Sega Capcom vs SNK 2 Troubleshooting guide

1ST PRINTING SEPT 01
MANUAL NO. 999-1318
SEGA ENTERPRISES, INC. USA
Universal Kit
Kit Installation Instructions
& Service Manual
S itchable FROM High Resolution 31K
TO Standard (Lo ) Resolution 15.75K.
1 - 2 PLAYER GAME
www.seuservice.com

VISIT OUR WEBSITE!

1www.seuservice.com
Capcom vs SNK 2
Sega Naomi System
Kit Contains List
Part #
400-5397-01
838-13616
560-5407-UL
838-13683-93CV1
600-7141- 00
600-7009- 500
840-0051D-01
600-7 47-500
837-13938
LOC. PURCHASE
XKT-0833
999-13 6
999-13 7
999-13 8
999-13 5
999-13 9
Desc
NAOMI POWER SUPPLY
AUDIO POWER AMP CH
AUDIO XFORMER 1 0V
JAMMA I/O BD (NAOMI)
USB CABLE
VGA VIDEO CABLE
ASSY CASE PC1 DIMM BD
CABLE SCSI TYPE 500MM
I/O CTRL BD JVS ENCORD.
SERVICE SWT BRKT ASSY
GD-ROM DRIVE KIT
JOYSTICK, COMP. BLUE
BUTTON, COMP. BLUE
BUTTON, COMP. RED
BUTTON, COMP. GREEN
SWITCH PB LARGE
Qty
1
1
1
1
1
1
1
1
1
1
1
4
4
4

2
www.seuservice.com
Capcom vs SNK 2
Sega Naomi System
Kit Contains List
Part #
999-1330
999-1331
999-133
999-1333
999-1334
999-1335
999-1336
999-1337
999-1338
999-1339
999-1340
Desc
MARQUEE ART
INSTR. SHEET (PLAYER)
INSTR. SHEET # (CNTRL)
SIDE ART
CTRL PNL OVERLAY
DECAL BTTN (LIGHT)PNCH-RED
DECAL BTTN (MIDDLE)PNCH-GRN
DECAL BTTN (HEAVY)PNCH-BL
DECAL BTTN (LIGHT)KICK-RED
DECAL BTTN (MIDDLE)KICK-GRN
DECAL BTTN (HEAVY)KICK-BL
Qty
1
1
1
1

3www.seuservice.com
DESIGNED RELATED PARTS
MARQUEE ART
999-1330
CTRL PNL OVERLAY
999-1334
INSTR. SHEET # (CNTRL)
999-133

4
www.seuservice.com
SIDE ART
999-1333
999
INSTR. SHEET (PLAYER)
999-1331
DECAL BTTN (LIGHT)PNCH-RED[999-1335]
DECAL BTTN (MIDDLE)PNCH-GRN[999-1336]
DECAL BTTN (HEAVY)PNCH-BL[999-1337]
DECAL BTTN (LIGHT)KICK-RED [999-1338]
DECAL BTTN (MIDDLE)KICK-GRN [999-1339]
DECAL BTTN (HEAVY)KICK-BL [999-1340]
NOT PICTURED

