Sega JUNGLE TREASURES User manual

1ST PRINTING JULY ‘03
MANUAL NO. 999-1763
Owner’s Manual
SEGA AMUSEMENTS USA, INC.
A Game of Skill
www.seuservice.com
GAME CODE: JT
REV. 2

VISIT OUR WEBSITE!

BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain the safety:
To ensure the safe usage of the product, be sure to read the following before using the product. The
following instructions are intended for the users, operators and the personnel in charge of the opera-
tion of the product. After carefully reading and sufciently understanding the warning displays and
cautions, handle the product appropriately. Be sure to keep this manual nearby the product or else-
where convenient for referring to it when necessary.
Herein, explanations which require special attention are enclosed with dual lines. Depending on the
potentially hazardous degrees, the terms of WARNING, CAUTION, etc. are used. Be sure to under-
stand the contents of the displays before reading the text.
Indicates that mishandling the prod-
uct by disregarding this warning
will cause a potentially hazardous
situation which can result in death
or serious injury.
Indicates that mishandling the product
by disregarding this caution will cause
a slight hazardous situation which can
result in personal injury and or material
damage.
For the safe usage of the product, the following pictographs are used:
Indicates “HANDLE WITH CARE.” In order to protect the human body an equipment,
this display is attached to places where the Owner’s Manual and or Service Manual should
be referred to.
Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention. Failing to
perform work as per the instructions can cause accidents. In the case where only those who have tech-
nical expertise should perform the work to avoid hazardous situation, the instructions herein state that the
serviceman should perform such work.
Be sure to turn off power before working on the machine.
To prevent electric shock, be sure to turn off power before starting the work in which the worker touches
the interior of the product. If the work is to be performed in the power-on status, the Instruction Manual
herein always states to that effect.
Be sure to ground the Earth Terminal (this, however, is not required in the case where a power cord
with earth is used).
This product is equipped with the Earth Terminal. When installing the product, Connect the Earth Ter-
minal to the “accurately grounded indoor earth terminal” by using an earth wire. Unless the product is
grounded appropriately, the user can be subject to electric shock. After performing repair, etc. for the
Control equipment, ensure that the Earth Wire is rmly connected to the Control equipment.
Ensure that the Power Supply used is equipped with an Earth Leakage Breaker.
This product does not incorporate the Earth Leakage Breaker. Using a power supply which is not
equipped with the Earth Leakage Breaker can cause a re when earth leakage occurs.
Be sure to use fuses which meet the specied rating. (only for the machines which use fuses).
Using fuses exceeding the specied rating can cause a re and electric shock.
WARNING! CAUTION!

