Seaside Casual 44 SYM Table User manual

Page 1
220- rev A
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
x 1
80mm Hex Lag
Stretchers
Leg Assemblies
x 2
Part Code: 4MMALLEN
Actual Size
4mm Allen Wrench
x 1
x 2
X 8
44” SYM Table
(220)
Part Code: 316-1/4-10-80HL
ASSEMBLY INSTRUCTIONS
Table Top Assembly
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
Tools Required:
Actual Size
Actual Size
5/8” Bung
X 8
Actual Size
3/4” Phillips Pan Head Screw
x 8
Part Code: 316-8X3/4PPS

Page 2
220- rev A
2ATTACH STRETCHERS TO LEG ASSEMBLIES
Attach stretchers to leg as-
semblies using (8) 80 mm Hex
Lags thru counter-bored holes
in Leg Assembly into pilot
holes in ends of Stretchers.
Plug holes with 5/8” Bungs.
Turn Base upside
down onto Table Top
aligning legs outside of
the aluminum table
top cleats. Secure using
(8) 3/4” Phillips Pan
Head Screws.
3ATTACH BASE ASSEMBLY TO TABLE TOP