5www.seuservice.com
SERVICE BULLETIN
SEGA Service Department http://www.seuservice.com
45133 Industrial Drive hone: 415.701.6580
Fremont, Ca. 94538 Fax: [phone]
If you have any questions please contact the SEGA Service Department at the numbers given above.
120
Feb 9. 000
The SEGA Naomi Game kits are actually ‘JAMMA Dependent’. What this means exactly is they will only
install into existing JAMMA Cabinets. If an operator tries to install these kits into a Non-JAMMA cabinet,
they will first have to bring the wiring up to JAMMA Standards.
°Step 1 Disconnect the games original DC Power Supply. You may only use the power supply provided
with your kit. Be sure to set the voltages going to your Game BD to 5.1 and 3.3 volts DC to assure proper
operation ( Measure on Square Connector at Game BD. Yellow = 5vdc / Brown = 3.3vdc / White = Gnd )
°Step You MUST USE THE COIN METER SUPPLIED WITH YOUR KIT to assure proper Coin
acceptance. A minimum 18 Gauge wire should be used from the Coin Meter 1 output line on your
JAMMA Harness. The 5vdc ( Yellow ) wire found in the wiring bag of your kit MUST BE USED for the
supply voltage to the meter.
SPECIAL NOTICE FOR
ALL SEGA NAOMI KITS
PROBLEM:
SOLUTION:
Not following the directions provided herein may cause your game to malfunction.
All electrical work should be performed by the site’s Serviceman or Technician.
In order to prevent an electric shock and short circuit, be sure to turn power off before performing
work or touching the interior parts of the product.
Be careful so as not to damage wirings. Damaged wiring can cause an electric shock or short circuit
accident.
Do not touch places other than those specified. Touching places not specified can cause an electric
shock or short circuit accident.

6
www.seuservice.com
INSTALLATION INSTRUCTIONS
1) First. Remove all access panels from the game. Locate the original game Logic PCB’s & Power
Supply and remove from the Cabinet by first disconnecting all harnesses from the boards. (You need
only to splice in the Main Power (110v AC) into the 3-Pin Connector (GRN/WHT/BLK).)
) Remove all existing game harnesses (we suggest using New Jamma Harnesses (NOT contained in the
kit) to ensure reliability).
3) Locate the most convenient and open area of the cabinet to mount the Capcom vs. SNK2 Naomi
System Assembly. Make sure this area is free and clear of all cable harnesses and grounds, cable
clamps, etc.
Vacuum out or clean bottom of cabinet of dirt & miscellaneous parts (e.g.
screws, loose coins / tokens, etc.).
Remove all exterior decals and repair any cabinet damage. Repaint
cabinet if necessary. Remove the Monitor Plexi or if your game plexi has
Silk-screened artwork, you will need to strip it off.
4) Connect the JAMMA Harnesses to the JVS-JAMMA Interface Boards. Separate the wires from each
other (i.e. Control Panel, Video, Speaker, Power Supply). Run the various harnesses to the part of the
cabinet they go to ensuring they are dressed properly & secured to the cabinet. Locate the Volume/
Speaker/Coin Meter Cable and connect to your existing Swi ch Bracke or use the new one included
with the kit. No e: If you are using a VGA Compatible Monitor you can run your VGA Cable directly
to the monitor or connect it to your JVS JAMMA Interface for RGB Conversion to your JAMMA
Cables.
5) Remove Marquee from cabinet and cut to fit the new Capcom vs. SNK 2 Marquee in place.
REPLACE old Joysticks & Buttons with the NEW ones supplied in Kit.
6) First remove all Joystick and Button assemblies from the Control Panel. Remove Lexan and Control
Panel Overlay. Proceed to clean surface of the Control Panel by removing all adhesive and dirt. Fill
in or plug up existing button holes to set up a blank work area for your new controls.
7) Install the new Control Panel Overlay by carefully peeling off the paper backing and laying down on
the panel. Smooth it out, starting in the center and working your way to the edges (removing all of
the trapped air pockets). If necessary, cut the edges of the overlay excess and fold under panel.
8) Cut out the button and Joystick Holes. Install Joystick and buttons from kit into the Control Panel
and tighten down. Connect all game harness wires to switches and buttons.

