SICK UM12 Series User manual

OPERATING INSTRUCTIONS
UM12
Ultrasonic sensor

Described product
UM12
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
25
2O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 5
1.1 Information on the operating instructions.............................................. 5
1.2 Explanation of symbols............................................................................ 5
1.3 Further information................................................................................... 6
2 Safety information............................................................................ 7
2.1 Intended use............................................................................................. 7
2.2 Improper use............................................................................................. 7
2.3 Cybersecurity............................................................................................ 7
2.4 Limitation of liability................................................................................. 7
2.5 Modifications and conversions................................................................ 8
2.6 Requirements for skilled persons and operating personnel.................. 8
2.7 Operational safety and particular hazards.............................................. 8
2.8 UL conformity............................................................................................ 9
3 Product description........................................................................... 10
3.1 Scope of delivery....................................................................................... 10
3.2 Product ID.................................................................................................. 10
3.3 Type code.................................................................................................. 11
3.4 Setup and dimensions............................................................................. 12
3.5 Status indicators....................................................................................... 12
3.6 Temperature compensation..................................................................... 13
4 Transport and storage....................................................................... 14
4.1 Transport................................................................................................... 14
4.2 Unpacking.................................................................................................. 14
4.3 Transport inspection................................................................................. 14
4.4 Storage...................................................................................................... 14
5 Mounting............................................................................................. 15
5.1 Mounting instructions............................................................................... 15
5.2 Mounting distances.................................................................................. 15
5.3 Aligning the device.................................................................................... 15
6 Electrical installation........................................................................ 16
6.1 Wiring instructions.................................................................................... 16
6.2 Prerequisites for safe operation of the device........................................ 16
6.3 Pin assignment......................................................................................... 18
7 Operation............................................................................................ 21
7.1 LED behavior during teach-in................................................................... 21
7.2 Teaching in the digital output................................................................... 21
7.2.1 Factory settings of the digital output...................................... 21
7.2.2 Teaching in the switching point, IO-Link: Single point (DtO)
or single point + 8% (DtO + 8%).............................................. 21
CONTENTS
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 3
Subject to change without notice

7.2.3 Teaching in the switching window, IO-Link: Window (win‐
dow mode)................................................................................ 21
7.2.4 Teaching in the background, IO-Link: Window ± 8% (ObSB). 22
7.2.5 Adjusting the N/C contact and N/O contact.......................... 22
7.3 Teaching in the analog output................................................................. 23
7.3.1 Factory settings of the analog output.................................... 23
7.3.2 Scaling the analog output....................................................... 23
7.3.3 Adjusting the rising or falling output characteristic............... 23
7.4 Resetting the device to factory settings.................................................. 23
7.5 IO-Link....................................................................................................... 23
7.6 SOPAS ET................................................................................................... 24
8 Maintenance...................................................................................... 25
8.1 Maintenance plan..................................................................................... 25
8.2 Cleaning..................................................................................................... 25
9 Troubleshooting................................................................................. 26
9.1 Repairs...................................................................................................... 26
9.2 Returns...................................................................................................... 26
9.3 Disposal..................................................................................................... 26
10 Technical data.................................................................................... 27
10.1 Mechanics/Electronics............................................................................. 27
10.2 Performance............................................................................................. 27
10.3 Interfaces.................................................................................................. 28
10.4 Ambient data............................................................................................. 29
10.5 Detection ranges....................................................................................... 29
11 Accessories........................................................................................ 31
12 Annex.................................................................................................. 32
12.1 Declarations of conformity and certificates............................................ 32
12.2 Licenses.................................................................................................... 32
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

