Seca 745 Instruction Manual

seca 745
seca 725

Bedienungsanleitung und Garantieerklärung . . . . . . . . . . 3
Instruction manual and guarantee . . . . . . . . . . . . . . . . . . 25
Mode d’emploi et garantie. . . . . . . . . . . . . . . . . . . . . . . . . 45
Manuale di istruzioni e garanzia . . . . . . . . . . . . . . . . . . . . 67
Manual de instrucciones y garantia . . . . . . . . . . . . . . . . . 89
Instruções de utilização e declaração de garantia . . . . . 111
Instrukcja obsługi i gwarancja . . . . . . . . . . . . . . . . . . . . 133
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . 155
D
GB
FR
IT
ES
P
PL

• 25
English
CONTENTS
English
1. Full certification . . . . . . . . . . . . . 26
2. Description of device . . . . . . . . . 26
2.1 Congratulations! . . . . . . . . . . . 26
2.2 Intended use . . . . . . . . . . . . . . 27
2.3 Description of function . . . . . . 27
2.4 User qualification . . . . . . . . . . 27
3. Safety information . . . . . . . . . . . . 28
3.1 Safety information in these
instructions for use . . . . . . . . . 28
3.2 Basic safety precautions . . . . . 28
Handling the device . . . . . . . . 28
Avoiding infections . . . . . . . . . 29
Avoiding injury . . . . . . . . . . . . 29
Avoiding damage to the
device . . . . . . . . . . . . . . . . . . . 29
Handling the measurement
results . . . . . . . . . . . . . . . . . . . 30
Handling the packaging
material . . . . . . . . . . . . . . . . . . 30
4. Overview . . . . . . . . . . . . . . . . . . . 31
4.1 Controls . . . . . . . . . . . . . . . . . 31
4.2 Information on device and
on rating plate . . . . . . . . . . . . . 32
4.3 Information on the
packaging . . . . . . . . . . . . . . . . 32
5. Before you get started … . . . . . . 33
5.1 Scope of supply . . . . . . . . . . . 33
5.2 Remove transport lock . . . . . . 33
5.3 Put on tray . . . . . . . . . . . . . . . 34
5.4 Set up and align scale . . . . . . . 34
6. Operation . . . . . . . . . . . . . . . . . . . 35
6.1 Rendering the scale
operational . . . . . . . . . . . . . . . 35
Releasing/locking the beam . . 35
Checking the position of
the beam . . . . . . . . . . . . . . . . 35
Balancing the beam . . . . . . . . 36
6.2 Weighing . . . . . . . . . . . . . . . . 37
Performing a weighing
operation . . . . . . . . . . . . . . . . 37
Taring additional weight . . . . . 38
7. Hygiene treatment . . . . . . . . . . . 39
7.1 Cleaning . . . . . . . . . . . . . . . . . 39
7.2 Disinfecting . . . . . . . . . . . . . . . 39
7.3 Sterilisation . . . . . . . . . . . . . . . 39
8. Function check . . . . . . . . . . . . . . 40
9. What do I do if …? . . . . . . . . . . . 41
10. Servicing/subsequent
verification . . . . . . . . . . . . . . . . . 41
10.1 Information on servicing
(seca 725) . . . . . . . . . . . . . . 41
10.2 Information on servicing and
subsequent verification
(seca 745) . . . . . . . . . . . . . . 42
11. Technical data . . . . . . . . . . . . . . 42
11.1 General technical data . . . . . 42
11.2 Weighing data . . . . . . . . . . . 43
12. Disposal . . . . . . . . . . . . . . . . . . . 43
13. Warranty . . . . . . . . . . . . . . . . . . 44

