Siemens RCM-1 Service manual

P/N 315-093878-11
Installation Instructions
Model RCM-1
Riser Control Module
Fire Safety
Siemens Building Technologies, Inc.
8 Fernwood Road
Florham Park, New Jersey 07932
Siemens Building Technologies, Ltd.
2 Kenview Boulevard
Brampton, Ontario L6T 5E4 CN

2
Table of Contents
INTRODUCTION................................................................................................... 3
Electrical Ratings ............................................................................................ 3
Modes of Operation ........................................................................................ 3
Diagnostic LEDs ............................................................................................. 3
RCM-1 Diagnostic LEDs - Table 1 .................................................................. 4
DESCRIPTION OF THE RCM-1 TERMINALS ..................................................... 5
RCM-1 APPLICATIONS - Table 2 ....................................................................... 5
Application 1 - Typical Style 4 Installation....................................................... 6
Application 2 - Style 4 with a Style 4 Output Only Extension ......................... 6
Application 3 - Typical Style 7 Installation....................................................... 6
Application 4 - Style 7 with a PORT C Extension ........................................... 7
Application 5 - Style 4 Fiber Optic Installation ................................................ 7
Application 6 - Style 4 Fiber Optic with a PORT C Fiber Optic Extension...... 8
Application 7 - Style 7 Fiber Optic with a PORT C Fiber Optic Extension...... 8
Application 8 - Combination Wire and Fiber Installation................................. 9
Application 9 - Style 4 Repeater Installation ................................................... 9
INSTALLATION .................................................................................................... 9
Network Address Programming (S1) - Table 3 ............................................. 10
S2 Settings - Table 4 ..................................................................................... 11
Application 1 - Typical Style 4 Connections .................................................. 12
Application 2 - Typical Style 4 Connections with PORT C Extension ........... 13
Application 3 - Typical Style 7 Connections .................................................. 14
Application 4 - Style 7 Connections with PORT C Extension ....................... 15
Applications 5 and 6 - Typical Style 4 Fiber Optic Connections with Optional
PORT C Extension ........................................................................................ 16
Application 7 - Typical Style 7 Fiber Optic Connections with Optional
PORT C Extension ........................................................................................ 17
Application 8 - Combination Fiber and Wire Style 4 Connection.................. 18
Application 9 - Style 4 Repeater Connection ................................................ 19
WIRING CONFIGURATIONS FOR THE OCC AND ACM ................................. 20

3
must be used for transient protection (UL 1459).
Refer to LLM-1 Installation Instructions, P/N 315-
093530.
Modes of Operation
The RCM-1 can operate in the following modes:
Local Mode The audio from the local MXL
(ACM) will be switched to local
speaker zones (OCCs). The
global audio riser will be
switched to Port C, the Style 4
output riser.
Global Mode 1 The audio output from the local
MXL is disconnected. The
audio from the global riser is
connected to the local speaker
zones and to Port C, the Style
4 output riser.
Global Mode 2 The audio from the local
system is connected to both
the local speaker outputs and
the global risers.
For additional information on the MXL/MXLV
System, refer to the MXL/MXLV Manual, P/N
315-092036.
Diagnostic LEDs
The RCM-1 has two yellow diagnostic LEDs and
six green diagnostic LEDs along its top edge.
Their functions are described in Table 1 (Refer to
Figure 2 for their location).
PORT STYLE FUNCTION
A6 Audio signal input
B4/7 Audio signal input/output
C4 Audio signal output
D6 Audio signal output
The RCM-1 supervises Port B for open and
short circuits, reports by exception to the MXL,
and isolates the fault.
INTRODUCTION
The Model RCM-1 Riser Control module from
Siemens Building Technologies, Inc.provides
control and supervision of global paging risers
in MXL voice networks. The RCM-1 is a double-
width card and has 4 ports (See Figure 1) with
the following inputs and outputs:
Figure 1
RCM-1 Ports
A D and B C
B C and D
A B, C and D
Only one RCM-1 may be connected to the
MXL. The module communicates with the MXL
using the RS-485 MNET. If the RCM-1 detects
that supervision is lost with the MXL, it will
automatically switch to Local Mode.
If any copper wire pair leaves the building
(Campus Configuration) the LLM-1 module
ELECTRICAL RATINGS
tnerruCeludoMCDV5evitcAAm08
tnerruCeludoMCDV42evitcAAm081
tnerruCeludoMCDV42ybdnatSAm002