1 About this document
1.1 Information on the operating instructions
These operating instructions provide important information on how to use devices from
SICK AG.
Prerequisites for safe work are:
•Compliance with all safety notes and handling instructions supplied.
•Compliance with local work safety regulations and general safety regulations for
device applications
The operating instructions are intended to be used by qualified personnel and electrical
specialists.
NOTE
Read these operating instructions carefully to familiarize yourself with the device and its
functions before commencing any work.
The operating instructions are an integral part of the product. Store the instructions
in the immediate vicinity of the device so they remain accessible to staff at all times.
Should the device be passed on to a third party, these operating instructions should be
handed over with it.
These operating instructions do not provide information on operating the machine or
system in which the device is integrated. Information on this can be found in the
operating instructions for the machine or system.
1.2 Explanation of symbols
Warnings and important information in this document are labeled with symbols. Sig‐
nal words introduce the instructions and indicate the extent of the hazard. To avoid
accidents, damage, and personal injury, always comply with the instructions and act
carefully.
DANGER
… indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
WARNING
… indicates a potentially dangerous situation, which may lead to a fatality or serious
injuries if not prevented.
CAUTION
… indicates a potentially dangerous situation, which may lead to minor/slight injuries if
not prevented.
NOTICE
… indicates a potentially harmful situation, which may lead to material damage if not
prevented.
NOTE
… highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
ABOUT THIS DOCUMENT 1
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 5
Subject to change without notice

1.3 Further information
NOTE
Further documentation for the device can be found on the online product page at:
•www.sick.com/UM12
Additional information is available there, depending on the product, e.g.:
•Model-specific online data sheets for device types, containing technical data,
dimensional drawing, and specification diagrams
•EU declaration of conformity and certificates of the product family
•Dimensional drawings and 3D CAD dimension models of the device types in
various electronic formats
•Other publications related to the devices described here
•Publications dealing with accessories
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

2 Safety information
2.1 Intended use
The UM12 ultrasonic sensor is used for non-contact detection and distance measure‐
ment. Distance measurement is not possible below the operating range of the device.
SICK AG assumes no liability for losses or damage arising from the use of the product,
either directly or indirectly. This applies in particular to use of the product that does not
conform to its intended purpose and is not described in this documentation.
2.2 Improper use
Any use outside of the stated areas, in particular use outside of the technical specifica‐
tions and the requirements for intended use, will be deemed to be incorrect use.
•The device does not constitute a safety component in accordance with the respec‐
tive applicable safety standards for machines.
•The device must not be used in explosion-hazardous areas, in corrosive environ‐
ments or under extreme environmental conditions.
•Any use of accessories not specifically approved by SICK AG is at your own risk.
WARNING
Danger due to improper use!
Any improper use can result in dangerous situations.
Therefore, observe the following information:
■Product should be used only in accordance with its intended use.
■All information in these operating instructions must be strictly observed.
■Shut down the product immediately in case of damage.
2.3 Cybersecurity
To protect against cybersecurity threats, it is necessary to continuously monitor and
maintain a comprehensive and holistic cybersecurity concept. A suitable concept com‐
prises organizational, technical, procedural, electronic, and physical levels of defense
and provides suitable measures for different types of risks. SICK's products and solu‐
tions must be viewed as a component of this concept.
Information on Cybersecurity can be found at: www.sick.com/psirt .
2.4 Limitation of liability
Relevant standards and regulations, the latest technological developments, and our
many years of knowledge and experience have all been taken into account when
compiling the data and information contained in these operating instructions. The
manufacturer accepts no liability for damage caused by:
■Non-adherence to the product documentation (e.g., operating instructions)
■Incorrect use
■Use of untrained staff
■Unauthorized conversions or repair
■Technical modifications
■Use of unauthorized spare parts, consumables, and accessories
SAFETY INFORMATION 2
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 7
Subject to change without notice