26 •
1. FULL CERTIFICATION
With seca products, you are not only purchasing tech-
nology which has been perfected over 100 years, but
also quality with official legal certification confirmed by
institutions. seca products comply with European
directives, standards and national laws. When you buy
seca, you buy the future.
seca’s professionalism is also recognized by official
testing agencies. TÜV SÜD Product Service, the
appointed office for medical devices, confirms with this
certificate that as a medical devices manufacturer,
seca consistently complies with the strict legal require-
ments. seca’s quality assurance system includes the
areas of design, development, production, sales and
service of medical scales and length measuring sys-
tems as well as software and measuring systems for
assessing state of health and nutrition.
seca helps the environment. Saving natural resources
is very important to us. We therefore make every effort
to save on packaging materials wherever it makes
sense and whatever is left over can be conveniently
disposed of on site via the recycling system.
2. DESCRIPTION OF DEVICE
2.1 Congratulations!
By purchasing this mechanical baby scale you are now
in possession of an extremely accurate yet robust
device.
seca has put its experience at the service of health care
for over 170 years and as a market leader in many
countries, is constantly setting new standards with its
innovative developments for weighing and measure-
ment.

Description of device • 27
English
2.2 Intended use
The seca mechanical baby scale is mainly used in hos-
pitals, doctors' surgeries and inpatient care facilities in
accordance with national regulations.
The scale is both for determining birth weight and
checking weight gain during the growth process, and it
supports the doctor supervising treatment in making a
diagnosis or deciding on a treatment.
In order to make a precise diagnosis, however, other
specific examinations must be set up by the physician
in addition to determination of weight and their results
taken into account.
2.3 Description of function
On mechanical scales, weight is determined by a load
lever system. To display the weight, the user moves
two sliding weights on a beam until the beam is
balanced. The patient's weight can then be read off at
the position of the sliding weights.
Use the scale only for the purpose quoted in the
section entitled “Intended use”.
2.4 User qualification
The device may only be operated by healthcare
professionals.

28 •
3. SAFETY INFORMATION
3.1 Safety information in these instructions for use
DANGER!
Used to identify an extremely hazardous situa-
tion. If you fail to take note of this information,
serious irreversible or fatal injuries will occur.
WARNING!
Used to identify an extremely hazardous situa-
tion. If you fail to take note of this information,
serious irreversible or fatal injuries may result.
CAUTION!
Used to identify a hazardous situation. If you fail
to take note of this information, minor to moder-
ate injuries may result.
NOTICE!
Used to identify possible incorrect usage of the
device. If you fail to take note of this information,
you may damage the device, or the measured
results may be incorrect.
NOTE
Includes additional information about use of the
device.
3.2 Basic safety precautions
Handling the device • Please take note of the information in these instruc-
tions for use.
• Keep the instructions for use in a safe place. The
instructions for use are a component of the device
and must be available at all times.
CAUTION!
Patient hazard, damage to device
• Have servicing and subsequent verification
carried out regularly as described in the rele-
vant section of this document.
• Technical modifications may not be made to
the device. The device does not contain any
parts for servicing by the user. Only have serv-
icing and repairs performed by an authorized

Safety information • 29
English
seca service partner.
• Only use original seca accessories and spare
parts, otherwise seca will not grant any
warranty.
Avoiding infections WARNING!
Risk of infection
• Hygienically reprocess the scale regularly as
described in the respective section in this
document.
• Make sure that the patient has no infectious
diseases.
• Make sure that the patient has no open
wounds or infectious skin alterations, which
may come into contact with the device.
Avoiding injury WARNING!
Risk of falling
Baby scales generally stand on raised work sur-
faces. If the baby falls from this surface, this
may result in serious irreversible or fatal injuries.
– Ensure that the device is steady and level.
– Route connecting cables (if present) in such a
way that people cannot trip over them.
– Never leave a baby unsupervised.
Avoiding damage to the
device
NOTICE!
Damage to device
• Make sure not to drop the device.
• Do not expose the device to any impact or
vibration.
• Perform function controls regularly as
described in the relevant section in this docu-
ment. Do not operate the device if it is dam-
aged or not working properly.
• Caustic detergents may damage the surfaces.
Only use a soft cloth dampened with mild
soapsuds to clean the surfaces of the device.
• Only use disinfectants suitable for sensitive
surfaces. Suitable disinfectants are available
from specialist dealers.