4
TABLE 1
RCM-1 DIAGNOSTIC LEDS
LED COLOR FUNCTION
Any Trouble Yellow Lights when the RCM-1 cannot communicate with the MXL.
XMIT Enable Yellow Lights whenever the RCM-1 transmits a message to the MXL.
XMIT A Green Lights when the RCM-1 transmits voice using the copper
wire RECV connections.
XMIT B Green Lights when the RCM-1 transmits voice using the copper
wire XMIT connections.
XMIT F Green Lights when the RCM-1 transmits voice using any of the fiber
optic ports.
LM1 Green Lights when the RCM-1 is in local mode.
Flashes when there is no valid carrier on the riser.
GM1 Green Lights when the RCM-1 is in global mode 1.
Flashes when there is no valid carrier on the riser.
GM2 Green Lights when the RCM-1 is in global mode 2.
Flashes when there is no valid carrier on the riser.
Figure 2
RCM-1 Module Board

5
Figure 3
Description of the RCM-1 Terminals
The RCM-1 can be connected in many different ways. Table 2 describes the various applications. The
block diagrams below show the possible configurations.
Note:
Polarity must be observed
with all riser connections.
Odd pins are hi side while
even pins are lo side. See
the separate wiring
connections for the ACM/
TBM and the OCC shown
in Figure 12.
TABLE 2
RCM-1 APPLICATIONS
Application No.
(See Corresponding Diagram) Configuration
1Typical Style 4 installation
2Style 4 installation with a Style 4 output only extension
3Typical Style 7 installation
4Style 7 installation with a Style 4 extension
5Style 4 installation with fiber optic transmission
6Style 4 fiber optic with a Style 4 fiber optic output only extension
7Style 7 fiber connections with a Style 4 output only fiber extension
8Combination wire and fiber installation
9Style 4 Repeater Installation
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
PORT C: Copper Interface, Transmit, Style 4 (CT4)
PORT B: Copper Interface, Receive, Style 4 (BR4)
PORT B: Copper Interface, Transmit, Style 4 (BT4)
PORT B: Copper Interface, Receive, Style 7 (BR7)
PORT B: Copper Interface, Transmit, Style 7 (BT7)
NOT USED
NOT USED
NOT USED
NOT USED
PORT B: Fiber Interface, Style 4 (BF4)
PORT B: Fiber Interface, Style 7 (BF7)
PORT C: Fiber Interface, Style 4 (CF4)
CABLE TO
MMB OR PSR
P/N 555-190967
PORT D: Copper Connection To The OCC
PORT D: Copper Connection To The OCC
PORT A: Copper Connection To The ACM
RCM-1
OMM-1
or
OMM-2

6
Application 1
Typical Style 4 Installation
Application 3
Typical Style 7 Installation
Application 2
Style 4 with a Style 4 Output Only Extension
RCM-1 Nos. 4, 5, and 6 have local ACMs, but cannot
output to the global bus — they can only receive.