Specication changes (removal of equipment, conversion and addition) not designated by SEGA
are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc. It is
very hazardous to operate the product by removing parts and or modifying the circuits. Should doors,
lids and protective parts be damaged or lost, refrain from operating the product, and contact where the
product was purchased from or the ofce herein stated. SEGA shall not be held responsible for any
accidents, compensation for damage to a third party, resulting from the specications not designated by
SEGA.
Ensure that the product meets the requirements of appropriate Electrical Specications.
Before installing the product, check for Electrical Specications. SEGA products have a nameplate
on which Electrical Specications are described. Ensure that the product is compatible with the power
supply voltage and frequency requirements of the location. Using any Electrical Specications different
from the designated Specications can cause a re and electric shock.
Install and operate the product in places where appropriate lighting is available, allowing warning
labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially hazardous situ-
ation are applied to places where accidents can be caused. Ensure that where the product is operated
has sufcient lighting allowing the warnings to be read. If any label is peeled off, apply it again imme-
diately. Please place an order with where the product was purchased from or the ofce herein stated.
When handling the Monitor, be very careful. (Applies only to the product w/monitor.)
Some of the monitor (TV) parts are subject to high tension voltage. Even after running off power, some
portions are still subject to high tension voltage sometimes. Monitor repair and replacement should be
performed only be those technical personnel who have knowledge of electricity and technical expertise.
Be sure to adjust the monitor (projector) properly. (Applies only to the product w/monitor.)
Do not operate the product leaving on-screen ickering or blurring as it is. Using the product with the
monitor not properly adjusted may cause dizziness or a headache to an operator, a player, or the cus-
tomers.
When transporting or reselling this product, be sure to attach this manual to the product.
In the case where commercially available monitors and printers are used in this product, only the con-
tents relating to this product are explained herein. Some commercially available equipment has func-
tions and reactions not stated in this manual. Read this manual together with the specic Instruction
Manual of such equipment.
Descriptions herein contained may be subject to improvement changes without notice.
The contents described herein are fully prepared with due care. However, should any question arise or
errors be found, please contact SEGA.
•
•
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION.
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately after
transporting to the location. Nevertheless, an irregular situation may occur during transportation. Before
turning on power, check the following points to ensure that the product has been transported in a satis-
factory status.
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
Are Casters and Adjusters, damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
Are all wiring connectors correctly and securely connected? Unless connected in the correct direction,
connector connections can not be made accurately. Do not insert connectors forcibly.
Do power cords have cuts and dents?
Do the fuses used meet specied rating? Is the Circuit Protector in an energized status?
Are all accessories available?
Can all Doors and Lids be opened with the Accessory keys? Can Doors and Lids be rmly closed?

TABLE OF CONTENTS
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
TABLE OF CONTENTS
INTRODUCTION OF THE OWNER’S MANUAL
1. HANDLING PRECAUTIONS ..........................................................................................
2. PRECAUTIONS CONCERNING INSTALLATION LOCATION ...................................
3. OPERATION .....................................................................................................................
4. ASSEMBLING AND INSTALLATION ............................................................................
5. PRECAUTIONS TO BE HEEDED WHEN MOVING THE MACHINE ........................
6. NAME OF PARTS .............................................................................................................
7. GAME DESCRIPTION .....................................................................................................
8. HOW TO PLAY .................................................................................................................
9. GAMEBOARD CONFIG SETTINGS...............................................................................
10. GAME FEATURES ..........................................................................................................
11. GAME ERRORS ..............................................................................................................
12. TEST MODE ....................................................................................................................
13. DESIGN RELATED PARTS ............................................................................................
14. PARTS ..............................................................................................................................
15. WIRE COLOR CODE TABLE ........................................................................................
16. INPUT PORT ASSIGNMENTS .......................................................................................
17. OUTPUT PORT ASSIGNMENTS ...................................................................................
1 - 2
3 - 4
5 - 6
7 - 9
10
11
12
13
14
14
15
16
17
18 - 25
26
27
27 - 28

SPECIFICATIONS
INTRODUCTION OF THE OWNERS MANUAL
This Owner's Manual is intended to provide detailed descriptions together with all the
necessary information covering the general operation of electronic assemblies, electrome-
chanicals, servicing control, spare parts, etc. as regards the product,
SEGA JUNGLE TREASURES GAME OF SKILL.
This manual is intended for the owners, personnel and managers in charge of operation
of the product. Operate the product after carefully reading and sufciently understand-
ing the instructions. If the product fails to function satisfactorily, non-technical personnel
should under no circumstances touch the internal system. Please contact where the prod-
uct was purchased from.
SEGA AMUSEMENTS USA, INC./CUSTOMER SERVICE
45133 Industrial Drive, Fremont, California 94538, U.S.A.
Phone : [phone]
Fax : [phone]
Use of this product is unlikely to cause physical injuries or damages to property. However,
where special attention is required this is indicated by a thick line, the word "IMPORTANT"
and its sign in this manual.
Indicates that mishandling the product by disregarding this display can cause the
product's intrinsic performance not to be obtained, resulting in malfunctioning.
Installation Space : 24.75 inches width X 42.25 inches deep
Height : 62.5 inches
Width : 24.75 inches
Length : 34.25 inches
Weight : 210 lbs
Power, maximum current : 480W 4A (AC 120V 60 Hz AREA)
MONITOR : No Monitor is used on this product
STOP
IMPORTANT!
 PRODUCTION DATE 
This SEGA product was produced in the year of:
2003
This signies that this work was disclosed in 2003.