30 •
Handling the
measurement results
WARNING!
Patient hazard
This device is no diagnostic device. It simply
assists the treating physician in establishing a
diagnosis.
– In order to make a precise diagnosis and
initiate therapeutic measures, besides
determination of the weight, further targeted
examinations must be set up by the
physician, and their results must be
considered.
– The responsibility for diagnosis and treatment
lies with the treating physician.
NOTICE!
Inconsistent measuring results
• Before you save measurement values deter-
mined using this device and use them further
(e.g. in seca PC software or in a hospital infor-
mation system), make sure that the measure-
ment values are plausible.
• If measurement values are transmitted to seca
PC software or a hospital information system,
make sure prior to further use that the meas-
urement values are plausible and are assigned
to the correct patient.
Handling the packaging
material
WARNING!
Risk of suffocation
Packaging material made of plastic foil (bags) is
a choking hazard.
– Keep packaging material out of reach of
children.
– In the event that the original packing material
may not be available anymore, only use
plastic bags with security holes in order to
reduce the risk of suffocation.
NOTE
Keep the original packing material for future use
(e.g. returning for maintenance service).

Overview • 31
English
4. OVERVIEW
4.1 Controls
seca 745/725:
1
3
7
8
9
10 11
6
4
2
5
No. Control Function
1Large sliding weight
Can be moved to set the weight display roughly
• Pull forward: release sliding weight
• Release: lock sliding weight in position
2Small sliding weight Can be moved to set the weight display
accurately
3Tare weight with
knurled screw
Can be moved to balance the beam
• On initial use and before every weighing
operation
• To tare off an additional weight
4Fine-tare screw
Can be adjusted to balance the beam exactly
• On initial use and before every weighing
operation
• To tare off an additional weight
5Tray Where the baby is placed
6Locking lever
•2pcs
• For locking the tray in position on the scale
housing
7Pointer and counter-
pointer Indicate whether the beam is balanced
8Beam with scale For reading off the weight
9Locking lever
For locking/releasing the beam
• Push down: lock in position
• Raise: release

32 •
4.2 Information on device and on rating plate
4.3 Information on the packaging
10 Spirit level Indicates whether the device is horizontal
(verified models)
11 Device feet
•4pcs
• Adjustable to align the scale accurately
(verified models)
No. Control Function
Text/symbol Meaning
Model Model number
Ser. No. Serial number
Follow instructions for use
Conformity label according to Directive 2009/23/EC gov-
erning non-automatic weighing instruments (verified
models)
eValue in mass units used for classifying and for verifying
the scale (verified models)
dValue in mass units indicating the difference between the
values of two adjacent increments
TMarks the zero position of the tare weight. Visible when
tare weight is moved out of zero position.
Scale of verification class III as per Directive 2009/23/EC
Device complies with EC standards and directives.
•xx: Year in which EC verification was carried out and
the CE label was affixed (verified models)
• 0109: Notified body, metrology: Hessen Weights &
Measures Office [Hessische Eichdirektion, Germany]
(verified models)
•0123: Notified body, medical devices:
TÜV SÜD Product Service
xx
0109
0123
Protect from moisture
Arrows indicate top of product.
Transport and store in an upright position.
Fragile
Do not throw or drop.

Before you get started … • 33
English
5. BEFORE YOU GET STARTED …
5.1 Scope of supply
5.2 Remove transport lock
The sliding weights and the tare weight are fixed in
position by a transport lock (rubber band).
Remove the transport lock as shown in the
adjacent diagram before using the scale.
NOTE
Keep the transport lock for subsequent
transport of the scale.
Permitted min. and max. temperature for transport and
storage
Permitted min. and max. moisture for transport and
storage
Packaging material can be disposed of through recycling
programs
b
a
No. Component Qty.
aScale 1
bTray 1
-User manual, not illustrated 1

34 •
5.3 Put on tray
1. Place the tray centrally on the scale.
2. Ensure that the locking levers for the tray engage in
the openings in the housing.
3. Push the locking levers down.
The tray is attached to the housing.
5.4 Set up and align scale
NOTICE!
Incorrect measurement due to force shunts
If the scale is set up or aligned incorrectly,
weight will not be measured correctly.
– Place the scale on a firm and level surface.
– Do not place the scale on changing mats or
towels.
– Set up the scale so that it is not in contact
with any walls or objects.
1. Place the scale on a firm and level surface.
2. Verified models: align the scale by turning its feet so
that the air bubble is in the exact centre of the spirit
level.
NOTE
Alignment of the scale must be checked and
corrected every time the location of the scale is
changed.
1.
3.
2.
Spirit level
Air bubble