7
Application 4
Style 7 with a PORT C Extension
Application 5
Style 4 Fiber Optic Installation

8
Application 6
Style 4 Fiber Optic with a PORT C Fiber Optic Extension
Application 7
Style 7 Fiber Optic with a PORT C Fiber Optic Extension

9
INSTALLATION
Remove all system power before
installation, first battery and then AC.
(To power up, connect the
AC first, then the battery.)
The RCM-1 has two configuration dipswitches,
S1 and S2. Set the dipswitches before install-
ing the RCM-1 into the OMM-1/2. (See NOTE
following Table 4 for the operation of
dipswitches.)
The RCM-1 takes up one of the 255 possible
network addresses. Use switch S1 to set the
MXL network address. Set this switch according
to the address where the RCM-1 is installed in
the MXL’s network map. Refer to the AccuLINK
(CSG-M) configuration printout for the address of
the module. See Table 3 for settings.
In addition to S1 which is used to set the network
address, the RCM-1 has a second bank of
dipswitches, S2, which must be correctly config-
ured for the RCM-1 to operate properly. Refer to
Table 4 for a description of the functions for each
of the switches in S2.
Application 8
Combination Wire and Fiber Installation
Application 9
Style 4 Repeater Installation

10
TABLE 3
NETWORK ADDRESS PROGRAMMING (S1)
RDDA12345678RDDA12345678RDDA12345678RDDA12345678
000
100
200
300
400
500
600
700
800
900
010
110
210
310
410
510
610
710
810
910
020
120
220
320
420
520
620
720
820
920
030
130
230
330
430
530
630
730
830
930
040
140
240
340
440
540
640
740
840
940
050
150
250
35
0
450
550
650
750
850
950
060
160
260
360
LAGELLI
LAGELLI
LAGELLI
XXOOOOOO
OOXOOOOO
XOXOOOOO
OXXOOOOO
XXXOOOOO
OOOXOOOO
X
OOXOOOO
OXOXOOOO
XXOXOOOO
OOXXOOOO
XOXXOOOO
OXXXOOOO
XXXXOOOO
OOOOXOOO
XOOOXOOO
OXOOXOOO
XXOOXOOO
OOXOXOOO
XOXOXO
OO
OXXOXOOO
XXXOXOOO
OOOXXOOO
XOOXXOOO
OXOXXOOO
XXOXXOOO
OOXXXOOO
XOXXXOOO
OXXXXOOO
XXXXXOOO
OOOOOXOO
XOOOOXOO
OXO
OOXOO
XXOOOXOO
OOXOOXOO
XOXOOXOO
OXXOOXOO
XXXOOXOO
OOOXOXOO
XOOXOXOO
OXOXOXOO
XXOXOXOO
OOXXOXOO
XOXXOXOO
OXXXOXOO
XXXXOXOO
OOOOXXOO
XOOOXXOO
OXOOXXOO
XXOOXXOO
OOXOXXOO
XOXOXXOO
OXXOXXOO
XXXOXXOO
OOOXXXOO
XOOXXXOO
OXOXXXOO
XXOXX
XOO
OOXXXXOO
XOXXXXOO
OXXXXXOO
XXXXXXOO
460
560
660
760
860
960
070
170
270
370
470
570
670
770
870
970
080
180
280
380
480
580
680
780
880
980
090
190
290
390
490
590
690
790
890
990
001
101
201
301
401
501
601
701
801
