Seaside Casual MAD Fusion Chaise 400 User manual

Page 1
REV C
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Actual Size
3/4” Phillips Pan Head Screw
Base Assembly
x 1
Woven Seat Insert
Slat Frame Insert
Seat Slat Assembly
x 1
x 1
x 33
MAD Fusion Chaise
Slat or Woven
(400)
x 1
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver; Rubber Mallet.
Tools Required:
Part Code: 316-M5X40PPMS
Actual Size
Actual Size
1-1/2” Phillips Pan Head Machine Screw
x 4
Base Trim
x 2
Back Slat Assembly
x 1
1/4” Flat Washer
x 4
316-1/4FW
Part Code: 316-8X3/4PTS

Page 2
REV C
Align trim with Base as
shown. Secure using (12) 3/4”
Pan Head Screws through
deep holes in sides of base
into drilled holes in Base Trim
using Philips Head Screw
Driver. Note: Attach all screws
loosely before final tightening.
Align Back Slat Assembly
and Seat Slat Assembly with
stickers facing each other, so
that slats sit close to flush to
frame on the inside nearest to
the hinge when assembled.
Place insert over top of slats
as shown. Secure using (21)
3/4” Pan Head Screws.
2ATTACH BACK AND SEAT SLATS TO SEAT FRAME ASSEMBLY (SLATTED
VERSION ONLY)
3ATTACH TRIM TO BASE
Attach Seat Assembly (Slat or
Woven) to Base using (4) 1-
1/2” Phillips Pan Head Ma-
chine Screws and 1/4” Flat
Washers through holes in
Base into threaded inserts in
Seat Frame as shown. Leave
these loose. Check for even
spacing between slats and
trim. Adjust as needed. Tight-
en Seat Assembly to Base,
and all remaining hardware.
4ATTACH SEAT ASSEMBLY TO BASE (SLAT OR WOVEN)
STICKERS