DEFINITION OF LOCATION MAINTENANCE MAN AND SERVICEMAN
Non-technical personnel who do not have technical knowledge and expertise should
refrain from performing such work that this manual requires the location's main-
tenance man or a serviceman to carry out, or work which is not explained in this
manual. Failing to comply with this instruction can cause a severe accident such
as electric shock.
Ensure that parts replacement, servicing & inspections, and troubleshooting are performed by the
location's maintenance man or the serviceman. It is instructed herein that particularly hazardous work
should be performed by the serviceman who has technical expertise and knowledge.
The location's maintenance man and serviceman are herein dened as follows:
"Location's Maintenance Man" :
Those who have experience in the maintenance of amusement equipment and vending machines, etc.,
and also participate in the servicing and control of the equipment through such routine work as equip-
ment assembly and installation, servicing and inspections, replacement of units and consumables, etc.
within the Amusement Facilities and or locations under the management of the Owner and Owner's
Operators of the product.
Activities of Location's Maintenance Man :
Assembly & installation, servicing & inspections, and replacement of units & consumables as regards
amusement equipment, vending machines, etc.
Serviceman :
Those who participate in the designing, manufacturing, inspections and maintenance service of the
equipment at an amusement equipment manufacturer.
Those who have technical expertise equivalent to that of technical high school graduates as regards
electricity, electronics and or mechanical engineering, and daily take part in the servicing & control
and repair of amusement equipment.
Serviceman's Activities :
Assembly & installation and repair & adjustments of electrical, electronic and mechanical parts of
amusement equipment and vending machines.
WARNING!

Notes:

1www.seuservice.com
1. HANDLING PRECAUTIONS
When installing or inspecting the machine, be very careful of the following points and pay attention
to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cau-
tionary matters herein stated can cause personal injury or damage to the machine.
 Before performing work, be sure to turn power off. Performing the work without
turning power off can cause an electric shock or short circuit. In the case work
should be performed in the status of power on, this manual always states to that
effect.
 To avoid electric shock or short circuit, do not plug in or unplug quickly.
 To avoid electric shock, do not plug in or unplug with a wet hand.
 Do not expose Power Cords and Earth Wires on the surface, (oor, passage, etc.).
If exposed, the Power Cords and Earth Wires are susceptible to damage. Dam-
aged cords and wires can cause electric shock or short circuit.
 To avoid causing a re or electric shock, do not put things on or damage Power
Cords.
 When or after installing the product, do not unnecessarily pull the power cord. If
damaged, the power cord can cause a re or electric shock.
 In case the power cord is damaged, ask for replacement through where the prod-
uct was purchased from or the ofce herein stated. Using the cord as is damaged
can cause re, electric shock or leakage.
 Be sure to perform grounding appropriately. Inappropriate grounding can cause
an electric shock.
 Be sure to use fuses meeting specied rating. Using fuses exceeding the specied
rating can cause a re or electric shock.
 Completely make connector connections for IC BD and others. Insufcient inser-
tion can cause an electric shock.
 Specication changes, removal of equipment, conversion and/or addition, not
designated by SEGA are not permitted.
• Failure to observe this may cause a re or an electric shock. Non-compliance
with this instruction can have a bad inuence upon physical conditions of the
players or the lookers-on, or result in injury during play.
• SEGA shall not be held responsible for damage, compensation for damage to a
third party, caused by specication changes not designated by SEGA.
 Be sure to perform periodic maintenance inspections herein stated.
WARNING!

