Plasmacluster Ion Generator
OPERATION MANUAL
IG-A20U
IG-A40U
Device of this mark is a trademark of Sharp
Corporation.
“Plasmacluster” and “Device of cluster of
grapes” are registered trademarks of Sharp
Corporation in Japan, USA and elsewhere.
Please read this manual carefully and retain for
future reference.
Veuillez lire et enregistrer ces instructions.
Lea atentamente este manual y consérvelo.
Générateur d’ions Plasmacluster
MODE D’EMPLOI
Generador de iones Plasmacluster
MANUAL DE FUNCIONAMIENTO
IG-A20U
IG-A40U
IG-A20UA40U.eng.indd1IG-A20UA40U.eng.indd1 2010/09/2915:31:142010/09/2915:31:14

IG-A20UA40U.eng.indd2IG-A20UA40U.eng.indd2 2010/09/2915:31:152010/09/2915:31:15

ENGLISH
FRANÇAIS
ESPAÑOL
ENGLISH
Thank you for purchasing this SHARP Plasmacluster Ion Generator. Please read this manual
carefully before using Plasmacluster Ion Generator.
After reading, keep the manual in a convenient location for future reference.
E-1
CONTENTS
FOR CUSTOMER ASSISTANCE (U.S)
...........................E-2
CONSUMER LIMITED WARRANTY (U.S)
.........................E-3
FOR CUSTOMER ASSISTANCE (CANADA)
.........................E-4
LIMITED WARRANTY (CANADA) ..............................E-5
IMPORTANT SAFETY INSTRUCTIONS...........................E-6
• WARNING............................................................................E-6
• CAUTIONS CONCERNING OPERATION...........................E-6
• INSTALLATION GUIDELINES .............................................E-6
PARTS NAME...........................................................E-7
• DISPLAY ..............................................................................E-7
• FIX THE OPERATION COVER BY SCREW .......................E-7
INSTALLATION POSITION ................................................E-8
ACCESSORIES ...................................................................E-8
OPERATION.........................................................................E-9
CLEANING AND MAINTENANCE...................................E-10
• MAIN UNIT.........................................................................E-10
• FILTER...............................................................................E-10
PLASMACLUSTER ION GENERATING UNIT REPLACEMENT
.......E-12
HOW TO REPLACE THE PLASMACLUSTER ION GENERATING UNIT
.......E-13
SPECIFICATIONS .............................................................E-15
TROUBLESHOOTING ......................................................E-16
•To enable stable emission of high-density Plasmacluster ions, the Plasmacluster Ion Generat-
ing Unit mounted in IG-A20U and IG-A40U will need to be replaced periodically*.
* Replacement is required approximately every 2 years (17,500 hours) when operated 24 hours a day. IG-
A20U and IG-A40U will stop operating after about 26 months (19,000 hours) if the Plasmacluster Ion
Generating Unit is not replaced.
Declaration of Conformity