2.5 Modifications and conversions
NOTICE
Modifications and conversions to the device may result in unforeseeable dangers.
Interrupting or modifying the device or SICK software will invalidate any warranty claims
against SICK AG. This applies in particular to opening the housing, even as part of
mounting and electrical installation.
2.6 Requirements for skilled persons and operating personnel
WARNING
Risk of injury due to insufficient training.
Improper handling of the device may result in considerable personal injury and material
damage.
■All work must only ever be carried out by the stipulated persons.
The following qualifications are required for various activities:
Table 1: Activities and technical requirements
Activities Qualification
Mounting, maintenance ■Basic practical technical training
■Knowledge of the current safety regulations in the workplace
Electrical installation,
device replacement
■Practical electrical training
■Knowledge of current electrical safety regulations
■Knowledge of the operation and control of the devices in their
particular application
Commissioning, configura‐
tion
■Basic knowledge of the computer operating system used
■Basic knowledge of the design and setup of the described
connections and interfaces
■Basic knowledge of data transmission
Operation of the device for
the particular application
■Knowledge of the operation and control of the devices in their
particular application
■Knowledge of the software and hardware environment for the
particular application
2.7 Operational safety and particular hazards
Please observe the safety notes and the warnings listed here and in other sections
of this production documentation to reduce the possibility of risks to health and avoid
dangerous situations.
WARNING
Electrical voltage!
Electrical voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■The power supply must be disconnected when attaching and detaching electrical
connections.
■The product must only be connected to a voltage supply as set out in the require‐
ments in the operating instructions.
■National and regional regulations must be complied with.
■Safety requirements relating to work on electrical systems must be complied with.
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

WARNING
Risk of injury and damage caused by potential equalization currents!
Improper grounding can lead to dangerous equipotential bonding currents, which may
in turn lead to dangerous voltages on metallic surfaces, such as the housing. Electrical
voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■Follow the notes in the operating instructions.
■Install the grounding for the product and the system in accordance with national
and regional regulations.
2.8 UL conformity
The UL certification is dependent on the type. Any existing UL certification can be found
on the type label.
NFPA79 applications only. Adapters including field wiring cables are available.
For more information visit:
bwww.sick.com/UM12
SAFETY INFORMATION 2
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 9
Subject to change without notice

3 Product description
3.1 Scope of delivery
The delivery of the device includes the following components:
No. of
units
Component Remarks
1 Device in the version ordered Device versions
•Digital output without IO-Link
•Digital output with IO-Link
•Analog output
1 Printed safety notes, multilingual Brief information and general safety notes
Accessories are only supplied if you order them separately, see "Accessories",
page 31.
With special variants, where optional extras have been ordered, or owing to the latest
technical changes, the actual scope of delivery may vary from the features and illustra‐
tions shown here.
3.2 Product ID
Packaging
UM12-1172211
6053542
20...150
1 x P N P
250m m , m m
SN220734567
10...30 V DC
out ≤ 200 mA
D-79183 Waldkirch Made in Germany
25
www.sick.com/8016973
1
2
3
3
4
5
6
7
8
9
Figure 1: Packaging (example)
1Data Matrix code with product data
2Link to the operating instructions
3Approval marks and test symbols
4Supply voltage and output current
5Interface
6Operating range and limiting range
7Serial number
8Part number
9Type code
3 PRODUCT DESCRIPTION
10 O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

Type label
D-79183 Waldkirch
Made in Germany
UM12-1172211
6053542
10...30 V DC
20...150 m m
SN183334567
POWER/Q
21
3
45
Figure 2: Type label (example)
1Part number
2Type code
3Serial number
4Approval marks and test symbols
5Operating range and supply voltage
3.3 Type code
The devices of the UM12 product family are arranged according to the following type
code:
UM12 - 1 1 x 2 2 x 1
1 -23456
Table 2: Type code
Position Description Characteristic
1 Device name type UM12: Ultrasonic, metric thread, 12 mm diameter
–
2 Generation 1: 1. generation
3 Principle of operation 1: Button operation
4 Detection range,
mounting distance
(UD)
7: 20 mm … 150 mm
9: 40 mm … 240 mm
5 Connectivity 2: Male connector M12, 4-pin
6 Housing version 2: Nickel-plated brass
7 Output function 1: 1 x PNP
5: 1 x NPN
6: Analog, current interface
7: Analog, voltage interface
B: 1 x push-pull: PNP/NPN with IO-Link 1.1
8 Alignment 1: Straight
NOTE
Not all combinations based on type code are possible. The available device types can
be found online at www.sick.com/UM12.
PRODUCT DESCRIPTION 3
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 11
Subject to change without notice

