Seaside Casual Nantucket 089 User manual

Page 1
089-REV C 090-REV D 091-REV D
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Part Code: 18/8-14X2-1/2PPMS
Actual Size
2 1/2” Pan Head Screw
Back Assembly
x 1
Front Legs
Rear Legs
80mm Hex Lag
Arms
Seat Assembly
x 1
Part Code: 4MMALLEN
Actual Size
4mm Allen Wrench
x 1
x 1ea
x 1ea
x 22
x2
Nantucket Collection
(089 Love Seat, 090 Sofa,
091 Chair)
Part Code: 316-1/4-10-80HL
x 1ea
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
#3 Phillips Head Screwdriver; (Recommended: Rubber Mallet; High Powered Drill)
Tools Required:
Part Code: 316-8X1-3/4PFDS
Actual Size
1-3/4” Phillips Head Screw
x 9
Actual Size
Bungs
x 3
x 22
5/8“ 3/8“
Right
Left
Left
Right
Right
Left
Mid (Sofa Only)

Page 2
089-REV C 090-REV D 091-REV D
2ATTACH FRONT LEGS TO
ARMS
Insert left side Front Leg into
threaded inserts in Left Arm as
shown. Turn clock-wise until
snug. Continue turning until
legs are into aligned position.
Secure with (2) 1-3/4” Phil-
lips Head Screws.
Repeat process for Right Side.
Align counter-bored
hole in Rear Left Leg
with Pilot hole in Left
Arm. Attach using (1)
80mm Hex Lag. Plug
holes with (1) 5/8” Bung using rubber
mallet.
Repeat process for Right side.
Attach Back to Mid
Leg using (2) 1-3/4”
P h i l l i p s H e a d
Screws.
3ATTACH REAR LEGS TO ARMS
7ATTACH BACK (090 ONLY)
Lay seat upside down on a
bench with side hanging
over. Align Counter-bored
holes in legs with pilot
holes in aprons. Front of
seat will be marked with an “F” on the bottom of
the apron. Attach using (8) 80mm Hex Lags.
Plug holes with 5/8” Bungs using rubber mallet.
Repeat Process for other side.
4ATTACH SIDE ASSEMBLIES TO
SEAT
Front
Tapered side
Counter-bores
If you are assembling a
Sofa (090), Align Mid
Rear Leg with Rear
Apron and Last Slat
and Secure using (2) 2-
1/2” Pan Head Screws
thru holes in Rear
Apron using a #3 Phil-
lips Head Screwdriver.
5ATTACH MID REAR LEG (090
ONLY)
Turn Assembly upright.
Attach Back Assembly to
Rear Legs using (4) 80mm
Hex Lags thru counter-bored holes in
Rear Legs into pilot holes in lower back.
Plug holes with (4) 5/8” Bungs. Secure
upper back using (2) 1 3/4” Phillips
Head Screws (3 for 090). Plug holes with
3/8” Bungs using rubber mallet.
6ATTACH BACK
Front
