Seaside Casual DEX 150 User manual

Page 1
150
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
TOP
x 1
CONNECTOR
50mm Hex Lag
5/8 taps®
SHORT LEG
x 2
Part Code: 4MMALLEN
Actual Size
4mm Allen Wrench
x 1
x 2
DEX Coffee Table
150
Part Code: 316-1/4-10-50HL
x 1
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
(Recommended: Rubber Mallet; Power Drill)
Tools Required:
Actual Size
1 1/4” Philips Head Screw
x 2
LONG LEG
x 1
x 8
Actual Size
Actual Size
Part Code: TAP-5/8

Page 2
150
2ASSEMBLE LEGS
Attach Long Leg to Short Leg using
(2) 50mm Lags and (2) 1 1/4” Philips
head screws. Plug holes with 5/8”
taps®.
Attach Connector to legs using (4)
50mm Lags.
3ATTACH CONNECTOR TO LEGS
Attach Leg Assemby to Top using (4)
50mm Lags to Connector through alu-
minum holes.
4ATTACH CONNECTOR TO ALUMINUM FROM UNDERNEATH