7www.seuservice.com
INSTALLATION INSTRUCTIONS
9) Proceed to place new decals on the sides of the cabinet. Locate a new monitor bezel, if needed, and
replace glass, if required (due scratches). Install Instruction Placard to the back of the Monitor Glass.
NOTE: As a precaution, disconnect the JAMMA Harness from the I/O Boards and turn power on. With a
Multi-Meter, measure the 5v and 3.3v. Adjust if necessary to 5.15v DCand 3.3vDC. Measure the +1 to
ensure the wires and voltages are in the correct position. Turn power off. Plug in the JAMMA Harness once
again to the I/O Boards. The Attract Mode should appear on the screen.
Adjust the SIZE, CONTRAST, BRIGHTNESS, and COLORS on the
Monitor for optimum appearance. Adjust VERTICAL/HORIZONTAL
Hold to get a stable picture, if required.
Enter DIAGNOSTICS and adjust the Volume Level, test all Buttons &
Joystick for proper operation & wiring. Adjust Pricing. Coin-Up and
test out a game to ensure proper play functions are as they should be.

8
www.seuservice.com
Sega Naomi Sys em Swi ch
Bracke and Speaker
Ins alla ion Diagrams
(Figure 3)
Coin Meter
Test Service
Volume
JAMMA Pin R
JAMMA Pin 15
JAMMA Pin 1
Yellow Wire from Extra
arness (+5v)
JAMMA Pin 8
+
_
Pin 1
Pin 5
Pin 4
To CN1 of
Amplifier Board
YEL/RED
W T/RED
GRN/RED
From CN2 of
Amplifier Board
From CN4 of
Amplifier Board
GRY/RED
ORG/RED
ORG/BLUE
GRY/BLUE
Left
Speaker
Right
Speaker

9www.seuservice.com
Sega Naomi Sys em
JAMMA Harness Wiring
(JAMMA I/O BD)
(Figure 4)
4
1
2
3
5
6
7
8
10
11
12
13
14
15
16
17
18
19
20
21
A
B
C
D
E
F
J
K
L
M
N
P
R
S
T
U
V
X
Y
Z
a
22
23
24
4
e
d
26
25 c
b
28 f
27
9
W
Ground
Ground
Ground
Ground
+5v (Not Used) +5v (Not Used)
+5v (Not Used) +5v (Not Used)
(Not Used) (Not Used)
+12v (Not Used) +12v (Not Used)
Key Key
Coin Meter 1 Coin Meter 2
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
Video Red
Video Blue
Video Ground
Video Green
Video Sync
Service
Test (Not Used)
Coin 1 Coin 2
1P Start 2P Start
1P UP 2P UP
2P Down
1P Down
1P Left 2P Left
1P Right
Attack 1P (1P SW1)
Grapple 1P (1P SW2)
Support 1P (1P SW3)
Ground
Ground
2P Right
Attack 2P (2P SW1)
Ground
Ground
Support 2P (2P SW3)
Grapple 2P (2P SW2)
(Not Used)
(Not Used)
(Not Used)
(Not Used)

10
www.seuservice.com
CN4
Sega Naomi System
Filter Board Information
Connector Description etc.
PSW2 PSW1
CN3 CN2 CN1
DIPSW1
Power Connectors
VGA Level
Video Out
Preamp Level
Audio Out
Test
Switch
Service
Switch
1
1
2
2
3
3
4
Setting for igh
Resolution 31K Z
1 -4 off
Setting for Standard
Resolution 15K Z
1 on 2-4 off.

11 www.seuservice.com
SOFT KIT
Handling the GD-ROM Disk
 Do not contaminate the disks with your fingerprints or dust particles.
Contaminated disks may lower audio and video quality.
 When cleaning the disks, do not use volatile chemicals (benzine, thinner, etc.),
cleaning sprays, and antistatic agents.
 Do not use cracked, warped, or damaged disks.
Do not attach papers or seals onto the disks; do notscratch the disks.
Do not use the disks with a sign of peeled seals, tapes, etc.
Observing these instructions, do not insert such a non-usable disk into the GD-ROM drive. Otherwise the 
inserted disk can not be ejected.
 When cleaning a heavily contaminated disk, use clean cloth that has been soaked in water and
squeezed. Then remove moisture with drycloth.
 When holding a disk, be careful not to contaminate it with your fingerprints.
How to Hold a Disk
3
PART NO. DESCRIPTION
1 + +
3 610-0624-0003 GD SOFT KIT CAPCOM VS.SNK 2
1 GDS-0003 NAOMI GDROM CAPCOM VS.SNK 2
KEY CHIP
3253-5507 DISK CASE WITH IC HOLDER
1
•With both hands:
Put your thumbs and
forefingers of both hands
on the disk's edge.
•With one hand:
Insert your forefinger into
a central hole and at the same
time put your thumb and middle
finger on the disk's edges.