3.4 Setup and dimensions
UM12-xxxxx1x, UM12-xxxxx5x, UM12-xxxxxBx
4
(0.16)
M12 x 1
10
(0.39)
15
(0.59) 30.1 (1.19)
55.1 (2.17)
1
2
3
Figure 3: structure and device dimensions, unit: mm (inch), decimal separator: period
1Connection
2Display (2 status LEDs)
3Fixing nuts, width 17 mm
UM12-xxxxx6x, UM12-xxxxx7x
10
(0.39)
15
(0.59) 35.1 (1.38)
60.1 (2.37)
4
(0.16)
M12 x 1
2
1
3
Figure 4: structure and device dimensions, unit: mm (inch), decimal separator: period
1Connection
2Display (2 status LEDs)
3Fixing nuts, width 17 mm
3.5 Status indicators
1
1Display (2 status LEDs)
The display consists of two status LEDs behind an opening in the housing.
LED Status (color) Status
Status LED: Sup‐
ply voltage active
O (Green) Device ready
IO-Link operation:
Ö (green)
3 PRODUCT DESCRIPTION
12 O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

LED Status (color) Status
Status LED: digi‐
tal output or ana‐
log output
O (Orange) Digital output: digital output active
Analog output: object in scaling range
Ö (Orange)
Flashes quickly
for 3 seconds.
Teach-in:
•No object detected
•Object outside the detection range
•First switching point within and second switching
point outside the detection range 1)
•Scaling < 1 mm taught-in 2)
The existing switching points are retained.
O = Lights up; Ö = Flashes; o = Does not light up.
1) Applies to the switching window and ObSB switching modes.
2) Applies when teaching in the analog output.
3.6 Temperature compensation
The internal temperature compensation reaches the optimal operating point after an
uptime of 1 minute. The temperature compensation is factory calibrated for the stand‐
ard mounting conditions using an aluminum mounting bracket and mounting screws.
The temperature compensation is automatically calibrated for the specific installation
situation under the conditions specified below.
Conditions for automatic calibration
•The device is in a cold state.
•Digital output: The digital output is deactivated for approx. 30 minutes.
•Analog output: The analog output delivers a constant value of 11 mA ... 13 mA or
4.4 V ... 5.6 V for approx. 30 minutes.
If the measured value changes during the 30 minutes, the calibration is aborted. The
standard parameters or the parameters last calibrated are retained. The automatic
calibration is suitable for installation situations that differ greatly from the standard
mounting conditions or where a high measurement accuracy is required. One example
is thermally insulated mounting.
PRODUCT DESCRIPTION 3
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 13
Subject to change without notice

4 Transport and storage
4.1 Transport
For your own safety, please read and observe the following notes:
NOTICE
Damage to the product due to improper transport.
■The device must be packaged for transport with protection against shock and
damp.
■Recommendation: Use the original packaging as it provides the best protection.
■Transport should be performed by trained specialist staff only.
■The utmost care and attention is required at all times during unloading and
transportation on company premises.
■Note the symbols on the packaging.
■Do not remove packaging until immediately before you start mounting.
4.2 Unpacking
•To protect the device against condensation, allow it to equilibrate with the ambient
temperature before unpacking if necessary.
•Handle the device with care and protect it from mechanical damage.
4.3 Transport inspection
Immediately upon receipt in Goods-in, check the delivery for completeness and for any
damage that may have occurred in transit. In the case of transit damage that is visible
externally, proceed as follows:
•Do not accept the delivery or only do so conditionally.
•Note the scope of damage on the transport documents or on the transport compa‐
ny's delivery note.
•File a complaint.
NOTE
Complaints regarding defects should be filed as soon as these are detected. Damage
claims are only valid before the applicable complaint deadlines.
4.4 Storage
Store the device under the following conditions:
•Recommendation: Use the original packaging.
•Do not store outdoors.
•Store in a dry area that is protected from dust.
•Do not expose to any aggressive substances.
•Protect from sunlight.
•Avoid mechanical shocks.
•Storage temperature: see "Technical data", page 27.
•For storage periods of longer than 3 months, check the general condition of all
components and packaging on a regular basis.
4 TRANSPORT AND STORAGE
14 O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

