Siargo MFFD series User manual

© 2013 Siargo Ltd.
SIARGO MEMS FLOW SENSING PRODUCTS
MFFD/MFFE/MFI series
MEMS Mass Flow Meters
User Manual
Länna,S-14250SKOGÅS Ordertel 08-771 00 04 Växel 08-771 02 20 Email [email protected]
Stockholm,Sweden Orderfax 08-771 62 00 Teknisk 08-771 35 80 Internet www.hemomatik.se
HM-1404

MEMS Mass Flow Meters
MFFD/MFFE/MFI Series
User Manual
Document No.07-2013-2 EN
Issue date: 2013.07
Revision: B.1
Siargo Ltd.
2041 Mission College Boulevard
Suite 250
Santa Clara, CA 95054
USA
Tel: [phone]
Email: [e-mail]
© Copyright 2013 by Siargo Ltd.
Siargo Ltd. and its subsidiaries reserve the rights to change the specifications and/or
descriptions without prior notice. For further information and updates, please visit:
www.Siargo.com
Länna,S-14250SKOGÅS Ordertel 08-771 00 04 Växel 08-771 02 20 Email [email protected]
Stockholm,Sweden Orderfax 08-771 62 00 Teknisk 08-771 35 80 Internet www.hemomatik.se

1www.Siargo.com
Introduction
The MF series MEMS mass flow meters are the second generation products
on Siargo's proprietary sensor technology and control circuit technology. These
meters offer a higher standards of intelligent all-electronic mass flow technology.
With the smart software well tested for various applications, the MF series MEMS
mass flow meters achieve high sensitivity, large dynamic range, and high accuracy.
The MF series MEMS mass flow meters incorporate a number of advanced
techniques such as multiple-compensation scheme, noise reduction solution,
multiple signal outputs, and network management feature.
The MF series MEMS mass flow meters can be used for general purpose gas
metering in industry or commercial applications. The user shall observe the general
guidelines in the meter applications in accordance with the safety and other
metrology requirements. It is advised that the user must read this user manual
carefully before processing to field applications. It is mandatory to follow the
instruction of the for installation and operation requirements to ensure the meter
can work properly without malfunctions or even damages.
based
Declarations
Do not alter any software and hardware of the product.
Do not use the product if any suspect for malfunction or damage.
Do not use this product in any corrosive gas environment.
Observe all requirements in accordance with the product specifications.
Only qualified personnel from Siargo or a person who is accredited by Siargo
can perform troubleshooting or service to the product.
1.
2.
4.
3.
MEMS Mass Flow Meter User Manual
5.

2
MEMS Mass Flow Meter User Manual
Introduction
1 Usage and Safety
2 Overview
2.1 Siargo's MEMS Thermal Mass Flow Sensor Technology
2.2 Siargo's MEMS Thermal Mass Flow Meter
3 Working Principle
3.1 Working Principle
3.2 Volume Flow vs. Mass Flow
4 Product Model Selections
4.1 In-line Meters
4.2 Insertion Meters
5 Product Configuration
5.1 In-line Meters
5.2 Insertion Meters
6 Product Specifications
6.1 Physical Dimensions of In-line Meters
6.2 Physical Dimensions of Insertion Meters
6.3 Flow Range of In-line Meters
6.4 Flow Range of Insertion Meters
6.5 Environmental Conditions
6.6 Medium Conditions
6.7 Electrical Specifications
6.8 Other Specifications
7 Installation
7.1 Description of Parts in Package
7.2 Installation Preparation
7.3 Installation Procedure of In-line Meters
7.4 Installation Procedure of Insertion Meters
7.5 Power Up
7.5 Caution Notes on Installation
8 Display and Functions
8.1 Display
8.2 Access Points and User Interface
8.3 Real time display of both flow rate and accumulated volume
8.4 RS485 data communication protocole
8.5 4~20mA Connection
8.6 Pulse Output
8.7 Automatic stored data
8.8 Buttons
9 Safety and Maintenance
9.1 Wetted Materials and Compatibility
9.2 Safety Precautions
10 Maintenance
10.1 Calibration
10.2 Maintenance
11 Warranty
12 Troubleshooting
13 Storage
13.1 Storage
13.2 Transportation
14 Customer Service and Order information
Contents
1
3
3
4
5
6
7
10
15
18
18
19
19
20
20