12
www.seuservice.com
421-11465
©CAPCOM CO., LTD. 2001 ALL RIGHTS RESERVED. ©SNK 2001
MANUAL
WARNING
U.S.A. version of this game is for the North American
countries only.
Europe version of this game is for the European countrie
s
only.
Sales, export, or operation outside these countries may
b
construed as copyright and trademark infringement and is
strictly prohibited.
Violators are subject to severe penalties and will be pr
o

13 www.seuservice.com
SHOT 1
SHOT 4
SHOT 2
SHOT 5
SHOT 3
SHOT 6
CAUTION
For your safety, please read and abide by the following
instructions when handling the P.C. board.
 Make sure the power is off before installing the board or changing 
 the settings of the board.
 Do not damage the wiring cables.
 Do not disassemble the case.
 Do not touch the board, connectors or the harness with wet hands.
Please keep the following instructions to keep the P.C.
board in good condition.
 Do not block the ventilation slots.
 Do not keep the board in extremely cold/hot places.
 Do not drop or bump the board.
 Do not spill any liquids on the case.
 Do not disassemble the case.
 Always keep the connectors clean.
 Do not disconnect the connectors, cables, or the harness while the 
 power is on.
Disassembling the case or removing the sticker may cause the termination of your
repair warranty.
No desarme la caja. Si la caja est· desarmada o hay evidencia de que lo ha estado,
se deneger·n las reparaciones.
Ne pas dÈmonter la boÓte. Au cas o˘ il apparaÓt que cette boÓte a ÈtÈ dÈmontÈe,
votre demande de rÈparation sera refusÈe.
Das Geh‰use nicht ˆffnen. Falls das Geh‰use geˆffnet wurde oder falls
ersichtlich ist, dafl es geˆffnet wurde, wird die Reparatur verweigert.
Non smontare la scatola involucro. In caso sia stata smontata, o sia evidente che
ciÚ Ë avvenuto, la riparazione sar‡ rifiutata

