).
4.3. REMOVE DRAWERS (if applicable)
4.3.1. Pull drawer out fully and push black lever in each drawer runner up or down, then pull out drawer to release (see g.1).
4.4.
4.5.
.
fig.1fig.2
Original Language Version
© Jack Sealey Limited APMS01, APMS02, APMS03, APMS04 | Issue:3 (H,F) 15/01/19
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
