Seaside Casual AURA 901R6 User manual

Page 1
901R6
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
FRONT
x 1
50mm Hex Lag
SIDE
x 2
Part Code: 4MMALLEN
Actual Size
4mm Allen Wrench
x 1
AURA 6” DINING RISER
901R6
Part Code: 316-1/4-10-50HL
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
(Recommended: Rubber Mallet; Power Drill)
Tools Required:
Actual Size
BACK
x 1
x 16
80mm Hex Lag
Part Code: 316-1/4-10-80HL
Actual Size
x 1
CORNER
x 4
SUPPORT
x 1

Page 2
901R6
2 ARRANGE PARTS
Begin by arranging parts on a flat
surface as shown. Holes facing
up. Take note of location of com-
ponents.
Using (16) 50mm Lags, align (4)
CORNER with pre-drilled holes
on FRONT, BACK, and SIDE(s).
Do not tighten completely. Once
(4) corners are upright and in po-
sition, fully tighten all hardware.
3 ATTACH CORNERS
Finally, remove access door on your
901 Aura Fire Table. Locate hole to be
used to attach SUPPORT. Remove ex-
isting LAG and replace with 80mm
LAG included in your hardware pack.
Place 901 AURA Fire Table on top of
901R6.
4 ATTACH SUPPORT AND COMPLETE ASSEMBLY
FRONT
BACK
SIDE
SIDE