2
www.seuservice.com
3www.seuservice.com
 For the IC board circuit inspections, only the logic tester is allowed. The use of a
multiple-purpose tester is not permitted, so be careful in this regard.
 Static electricity from your body may damage some electronics devices on the IC
board. Before handling the IC board, touch a grounded metallic surface so that
the static electricity can be discharged.
 Some parts are the ones designed and manufactured not specically for this
game machine. The manufacturers may discontinue, or change the specications
of, such general-purpose parts. If this is the case, Sega cannot repair or replace a
failed game machine whether or not a warranty period has expired.
STOP
IMPORTANT!

2
www.seuservice.com
3www.seuservice.com
2. PRECAUTIONS CONCERNING INSTALLATION LOCATION
This product is an indoor game machine. Do not install it outside. Even indoors,
avoid installing in places mentioned below so as not to cause a re, electric shock,
injury and or malfunctioning.
 Places subject to rain or water leakage, or places subject to high humidity in the
proximity of an indoor swimming pool and or shower, etc.
 Places subject to direct sunlight, or places subject to high temperatures in the
proximity of heating units, etc.
 Places lled with inammable gas or vicinity of highly inammable/volatile
chemicals or hazardous matter.
 Dusty places.
 Sloped surfaces.
 Places subject to any type of violent impact.
 Vicinity of anti-disaster facilities such as re exits and re extinguishers.
 The operating (ambient) temperature range is from 5ºC to 30ºC.
LIMITATIONS OF USAGE REQUIREMENTS
 Be sure to check the Electrical Specications.
Ensure that this product is compatible with the location's power supply, voltage
and frequency requirements.
A plate describing Electrical Specications is attached to the product.
Non-compliance with the Electrical Specications can cause a re and electric
shock.
 This product requires the Breaker and Earth Mechanisms as part of the location
facilities. Using them in a manner not independent can cause a re and electric
shock.
 Ensure that the indoor wiring for the power supply is rated at 4 A or higher (AC
single phase 100 ~ 120 V area). Non-compliance with the Electrical Specica-
tions can cause a re and electric shock.
 Be sure to independently use the power supply equipped with the Earth Leakage
Breaker. Using a power supply without the Earth Leakage Breaker can cause an
outbreak of re when earth leakage occurs.
 Putting many loads on one electrical outlet can cause generation of heat and a
re resulting from overload.
 When using an extension cord, ensure that the cord is rated at 4 A or higher (AC
100 ~ 120 V area). Using a cord rated lower than the specied rating can cause a
re and electric shock.
WARNING!
WARNING!

4
www.seuservice.com
5www.seuservice.com
Electric current consumption
MAX. 4 A (AC 120 V 60 Hz)
For transporting the machine into the location's building, the minimum necessary
dimensions of the opening (of doors, etc.) are 24.75 in. (W) and 62.5 in. (H).
 For the operation of this machine, secure a minimum area of 24.75 in. (W) ×
42.25 in. (D). In order to prevent injury resulting from the falling down acci-
dent during game play, be sure to secure the minimum area for operation.
 Be sure to provide sufcient space so as to allow this product's ventilation fan
to function efciently. To avoid machine malfunctioning and a re, do not
place any obstacles near the ventilation opening.
 SEGA shall not be held responsible for damage, compensation for damage to a
third party, resulting from the failure to observe this instruction.
WARNING!
STOP
IMPORTANT!
Operation Area
42.25 in.
Vent approx. 8 in.
24.75 in.

4
www.seuservice.com
5www.seuservice.com
3. OPERATION
PRECAUTIONS TO BE HEEDED BEFORE STARTING THE OPERATION
To avoid injury and trouble, be sure to constantly give careful attention to the behavior and manner
of the visitors and players.
In order to avoid accidents, check the following before starting the operation:
 To ensure maximum safety for the players and the customers, ensure that where
the product is operated has sufcient lighting to allow any warnings to be read.
Operation under insufcient lighting can cause bodily contact with each other,
hitting accident, and or trouble between customers.
 It is suggested to ensure a space allowing the players who feel sick while play-
ing the game to take a rest.
 Check if all of the adjusters are in contact with the surface. If they are not, the
Cabinet may move and cause an accident.
Ensure that all of the Adjusters are in contact
with the oor.
WARNING!

