Seaside Casual DEX Ottoman User manual

Page 1
146-Rev A
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Actual Size
5/8” tap®
x 8
Foot Rest
50mm Hex Lag
Apron
Leg Assembly
x 2
Part Code: 4MMALLEN
Actual Size
4mm Allen Wrench
x 1
x 2
x 1
x 8
DEX Ottoman
(146)
Part Code: 316-1/4-10-50HL
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
Tools Required:
Part Code: 316-8X1-3/4PFDS
Actual Size
1-3/4” Phillips Head Screw
x 8
Actual Size

Page 2
146-Rev A
Attach Leg Assembly to
Aprons using (4) 50 mm Hex
Lags thru counter-bored holes
in Leg Assembly into pilot
holes in aprons. Plug Holes
using 5/8” taps®.
Repeat process for other side.
2ATTACH LEGS TO APRONS
Secure Foot Rest to Leg As-
sembly using (4) 1-3/4” Phil-
lips Head Screws through
counter-sunk holes in cleats
into pilot holes in Leg Assem-
bly. (Confirm that Foot Rest is
flush with Aprons before tighten-
ing)
Repeat process for other side.
3SECURE FOOT REST TO LEGS