Operation • 35
English
6. OPERATION
6.1 Rendering the scale operational
Releasing/locking the
beam
The beam must be locked in position when the device
is transported and when the tray is to be placed on the
housing. The beam must be released before weighing.
Push the locking lever upwards.
The beam is released.
Push the locking lever downwards.
The beam is locked in position.
Checking the position
of the beam
1. Ensure that the beam is released (see previous
section).
2. Ensure that there is no load on the scale.
3. Push both sliding weights to the “0” position.
4. Wait until the beam has stopped swinging.
NOTICE!
Incorrect measurement due to force shunt
If you touch the scale, weight will not be
measured correctly.
– Ensure that you do not touch the scale while
the beam is swinging.
5. Check whether the beam is balanced.
The pointer and counterpointer must be at exactly
the same level.
6. If the pointer and the counterpointer are not at ex-
actly the same level, balance the beam as de-
scribed in the section below.

36 •
Balancing the beam
1. Ensure that both sliding weights are in the “0”
position.
2. Undo the knurled screw on the tare weight.
3. Move the tare weight to balance the beam.
4. Wait until the beam has stopped swinging.
NOTICE!
Incorrect measurement due to force shunt
If you touch the scale, weight will not be
measured correctly.
– Ensure that you do not touch the scale while
the beam is swinging.
5. Check whether the beam is balanced.
Pointer and counterpointer must be at exactly or
approximately the same level.
6. Repeat Step 3 if required.
7. Fix the tare weight in position using the knurled
screw.
8. Turn the fine-tare screw until the pointer and
counterpointer are exactly opposite one another.
The scale is operational.
2.
3.3.
8.
7.

Operation • 37
English
6.2 Weighing
CAUTION!
Risk of falling, faulty operation
To prevent falls from the scale and faulty opera-
tion, you must ensure before each use that the
scale is operational.
– Ensure that the tray is correctly fixed in
position (see “Put on tray” on page 34).
– Perform a function check (see “Function
check” on page 40).
– Check whether the beam is balanced (see
“Checking the position of the beam” on
page 35).
Performing a weighing
operation
1. Ensure that the locking lever of the beam is re-
leased (see “Releasing/locking the beam” on
page 35).
2. Place the baby on the tray.
WARNING!
Risk of falling
Baby scales generally stand on raised work sur-
faces. If the baby falls from this surface, this
may result in serious irreversible or fatal injuries.
– Ensure that the device is steady and level.
– Route connecting cables (if present) in such a
way that people cannot trip over them.
– Never leave a baby unsupervised.
3. Move the large sliding weight until the beam is
balanced approximately.
Pointer and counterpointer must be at
approximately the same level.
4. Wait until the beam has stopped swinging.
NOTICE!
Incorrect measurement due to force shunt
If you touch the scale, weight will not be
measured correctly.
– Ensure that you do not touch the scale while
the beam is swinging.
3.

38 •
5. Move the small sliding weight until the beam is bal-
anced exactly.
Pointer and counterpointer must be at exactly the
same level.
6. Wait until the beam has stopped swinging.
NOTICE!
Incorrect measurement due to force shunt
If you touch the scale, weight will not be
measured correctly.
– Ensure that you do not touch the scale while
the beam is swinging.
7. Read off the baby's weight:
– read off the kilogram number at the large slid-
ing weight (in this case: 3 kg = 3,000 g)
– read off the gram number at the small sliding
weight (in this case: 600 g)
– add the two values (in this case: 3,600 g)
Taring additional
weight
You can use the tare weight to compensate for a maxi-
mum of 2,500 g additional weight (e.g. a towel or pad-
ding). The additional weight is not taken into account in
the weighing result.
NOTICE!
Incorrect measurement due to force shunts
If an additional weight such as a large towel is in
contact with the surface on which the scale is
standing, the weight will not be measured
correctly.
– Make sure that any additional weights is only
placed on the tray of the scale.
1. Place the additional weight on the tray.
2. Balance the beam (see the section entitled “Balanc-
ing the beam” on page 36).
3. Perform the weighing operation (see “Performing a
weighing operation” on page 37).
5.
3 kg
600 g