6
www.seuservice.com
7www.seuservice.com
WARNING: HAZARD TO EPILEPTICS.
 A very small portion of the population has a condition which may cause them to ex-
perience epileptic seizures or have momentary loss of consciousness when viewing
certain kinds of ashing lights or patterns that are present in our daily environment.
These persons may experience seizures while watching some kinds of television
pictures or playing certain video games. People who have not had any previous
seizures may nonetheless have an undetected epileptic condition.
 If you or anyone in your family has experienced symptoms linked to an epileptic
condition (e.g., seizures or loss of awareness), immediately consult your physician
before using any video games.
 We recommend that parents observe their children while they play video games. If
you or your child experience the following symptoms: dizziness, altered vision, eye
or muscle twitching, involuntary movements, loss of awareness, disorientation, or
convulsions, DISCONTINUE USE IMMEDIATELY and consult your physician.
WARNING!
 Immediately stop such violent acts as hitting and kicking the product. Such
violent acts can cause parts damage or falling down, resulting in injury due to
fragments and falling down.
CAUTION!
 Do not put any heavy item on this product. Placing any heavy item on the prod-
uct can cause a falling down accident or parts damage.
 Do not climb on the product. Climbing on the product can cause falling down
accidents. To check the top portion of the product, use a step.
 To avoid electric shock, check to see if door & cover parts are damaged or omit-
ted.
 To avoid electric shock, short circuit and or parts damage, do not put the follow-
ing items on or in the periphery of the product.
Flower vases, owerpots, cups, water tanks, cosmetics, and receptacles/
containers/vessels containing chemicals and water.
WARNING!
To avoid injury and trouble, be sure to constantly give careful attention to the behavior and man-
ner of the visitors and players.
PRECAUTIONS TO BE HEEDED DURING OPERATION (PAYING ATTENTION TO CUSTOMERS)
 To avoid injury and accidents, those who fall under the following categories are
not allowed to play the game.
• Those who have experienced muscle convulsion or loss of consciousness when play-
ing video game, etc.
• Intoxicated persons.
• Persons whose act runs counter to the product's warning displays.
 To avoid injury resulting from falling down and electric shock due to spilled
drinks, instruct the player not to place heavy items or drinks on the product.
 To avoid electric shock and short circuit, do not allow customers to put hands
and ngers or extraneous matter in the openings of the product or small open-
ings in or around the doors.
 To avoid falling down and injury resulting from falling down, immediately stop
the customer's leaning against or climbing on the product, etc.
WARNING!

6
www.seuservice.com
7www.seuservice.com
4. ASSEMBLING AND INSTALLATION
 Perform assembly work by following the procedure herein stated. Failing to
comply with the instructions can cause electric shock hazard.
 Perform assembling as per this manual. Since this is a complex machine,
erroneous assembling can cause an electric shock, machine damage and or not
functioning as per specied performance.
 When assembling, be sure to use more then one person. Depending on the
assembly work, there are some cases in which working by one person alone can
cause personal injury or parts damage.
 Ensure that connectors are accurately connected. Incomplete connections can
cause electric shock hazard.
 Be careful not to damage the wires. Damaged wires may cause electric shock or
short circuit or present a re risk.
 This work should be performed by the Location's Maintenance Man or
Serviceman. Performing work by non-technical personnel can cause a severe
accident such as electric shock. Failing to comply with this instruction can cause
a severe accident such as electric shock to the player during operation.
 Provide sufcient space so that assembling can be performed. Performing work
in places with narrow space or low ceiling may cause an accident and assembly
work to be difcult.
 To perform work safely and avoid serious accident such as the cabinet's falling
down, do not perform work in places where step-like grade differences, a ditch,
or slope exist.
 Handle molded parts with care. Undue weight or pressure may cause them to
break and the broken pieces may cause injury.
 To perform work safely and securely, be sure to prepare a step which is in a
secure and stable condition. Performing work without using the step can cause
violent falling down accidents.
WARNING!
CAUTION!
Tools such as a Phillips type screwdriver may be required for the assembly work.
Phillips type screwdriver

8
www.seuservice.com
9www.seuservice.com
FIG. 6. 2 e
Provide ventilation space for the ventilation
opening.
Allow more than 28 in. of space for customer
trafc.
42.25 in.
Vent approx. 8 in.
24.75 in.