901
011
111
211
311
411
511
611
711
811
91
1
021
121
221
321
421
521
621
721
OOOOOOXO
XOOOOOXO
OXOOOOXO
XXOOOOXO
OOXOOOXO
XOXOOOXO
OXXOOOXO
XXXOOOXO
OOOXOOXO
XOOX
OOXO
OXOXOOXO
XXOXOOXO
OOXXOOXO
XOXXOOXO
OXXXOOXO
XXXXOOXO
OOOOXOXO
XOOOXOXO
OXOOXOXO
XXOOXOXO
OOXOXOXO
XOXOXOXO
O
XXOXOXO
XXXOXOXO
OOOXXOXO
XOOXXOXO
OXOXXOXO
XXOXXOXO
OOXXXOXO
XOXXXOXO
OXXXXOXO
XXXXXOXO
OOOOOXXO
XOOOOXXO
OXOOOX
XO
XXOOOXXO
OOXOOXXO
XOXOOXXO
OXXOOXXO
XXXOOXXO
OOOXOXXO
XOOXOXXO
OXOXOXXO
XXOXOXXO
OOXXOXXO
XOXXOXXO
OXXXOXXO
XXX
XOXXO
OOOOXXXO
XOOOXXXO
OXOOXXXO
XXOOXXXO
OOXOXXXO
XOXOXXXO
OXXOXXXO
XXXOXXXO
OOOXXXXO
XOOXXXXO
OXOXXXXO
XXOXXXXO
OOXXXXXO
XOXXXXXO
OXXXXXXO
XXXXXXXO
821
921
031
131
231
331
431
531
631
731
831
931
041
141
241
341
441
541
641
741
841
941
051
151
251
351
451
551
651
751
851
951
061
161
261
361
461
561
661
761
861
961
071
171
271
371
471
571
671
771
871
971
081
181
281
381
48
1
581
681
781
881
981
091
191
OOOOOOOX
XOOOOOOX
OXOOOOOX
XXOOOOOX
OOXOOOOX
XOXOOOOX
OXXOOOOX
XXXOOOOX
OOOXOOOX
XOOXOOO
X
OXOXOOOX
XXOXOOOX
OOXXOOOX
XOXXOOOX
OXXXOOOX
XXXXOOOX
OOOOXOOX
XOOOXOOX
OXOOXOOX
XXOOXOOX
OOXOXOOX
XOXOXOOX
OXXO
XOOX
XXXOXOOX
OOOXXOOX
XOOXXOOX
OXOXXOOX
XXOXXOOX
OOXXXOOX
XOXXXOOX
OXXXXOOX
XXXXXOOX
OOOOOXOX
XOOOOXOX
OXOOOXOX
X
XOOOXOX
OOXOOXOX
XOXOOXOX
OXXOOXOX
XXXOOXOX
OOOXOXOX
XOOXOXOX
OXOXOXOX
XXOXOXOX
OOXXOXOX
XOXXOXOX
OXXXOXOX
XXXXOX
OX
OOOOXXOX
XOOOXXOX
OXOOXXOX
XXOOXXOX
OOXOXXOX
XOXOXXOX
OXXOXXOX
XXXOXXOX
OOOXXXOX
XOOXXXOX
OXOXXXOX
XXOXXXOX
OOX
XXXOX
XOXXXXOX
OXXXXXOX
XXXXXXOX
291
391
491
591
691
791
891
991
002
102
202
302
402
502
602
702
802
902
012
112
212
312
412
512
612
712
812
912
022
122
222
322
422
522
622
722
822
922
032
132
232
332
432
532
632
732
832
932
042
142
242
342
442
542
642
742
842
94
2
052
152
252
352
452
552
OOOOOOXX
XOOOOOXX
OXOOOOXX
XXOOOOXX
OOXOOOXX
XOXOOOXX
OXXOOOXX
XXXOOOXX
OOOXOOXX
XOOXOOXX
OX
OXOOXX
XXOXOOXX
OOXXOOXX
XOXXOOXX
OXXXOOXX
XXXXOOXX
OOOOXOXX
XOOOXOXX
OXOOXOXX
XXOOXOXX
OOXOXOXX
XOXOXOXX
OXXOXOX
X
XXXOXOXX
OOOXXOXX
XOOXXOXX
OXOXXOXX
XXOXXOXX
OOXXXOXX
XOXXXOXX
OXXXXOXX
XXXXXOXX
OOOOOXXX
XOOOOXXX
OXOOOXXX
XXOO
OXXX
OOXOOXXX
XOXOOXXX
OXXOOXXX
XXXOOXXX
OOOXOXXX
XOOXOXXX
OXOXOXXX
XXOXOXXX
OOXXOXXX
XOXXOXXX
OXXXOXXX
XXXXOXXX
O
OOOXXXX
XOOOXXXX
OXOOXXXX
XXOOXXXX
OOXOXXXX
XOXOXXXX
OXXOXXXX
XXXOXXXX
LAGELLI
LAGELLI
LAGELLI
LAGELLI
LAGELLI
LAG
ELLI
LAGELLI
LAGELLI
)NOro(DESOLC=X)FFOro(NEPO=O

