INSTRUCTIONS FOR:
41 7 DRAWER STAINLESS STEEL TOP CHEST
MODEL: AP4707S
1. SAFETY PRECAUTIONS
2. CONTENTS
3. ASSEMBLY
4. OPERATION
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS. USE THIS
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
1.1. GENERAL SAFETY INSTRUCTIONS.
3Read the operators Manual carefully before using your tool chest.
7DO NOT open more than one drawer at a time.
7DO NOT step on the drawers.
7DO NOT let children near the tool chest.
3Lock drawers and top lid before moving the tool chest.
Check that the kit contains the following parts, if not contact your supplier immediately.
3.1 Install Side Handles.
3.1.1 Line up the side handles x 2 on either side of the chest. (fig.2)
3.1.2 Using the M6 x 1.0mm HEX bolts secure the handles to the cabinet.
3.1.3 Tighten M6 HEX bolts securely.
3.2 Install drawer liners.
3.2.1 Place liners x 8 inside top compartment and each drawer to protect the surface.
4.1 Remove and Replace Drawer.
4.1.1 Extend drawer fully, press down the black lever on the right hand slider
(fig.3), and pull up the black lever on the left hand slide (fig.4).
4.1.2 Hold the levers and then extend the drawer fully outward until the drawer is out of the slides.
4.1.3 Replace by pulling out the slides.
4.1.4 Insert the rails on either side of the drawer into the slots of the slides and gently push the drawer into place.
AP4707S - 1 - 070604
Fig.1
Fig.2
Fig.3 Fig.4

PARTS FOR:
41 7 DRAWER STAINLESS STEEL TOP CHEST
MODEL:AP4707S
01284 757500
01284 703534 [e-mail]
Sole UK Distributor
Sealey Group,
Bury St. Edmunds, Suffolk.
www.sealey.co.uk
Web
email
ITEM DESCRIPTION PART No.
1 SIDE HANDLE AP4707S.01
2 M6 HEX BOLT AP4707S.02
3 BEARING SLIDE AP4707S.03
4 AIR LIFT AP4707S.04
5 LINER (L) AP4707S.05
6 LINER (S) AP4707S.06
ITEM DESCRIPTION PART No.
7LOGO AP4707S.07
8LOCK AP4707S.08
9KEY AP4707S.09
10 HANDLE (S) AP4707S.010
11 HANDLE (L) AP4707S.011
PARTS ISSUE 1
ISSUE DATE 070604