8
www.seuservice.com
9www.seuservice.com
 Ensure that the Main SW is OFF.
The AC Unit is located inside on one side of Cabinet. The AC Unit has Main SW, Earth Terminal
and the Inlet which connects the Power Cord.
 Be sure to independently use the power supply socket outlet equipped with
an Earth Leakage Breaker. Using a power supply without an Earth Leakage
Breaker can cause a re when electric leakage occurs.
 Ensure that the "accurately grounded indoor earth terminal" and the earth wire
cable are available (except in the case where a power cord plug with earth is
used). If the grounding work is not performed appropriately, customers can be
subjected to an electric shock, and the product's functioning may not be stable.
 Ensure that the power cord and earth wire are not exposed on the surface
(passage, etc.). If exposed, they can be caught and are susceptible to damage. If
damaged, the cord and wire can cause electric shock and short circuit accidents.
Ensure that the wiring position is not in the customer's passage way or the wiring
has protective covering.
 After wiring power cord on the oor, be sure to protect the power cord. Exposed
power cord is susceptible to damage and causes an electric shock accident.
POWER SUPPLY, AND EARTH CONNECTION
WARNING!
INLET
MAIN SW
AC Cable (Power Cord)
* Note: Actual Power Supply connection
may vary from photo
Power is off when the
MAIN SWitch is in the
down position. To supply
power to the unit, ip the
MAIN SWitch upwards.

10
www.seuservice.com
11 www.seuservice.com
5. PRECAUTIONS WHEN MOVING THE MACHINE
 When moving the machine, be sure to unplug the power plug. Moving the
machine with the plug as is inserted can damage the power cord and cause re
and electric shock hazards.
 When moving the machine on the oor, pay careful attention so that adjusters
do not tread power cords and earth wires. Damaging the power cords can cause
electric shock and short circuit hazards.
 Do not push the cabinet from the left/right when attempting to move the unit.
Pushing from the sides may cause the unit to tip and result in injury and damage
to parts.
Do not push on any parts made of glass (e.g. Main Plex) or plastic, as these parts
may break and result in bodily injury.
WARNING!
CAUTION!

10
www.seuservice.com
11 www.seuservice.com
6. NAME OF PARTS
CABINET 24.75 in x 34.25 in x 62.5 in 210 LBS
TABLE 1 Dimensions and Weights
Width x Length x Height Weight
Marquee
Speaker
Play Area
Play Button
Coin Inlet
Prize Chute
7 Seg. Display

12
www.seuservice.com
13 www.seuservice.com
7. GAME DESCRIPTION
Game Overview
This is a Bulk Vending Product. Meaning the customer inputs money/tokens and recieves a product.
The customer inputs his monies and then Elephant moves his head to attempt to dispense a products
through the Output Chute. The game can be set to play until the customer wins a prize or on a pay
per play basis.
The following explanations apply to cases where the product is functioning satisfactorily. Should
there be anything different then the following contents, some sort of faults may have occurred.
Immediately look into the cause of the fault and eliminate the cause thereof to ensure satiffactory
operation.
Connect the Power cord to an A/C source, turn on the power switch, then verify the following:
• A lamp is lit in the Marquee
• Sound is emitted from the speaker below the marquee
• The Prize bucket starts spinning
• The Play button Lights up
• The 7 SEG LED starts it attaction spinning display
Lights up
Sound is emitted
Flashes
Lights up