5 Mounting
5.1 Mounting instructions
•Observe the technical data.
•To prevent condensation, avoid exposing the device to rapid changes in tempera‐
ture.
•The mounting site has to be designed for the weight of the device.
•When using multiple devices, observe the mounting distance, see "Mounting dis‐
tances", page 15.
5.2 Mounting distances
Table 3: Mounting distances
Device type Parallel Opposite
UM12-117x > 250 mm > 1300 mm
UM12-119x > 250 mm > 1400 mm
5.3 Aligning the device
≤ ± 3° ≥ ± 3°
1 2
Figure 5: Aligning the device for smooth and rough surfaces
1Smooth surface: Angle ≤ 90° ± 3° between the sensor axis and object surface
2Rough surface: Angle ≥ 90° ± 3° between the sensor axis and object surface
MOUNTING 5
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 15
Subject to change without notice

6 Electrical installation
6.1 Wiring instructions
NOTE
Pre-assembled cables can be found online at:
•www.sick.com/UM12
NOTICE
Faults during operation and device or system defects!
Incorrect wiring may result in operational faults and defects.
■Follow the wiring notes precisely.
The enclosure rating stated in the technical data is achieved only with a screwed plug
connector or protective cap.
Connect the connecting cables in a de-energized state. Do not switch on the supply
voltage until installation is complete and all connecting cables are connected to the
device and control.
The supply voltage must be as specified in the technical data, see "Technical data",
page 27.
When commissioning, protect the device from moisture and contamination.
6.2 Prerequisites for safe operation of the device
WARNING
Risk of injury and damage caused by electrical current!
As a result of equipotential bonding currents between the device and other grounded
devices in the system, faulty grounding of the device can give rise to the following
dangers and faults:
•Dangerous voltages are applied to the metal housings.
•Devices will behave incorrectly or be destroyed.
•Cable shielding will be damaged by overheating and cause cable fires.
Remedial measures
•Only skilled electricians should be permitted to carry out work on the electrical
system.
•If the cable insulation is damaged, disconnect the voltage supply immediately and
have the damage repaired.
•Ensure that the ground potential is the same at all grounding points.
•Where local conditions do not meet the requirements for a safe earthing method,
take appropriate measures. For example, ensure low-impedance and current-carry‐
ing equipotential bonding.
The device is connected to the peripheral devices (any local trigger sensor(s), system
controller) via shielded cables. The cable shield – for the data cable, for example –
rests against the metal housing of the device.
The device can be grounded through the cable shield or through a blind tapped hole in
the housing, for example.
6 ELECTRICAL INSTALLATION
16 O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

If the peripheral devices have metal housings and the cable shields are also in contact
with their housings, it is assumed that all devices involved in the installation have the
same ground potential.
This is achieved by complying with the following conditions:
■Mounting the devices on conductive metal surfaces
■Correctly grounding the devices and metal surfaces in the system
■If necessary: low-impedance and current-carrying equipotential bonding between
areas with different ground potentials
SICK
Device
7 46
Power Supply
U
= 8
= 9
1 2 3
I
5
System
Controller
Figure 6: Example: Occurrence of equipotential bonding currents in the system configuration
1System controller
2Device
3Voltage supply
4Grounding point 2
5Closed current loop with equalizing currents via cable shield
6Ground potential difference
7Grounding point 1
8Metal housing
9Shielded electrical cable
If these conditions are not fulfilled, equipotential bonding currents can flow along the
cable shielding between the devices due to differing ground potentials and cause the
hazards specified. This is, for example, possible in cases where there are devices within
a widely distributed system covering several buildings.
Remedial measures
The most common solution to prevent equipotential bonding currents on cable shields
is to ensure low-impedance and current-carrying equipotential bonding. If this equipo‐
tential bonding is not possible, the following solution approaches serve as a suggestion.
NOTICE
We expressly advise against opening up the cable shields. This would mean that the
EMC limit values can no longer be complied with and that the safe operation of the
device data interfaces can no longer be guaranteed.
Measures for widely distributed system installations
On widely distributed system installations with correspondingly large potential differen‐
ces, the setting up of local islands and connecting them using commercially available
electro-optical signal isolators is recommended. This measure achieves a high degree
of resistance to electromagnetic interference.
ELECTRICAL INSTALLATION 6
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 17
Subject to change without notice