11
TABLE 4
S2 SETTINGS
(0 = OFF, 1 = ON)
Switch No. Function Description
1 - 3 Copper Riser Modes
Location SW1 SW2 SW3
A 1 1 1 No copper connection
B 0 1 1 Normal connections on both R and T (Style 4 and 7)
C 1 0 1 EOL Tx, connections on T terminals only (Style 4 and 7)
D 0 0 1 EOL Rx, connections on the R terminals only (Style 4 and 7)
E 1 1 0 EOL Rx4, connections on Style 4 R terminals; connections on
the Style 7 R and T terminals (Style 7 only)
F 0 1 0 EOL Rx7, connections on Style 7 R terminals; connections on
the Style 4 R and T terminals (Style 7 only)
G 1 0 0 First and only RCM-1 in a PORT C Style 4 extension
H 0 0 0 First RCM-1 in a PORT C Style 4 extension with
other RCM-1s connected to PORT C
4Copper Repeater Repeater enabled when off, disabled when on
Configuration
5 - 6 SW5 SW6
1 1 No fiber connection
0 1 Normal fiber connection
1 0 Spare
0 0 Spare
7Style On for Style 4
Off for Style 7
NOTE: To open a dipswitch, press down on the side of the dipswitch marked OPEN.
To close a dipswitch, press down on the side of the dipswitch opposite the side marked OPEN.
To open a slide switch, push the slide to the side opposite the side marked ON.
To close a slide switch, push the slide to the side marked ON.
Use switch S2 to set the correct module configu-
ration for the application you have selected. Refer
to Table 4 and Application Diagrams 1-8 to
determine the setting for your application.
After setting the switches, install the RCM-1 into
the OMM card cage according to the following
instructions. Make sure that the module is in the
card guides and the card edge is firmly seated in
the connectors on the OMM.
CAUTION
At all times handle all plug-in cards with
extreme care. When inserting or removing a
card, be sure the position of the card is kept
at right angles to the OMM board. Other-
wise, the plug-in card can damage or
displace other components.

12
Port B receive from transmit out on other RCMs.
No connection if first RCM.
Port B transmit pair to receive inputs on other RCMs.
No connection if last RCM.
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
The RCM-1 mounts in the OMM-1 or OMM-2
inside the MXL cabinet. Note that the RCM-1 is a
double-width card that requires the removal of the
middle card guides on the OMM-1 and OMM-2
before the card can be installed. On early ver-
sions of the OMM-1 and OMM-2 this was not
possible. Make sure that the OMM-1 and OMM-2
assemblies have date codes later than 3/1/95.
If the OMM-1 or OMM-2 is already installed in
the MXL, follow these steps:
1. Unfasten the screws that secure the
OMM-1/2 and remove it from the MXL
cabinet.
2. Remove the screws on the rear of the
OMM-1/2 which secure the two middle card
guides and remove the guides.
3. Re-install the OMM-1/2 into the MXL
backbox.
4. Install the RCM-1 into the OMM-1/2.
CAUTION
INSERT THE RCM-1 MODULE IN THE
OMM-1/2 WITH THE ELECTRONIC
COMPONENTS FACING OUTWARD
TOWARDS THE OMM SCREW TERMINALS.
INSTALLATION IN ANY OTHER WAY WILL
CAUSE DAMAGE TO THE RCM-1.
Typical Style 4 Connections - Application 1
(See Figure 4)
This is the basic configuration of the RCM-1. It
allows multiple networked MXL voice systems to
be connected together to act as one large
integrated voice evacuation system.
Figure 4
Typical Style 4 Connections
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 17-20.
SGNITTES2S
WSnoitpircseD noitacoL
B
noitacoL
C
noitacoL
D
1gifnocreppoCffonoffo
2gifnocreppoCnoffoffo
3gifnocreppoCnonono
4retaeperreppo
Cnonono
5gifnocrebiFnonono
6gifnocrebiFnonono
77elytSnonono