Hygiene treatment • 39
English
7. HYGIENE TREATMENT
NOTICE!
Damage to device
Inappropriate detergents may damage the
sensitive surfaces of the device.
– Do not use caustic or abrasive detergents.
– Do not use spirits or benzine.
7.1 Cleaning
Use a soft cloth dampened with mild soapsuds to
clean the surfaces of the device.
7.2 Disinfecting
NOTICE!
Damage to device
Only use disinfectants suitable for sensitive sur-
faces. Suitable disinfectants are available from
specialist dealers.
1. Follow the instructions on the disinfectant.
2. Disinfect the device at regular intervals with a com-
mercially available disinfectant, e.g. with 70% iso-
propyl alcohol.
3. Please take note of the following terms:
7.3 Sterilisation
This device may not be sterilised.
Interval Component
Before every measurement Tray
After every measurement Tray
If required Display elements,
controls, housing

40 •
8. FUNCTION CHECK
Perform a function check prior to each use.
A complete function check includes:
• visual inspection for mechanical damage
• checking the alignment of the device
• visual and function check of the display elements
• function check of all the controls shown in the
section entitled “Overview”
• function check of optional accessories
If you notice any faults or deviations during the function
check, first try to resolve the error with the aid of the
section entitled “What do I do if ...” in this document.
CAUTION!
Personal injury
If you notice any faults or deviations during the
function check which cannot be resolved with
the aid of the section entitled “What do I do
if ...” in this document, you may not use the
device.
– Have the device repaired by seca service or
by an authorized service partner.
– Follow the section entitled “Servicing/
recalibration” in this document.

What do I do if …? • 41
English
9. WHAT DO I DO IF …?
10.SERVICING/SUBSEQUENT VERIFICATION
10.1 Information on servicing (seca 725)
The product must be set up carefully and serviced reg-
ularly. Depending on how frequently the product is
used, we recommended servicing at intervals of 3 to 5
years.
NOTICE!
Incorrect measurements as a result of poor
servicing
– Have servicing and repairs carried out
exclusively by seca service or by an
authorized service partner.
Fault Cause/Remedy
... the beam does not
move when the scale is
loaded?
Scale is not operational
- Remove transport lock (rubber band)
- Release locking lever
... the scale is not dis-
playing plausible values?
Scale is not correctly aligned
- Align scale, see 5.4
Beam was not balanced before the weighing
operation
- Balancing the beam, see 6.1
Force shunt, scale is in contact with a wall or the
housing is abutting something (e.g. a towel)
- Increase distance from wall
- Set up scale so that only the device feet are in
contact with the floor
Force shunt, an additional weight (e.g. towel) is in
contact with the surface on which the scale is
standing
- Ensure that additional weights are only on the
tray

42 •
10.2 Information on servicing and subsequent verification
(seca 745)
We recommend having your device serviced prior to
subsequent verification.
NOTICE!
Incorrect measurements as a result of poor
servicing
– Please only have servicing and repairs
performed by an authorized service partner.
Have an authorized technician perform subsequent
verification according to national legal regulations. The
year of first verification can be found after the CE sym-
bol on the rating plate above the number of the notified
body 0109 (Hessen Weights & Measures Office [Hes-
sische Eichdirektion, Germany]).
Subsequent verification is necessary whenever one or
more verification seals are damaged.
11.TECHNICAL DATA
11.1 General technical data
General technical data seca 745/725
Dimensions
•Width
•Height
•Depth
555 mm
185 mm
320 mm
Weight approx. 6 kg
Ambient conditions, operation
•Temperature
• Air pressure
•Humidity
+10 °C to +40 °C (50 °F to 104 °F)
700 - 1060 hPa
30 % - 80 %, no condensation
Ambient conditions, storage
•Temperature
• Air pressure
•Humidity
-10 °C to +65 °C (14 °F to 149 °F)
700 - 1060 hPa
0 % - 95 %, no condensation