14
www.seuservice.com
CONTROL PANEL LAYOUT
JAMMA CONNECTOR
CRT MONITOR
Either 15k or 31k horizontal monitor can be used.
Locate the DIP switch 1 on the connector side of NAOMI board.
Turn it ON for 15k monitor. Turn it OFF for 31k monitor.
(Default is set to ON)
* Please refer to page 17 "CAPCOM VS. SNK SETTING TIPS" for 31k monitors.
Left Right
Crouch
Jump
SHOT 1SHOT 1
SHOT 4SHOT 4
Light Punch
Light Kick
SHOT 2SHOT 2
SHOT 5SHOT 5
Middle Punch
Middle Kick
SHOT 3SHOT 3
SHOT 6SHOT 6
Heavy Punch
Heavy Kick
Lever
Moves the player to the
jump/crouch, left/right
of the screen.
Buttons
* Please use the
illustrated setting for
the best possible
game play.
15k monitor 31k monitor
SOLDER SIDE COMPONENT SIDE
JAMMA CONNECTOR
GND
GND
+5V
+5V
N.C.
+1 V
N.C.
(COIN LOCK OUT )
SP(-)
N.C.
VIDEO GREEN
VIDEO SYNC
SERVICE SW
N.C.
COIN SW
START SW
P UP
P DOWN
P LEFT
P RIGHT
P SHOT 1
P SHOT
P SHOT 3
P SHOT 4
P SHOT 5
GND
GND
A
B
C
D
E
F
H
J
K
L
M
N
P
R
S
T
U
V
W
X
Y
Z
a
b
c
d
e
f
1
3
4
5
6
7
8
9
10
11
1
13
14
15
16
17
18
19
0
1
3
4
5
6
7
8
GND
GND
+5V
+5V
N.C.
+1 V
COIN COUNTER 1
(COIN LOCK OUT 1)
SP(+)
N.C.
VIDEO RED
VIDEO BLUE
VIDEO GND
TEST SW
COIN SW 1
START SW 1
1P UP
1P DOWN
1P LEFT
1P RIGHT
1P SHOT 1
1P SHOT
1P SHOT 3
1P SHOT 4
1P SHOT 5
GND
GND
PARTS NAME
CR7E-56DA-3.96E : (HIROSE)
OR
1168-056-009: (KEL)
( P Light Punch)
( P Middle Punch)
( P Heavy Punch)
( P Light Kick)
( P Middle Kick)
( 1P Light Punch )
(1P Middle Punch)
(1P Heavy Punch)
(1P Light Kick)
(1P Middle Kick)
1 +5v
2 +5v
3 N.C.
4 SHOT 6 (1PW SW6)
5 (1P SW7) NOT USED
6 (1P SW8) NOT USED
7 N.C.
8 SHOT 6 (2PW SW6)
9 (2P SW7) NOT USED
10 (2P SW8) NOT USED
11 N.C.
12 N.C.
13 GND
14 GND
  
JP1---->
I/O BOARD CN3
OUT IN
* Must be set for proper
operation
*

15 www.seuservice.com
SYSTEM MENU
JAPAN VERSION
g RAM TEST
JVS TEST
SOUND TEST
C. R. T. TEST
SYSTEM ASSIGNMENTS
COIN ASSIGNMENTS
BOOKKEEPING
BACKUP DATA CLEAR
CLOCK SETTING
DIMM BOARD TEST
GAME TEST MODE
[CAPCOM VS. SNK EXPORT]
EXIT
SELECT WITH SERVICE BUTTON
AND
PRESS TEST BUTTON
GAME TEST MODE
g
INPUT TEST
GAME DATA
GAME CONFIGURATION
PASSWORD
EXIT
SELECT OPTION = 1P UP or DOWN
START = 1P SHOT1
HOW TO ENTER THE TEST MODE
Press the Test Button inside the cabinet and the "NAOMI SYSTEM MENU" will appear on the screen.
Press the Service Button to move the "g" cursor and press the Test Button to enter various test modes.
(For the details on "NAOMI SYSTEM MENU", please refer to "NAOMI SERVICE MANUAL".)
To enter the GAME TEST MODE, move the "g" cursor to GAME TEST MODE in the NAOMI SYSTEM MENU and press the
Test Button.
NAOMI SYSTEM MENU
GAME TEST MODE
 CAUTIONS ON NAOMI SYSTEM MENU
1) Please set the CABINET TYPE and the MONITOR TYPE of the SYSTEM ASSIGNMENTS menu to
" PLAYER(S)" and "HORIZONTAL" respectively.
This game will not function properly if above is not followed.
) The following is the default settings of COIN ASSIGNMENTS.
COIN CHUTE TYPE COMMON
COIN/CREDIT SETTING #1
COIN CHUTE #1 1 COIN 1 CREDIT
COIN CHUTE #  1 COIN 1 CREDIT
3) Please refer to the following for the SEQUENCE SETTING of the COIN ASSIGNMENTS.
SEQUENCE 1: Credits required to start the game.
SEQUENCE : Credits required to continue the game.
* SEQUENCE 3~8 is not available in CAPCOM VS. SNK .
Ex) Standard setting
 One(1) credit to start and continue the game.
SEQUENCE 1 1 CREDIT(S)
Credits required to start the game.
SEQUENCE 1 CREDIT(S) Credits required to continue the game.
Ex) credits start, 1 credit continue setting
 Players need credits to start the game but only one credit to continue the game.
SEQUENCE 1 CREDIT(S) Credits required to start the game.
SEQUENCE 1 CREDIT(S) Credits required to continue the game.
4) BOOKKEEPING / indicates the following:
P1(P ) SEQ 1: The number of times the game was started from Player 1 and Player each.
P1(P ) SEQ : The number of times the game was continued from Player 1 and Player each.
* SEQ 3~8 is not available in CAPCOM VS. SNK .
Ex)
P1 SEQ 1 8  P SEQ 1 45
P1 SEQ  36 P SEQ  15
The number of "Start" of 1P side The number of "Start" of P side
The number of "Continue" of 1P side The number of "Continue" of P side