13
Port C output connects port B receive input on other RCMs.
Port B receive from transmit out on other RCMs.
No connection if first RCM.
Port B transmit pair to receive inputs on other RCMs.
No connection if last RCM.
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
NOT USED
Figure 5
Typical Style 4 Connections with PORT C Extension
Typical Style 4 Connections with PORT C
Extension - Application 2 (See Figure 5)
The RCM-1 provides a Style 4 output which
can be used to connect to other systems which
require global paging capability. A Style 4
output only (PORT C) extension is also
supported.
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 17-20.
SGNITTES2S
WSnoitpircseD noitacoL
B
noitacoL
C
noitacoL
D
noitacoL
G
noitacoL
H
1gifnocreppoCffonoffonoffo
2gifnocreppoCnoffoffonoffo
3gifn
ocreppoCnonononoffo
4retaeperreppoCnonononono
5gifnocrebiFnonononono
6gifnocrebiFnonononono
77elytSnonononono

14
Figure 6
Typical Style 7 Connections
Port B Style 7 receive from transmit out on other RCMs.
No connection if first RCM.
Port B Style 7 transmit pair to receive inputs on other RCMs.
No connection if last RCM.
Port B Style 4 receive from transmit out on other RCMs.
No connection if first RCM.
Port B Style 4 transmit pair to receive inputs on other RCMs.
No connection if last RCM.
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
NOT USED
NOT USED
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 17-20.
Typical Style 7 Connections - Application 3
(See Figure 6)
The RCM-1 provides a Style 7 output which can
be used to connect to other systems which
require global paging capability.
SGNITTES2S
WSnoitpircseD noitacoL
B
noitacoL
C
noitacoL
E
noitacoL
F
1gifnocreppoCffononoffo
2gifnocreppoCnoffonono
3gifnocreppoCnonoffoffo
4retaeperreppoCnononono
5gifnocrebiFnononono
6gifnocrebiFnononono
77elytSffoffoffono

15
Style 7 Connections with PORT C
Extension - Application 4 (See Figure 7)
The RCM-1 provides a Style 7 output which
can be used to connect to other systems which
require global paging capability. A Style 4
output only (PORT C) extension is also
supported.
Figure 7
Style 7 with Style 4 Extension
Port B Style 7 receive from transmit out on other RCMs.
No connection if first RCM.
Port B Style 7 transmit pair to receive inputs on other RCMs.
No connection if last RCM.
Port B Style 4 receive from transmit out on other RCMs.
No connection if first RCM.
Port C output connects to riser B Style 4 receive input on other RCMs.
Port B Style 4 transmit pair to receive inputs on other RCMs.
No connection if last RCM.
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
NOT USED
NOT USED
NOT USED
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 17-20.
SGNITTES2S
WSnoitpircseD noitacoL
B
noitacoL
C
noitacoL
E
noitacoL
F
1gifnocreppoCffononoffo
2gifnocreppoCnoffonoffo
3gifnocreppoCnononoffo
4retaeperreppoCnononono
5gifnocrebiFnononono
6gifnocrebiFnononono
77elytSffoffonono

16
Figure 8
Style 4 Fiber Optic Connection with Optional PORT C Extension
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
NOT USED
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
To fiber optic module from Fiber Optic Model D2300CP.
To optional fiber module if a Style 4
output only extension is required.
(SEE APPLICATION 6)
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 1-6 and 17-20.
Typical Style 4 Fiber Optic Connections
with Optional PORT C Extension -
Applications 5 and 6 (See Figure 8)
The RCM-1 provides a Style 4 Fiber Optic
output which can be used to connect to other
systems which only require global voice
output. A Style 4 Fiber Optic output only
(PORT C) extension is also supported.
SGNITTES2S
WSnoitpircseD sA
nwohS
1gifnocreppoCno
2gifnocreppoCno
3gifnocreppoCno
4retaeperreppoCno
5gifnocrebiFffo
6gifnocrebiFno
77el
ytSno