Electro-
optical
signal
isolator
Electro-
optical
signal
isolator
Power
Supply
SICK
Device
1 2 2 43
6 5
System
Controller
= 7= 8= 9
Figure 7: Example: Prevention of equipotential bonding currents in the system configuration by
the use of electro-optical signal isolators
1System controller
2Electro-optical signal isolator
3Device
4Voltage supply
5Grounding point 2
6Grounding point 1
7Metal housing
8Shielded electrical cable
9Optical fiber
The use of electro-optical signal isolators between the islands isolates the ground loop.
Within the islands, a stable equipotential bonding prevents equalizing currents on the
cable shields.
Measures for small system installations
For smaller installations with only slight potential differences, insulated mounting of the
device and peripheral devices may be an adequate solution.
Even in the event of large differences in the ground potential, ground loops are effec‐
tively prevented. As a result, equalizing currents can no longer flow via the cable shields
and metal housing.
NOTICE
The voltage supply for the device and the connected peripheral devices must also
guarantee the required level of insulation.
Under certain circumstances, a tangible potential can develop between the insulated
metal housings and the local ground potential.
6.3 Pin assignment
UM12-xxxxx1x, UM12-xxxxx5x
1
4 3
2
6 ELECTRICAL INSTALLATION
18 O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice

L+
Q/Q
M
Teach-in
1
4
3
2
brn
blk
blu
wht
¯
Figure 8: Male connector, M12, 4-pin
Table 4: Pin assignment for UM12-xxxxx1x, UM12-xxxxx5x
Contact Signs Wire color Description
1 L+ Brown Supply voltage, see "Mechanics/Electron‐
ics", page 27
2 Teach-in White Device teach-in
3 M Blue Supply voltage: 0 V
4 Q/Q Black Digital output / inverted digital output
UM12-xxxxxBx
1
4 3
2
L+
M
Teach-in
1
4
3
2
brn
blk
blu
wht
Q/Q/C
Figure 9: Male connector, M12, 4-pin
Table 5: Pin assignment for UM12-xxxxxBx
Contact Signs Wire color Description
1 L+ Brown Supply voltage, see "Mechanics/Electron‐
ics", page 27
2 Teach-in White Device teach-in
3 M Blue Supply voltage: 0 V
4 Q/Q/C Black Digital input / inverted digital output / IO-
Link
UM12-xxxxx6x, UM12-xxxxx7x
1
4 3
2
L+
QA
M
Teach-in
1
4
3
2
brn
blk
blu
wht
Figure 10: Male connector, M12, 4-pin
ELECTRICAL INSTALLATION 6
8016973/1BNC/2022-02-23 | SICK O P E R A T I N G I N S T R U C T I O N S | UM12 19
Subject to change without notice

Table 6: Pin assignment for UM12-xxxxx6x, UM12-xxxxx7x
Contact Signs Wire color Description
1 L+ Brown Supply voltage, see "Mechanics/Electron‐
ics", page 27
2 Teach-in White Device teach-in
3 M Blue Supply voltage: 0 V
4 QABlack Analog output
6 ELECTRICAL INSTALLATION
20 O P E R A T I N G I N S T R U C T I O N S | UM12 8016973/1BNC/2022-02-23 | SICK
Subject to change without notice