16
www.seuservice.com
Change setting Change setting
Select an item
Select an item
SHOT 1
SHOT 1
SHOT 1
Decide an item
* Not used
* Not used
* Not used
SHOT 1
SHOT 1
SHOT 1
SHOT 4
SHOT 4
SHOT 4
SHOT 2
SHOT 2
SHOT 2
SHOT 5
SHOT 5
SHOT 5
* Not used
* Not used
SHOT 3
SHOT 3
SHOT 3
SHOT 6
SHOT 6
SHOT 6
GAME TEST MODE
g INPUT TEST
GAME DATA
GAME CONFIGURATION
PASSWORD
EXIT
SELECT OPTION = 1P UP or DOWN
START = 1P SHOT1
* Use the lever and the buttons
as illustrated.
CONTROLS IN GAME TEST MODE
GAME TEST MODE
• INPUT TEST
Tests the "input signal" of the lever and the buttons. When the "input signal" is detected, the number changes from
"0" to "1".
* Inside INPUT TEST, you can test up to two Service Buttons. In case your cabinet has only one Service
Button, please make sure if the 1P Service Button functions properly.
(Please note however, on certain cabinets, it is possible the number changes to "1" on both 1P and P side.)
• GAME DATA
Shows the earning-related data. Please use the info to determine the best coin settings for your arcade.
• GAME CONFIGURATION
Sets the game play settings such as difficulty, number of rounds, timer, etc.
• PASSWORD
Enter the password to unlock the hidden features in the game.
• EXIT
Returns to NAOMI SYSTEM MENU
GAME TEST MODE
GAME TEST MODE
On this screen, you can test "input signal" of the lever/buttons and can also set the game's difficulty.
Your setting will be saved in the backup RAM.