17
Figure 9
Style 7 Fiber Optic Connection with Optional PORT C Extension
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
To fiber optic module from Fiber Optic Model D2300CP.
To fiber optic module from Fiber Optic Model D2300CP.
To optional fiber module if a Style 4
output only extension is required.
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 1-6 and 17-20.
Typical Style 7 Fiber Optic Connections
with Optional PORT C Extension -
Application 7 (See Figure 9)
The RCM-1 provides a Style 7 Fiber Optic
output which can be used to connect to other
systems which require global paging
capability. A Style 4 Fiber Optic output only
(PORT C) extension is also supported.
SGNITTES2S
WSnoitpircseD sA
nwohS
1gifnocreppoCno
2gifnocreppoCno
3gifnocreppoCno
4retaeperreppoCno
5gifnocrebiFffo
6gifnocrebiFno
77el
ytSffo

18
Combination Fiber and Wire Style 4
Connection - Application 8 (See Figure 10)
The RCM-1 can support a combination of fiber
optics and wire which can be used to connect
to other systems which require global paging
capability.
Figure 10
Combination Fiber and Wire Connection
To fiber optic module from Fiber Optic Model D2300CP.
Port B receive from transmit out on other RCMs.
No connection if first RCM.
Port B transmit pair to receive inputs on other RCMs.
No connection if last RCM.
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
NOT USED
NOT USED
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 1-6 and 17-20.
SGNITTES2S
WSnoitpircseD noitacoL
B
noitacoL
C
noitacoL
D
1gifnocreppoCffonoffo
2gifnocreppoCnoffoffo
3gifnocreppoCnonono
4retaeperreppo
Cnonono
5gifnocrebiFffonono
6gifnocrebiFnonono
77elytSnonono

19
Style 4 Repeater Connection - Application 9
(See Figure 11)
The RCM-1 can be used as a repeater when the
required global riser exceeds 100 ohms. Do not
install more than two repeaters in any global
riser.
Figure 11
Riser Repeater
Port B receive from transmit out on
last RCM in the old global riser.
Port B transmit pair to receive inputs
on first RCM in the new global riser.
To OCC-1, TB 2/TB4, 1
To OCC-1, TB 2/TB4, 2
To TBM-2, TB5, 1
To TBM-2, TB5, 4
+
+
_
_
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
NOT USED
CABLE TO
MMB OR PSR
P/N 555-190967
RCM-1
OMM-1
or
OMM-2
NOT USED
NOT USED
Notes:
1. Use 18AWG minimum wire.
2. Limit the maximum resistance of loop total from the first RCM to
the last RCM to 100 ohms. Maximum line capacitance = 1µF.
3. The wiring is power limited to NFPA 70 per NEC 760.
4. Maximum voltage is 1.5V RMS.
5. Maximum current is 50mA.
6. Refer to Figure 12 for proper EOLR placement.
7. Refer to Wiring Specification for MXL, MXL-IQ and MXLV
Systems, P/N 315-092772 revision 6 or higher, for additional
wiring information.
8. Positive and negative ground fault detected at <50K ohms for
terminals 17-20.
*Refer to Application 9,
page 9, for Location B
and Location B*.
SGNITTES2S
WSnoitpircseD noitacoL
B
noitacoL
*B
1gifnocreppoCffoffo
2gifnocreppoCnono
3gifnocreppoCnono
4retaeperreppoCnoffo
5gifnocreb
iFnono
6gifnocrebiFnono
77elytSnono

RCM Style 4 connections to the OCC
Figure 12
Wiring Configurations for the OCC and ACM
P/N 315-093878-11
RCM Style 6 connections to the OCC
RCM Style 4 connections to the ACM
RCM Style 6 connections to the ACM
