Seaside Casual 411 User manual

Page 1
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware are in-
cluded using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
TOP
x 1
HAIRPIN LEG (411)
M6 SCREW
FRAME
x 1
Actual Size
5mm ALLEN WRENCH
x 1
HIP BENCH
411
412
x 4
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
(Recommended: Rubber Mallet; Power Drill)
Tools Required:
Actual Size
M6 SPLIT WASHER M6 WASHER
Actual Size
3/4” PHILLIPS PAN HEAD SCREW
x 26
x 12
x 12
Actual Size
ANCHOR LEG (412)
x 2
x 12
Actual Size

Page 2
2ATTACH TOP TO FRAME
On a clean flat surface align Frame pins
with holes underneath Top. Attach Frame
to Top with (26) 3/4” Phillips pan head
screws. Do not over tighten.
On a clean flat surface connect legs to
frame using (3) M6 screws, Split Wash-
ers, and washers (AS SHOWN). Finger
tighten. Repeat with remaining (9) M6
Screws, Split Washers, and Washers. Do
not over tighten.
3ATTACH LEGS