17 www.seuservice.com
GAME TEST MODE
INPUT TEST
GAME DATA
g
GAME CONFIGURATION
PASSWORD
EXIT
SELECT OPTION = 1P UP or DOWN
START = 1P SHOT1
GAME CONFIGURATION
g
SOUND MODE STEREO
DEMO SOUND HALF OFF
CONTINUE ON
DIFFICULTY EASY
[ * * * * * ]H A R D
DAMAGE LEVEL LOW [ * * * * * ]H I G H
TIMER SPEED SLOW
[ * * * * * ]H I G H
GAME SPEED SLOW[ * * 3 * * * * ]H I G H
EVENT OFF
JOIN-IN ON
DEFAULT
SAVE & EXIT
SELECT OPTION = 1P UP or DOWN
MODIFY SETTING = 1P LEFT or RIGHT
= 1P SHOT1 or SHOT
GAME TEST MODE
GAME CONFIGURATION
DECIDE WITH
SHOT 1
GAME CONFIGURATION
• SOUND MODE
Please set this item to "STEREO" for normal operations. Setting to "MONAURAL" will make your sound output monaural.
• DEMO SOUND HALF
ON: Plays the attract mode demo sound at half volume.
OFF: Plays the attract mode demo sound at regular volume.
• CONTINUE
Set this "ON" to enable the "CONTINUE" feature.
Set this "OFF" to disable the "CONTINUE" feature.
• DIFFICULTY
Sets the game's difficulty level. There are 8 levels in total.
As the number increases, the game gets more difficult.
• DAMAGE LEVEL
Sets the attacking power. There are 4 levels in total.
As the number increases, the attacking power increases. (Thus the average play time gets shorter.)
• TIMER SPEED
Sets the timer speed. There are 4 levels in total.
As the number increases, the time elapses quicker.
• GAME SPEED
Sets the game speed. 5 levels are available.
As the number gets higher, the game speed increases.
• EVENT
Use this function for events/tournaments. If set to "ON", only 1 credit is required for players "VS." game.
However, the game will be over for both players regardless of the game result.
Please set this to "OFF" for standard operations.
• JOIN-IN
Used to turn on and off the JOIN-IN feature. Please set to ON for standard operations.
If you wish the game setting to be played by 1 player only(advisable for beginners), set to OFF.
• DEFAULT
Resets all the settings to the factory defaults. (Initialise)
Not only the GAME CONFIGURATION but also the settings in NAOMI SYSTEM MENU(COIN ASSIGNMENTS, etc.) will be
reset to the following factory defaults.
ADVERTISE SOUND : ON
MONITOR TYPE : HORIZONTAL
COIN CHUTE TYPE : COMMON
COIN/CREDIT SETTING : #1 (1 coin 1 credit: Asia version)
 #1 ( coins 1 credit: European version)
SEQUENCE SETTING : SEQ1=1 (1 credit to start)
 SEQ =1 (1 credit to continue)
For more details regarding the NAOMI SYSTEM MENU, please refer to the "NAOMI SERVICE MANUAL."
• SAVE & EXIT
Saves your GAME CONFIGURATION and COIN/SYSTEM ASSIGNMENTS and returns to the GAME TEST MODE.
(It takes approximately seconds to save the settings. Please do not turn off the power while saving.)

18
www.seuservice.com
SOUND MODE
DEMO SOUND HALF
CONTINUE
DIFFICULTY
DAMAGE LEVEL
TIMER SPEED
GAME SPEED
EVENT
JOIN-IN
STEREO
ON
ON
ON
ON
1 EASY
5
1 LOW
1 SLOW
6
3
7
3
3
4
8 HARD
4 HIGH
4 HIGH
MONAURAL
OFF
OFF
OFF
OFF

GAME CONFIGURATION OPTIONS
1 SLOW 2345 HIGH
* Factory settings
* DEMO SOUND HALF setting is available only when ADVERTISE SOUND is set to ON.
A
DVERTISE SOUND setting can be found under the SYSTEM ASSIGNMENTS menu of the NAOMI SYSTEM MENU.
LARGE CABINET
Because of its simple controls, CAPCOM VS. SNK can be played by any game player.
Its unique characters and beautiful graphics that can only be achieved on the NAOMI board will surely appeal even to the
people who had never played video games before.
For this universal appeal of the game, we strongly recommend you to install this
game in a large cabinet and place it at the front of your arcade.
31K MONITOR CABINET
The NAOMI board is capable of handling the screen resolution that is three times as
high as the CP-SYSTEM board.
To exercise its maximum performance, it is indispensable to install the board in the
cabinet equipped with 31K monitor that is capable of high resolution graphics. (Ex.
"BLAST CITY" "MEGALO 410" etc. from Sega)
To enjoy NAOMI's graphics at its best, please use the cabinet with 31K monitor.
(When using 31K monitor, please set the DIP switch on the NAOMI board's
connector side as described in the right chart.)
CAPCOM VS. SNK 2 SETTING TIPSCAPCOM VS. SNK 2 SETTING TIPS
Turn this
switch off.
(Default Setting)
For
15K MONITOR
For
31K MONITOR
